Installation Guidelines :
The recommended concealed box to be used should be of 60mm depth.
¨
The concealed box must be fixed atleast 1 inch inside the wall surface.
¨
All the load wires connected to the panels must not be more than 6 inch
¨
long.
Avoid over tightening of the mounting screws in the concealed box.
¨
The VAVIS Panel back box should not get bend due to over tightening of
¨
screws.
Ensure that the wall surface is plain and in level on which the VAVIS back
¨
box is to be fixed. If it is un-even, the back box will get bend while
tightening the screws and there may be chances of loose connection.
After connecting all the loads and back box on the concealed box, fix the
¨
VAVIS Glass Panel properly and ensure that it is perfectly locked with the
back box.
Never use CAT5/6 Cable for any load or looping the power in the back
¨
box. This may result into improper functioning of VAVIS Panels.
Any VAVIS Panel damaged due to improper connections, installation by
¨
non technical person or improper power supply will not be covered under
warranty.
Convenience | Comfort | Sophistication
"VAVIS" 4 Touch Panel
Model : VTW/B-400
Installation Manual
Advertisement
Summary of Contents for VAVIS VTW/B-400
- Page 1 The VAVIS Panel back box should not get bend due to over tightening of ¨ screws. Ensure that the wall surface is plain and in level on which the VAVIS back ¨ box is to be fixed. If it is un-even, the back box will get bend while tightening the screws and there may be chances of loose connection.
- Page 2 Frequency : 50 - 60 Hz On/Off : 4 x 800W Max. Power Consumption : < 10mW Mounting Box 2 Module (75x75x60 mm approx.) VTW/B-400 Load (L1) Load (L3) Always Open from this side Load (L2) Load (L4) Convenience | Comfort | Sophistication...
- Page 3 Wiring Diagram Mains Supply VTW/B-400 Phase 230V AC Neutral Wiring Diagram Backup Supply VTW/B-400 Phase 230V AC Backup Supply Neutral Phase 230V AC Backup Neutral Note : Incase of Mains Supply failure, Loads L3 & L4 will work on Backup Supply.
- Page 4 WARRANTY VAVIS Products are warrantied against all manufacturing defects for a period of 12 months from the date of purchase (In case of any complaints please contact your dealer). Warranty is not applicable to rubber / plastic parts, glass, chipping / peeling of paint, coating, breakage and any other damage due to transportation, mishandling &...
