- Page 1 INSTRUCTION MANUAL DIGIT SMART 30/07/2007 30/07/2007 STARTING FROM Starting from 30/07/2007 Columbia...
-
Page 2: Table Of Contents
6. OPERATING INSTRUCTIONS page 7 7. WELDING INSPECTION page 10 8. MAINTENANCE AND REPAIRS page 11 9. GUARANTEE page 14 10. CE CONFORMITY CERTIFICATE page 15 11. DIGIT SMART SPARE PARTS page 17 12. ASSEMBLY DRAWING page 19 Starting from 30/07/2007 Columbia... -
Page 3: Safety Standards
This equipment has been designed to be used with environmental temperatures between +5 C° +45 C°, it is on any account advisable to avoid very damp locations, and when used outdoors avoid exposure to rain. Do not use in places where there is danger of fire or explosion Starting from 30/07/2007 Columbia... - Page 4 Also ensure that the battery housing is clean and the contacts are not damaged. Alway protect the charger from humidity, blows and temperatures exceeding 50°C and from frost. Further information is supplied in the enclosed instructions from the batteries manufacturer. Starting from 30/07/2007 Columbia...
-
Page 5: Technical Data
Battery charger 12 V power supply 110-220V Weight (including battery) 3.9 kg. MODEL TABLE Model Code Strap width DIGIT SMART 125.990.810 10-16 mm. 3. ACCESSORIES Only use original accessories listed in this manual. BATTERIES Spare batteries with the following codes are available: Type NI-CD 12 VDC 2.0 Ah code 521002600... -
Page 6: Machine Composition
The battery must be positioned in its housing at the end of the handle until it fits perfectly in the blocks (picture 3 ). Only use straps which are in perfect conditions. DISPLAY INDICATING Machine ready to tension strap Pos. 1 Pos. 2 Strap cooling after welding. Battery down (fix lamp) Pos. 3 Card overheating (flasher lamp) Starting from 30/07/2007 Columbia... -
Page 7: Operating Instructions
“program function”. Afterward push (+ or –) to increase or decrease welding time or strap tension (pict.5). The programming card will automatically record the new values after 10 seconds. § Position the strap around the package ( pict. 6 ). Starting from 30/07/2007 Columbia... - Page 8 Push the tension button until the programmed tension is reached (tension motor will stop). § Lower the lever in order to execute the cycle of welding, cut and cooling of the strap. § An acoustic signal will be transmitted at the end of the process. Starting from 30/07/2007 Columbia...
- Page 9 To remove the battery, release the safety spring and press the release buttons; replace with a fully charged battery. Any insufficient seal or weld is to be considered not adequate and must be discarded. Starting from 30/07/2007 Columbia...
- Page 10 Regulate the height of the feedwheel unfasten the screw code 515009790 with allen wrench for size 2.5 ( 2 ). Adjusted the height of the feedwheel fasten the nut code 516002250 with a socket wrench size 10. ( 1 ). Starting from 30/07/2007 Columbia...
-
Page 11: Maintenance And Repairs
“7” “8” “9”, “10”, § Unfasten no.4 screws , remove the clip , remove the spacer remove the cover “11” “A” remove the bearing and replace the feedwheel TAKE CARE TO THE WIRING. Starting from 30/07/2007 Columbia... - Page 12 Unscrew the screw and remove the smart welding cover § “3” “4” “A”. Unscrew the screw , remove the cutter guide space rand replace cutter To reassemble the machine repeat the operations described in reverse order. Starting from 30/07/2007 Columbia...
- Page 13 , remove the old plate and replace it with a new § To obtain the strap sizes 10-13 or 16 mm. follow the indications (pict. 20). No. 1 guide strap spacer code 402005790 and no.1 spacer code 402009540 are in equipment inside the box. Starting from 30/07/2007 Columbia...
-
Page 14: Guarantee
Our guarantee shall not apply to all parts subject to normal usage wear (refer to basic list). NOTE: Columbia will not undertake any intervention on machines whose serial number, engraved during manufacture and quoted on the sales document provided, has been intentionally modified or removed. -
Page 15: Ce Conformity Certificate
REGGIATRICE ELETTRICA A BATTERIA BATTERY STRAPPING TOOL OUTIL A BATERIE MODELLO - MODEL - MODELE:....DIGIT SMART ........... NUMERO MATRICOLA - SERIAL NUMBER - NO. DE SERIE: ............ANNO DI COSTRUZIONE - YEAR OF PRODUCTION - ANNEE DE CONSTRUCTION:...2 0..... e' conforme ai requisiti essenziali di sicurezza e di tutela della salute richiesti dalle direttive CEE 98/37 e CEE 89/336 e...
