Summary of Contents for SteadiStand STNDI2
- Page 1 SteadiStand Installation Manual For part numbers: STNDI2 (i2 stand), STNDX2 (x2 stand) Version 1.3 – August 2008...
-
Page 2: Table Of Contents
Overview..................5 Installation Procedure ..............6 Troubleshooting ................13 Warranty information..............13 © SteadiStand, LLC 2009, all rights reserved. This material may be freely copied and distributed subject to inclusion of this copyright notice and our World Wide Web URL http://www.SteadiStand.com... -
Page 3: Letter To Our Customers
Page 1 Dear valued customer, It is our hope that the SteadiStand will serve your needs for years to come. We’ve worked hard to design and manufacture the best product we can. We invite you to let us know how the SteadiStand has worked for you. -
Page 4: Preface
® well as through participating Segway dealers. The SteadiStand is so simple, easy to install and use, and works so well- it seemed unfair to keep it to ourselves. -
Page 5: Cautions And Warnings
PT is heavily loaded with cargo, particularly if placed in the handlebar bag. Doing so ® may damage the stand or your Segway While very sturdy, the ‘SteadiStand’ parking stand is designed to support only the weight of your ® Segway Periodically check the tension of your stand. -
Page 6: Recommended Tools
Page 4 Recommended tools: The following tools may be necessary to complete the installation of the SteadiStand: □ 3mm Allen (hex) key Used to make adjustments to the tensioning set screw located ® inside the stock Segway parking stand swivel mount. This tool ®... -
Page 7: Overview
If you do not have these installation instructions, you ® can download them from the Segway website: http://www.segway.com/downloads/pdfs/Parking_Stand.pdf Installation of the SteadiStand retrofit kit is simple and straightforward. Essentially, the spring portion of the stock ® Segway parking stand is removed, the tension of the swivel mount is adjusted (if necessary), and the SteadiStand is threaded into place. -
Page 8: Installation Procedure
Page 6 Installation Procedure: STEP #1 ____________________ ____________________ ® Remove the spring portion of the stock Segway parking stand ® a. Identify the stock Segway parking stand swivel mount. See figure 1.1 b. Remove the spring stand from the stock ®... - Page 9 Page 7 Fig. 1.1 Fig 1.2 c. If this doesn't work, try using ® a pair of pliers (Channel Lock style pliers work great) to unscrew the spring from the mount. Grasp the top of the spring with the pliers, which will apply pressure on the set screw inside.
- Page 10 Page 8 STEP #2 ____________________ ____________________ Once the spring portion is removed, check to be sure ® that your stock Segway parking stand swivel mount locks into position (left, center, right) firmly. It is important to adjust the tensioning set screw while the adjustment screw is readily accessible.
- Page 11 Page 9 Fig. 1.4 b. Be sure the swinging portion of the mount is set to one of the three positions: • straight down • completely up to the left • completely up to the right...
- Page 12 This setting will offer a solid click into the desired stand position. Note: There is nothing permanent about installing the SteadiStand retrofit kit. Should the stand positions become loose in the future, simply unscrew the ®...
- Page 13 Fig. 1.5 ® b. If necessary, smooth the pre-applied Teflon tape around the threads. This tape will ease the installation of the SteadiStand as well as prevent the SteadiStand from unthreading due to vibration. c. Thread the SteadiStand assembly into the ®...
- Page 14 Page 12 Fig. 1.6 Hint: Do not use tools such as pliers or wrenches to ® tighten the retrofit kit to the stock Segway parking stand swivel mount. Doing so may damage the painted surface or the rubber base.
-
Page 15: Troubleshooting
(919) 600-2001 Hours: M-F 8:30am – 5:30pm ET Limited One Year Warranty The SteadiStand retrofit kit comes with a limited one (1) year warranty from date of purchase against original defects in materials or workmanship. Should this product fail to perform... - Page 16 SteadiStand, LLC 825 Maurepas Drive Knightdale, NC 27545 V. (919) 600-2001 F. (919) 869-2483 www.SteadiStand.com info@SteadiStand.com...
