BRUSH CUTTER
DESBROZADORA
DEBROUSSAILLEUSE
ROÇADORAS
DECESPUGLIATORI
DRAAGBARE BOSMAAIER
TRAGBARE MOTORSENSE
Model
V241LPS
V241W
Modelo
V26LPS
Modèle
V26W
Modelo
V28LS
Modèllo
V28W
Model
V28FW
Model
V28FHW
VG404DXLPS
VG504DXLP
(ENGLISH) OPERATING MANUAL
(ESPAÑOL) MANUAL DE INSTRUCCIONES
(FRANÇAIS) MANUAL DE FONCTIONNEMENT
(PORTUGUÊS) MANUAL DE INSTRUÇÕES
(ITALIANO) MANUAL DI USO E MANUTENZIONE
(NEDERLANDS) HANDLEIDING
(DEUTSCH) BEDIENUNGSANLEITUNG
11MUKAIDANISHI-MACHI.KISSHOIN.MINAMI-KU.KYOTO,JAPAN.601-8307
info-e@marunaka-japan.co.jp
http://www.marunaka-japan.co.jp
CODE: 800202597
0610

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V241LPS and is the answer not in the manual?

Questions and answers

Related Manuals for Marunaka V241LPS

Summary of Contents for Marunaka V241LPS

  • Page 1 BRUSH CUTTER DESBROZADORA DEBROUSSAILLEUSE ROÇADORAS DECESPUGLIATORI DRAAGBARE BOSMAAIER TRAGBARE MOTORSENSE Model V241LPS V241W Modelo V26LPS Modèle V26W Modelo V28LS Modèllo V28W Model V28FW Model V28FHW VG404DXLPS VG504DXLP (ENGLISH) OPERATING MANUAL (ESPAÑOL) MANUAL DE INSTRUCCIONES (FRANÇAIS) MANUAL DE FONCTIONNEMENT (PORTUGUÊS) MANUAL DE INSTRUÇÕES...

  • Page 2: Table Of Contents

    Contents ENGLISH TECHNICAL DATE DECLARATION OF CONFORMITY SYMBOL MEANING GENERAL DESCRIPTION............1 SAFETY RULES ..............2 SAFETY USAGE ..............4 FUEL MIX ................6 SAFETY GUARD ASSEMBLY ..........7 BLADE AND NYLON STRING HEAD ASSEMBLY ....8 ENGINE/SHAFT HOUSING ASSEMBLY ........ 9 HANDLE GRIP/HANDLE/THROTTLE WIRE ASSEMBLY ..

  • Page 6: Symbol Meaning

    SYMBOL MEANING Warning-Caution Do not use saw-blade Minimum safety distance Safety clothing: 1) Approved safety glasses of face shield 2) Approved safety helmet 3) Approved ear defender 4) Approved gloves 5) Approved safety footwear Read operating manual carefully Single handle should be locked in place marked 90 °...

  • Page 7: General Description

    [1] GENERAL DESCRIPTION 1. Engine 2. Drive shaft housing 3. Trigger 4. STOP switch/throttle advance 5. Control handle 6. Blade 7. Harness 8. Spark plug 9. Air filter cover 10. Fuel tank cap 11. Muffler 12. Clutch housing 13. Safety guard 14.

  • Page 8: Safety Rules

    [2] SAFETY RULES Fig. 2-3 Fig. 2-1 3. Be careful. Prolonged usage of this product may expose 1. Make sure all operators study this manual carefully the operator to vibration which can produce Whitefinger before using the brush cutter. Do not allow children to disease (Raynand’s Phenomenon).
  • Page 9 Fig. 2-5 5. PRECAUTIONS AGAINST FIRE: Do not operate the brush cutter near fire or spilled petrol. Do not run the engine in closed or poorly ventilated Fig. 2-6 areas. EXHAUST GASES ARE POISONOUS WHEN 6. Keep people and animals away from working area INHALED.

  • Page 10: Safety Usage

    [3] SAFETY USAGE This product must be held to the right of the operator’s body. This will exhaust fumes are directed away from the operator and will not be obstructed by the operator’s clothing. If you have not used a brush cutter before, spend some time in becoming familiar with the controls and method of usage before operation.
  • Page 11 Fig. 3-2 Fig. 3-3 2. The following accessories can be assembled to your brush cutter. a) blade, b) nylon string head. 3 BLADES: a) WHEN USING A BLADE, ENSURE THE You can cut any type of grass, bushwood or shrub. CORRECT GUARD IS FITTED.

  • Page 12: Fuel Mix

    [4] FUEL MIX This product is fitted with a 2-stroke engine and therefore requires a 2-stroke fuel and oil mix. Use a high quality 2- stroke engine oil using 2% (50:1) oil. In order to obtain a good fuel mix, put the oil into the container before the petrol.

  • Page 13: Safety Guard Assembly

    [5] SAFETY GUARD ASSEMBLY Fig. 5-2 2. For a safety reasons, it is imperative that the unit is used with the correct guard when fitted with a nylon head. (Fig. 5-2) only manufacturer’s original blades. Fig. 5-1 Only use blades or nylon string heads clearly marked 1.

  • Page 14: Blade And Nylon String Head Assembly

    [6] BLADE AND NYLON STRING HEAD ASSEMBLY Assemble the correct guard to suit the kind of blade or nylon string head to be used (See section: SAFETY GUARD ASSEMBLY). Fig. 6-3 3. Assemble nylon string head as illustrated. Model: NV a) Loosen the nylon string head NV, and leave Disc B-1 only.

  • Page 15: Engine/Shaft Housing Assembly

    [7] ENGINE/SHAFT HOUSING [8] HANDLE GRIP/HANDLE/THROTTLE ASSEMBLY WIRE ASSEMBLY Mounting of handle grip DANGER Do not run the engine without shaft housing attached, as the clutch could fly off. Fig. 7-1 1. Assemble the engine onto the shaft housing. Make sure the shaft is fully and correctly up to the shank, then tighten the four screws A.

  • Page 16: Starting And Stopping The Engine

    [9] STARTING AND STOPPING THE Attach and tighten handle holder (J) with bolts and nuts. ENGINE (Fig.8-3) MODEL: V24IW V26W V28W V28FW V28FHW VG504DXLP Fig. 8-3 3. Loop handle The loop handle consists of loop handle body (A), Fig. 9-1 handle holder (B), Setting bolts M5 ×...
  • Page 17 The ring nut (D) located on the control handle is for MODEL: V241LPS V26LPS VG404DXLPS adjusting the engine. By turning ring nut (D) clockwise, the engine rpm is reduced during the subsequent use of throttle lever (B).

  • Page 18: Harness Handling Method

    [10] HARNESS HANDLING METHOD [11] REGULAR MAINTENANCE From time to time make sure all brush cutter screws are firmly secured. Replace damaged, worn, cracked or warped-blades. Always make sure nylon string head and blade have been assembled correctly (see section BLADE AND NYLON STRING HEAD ASSEMBLY) and blade fastener is tightened.

  • Page 19: Fault Finding Table

    [12] FAULT FINDING TABLE Engine Engine Engine will not will not brush runs start. start of cutter fast but does loses badly. not cut power well. when cutting. Check STOP switch is in the position I. Control fuel level min. 25% tank capacity.
  • Page 20 (ESPAÑOL) MANUAL DE INSTRUCCIONES (FRANÇAIS) MANUAL DE FONCTIONNEMENT (PORTUGUÊS) MANUAL DE INSTRUÇÕES (ITALIANO) MANUALE D’USO E MANUTENZIONE (NEDERLANDS) HANDLEIDING (DEUTSCH) BEDIENUNGSANLEITUNG (TÜRKÇE) KULLANMA KILAVUZU Make sure all operators study this Manual carefully before using the brush cutter. 11MUKAIDANISHI-MACHI.KISSHOIN.MINAMI-KU.KYOTO,JAPAN.601-8307 info-e@marunaka-japan.co.jp http://www.marunaka-japan.co.jp CODE: 800204407 0802...
  • Page 22 Contents ENGLISH TECHNICAL DATA SYMBOL MEANING [1] GENERAL DESCRIPTION ............[2] SAFETY RULES ..............[3] SAFETY USAGE ..............[4] FUEL AND OIL................. [5] SAFETY GUARD ASSEMBLY ..........[6] BLADE AND NYLON STRING HEAD ASSEMBLY ............ENGINE/ CLUTCH CASE ASSEMBLY [8] HANDLE GRIP/HANDLE/THROTTLE WIRE ASSEMBLY ..

  • Page 24: Symbol Meaning

    SYMBOL MEANING Warning-Caution Do not use saw-blade Minimum safety distance Safety clothing: 1) Approved safety glasses of face shield 2) Approved safety helmet 3) Approved ear defender 4) Approved gloves 5) Approved safety footwear Read operating manual carefully Single handle should be locked in place marked ‘○’ Do not smoke while refuelling or while operating the machine Beware of thrown objects...

  • Page 25: General Description

    [1] GENERAL DESCRIPTION 5 12 V242L V262L V242W V262W V282W V262 V242 V282 1. Engine 2. Drive shaft housing 3. Trigger 4. STOP switch/throttle advance 5. Control handle 6. Blade 7. Harness 8. Spark plug 9. Air cleaner cover 10. Fuel tank cap 11.

  • Page 26: Safety Rules

    [2] SAFETY RULES Fig.2-1 1. Make sure all operators study this manual carefully before Fig.2-4 using the brush cutter. Do not allow children to use the brush cutter. 4. Do not carry the brush cutter while the engine is running even for short distances;...

  • Page 27: Safety Usage

    [3] SAFETY USAGE This product must be held to the right of the operator’s body. This will exhaust fumes are directed away from the operator and will not be obstructed by the operator’s clothing. If you have not used a brush cutter before, spend some time in becoming familiar with the controls and method of usage before operation.
  • Page 28 Fig.3-2 Fig.3-3 2. The following accessories can be assembled to your brush 3 .BLADES: cutter. a) blade, b) nylon string head. You can cut any type of grass, bushwood or shrub. a)WHEN USING A BLADE, ENSURE THE CORRECT Operate the machine like a sickle always cutting at full GUARD IS FITTED.

  • Page 29: Fuel And Oil

    1. 2-STROKE ENGINE [4] FUEL AND OIL (KAWASAKI:TJ Series , MITSUBISHI:TLE Series) This product is fitted with a 2-stroke engine and therefore requires a 2-stroke fuel and oil mix. Use a high quality 2-stroke engine oil using 2% (50:1) oil. In order to obtain a good fuel mix, put the oil into the container before the petrol.

  • Page 30: Safety Guard Assembly

    [5] SAFETY GUARD ASSEMBLY Fig.5-2 2. For a safety reasons, it is imperative that the unit is used with the correct guard when fitted with a nylon head. (Fig. 5-2) Use only manufacturer’s original blades. Fig.5-1 Only use blades or nylon string heads clearly marked with a maximum R.P.M.

  • Page 31: Blade And Nylon String Head Assembly

    [6] BLADE AND NYLON STRING HEAD ASSEMBLY Assemble the correct guard to suit the kind of blade or nylon string head to be used (See section: SAFETY GUARD ASSEMBLY). Fig.6-3 3. Assemble nylon string head as illustrated. Model: NV Fig.6-1 a) Loosen the nylon string head NV, and leave Disc (B-1) only.

  • Page 32: Engine/ Clutch Case Assembly

    [7] ENGINE/ CLUTCH CASE ASSEMBLY [8] HANDLE GRIP/HANDLE/THROTTLE WIRE ASSEMBLY  DENGER Mounting of handle grip Do not run the engine without clutch case attached, as the clutch could fly off. V262W V282W V242W Fig.7-1 1. Assemble the engine onto the clutch case. Make sure the shaft is fully and correctly up to the shank, then tighten the four screws A.

  • Page 33: Starting And Stopping The Engine

    Connection of throttle wire [9] STARTING AND STOPPING THE ENGINE MODEL: V242W V262W V282W GX Series TJ Series TLE Series Fig.9-1 Fig.9-2 Fig.9-3 Fig.8-3 1～2 mm Remove the air cleaner cover (A). Attach the throttle wire (B). The normal play is 1 or 2 mm when measured at the throttle wire end.
  • Page 34 ・ENGINE MODEL: TJ Series STOPPING THE ENGINE To stop the engine, push the knob (A) in the “→ STOP” direction (Fig. 9-4). WARNING: When the engine is switched off, the rotating part, blade or nylon string head, will keep on rotating for a few seconds.
  • Page 35 ・ENGINE MODEL: TJ Series MODEL: V242L V262L Push knob (H) in the “→START” direction (Fig. 9-9). Push the priming pump (D:Fig. 9-5) several times. Move the choke lever (E:Fig. 9-5) to the “START” position. Pull the recoil starter grip (F:Fig. 9-5) firmly and rapidly until the engine fires (Fig.

  • Page 36: Harness Handling Method

    [10] HARNESS HANDLING METHOD Fig.10-3 In the case of an emergency pull up the belt (red), and the total machine can be separated from the harness. Be careful not to operate the belt carelessly except for a case of emergency. (Fig. 10-3) Fig.10-1 In normal use of the reaper, set the harness side hook on the hanger strap stem securely before starting the work.

  • Page 37: Regular Maintenance

    3. SPARK PLUG [11] REGULAR MAINTENANCE From time to time make sure all brush cutter screws are electrode cap firmly secured. Replace damaged, worn, cracked or warped- blades. Always make sure nylon string head and blade have been assembled correctly (see section BLADE AND NYLON STRING HEAD ASSEMBLY) and blade fastener is tightened.

  • Page 38: Fault Finding Table

    [12] FAULT FINDING TABLE Engine will not The brush Engine runs fast Engine will Start of run cutter does but loses power not start. badly. not cut well. when cutting. Check STOP switch is in ● ● the position I. Control fuel level min.
