LogicMark 41920 Setup Instructions

Emergency wall communicator caretakersentry series
Hide thumbs

Advertisement

Table of Contents

English
SET UP INSTRUCTIONS
Guardian Alert
Emergency Wall Communicator
Model #41920
This accessory is to be used with the LogicMark's CaretakerSentry
product line. U
p to 5 Two-way pendants and Emergency Wall Communicators
can be learned to one
plus 4 Waterproof pendants, or 9 Waterproof pendants
CaretakerSentry base unit.
CONTENTS:
Emergency Wall
Communicator
(EWC)
Double Stick Velcro
4 Screws
AAA Alkaline Batteries
4 pieces
C
S
ARETAKER
ENTRY
v5.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 41920 and is the answer not in the manual?

Questions and answers

Summary of Contents for LogicMark 41920

  • Page 1 SET UP INSTRUCTIONS Guardian Alert Emergency Wall Communicator Model #41920 This accessory is to be used with the LogicMark’s CaretakerSentry product line. U p to 5 Two-way pendants and Emergency Wall Communicators can be learned to one plus 4 Waterproof pendants, or 9 Waterproof pendants CaretakerSentry base unit.

  • Page 2: Table Of Contents

    Product Specifications ................9 NOTE: Before programming this Emergency Wall Communicator (EWC) to work with your LogicMark DECT base unit, you must acknowledge that all of the Warnings, Limitations of Liability, Disclaimers, FCC information and Testing Instructions written in the LogicMark Personal Emergency Response System (PERS) instruction manuals pertain to the use of this EWC as well when used with these products.

  • Page 3: Installing The Batteries

    Installing the Battery Slide the battery cover to the left to unlatch the cover Install the 4 AAA alkaline batteries - noting the polarity on the inside of the battery cover. The spring contacts are meant to touch the negative side of the batteries.

  • Page 4: Battery Check

    Notes: • You have up to 45 seconds after pushing the RED Code Learn button on the Base unit to get the EWC to enter “Pendant Learning”. • Learning additional Pendants or EWCs does not erase previously learned Pendants or EWCs. • The Base unit will automatically exit the Pendant learning mode after several seconds or if Pendant learning failed. • Only a combined total of 9 Pendants and EWCs (up to 5 two-way pendants and/or EWCs and 4 waterproof pendants) can be learned to a Base unit.

  • Page 5: System Check

    “Battery is ok.” Check the battery condition monthly. “Battery is low.” The batteries should be replaced within the week. “Replace battery now.” The 4 AAA batteries should be replaced now with 4 new AAA alkaline batteries. Please note: If there is no response after pressing the button for one second or more, the batteries are dead and must be replaced immediately Perform a system check at least once month as outlined below.

  • Page 6: Fcc Information

    This EWC is designed to be mounted on a bathroom wall if desired. However, it should never be submerged or exposed to water continuously. If your EWC is not working, call our tech support at 1-888-283-6516. Information The FCC Wants You To Know: CaretakerSentry Emergency Wall Communicator – Model 41920 FCC ID: TYD-CS41920 IC ID: 8471A-CS41920 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 7 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 8: Warranty

    LogicMark, LLC. will not be responsible for the improper use of this Sys- tem, nor will it be responsible for failure resulting from the use of other equipment connected to the same phone line. We will not be responsible for the quality of the phone line or the reliability or quality of the phone service with which the System is used.

  • Page 9: Product Specifications

    If the warranty period has expired or if you are not the original owner of the product, you can return the product pre-paid to LogicMark, LLC; 10106 Bluegrass Pkwy; Louisville KY, 40299, USA for repair or replacement at our standard rates.
