Summary of Contents for Ferroli SUN P7

  • Page 1 SUN P7 - P12 IT - ISTRUZIONE PER L’USO L'INSTALLAZIONE E LA MANUTENZIONE EN - INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE CS - NÁVOD K POUŽITÍ, INSTALACI A ÚDRŽB RO - INSTRUC IUNI DE UTILIZARE, INSTALARE I ÎNTRETINERE RU -...
  • Page 2: Avvertenze Generali

    La ringraziamo di aver scelto SUN P7 - P12, un bruciatore FERROLI di concezione avanzata, tecnologia all’avanguardia, elevata affidabilità e qualità costruttiva. SUN P7 - P12 è un bruciatore di pellet, la cui elevata compattezza e disegno originali lo rendono adatto all’impiego sulla maggior parte delle caldaie per combustibile solido oggi presenti sul mercato.
  • Page 3 SUN P7 - P12 2.4 Regolazioni Menù parametri Impostazione orologio (solo metodo B e C) L’accesso al menù parametri avviene premendo il pulsante programmazione “M” (part. 2 - fig. 1) per 5 secondi. Viene visualizzato il parametro “u01”: identificato dalla scritta Premere il pulsante impostazione giorno/ora (part.
  • Page 4: Installazione

    Fissare il bruciatore alla porta. Effettuare i collegamenti elettrici come riportato al cap. 5 (schema elettrico). Nel caso il bruciatore venga installato in una caldaia SUN P7 - P12, utilizzare l’apposito kit di trasformazione. Inserire la sonda di temperatura contenuta nel kit nella guaina sul corpo della caldaia in ghisa ed effettuare i relativi collegamenti elet- trici.
  • Page 5 SUN P7 - P12 fig. 8 fig. 11 3.3 Collegamenti elettrici Il bruciatore è dotato di una morsettiera multipolare per gli allacciamenti elettrici; far rife- rimento allo schema elettrico nel capitolo “4 Caratteristiche e dati tecnici” per le con- nessioni. I collegamenti da effettuare a cura dell’installatore sono: •...
  • Page 6: Servizio E Manutenzione

    Assistenza Clienti di Zona è a vostra disposizione per ogni ulteriore informazione. • Chiudere la linea dei termostati (caldaia/ambiente). FERROLI declina ogni responsabilità per danni a cose e/o persone derivanti dalla ma- Taratura del bruciatore nomissione dell’apparecchio da parte di persone non qualificate e non autorizzate.
  • Page 7: Caratteristiche E Dati Tecnici

    Pulirla e verificare il correttotiraggio Caldaia in pressione coclea minimo del camino (10Pa) Termostato di sicurezza guasto Sostituirlo fig. 14 - Dimensionale SUN P7 Tubetto del collegamento sensore di pres- Sostituire Anomalia regola- sione schiacciato zione pressione Motore ventilatore danneggiato...
  • Page 8 SUN P7 - P12 5.2 Vista generale e componenti principali fig. 16 Legenda Trasduttore di pressione Centralina Corpo bruciatore Morsettiera Interfaccia utente Resistenza Fotoresistenza Termostato 85° Tubo per carico bruciatore Motore Ventola Boccaglio Griglia 5.3 Tabella dati tecnici Dati Unità...
  • Page 9 SUN P7 - P12 5.4 Schema elettrico INTERFACCIA UTENTE BIT01.02 3.15 A 1 2 3 4 +15V DBM13 fig. 17 - Schema elettrico con morsettiera 12 poli INTERFACCIA UTENTE BIT01.02 3.15 A 1 2 3 4 +15V DBM13 fig. 18 - Schema elettrico con morsettiera 14 poli...
  • Page 10: Certificato Di Garanzia

    • La presente garanzia si aggiunge e non pregiudica i diritti dell’acquirente previsti dalla direttiva 99/44/CEE e relativo decreto nazionale di attuazione. FERROLI S.p.A. - Via Ritonda 78/a - 37047 San Bonifacio (Verona) Italy - tel. +39.045.6139411 - fax. +39.045.6100933 - www.ferroli.it...
  • Page 11: General Instructions

    Indications during operation SUN P7 - P12 is a pellet burner whose compact size and original design make it suitable for use with the majority of solid fuel-burning boilers available on the market. The care taken in its design and industrial production has resulted in a well-balanced product of- fering high efficiencies, low CO and NOx emissions and a very quiet flame.
  • Page 12 SUN P7 - P12 2.4 Adjustments Parameters menu Setting the clock (methods B and C only) Press the programming button “M” (detail 2 - fig. 1) for 5 seconds to access the param- eters menu. Parameter “u01”, identified by the message SET 01, is displayed. Press the Press the day/time setting button (detail 1 - fig.
  • Page 13: Installation

    Fix the burner to the door. Make the electrical connections as shown in cap. 5 (wiring di- Nominal heat output agram). If the burner is installed in a boiler SUN P7 - P12, use the special conversion kit. Parameter Insert the temperature probe (contained in the kit) in the sheathing on the cast-iron boiler shell and make the respective electrical connections.
  • Page 14 SUN P7 - P12 fig. 8 fig. 11 3.3 Electrical connections The burner is equipped with a multipole terminal block for the electrical connections; re- fer to the wiring diagram in section "4 Technical Characteristics and Data" for the con- nections.
  • Page 15: Service And Maintenance

    (boiler/room). information. Burner setting FERROLI declines any liability for damage and/or injury caused by unqualified and un- Connect a combustion analyser to the boiler outlet and leave the burner working at authorised persons tampering with the unit.
  • Page 16: Technical Data And Characteristics

    Boiler under pressure draught (10Pa) Faulty safety thermostat Replace it Pressure sensor connection tube Replace squashed fig. 14 - Dimensional SUN P7 Faulty pipe pres- sure adjustment Fan motor damaged Replace Fan dirty Clean it Pressure trans- ducer fault (dis-...
  • Page 17 SUN P7 - P12 5.2 General view and main components fig. 16 Pressure transducer Controller Burner body Terminal block User interface Heating element Photoresistance Thermostat 85° Burner loading tube Motor Nozzle Grille 5.3 Technical data table Data Unit SUN P7 SUN P12 Max.
  • Page 18 SUN P7 - P12 5.4 Wiring diagram INTERFACCIA UTENTE BIT01.02 3.15 A 1 2 3 4 +15V DBM13 fig. 17 - Wiring diagram with 12-pole terminal block INTERFACCIA UTENTE BIT01.02 3.15 A 1 2 3 4 +15V DBM13 fig. 18 - Wiring diagram with 14-pole terminal block...
  • Page 19 • °C • O/FH = • " " • SUN P7 - P12 FERROLI SUN P7 - P12 SUN P7 . 2 - . 3 - 7-8 ( . 17), . 10 - . 1). • • • 11 12 .
  • Page 20 SUN P7 - P12 • + - ( . 4 6 - . 1) , 16:00 "P" B C) . 5 - . 1) . 1 - . 1). 22:30 . 7 - . 1) . 1), • + - ( .
  • Page 21 SUN P7 - P12 SUN P7 - P12 SFL, “L” “M” “N”. “E” 11 12, “T” “V”. “P” “R” “S” . u02) SUN P7 SUN P12 “Y” “X” “W” . 11. 24.9 33.4 cap. 5 ( SUN P7 - P12,...
  • Page 22 SUN P7 - P12 . 11 “4 ”. • • • • 230 -50 sez. 5.3 , . . • • • . 10 “P” ( . 5 - . 1) “t 1”: SET 01. cod. 3540I815 - 07/2011 (Rev. 00)
  • Page 23 SUN P7 - P12 • • . sez. 3.4. • FERROLI 4.1 3.1 7-8 ( . 17). • • 1000 “ ser- On), vice” cap. 2.4). 7-8 ( . 17). “T18” “ service” cap. 2.4). 7-8 ( . 17). A, B "M"...
  • Page 24 SUN P7 - P12 . 7 - . 1) “A”): " " ( . 5 - . 1) “F”) . 3 - Ø190 . 14 - SUN P7 03=51 04=12 13-14 Ø225 . 15 - SUN P12 cod. 3540I815 - 07/2011 (Rev. 00)
  • Page 25 SUN P7 - P12 . 16 85° SUN P7 SUN P12 34.1 55.0 13.7 30.0 11.6 230/50 230/50 13.5 6/35 6/35 -0.2 -0.2 cod. 3540I815 - 07/2011 (Rev. 00)
  • Page 26 SUN P7 - P12 INTERFACCIA UTENTE BIT01.02 3.15 A 1 2 3 4 +15V DBM13 . 17 - INTERFACCIA UTENTE BIT01.02 3.15 A 1 2 3 4 +15V DBM13 . 18 - cod. 3540I815 - 07/2011 (Rev. 00)
  • Page 27: Dichiarazione Di Conformità

    Dichiarazione di conformità Il costruttore: FERROLI S.p.A. Indirizzo: Via Ritonda 78/a 37047 San Bonifacio VR dichiara che questo apparecchio è conforme alle seguenti direttive CEE: • Direttiva Bassa Tensione 73/23 (modificata dalla 93/68) • Direttiva Compatibilità Elettromagnetica 89/336 (modificata dalla 93/68) Presidente e Legale rappresentante Cav.
