Page 1
3 7 63 1515 0 For Japan model Ver. 1 SERVICE MANUAL DCD-SA100 MODEL SUPER AUDIO CD PLAYER L 13942296513 注 意 サービスをおこなう前に、このサービスマニュアルを 必ずお読みください。本機は、火災、感電、けがなど に対する安全性を確保するために、さまざまな配慮を おこなっており、また法的には「電気用品安全法」に もとづき、所定の許可を得て製造されております。 従ってサービスをおこなう際は、これらの安全性が維 持されるよう、このサービスマニュアルに記載されて いる注意事項を必ずお守りください。 For purposes of improvement, specifications and 本機の仕様は性能改良のため、予告なく変更すること ● ● があります。...
DCD-SA100 3 7 63 1515 0 SAFETY PRECAUTIONS The following check should be performed for the continued protection of the customer and service technician. LEAKAGE CURRENT CHECK Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
Page 3
DCD-SA100 3 7 63 1515 0 レーザーピックアップ取扱い上の注意と交換 1. 分解 /Disassembly 本メカニズムは、専門工場で、精密に組立て調整しております。安易に分解、調整を行わないで下さい。 Do not disassemble or adjust this mechanism due to precision component. 2. 保管 /Storage 高温、あるいは高湿度下での保管は避けて下さい。静電気、塵埃対策を行い異常な外力が加わらないように保管して下さ い。 Do not leave this mechanism in high temperature and humidity. Be sure to prevent this mechanism from static electricity, dust and excessive forces.
Page 4
DCD-SA100 3 7 63 1515 0 対物レンズ、アクチュエータ、レーザーダイオード、光検出器、及び半固定抵抗には絶対に触れいで下さい。 Never touch the objective lens, actuator, laser diode, photo detector and the trim-potentiometer. 対物レンズに、塵埃や汚れが付かないように充分注意して下さい。 Be sure no dust or soil on the objective lens. 対物レンズに埃が付いた場合、きれいな空気を吹き付けて取り去って下さい。 If dust is on the objective lens, below it away by clean air.
Page 5
DCD-SA100 DIAGNOSTICS OF OPTICAL PICKUP 3 7 63 1515 0 光ピックアップの故障診断とトラバース AND REPLACING TRAVERSE UNIT ユニットの交換 Make failure diagnostics of the Optical Pickup as follows. 次の順序で故障診断を行ってください。 If the laser drive current (Iop) becomes more than 1.5 times of レーザー駆動電流 Iop 値が初期値の 1.5 倍以上になっている場...
Page 6
DCD-SA100 1. Label Indication of SACD Mechanism. 3 7 63 1515 0 1. SACD メカのラベル表示 メカ背面のレーザー電流初期値 2. Note for Handling the Laser Pick-Up 2. レーザーピックアップの取扱注意 the protection for the damage of laser diode. レーザーダイオードの破壊防止。 If you want to change the optical device unit from any other 光素子ユニットを交換するときは、以下を遵守してください。...
Page 7
DCD-SA100 3 7 63 1515 0 4.1. DVD Laser current measurement 4.1. DVD レーザー電流測定 LD(DVD) LD(DVD) +5V-A2 +5V-A2 Oscilloscope Oscilloscope (1) Connect the oscilloscope to +5V-M2 of test point for GND (1) オシロスコープをテストポイント +5V-M2(GND) と side and LD(DVD) of test point for signal side.
Page 12
DCD-SA100 SETTING UP THE TEST MODE テストモード 3 7 63 1515 0 (1) Setting up (1) テストモードへの投入 • In order to set up the test mode, you press STOP button ・ テストモードへの投入はヒートランモード時に STOP and REV button simultaneously in the heat-run mode.Fun- キーと...
Page 13
DCD-SA100 (b) In the case of trace mode (error rate display) (refer to ta- (b) トレースモード ( エラーレート表示 ) の場合( 表 2 ト 3 7 63 1515 0 ble 2 trace mode details) レースモード詳細 参照) FL display (The display part of 13 digits) FL 管の表示...
Page 15
DCD-SA100 Fcs AGC レイヤ 1 CXD1885Q 内 部フォ ーカス ゲイン Fcs AGC layer 1 The inside focus gain (setting 0x2000 3 7 63 1515 0 (0x2000 を 1 として ) 値を表示。 to 1) value of CXD1885Q is displayed. 0x1FF2 や 0x2012 の場合、以下のよ...
Page 16
DCD-SA100 Table 2: trace mode details 表 2 トレースモード詳細 3 7 63 1515 0 YY 内容 補足説明 YY Contents Contents supplement 1 層内周の PO 誤り検出数とアド CD 時は無効。 A display of PO error detection It is invalid at the time of CD number of the inner circumfer - レスの表示...
Page 17
DCD-SA100 Table 3:Disc distinction information 表3 ディスク判別情報 3 7 63 1515 0 Mirr Width PI Level Mirr Coun FZC Coun Mirr Width PI Level Mirr Coun FZC Coun No Disc 2 と 3 以外 No Disc Except 2 and 3 CD 高反射...
Page 19
DCD-SA100 SEMICONDUCTORS 3 7 63 1515 0 Only major semiconductors are shown, general semiconductors etc. are omitted to list. 主な半導体を記載しています。汎用の半導体は記載を省略しています。 1. IC’s Note: Abbreviation ahead of IC No. indicates the name of P.W.B., etc. 注 ): IC No. の前の記号は、基板の名称を表します。...
Page 20
DCD-SA100 3 7 63 1515 0 Block Diagram 16/4M DRAM ECC Core Memory Data manager Slicer Demodulation Video MPEG I/F CD-DSP (DDCD) Data-PLL VSTEM Serial ASP Serial I/F VSTEM Serial I/F Command CD-ROM DSP CLK/Mode Header Dec. Spindle Audio I/F...
Page 21
DCD-SA100 3 7 63 1515 0 Terminal Name Classification Function 31 SYSCK Clock Clock Monitor output. 32 DV & GND Digital 1.8V Power. (Internal logic system power) 33 XI Clock Crystal oscillation input. 34 XO Clock Crystal oscillation output.
Page 23
DCD-SA100 3 7 63 1515 0 Terminal Name Classification Function 151 RD13 DRAM I/F DRAM data input/output terminal 13. 152 RD12 DRAM I/F DRAM data input/output terminal 12. 153 RD11 DRAM I/F DRAM data input/output terminal 11. 154 RD10 DRAM I/F DRAM data input/output terminal 10.
Page 25
DCD-SA100 3 7 63 1515 0 Terminal Functions Pin Name Functions 1 VSC It fixed to ground.( for Core) Latch input for µCOM serial communication. 2 XMSLAT 3 MSCK Shift clock input for µCOM serial communication. Data input for µCOM serial communication.
Page 26
DCD-SA100 3 7 63 1515 0 Pin Name Functions 51 TESTI Input for TEST. It fixed to “L” potential. 52 TESTI Input for TEST. It fixed to “L” potential. 53 TESTO Output for TEST. (open) 54 VDC +2.5V Power for CORE.
Page 27
DCD-SA100 3 7 63 1515 0 Pin Name Functions 97 TESTI TEST input terminal. It fixed to “H” potential. 98 TESTO TEST output terminal. (open) 99 VDC +2.5V Power for CORE. 100 TESTI TEST input terminal. It fixed to “L” potential.
Page 28
DCD-SA100 3 7 63 1515 0 Pin Name Functions 149 A10 Address output terminal for SDRAM. 150 VSC Ground for CORE. 151 A9 Address output terminal for SDRAM. 152 A8 Address output terminal for SDRAM. 153 VDC +2.5V Power for CORE.
Page 30
DCD-SA100 3 7 63 1515 0 M30624FGNGP Port Assignment Port Function Initial Mode Action Note 備考 (USER1:H/USER2:H) P94/DA1/TB4IN MULT_LED MULTI SURROUND(LED L=ON) MULTI SURROUND(LED L=ON) P93/DA0/TB3IN DSCS1 CHIP SELECT for FRONT DAC DCD1792/DXP7001 の P92/TB2IN/SOUT3 SOUT3 DSDO CONTOROL SERIAL DATA for...
Page 31
DCD-SA100 3 7 63 1515 0 Port Function Initial Mode Action Note 備考 P56/ALE OPEN1 OPEN(anytime) Flash(w: OPEN(anytime) pull up) P55/HOLD~ P_UP2 10K PULL UP(NON CONECT) Flash(w: GND) P54/HLDA~ OPEN2 OPEN P53/BCLK OPEN3 OPEN P52/RD~ READ STROBE for XD1885Q...
Page 32
DCD-SA100 3 7 63 1515 0 Port Function Initial Mode Action Note 備考 P03/D3 8bit DATA LINE P02/D2 8bit DATA LINE P01/D1 8bit DATA LINE P00/D0 8bit DATA LINE P107/AN7/KI3~ P107 MODE CD/SACD SWITCHING SACD と CD の digital SIGNAL(L:CD,SACD:H) audio data の切り換えを...
Page 36
DCD-SA100 3 7 63 1515 0 Terminal Function Power Supply Pins Name Function Power for RF and serial port Power for servo GND for RF and serial port GND for servo Power for output buffer Reference Power for servo output...
Page 37
DCD-SA100 3 7 63 1515 0 Analog Pins Name Function RF AGC integration capacitor connecting terminal Differential phase tracking LPF terminal Differential phase tracking LPF terminal Lens shift offset cancel LPF terminal Lens shift offset cancel LPF terminal MIRR top hold terminal...
Page 38
DCD-SA100 3 7 63 1515 0 16M SDRAM (TSOP)-7/8 (SM: IC402) (EM636165ST-7) 16M SDRAM (TSOP)-8 (DM: IC103, 104) K4S161622D-TC80 W981616AH-8 Terminal Function Pin No. Pin Name Symbol Function Power Supply/Ground Power and ground for the input buffer and the core logic...
Page 44
DCD-SA100 3 7 63 1515 0 AN8471SA (SM: IC505) Pin No. Pin Name Function Hall bias pin Hall element 3 input (-) Hall element 3 input (+) Hall element 2 input (-) Hall element 2 input (+) Hall element 1 input (-)
Page 45
DCD-SA100 3 7 63 1515 0 T14L1024N (SM: IC732) DSD1792DBR (CS: IC206, 207, 502, 503) DSDL DSDR AGND3L DBCK L– PLRCK PDATA AGND2 PBCK L 13942296513 DGND AGND1 R– AGND3R terminal functions T E R M INAL DESCRIPTIONS NAME P I N ‡...
Page 46
DCD-SA100 3 7 63 1515 0 T ER M INAL DESCRIPTIONS NAME P I N † PBCK Bit clock input. Connected GND for DSD mode † System clock input DGND Digital ground Digital power supply, +3.3 V ‡ I/O Chip select for mode control †...
Page 48
DCD-SA100 3. FL DISPLAY 3 7 63 1515 0 17-ST-04GNK (PD: FL601) COLOR ILLUMINATION Reddish Orange ----- Above pattern part Green ------------------ Other PIN CONNECTION PIN NO. CONNECTION NOTE 1) F-,F+ ---------- Filament 2) NP ------------- No pin PIN NO.
Page 49
DCD-SA100 PRINTED WIRING BOARDS 3 7 6 3 1 5 1 5 0 1U-3532 CD/SACD P.W.B. UNIT 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 COMPONENT SIDE http://www.xiaoyu163.com...
Page 50
DCD-SA100 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 FOIL SIDE http://www.xiaoyu163.com...
Page 51
DCD-SA100 3 7 6 3 1 5 1 5 0 1U-3533 POWER/DISPLAY P.W.B. UNIT 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 COMPONENT SIDE http://www.xiaoyu163.com...
Page 52
DCD-SA100 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 FOIL SIDE http://www.xiaoyu163.com...
Page 53
DCD-SA100 3 7 6 3 1 5 1 5 0 1U-3562 SACD MODULE P.W.B. UNIT 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 FOIL SIDE COMPONENT SIDE http://www.xiaoyu163.com...
Page 54
DCD-SA100 3 7 63 1515 0 NOTE FOR PARTS LIST Part indicated with the mark " " are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Page 55
DCD-SA100 PARTS LIST OF P.W.B. UNIT 3 7 63 1515 0 *本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります 1U-3532 CD/SACD P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty SEMICONDUCTORS GROUP IC201,202 262 2376 903 TC74HCT7007AF(TP1) IC204 263 1048 002 BA033T IC205 262 2978 000...
Page 69
DCD-SA100 EXPLODED VIEW 3 7 6 3 1 5 1 5 0 印の部分は安全を維持するために重要 Parts List な部品です。従って交換時は必ず指定の 部品を使用して下さい。 54,55 61,62 63,64 59,60 50,51 50,51 50,51 1 3 9 4 2 2 9 6 5 1 3 52,53 50,51 w w w u 1 6 3 http://www.xiaoyu163.com...
Page 70
DCD-SA100 PARTS LIST OF EXPLODED VIEW 3 7 63 1515 0 *本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。 Ref.No. Part No. Part Name Remarks Q'ty 1U-3532 CD/SACD P.W.B UNIT FRONT AUDIO UNIT SURROUND AUDIO UNIT JUNCTION UNIT 1U-3533 POWER/DISPLAY UNIT POWER UNIT DISPLAY UNIT LED UNIT P.SW UNIT...
Page 72
DCD-SA100 EXPLODED VIEW OF SACD MECHANISM 3 7 6 3 1 5 1 5 0 Parts List 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 http://www.xiaoyu163.com...
Page 73
DCD-SA100 PARTS LIST OF SACD MECHANISM 3 7 63 1515 0 *本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。 Ref. No. Part No. Part Name Remarks Q'ty 411 1988 101 MECHA CHASSIS 431 0426 503 PLATE GEAR 9KA 2A40 3D GEAR BASE SUB ASS'Y 441 1952 109...
Page 80
DCD-SA100 NOTE FOR SCHEMATIC DIAGRAM 3 7 63 1515 0 配線図について WARNING: ! 印の部品は安全を維持するために重要な部品です。 Parts marked with this symbol ! have critical characteristics. 従って交換時は必ず指定の部品を使用してください。 Use ONLY replacement parts recommended by the manufactur- 注) CAUTION: (1) 指定なき抵抗値は Ω、k は kΩ、M は MΩ を示す。...
Page 81
DCD-SA100 SCHEMATIC DIAGRAMS (1/7) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w SIGNAL LINE u 1 6 3 SCHEMATIC DIAGRAMS (1/7) 1U-3532-1 FRONT AUDIO UNIT 1U-3532-3 JUNCTION UNIT http://www.xiaoyu163.com...
Page 82
DCD-SA100 SCHEMATIC DIAGRAMS (2/7) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w SIGNAL LINE u 1 6 3 SCHEMATIC DIAGRAMS (2/7) 1U-3532-2 SURROUND AUDIO UNIT...
Page 83
DCD-SA100 SCHEMATIC DIAGRAMS (3/7) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 SCHEMATIC DIAGRAMS (3/7) 1U-3533-1 POWER UNIT http://www.xiaoyu163.com...
Page 84
DCD-SA100 SCHEMATIC DIAGRAMS (4/7) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 SCHEMATIC DIAGRAMS (4/7) 1U-3533-2 DISPLAY UNIT 1U-3533-3 LED UNIT 1U-3533-4 P.
Page 85
DCD-SA100 SCHEMATIC DIAGRAMS (5/7) 3 7 6 3 1 5 1 5 0 CY251 1 3 9 4 2 2 9 6 5 1 3 w w w SIGNAL LINE u 1 6 3 SCHEMATIC DIAGRAMS (5/7) 1U-3562 SACD MODULE UNIT (1/3)
Page 86
DCD-SA100 SCHEMATIC DIAGRAMS (6/7) 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 CX131 w w w SIGNAL LINE u 1 6 3 SCHEMATIC DIAGRAMS (6/7) 1U-3562 SACD MODULE UNIT (2/3)
Page 87
DCD-SA100 SCHEMATIC DIAGRAMS (7/7) 3 7 6 3 1 5 1 5 0 to 1U-3532-3 Junction Unit 1 3 9 4 2 2 9 6 5 1 3 to 1U-3532-1 Front Audio Unit w w w SIGNAL LINE u 1 6 3...
