Summary of Contents for Thurman 1000
- Page 1 Installation Manual 1000 Series Portable Beam Scale Model 1000 51003 © 1996-2013 by Thurman Scale Revision 3–03/13 All rights reserved.
- Page 2 Disclaimer: Every effort has been made to provide complete and accurate information in this manual. However, although this manual may include a specifically identified warranty notice for the product, Thurman Scale makes no representations or warranties with respect to the contents of this manual, and reserves the right to make changes to this manual without notice when and as improvements are made.
-
Page 3: Table Of Contents
SECTION 3: INSTALLATION ......................6 Unpacking ........................... 6 Assembly ............................. 6 3.2.1 Wheel and Pillar Assembly ....................... 6 3.2.2 Cap and Beam Assembly for Series 1000 Models ................7 Operation............................ 9 3.3.1 Zeroing ............................. 9 3.3.2 Weighing ............................9 SECTION 4: PARTS ........................ -
Page 4: Introduction
1.1 INTRODUCTION & GENERAL DESCRIPTION This manual provides information on installation, adjustment, and parts list for model 1000 Series portable platform scales. Please read carefully while assembling the scale. The scale is factory calibrated and supplied ready to be assembled and placed into service. -
Page 5: Description
Section 2: Description The 1000 Series Portable Beam Scale is constructed with a cast iron base and cast iron lever system. The indicating device is a mechanical beam (lbs. or kgs.) or with accessories, an electronic instrument for displaying the weight. -
Page 6: Installation
Section 3: Installation 3.1 UNPACKING Check that all parts are included using the packing list. Check for component damage that may have occurred during shipping. 3.2 ASSEMBLY CAUTION: The scale base assembly, as shipped, weighs 185 lbs., use caution when lifting. 3.2.1 Wheel and Pillar Assembly NOTE: The descriptions below refer to Item No to describe parts. -
Page 7: Cap And Beam Assembly For Series 1000 Models
Section 3: Installation 3.2.2 Cap and Beam Assembly for Series 1000 Models (Beam Installations): a. Place the beam support (#39) over the pillar rods with the "hook" facing to the right (when facing the scale platform). b. Place the beam cap (#45) over the pillar rods, with the beam cap extending to the right. - Page 8 Section 3: Installation : Check that the weighing platform "floats" on the levers' pivots and bearings NOTE and does not bind or set to one side. The platform should return to a centered position if moved to any position then released. o.
-
Page 9: Operation
Section 3: Installation 3.3 OPERATION 3.3.1 Zeroing Before weighing an object, ensure that the scale is on ZERO with nothing on the platform. To do this, set the sliding poise to "0" release the beam lock, and observe the beam within the beam lock loop. (The beam should move from near the top to near the bottom eventually settling 'balancing' in the center). -
Page 10: Parts
Section 4: Parts 4.1 1000 – LBS Part Item No. Description 71622 Pillar rod, long 58933 Pillar 95847 Platform cover 95848 Frame 95855 Cotter pin 58937 Bearing, platform 95856 Screw, Phillips Head 95857 Screw Allen 95858 Level, bubble 95859 Pin, corner loop... - Page 11 Section 4: PartsParts 1000 ‒ lbs –Diagram 03/13 51003 – Rev 3...
-
Page 12: 1001 - Kgs
Section 4: PartsParts 4.2 1001 – KGS Item No. Part Description 71622 Pillar rod, long 58933 Pillar 95847 Platform cover 95848 Frame 95855 Cotter pin 58937 Bearing, platform 95856 Screw, Phillips head 95857 Screw Allen 95858 Level, bubble 95859 Pin, corner loop 71623 Loop, corner 71624... - Page 13 Section 4: PartsParts 1000 ‒ kgs – Diagram 03/13 51003 – Rev 3...
- Page 14 1000 Series Portable Beam Scale Installation Manual Document 51003 Manufactured by Thurman Scale, Inc. 821 Locust Kansas City, MO 64106 www.Thurman.com...
