Installation and Basic Configuration

Release Date: December 17, 2008
Publish Date: December 31, 2008
®
Foundry
NetIron MLX Series
Release 04.0.00
Guide
NetIron MLX-4
NetIron MLX-8
NetIron MLX-16
NetIron MLX-32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetIron MLX-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Foundry Networks NetIron MLX-4

Summary of Contents for Foundry Networks NetIron MLX-4

  • Page 1: Installation And Basic Configuration

    ® Foundry NetIron MLX Series Installation and Basic Configuration Guide NetIron MLX-4 NetIron MLX-8 NetIron MLX-16 NetIron MLX-32 Release 04.0.00 Release Date: December 17, 2008 Publish Date: December 31, 2008...
  • Page 2 You are not permitted to use these Marks without the prior written consent of Foundry or such appropriate third party. Foundry Networks, BigIron, Terathon, FastIron, IronView, JetCore, NetIron, SecureIron, ServerIron, TurboIron, IronWare, EdgeIron, IronPoint, the Iron family of marks and the Foundry Logo are trademarks or registered trademarks of Foundry Networks, Inc.

  • Page 3: Table Of Contents

    ) ..........2-10 IGABIT THERNET NTERFACE ODULES PORT AND PORT FE/G E (100/1000) E (SFP)............2-12 THERNET NTERFACE ODULE 10/100/1000 E (RJ-45) ..............2-14 THERNET NTERFACE ODULE 48-T M ......................2-14 IGABIT X ODULE December 2008 © 2008 Foundry Networks, Inc. -iii...
  • Page 4 OUNTING A HASSIS IN A ...................... 3-15 EMOVING THE LANKS MLX-8 M ....................3-15 NSTALLING ODULES MLX-8 C ............3-17 NSTALLING OWER UPPLIES IN THE HASSIS AC P MLX-8 C ..............3-17 ONNECTING OWER TO A HASSIS © 2008 Foundry Networks, Inc. December 2008...
  • Page 5 TTACHING A ERMINAL TO THE ONSOLE ORT OR THERNET ’ ........3-50 TTACHING THE ANAGEMENT ODULE THERNET ORT TO A ETWORK ......................3-50 OWERING N THE OWER OURCE .......................3-51 ERIFYING ROPER PERATION ........................3-51 BSERVING THE December 2008 © 2008 Foundry Networks, Inc.

  • Page 6: Netiron Mlx

    ............5-18 HANGING RIORITY OF HASSIS LOTS FOR NTERFACE ODULES .............5-19 ISABLING AND EENABLING OWER TO THE NTERFACE ODULES CPU U .........5-19 NABLING AND ISABLING ANAGEMENT ODULE SAGE ALCULATIONS CPU U ........................5-20 ISPLAYING SAGE © 2008 Foundry Networks, Inc. December 2008...
  • Page 7 MLX-8........6-22 EPLACING THE ILTER IN THE HAPTER ....... 7-1 PGRADING OFTWARE MAGES AND ONFIGURATION ILES SNMP NI-MLX-1G 48-T M ................7-2 YSTEMS WITH ODULES ........................7-2 OFTWARE MAGES EQUIRED ....................7-3 MAGES AND ROCEDURES EQUIRED December 2008 © 2008 Foundry Networks, Inc. -vii...

  • Page 8: Nterface M

    TANDBY ANAGEMENT ODULES ..................7-37 OMPARING AND YNCHRONIZING ILES ................7-37 YNCHRONIZING ILES ITHOUT OMPARISON ........7-37 YNCHRONIZATION ETWEEN THE ANAGEMENT AND NTERFACE ODULES ......7-38 YNCHRONIZING THE NTERFACE ODULES MAGES URING OOTUP -viii © 2008 Foundry Networks, Inc. December 2008...
  • Page 9 U.S.A............................... A-1 ......................... A-1 NDUSTRY ANADA TATEMENT ........................... A-1 UROPE AND USTRALIA ..............................A-1 ERMANY ............................... A-2 APAN ..............................A-2 OREA PPENDIX ................B-1 AUTIONS AND ARNINGS ..............................B-1 AUTIONS .............................. B-11 ARNINGS December 2008 © 2008 Foundry Networks, Inc.

  • Page 10: Netiron Mlx

    Foundry NetIron MLX Series Installation and Basic Configuration Guide © 2008 Foundry Networks, Inc. December 2008...

  • Page 11: Chapter 1 Getting Started

    Getting Started Introduction This guide describes the NetIron MLX router from Foundry Networks. It provides procedures for installing modules into the NetIron MLX Series chassis, cabling the Ethernet interface ports, and performing a basic configuration of the software. This guide also explains how to perform tasks using the command line interface (CLI).

  • Page 12: How To Get Help Or Report Errors

    How to Get Help or Report Errors Foundry Networks is committed to ensuring that your investment in our products remains cost-effective. If you need assistance, or find errors in the manuals, contact Foundry Networks using one of the following options: Web Access If you find errors in this document, please report the error by going to kp.foundrynet.com.

  • Page 13: Chapter 2 Product Overview

    Service attack (DoS) on the data plane • Distributed data and control planes, which results in uncompromised wire-speed performance for the data plane and faster and more efficient performance of management functions for the control plane December 2008 © 2008 Foundry Networks, Inc.

  • Page 14: Netiron Mlx Series Router Applications

    The following sections provide more information about these components. Chassis The NetIron MLX Series chassis consists of the following four chassis: • NetIron MLX-4: Provides 4 interface slots • NetIron MLX-8: Provides 8 interface slots • NetIron MLX-16: Provides 16 interface slots •...
  • Page 15 Product Overview Figure 2.1 NetIron MLX-4 Chassis Interface Slot 2 Switch Fabric Slot 2 Switch Fabric ESD Connector Interface Slot 3 Slot 1 Switch Fabric Slot 1 Interface Slot 3 Management Slot 1 Management Interface Slot 2 Slot 4 Figure 2.2 NetIron MLX-8 Chassis...
  • Page 16 Slot 2 Interface Slot 2 Interface Slot 4 Interface Slot 6 Interface Slot 8 Switch Interface Interface Fabric Switch Interface Slot 16 Interface Slot 14 Slot 2 Fabric Slot 12 Slot 10 Slot 4 © 2008 Foundry Networks, Inc. December 2008...

  • Page 17: Product Overview

    DC OK DC OK DC OK Power Supply 5 Power Supply 8 AC OK AC OK AC OK AC OK DC OK DC OK DC OK DC OK Power Supply 6 Power Supply 7 December 2008 © 2008 Foundry Networks, Inc.

  • Page 18: Netiron Mlx-4

    In the slots of the chassis, you can install the following: • Up to two management modules (one active and one redundant). • Up to four switch fabric modules. • Up to sixteen interface modules. © 2008 Foundry Networks, Inc. December 2008...

  • Page 19: Netiron Mlx-32

    Before installing any modules or power supplies, you must remove the slot blank or blank power supply faceplate, respectively (NetIron MLX-4, -8, and 16). On the NetIron MLX-32, before installing any modules, you must remove the shipping panels covering the upper and lower card cages.

  • Page 20: Pcmcia Slots

    The NetIron MLX-32 chassis uses a different management module than any of the other Foundry Networks products. You cannot use management modules designed for the NetIron MLX-32 in any of the other NetIron MLX Series chassis or management modules in the NetIron MLX-32 chassis designed for the NetIron MLX-4, NetIron MLX-8, or NetIron MLX-16.

  • Page 21: Leds

    10/100/1000 Above and left On or blinking The port is transmitting and receiving packets. Ethernet Port of RJ-45 (Yellow) connector Off for an The port is not transmitting or receiving packets. extended period December 2008 © 2008 Foundry Networks, Inc.

  • Page 22: Interface Modules

    Foundry chassis in the NetIron MLX Series chassis, the module will not boot up to become active. Interface modules can be shared between NetIron MLX-4, NetIron MLX- 8, NetIron MLX-16, and NetIron MLX-32.
  • Page 23 Into a physical port, you must insert a fiber-optic transceiver provided by Foundry. The XFP-compliant fiber-optic modules provide an optical transceiver or physical medium-dependent (PMD) interface for single or multi-mode fiber that can be used with the LAN physical layer (PHY). December 2008 © 2008 Foundry Networks, Inc. 2-11...

  • Page 24: Fe/Gbe (100/1000) Ethernet Interface Module (Sfp)

    The port is transmitting and receiving Ethernet port packets. (Left-side LED Off for an extended The port is not transmitting or receiving supports port in period packets. top row while right-side LED supports port in bottom row) 2-12 © 2008 Foundry Networks, Inc. December 2008...
  • Page 25 This optic can only be connected to an E1MG-100BXU. E1MG-100FX-IR 100BaseFX-IR optic for SMF with LC connector. For distances up to 15nm. E1MG-100FX-LR 100BaseFX-LR SFP optic for SMF with LC connector. For distances up to 40km. December 2008 © 2008 Foundry Networks, Inc. 2-13...

  • Page 26: 10/100/1000 Ethernet Interface Module (Rj-45)

    RJ-45 connectors for each port. Cables and patch panels that support this module are available through any Tyco International distribution partner. Information about these products is available at the following URL: www.ampnetconnect.com/foundrynetworks 2-14 © 2008 Foundry Networks, Inc. December 2008...

  • Page 27: Pos Interface Modules

    4 LEDs per port that indicate the following port status: Active/Local Rail, TX Pkt, RX Pkt, and Carrier Rcvd / Remote Fail • 2 IN and 2 OUT RJ-48 connectors to provide an BITS external clock source and to propagate a common clock source (Line or BITS) among POS modules December 2008 © 2008 Foundry Networks, Inc. 2-15...

  • Page 28: Single -Speed

    4 LEDs per port that indicate the following port status: Active/Local Rail, TX Pkt, RX Pkt, and Carrier Rcvd / Remote Fail • 2 IN and 2 OUT RJ-48C connectors to provide an BITS external clock source and to propagate a common clock source (Line or BITS) among POS modules 2-16 © 2008 Foundry Networks, Inc. December 2008...

  • Page 29: Led Operation

    Green Port is enabled. • top position Port is enabled and their is a locally detected error condition. One LED per-port as defined by Port is disabled. column position December 2008 © 2008 Foundry Networks, Inc. 2-17...
  • Page 30 Supports POS OC-48 SR-1 up to 2 km over single-mode fiber (SMF), Hot- pluggable, Duplex LC Connector. OC48-SFP-IR1 Supports POS OC-48 IR-1 up to 15 km over single-mode fiber (SMF), Hot- pluggable, Duplex LC Connector. 2-18 © 2008 Foundry Networks, Inc. December 2008...

  • Page 31: Clocking And Timing A

    Packet Over SONET Modules" in the Foundry NetIron XMR/MLX Configuration Guide. Clocking Port Pin Assignments The Clocking ports are standard RJ-48C connectors. The BITS IN and BITS OUT connectors are configured differently as described in the following tables: December 2008 © 2008 Foundry Networks, Inc. 2-19...

  • Page 32: Switch Fabric Module

    Switch Fabric Module The following switch fabric modules are available for NetIron MLX Series routers: Part Number Description NI-X-SF1 NetIron MLX/XMR 4-slot system switch fabric module NI-X-SF3 NetIron MLX/XMR 8/16-slot system switch fabric module 2-20 © 2008 Foundry Networks, Inc. December 2008...
  • Page 33 • NetIron MLX-32: Accommodates and is shipped with eight switch fabric modules. NOTE: The switch fabric modules used for the NetIron MLX-4 are a different part than those used on the NetIron MLX-8, NetIron MLX-16, and NetIron MLX-32. Also, the switch fabric modules used for the NetIron MLX-32 are different than those used on the NetIron MLX-4, NetIron MLX-8, and NetIron MLX-16.

  • Page 34: Power Supplies

    In the NetIron MLX-8, NetIron MLX-16 and NetIron MLX-32, you install the power supplies (AC or DC) in the slots along the bottom of the chassis. In the NetIron MLX-4, the power supplies (AC or DC) are installed in slots in the rear of the chassis.

  • Page 35: Built-In Mounting Brackets

    As shown in Figure 2.13 and Figure 2.14, the fans are located in the front of the NetIron MLX-4 and NetIron MLX- 8 chassis.
  • Page 36 Foundry NetIron MLX Series Installation and Basic Configuration Guide Figure 2.14 Fan Component Locations for the NetIron MLX-8 Fan Module Figure 2.15 Front Fan Component Locations for the NetIron MLX-16 Front Fan Assembly 2-24 © 2008 Foundry Networks, Inc. December 2008...

  • Page 37: December 2008 © 2008 Foundry Networks, Inc

    Product Overview Figure 2.16 Rear Fan Component Locations for the NetIron MLX-16 Fan Modules December 2008 © 2008 Foundry Networks, Inc. 2-25...
  • Page 38 SNMP trap. The system can also shut the module down if the temperature exceeds the highest threshold. You can change default low and high temperature thresholds for modules and fan speeds. 2-26 © 2008 Foundry Networks, Inc. December 2008...

  • Page 39: Rack Mount Kit

    The NetIron MLX Series chassis are shipped equipped for mounting in a standard 19-inch (EIA310-D) rack as described: • The NetIron MLX-4 and NetIron MLX-8 are equipped with built-in mounting brackets. • The NetIron MLX-16 and NetIron MLX-32 chassis ship with two L-shaped mounting brackets.
  • Page 40 Foundry NetIron MLX Series Installation and Basic Configuration Guide 2-28 © 2008 Foundry Networks, Inc. December 2008...

  • Page 41: Installing A Netiron Mlx Series Router

    This chapter contains information on how to install a NetIron MLX Series router. Before proceeding, please read the cautions and warnings below that apply to the entire family of NetIron MLX Series routers. The remainder of this chapter contains the following topics: • “Installing a NetIron MLX-4 Router” • “Installing a NetIron MLX-8 Router” •...

  • Page 42: Power Precautions

    For NetIron MLX -8 and -4, use a grounding wire of at least 6 AWG. For the grounding lug, use UL- listed Panduit crimp connector, P/N LCD6-10A, and two 10-32, PPH screws to secure the crimp connector to chassis. The grounding position is located on the side of chassis adjacent ground symbol. © 2008 Foundry Networks, Inc. December 2008...
  • Page 43 The connector must be crimped with the proper tool, allowing it to be connected to both ground screws on the enclosure. Before crimping the ground wire into the provided ground lug, insure the bare copper wire has been cleaned and antioxidant is applied to the bare wire. December 2008 © 2008 Foundry Networks, Inc.

  • Page 44: Installing A Net Iron Mlx-4 R

    Bonding Network (IBN). It is not intended for Outside Plant installations (OSP). Unpacking a NetIron MLX-4 Router The NetIron MLX-4 router ships with several items. Review the list below, and verify the contents. If any items are missing, contact the place of purchase.

  • Page 45: Chassis Lifting Guidelines For Installing A Net Iron

    Removing NetIron MLX-4 Extra Shipment Screws The NetIron MLX-4 ships with two extra screws installed in the right side of the chassis. These screws secure the fan tray, protecting it from damage during shipment. You must remove these screws before installing the chassis.
  • Page 46 Figure 3.3. With two or more people lifting the chassis, slip the wide portion of each keyhole slot over the corresponding screw in the rack. Figure 3.3 Mounting the NetIron MLX-4 or NetIron MLX-8 Chassis in a Rack Standard 19-inch Rack Slide the chassis down so that the screw heads are in the narrow portion of the keyhole slots.

  • Page 47: Removing The Slotb

    Removing the Slot Blanks The NetIron MLX-4 chassis ships with slot blanks installed in all module slots. The slot blank covers a slot that does not currently have a module installed in it, ensuring proper airflow within the chassis. If you plan to install a module in a particular slot, you must remove the slot blank.
  • Page 48 Before installing a module in the NetIron MLX-4 chassis, have the following on hand: • An ESD wrist strap with a plug for connection to the ESD connector on the NetIron MLX-4 chassis. WARNING: For safety reasons, the ESD wrist strap should contain a 1 meg ohm series resistor.

  • Page 49: Installing Power Supplies In A

    AC power supplies from damage to excessive power line surges. At the rear of the NetIron MLX-4 chassis locate the power receptacle on the left side of the AC power supply. Lift the cord-retainer and connect a Foundry-supplied AC power cord to the power supply.

  • Page 50: Connecting Dc Power To A

    Connecting DC Power to a NetIron MLX-4 Chassis You can provide your own DC power source for the NetIron MLX-4 chassis. This is supported through use of a DC- to-DC power supply. DC power must be supplied at 48 V and 30 A. The DC-to-DC supply provides the DC power to the chassis at 12 V and 100 A.

  • Page 51: Final Steps

    DC return shall be isolated from the chassis ground (DC-I) when connections to the power supply are made. Final Steps Here are the final steps to complete in the order listed: • “Attaching a Management Station” • “Powering-On the Power Source” • “Verifying Proper Operation” December 2008 © 2008 Foundry Networks, Inc. 3-11...

  • Page 52: Installing A Net Iron Mlx-8 R

    Remove the strap that secures the shipping carton to the pallet. Remove the plastic cover and shipping carton. Save the shipping carton, pallet, and packing materials in case you need to move or ship the chassis at a later time. 3-12 © 2008 Foundry Networks, Inc. December 2008...

  • Page 53: Chassis Lifting Guidelines For Installing The Net Iron

    Determine the position of each chassis in the rack, for example, a chassis with the fewest modules on top, a chassis with more modules than the top chassis in the middle, and a fully populated chassis on the bottom. December 2008 © 2008 Foundry Networks, Inc. 3-13...
  • Page 54 Figure 3.11. With two or more people lifting the chassis, slip the wide portion of each keyhole slot over the corresponding screw in the rack. Figure 3.11 Mounting the NetIron MLX-4 or NetIron MLX-8 Chassis in a Rack Standard 19-inch Rack Slide the chassis down so that the screw heads are in the narrow portion of the keyhole slots.

  • Page 55: Odules

    Table 3.3: NetIron MLX-8 Module Installation NetIron MLX-8 Chassis Slot Number Module Management modules Active module – M1 (left). Redundant module – M2 (right). Interface modules 1 – 8 December 2008 © 2008 Foundry Networks, Inc. 3-15...

  • Page 56: Module

    Push the ejectors in until they are flush with the module front panel. This action will fully seat the module in the backplane. Modules have a snug fit for maximum EMI protection. 3-16 © 2008 Foundry Networks, Inc. December 2008...
  • Page 57 Chassis” on page 3-17, or “Connecting DC Power to a NetIron MLX-8 Chassis” on page 3-18. Connecting AC Power to a NetIron MLX-8 Chassis AC power is supplied through an AC power cord that is installed at the rear of the NetIron MLX-8 chassis. December 2008 © 2008 Foundry Networks, Inc. 3-17...
  • Page 58 WARNING: The procedure in this section is for qualified service personnel. To connect a DC power source, you must use the following directions: Use a flat-blade screwdriver to remove the two screws holding the transparent cover over the power supply lugs. 3-18 © 2008 Foundry Networks, Inc. December 2008...
  • Page 59 DC return shall be isolated from the chassis ground (DC-I) when connections to the power supply are made. Final Steps Here are the final steps that to complete in the order listed: • “Attaching a Management Station” • “Powering-On the Power Source” • “Verifying Proper Operation” December 2008 © 2008 Foundry Networks, Inc. 3-19...

  • Page 60: Mlx-16 R Outers

    Move the pallet to a staging area as close to the installation site as possible. Position the shipping carton with the arrows pointing up. Remove the strap that secures the shipping carton to the pallet. Remove the plastic cover and shipping carton. 3-20 © 2008 Foundry Networks, Inc. December 2008...
  • Page 61 Attach the mounting brackets to the sides of the chassis as illustrated in Figure 3.17. NOTE: The diagram shows locations for attaching the mounting brackets for either front-mount or mid-mount of the NetIron MLX-16 chassis. December 2008 © 2008 Foundry Networks, Inc. 3-21...
  • Page 62 Figure 3.18. With two or more people lifting the chassis, slip the wide portion of each keyhole slot over the corresponding screw in the rack. Figure 3.18 Mounting the NetIron MLX-16 or NetIron MLX-32 Chassis in a Rack 3-22 © 2008 Foundry Networks, Inc. December 2008...

  • Page 63: Hassis

    Table 3.4: NetIron MLX-16 Module Installation NetIron MLX-16 Chassis Slot Number Module Management modules Active module – M1 (upper). Redundant module – M2 (lower). December 2008 © 2008 Foundry Networks, Inc. 3-23...

  • Page 64: Hassis

    Push the ejectors in until they are flush with the module front panel. This action will fully seat the module in the backplane. Modules have a snug fit for maximum EMI protection. 3-24 © 2008 Foundry Networks, Inc. December 2008...

  • Page 65: Hassis

    Installing Power Supplies in a NetIron MLX-16 Chassis To install a power supply in a NetIron MLX-16 chassis, do the following: Remove the blank power supply faceplate, and expose the empty power supply slot. December 2008 © 2008 Foundry Networks, Inc. 3-25...
  • Page 66 At the rear of the NetIron MLX-16 chassis, locate the power receptacle where the power supplies have been installed. Lift the cord-retainer and connect a Foundry-supplied AC power cord to the power supply. Snap the cord-retainer over the power plug to hold it in place. 3-26 © 2008 Foundry Networks, Inc. December 2008...
  • Page 67 Use a flat-blade screwdriver to remove the two screws holding the transparent cover over the power supply lugs. Figure 3.22 The NetIron MLX-8 and NetIron MLX-16 DC Power Supply Screws Holding Power Lugs DC IN DC OUT ALM Screws Holding Screws Holding Transparent Cover Transparent Cover December 2008 © 2008 Foundry Networks, Inc. 3-27...
  • Page 68 DC return shall be isolated from the chassis ground (DC-I) when connections to the power supply are made. Final Steps Here are the final steps to complete in the order listed: • “Attaching a Management Station” • “Powering-On the Power Source” • “Verifying Proper Operation” 3-28 © 2008 Foundry Networks, Inc. December 2008...

  • Page 69: Rack"

    NOTE: You must provide standard #12-24 pan-head screws for mounting the NetIron MLX Series chassis into a rack. • Insertion/extraction tool for use with RJ-45 and fiber-optic connectors • CD-ROM containing software images and the user documentation (including this guide) • Warranty card December 2008 © 2008 Foundry Networks, Inc. 3-29...
  • Page 70 Figure 3.24. Remove the front shipping panel and set it aside. Figure 3.24 Removing Bolts and Screws on the NetIron MLX-32 Chassis 3-30 © 2008 Foundry Networks, Inc. December 2008...
  • Page 71 When positioning the chassis into the rack from the mechanical lift, use the hand pockets in the sides and back, and the lifting bar on the front of the chassis, and keep your back straight as you lift. To install a NetIron MLX-32 chassis, use the following procedure: December 2008 © 2008 Foundry Networks, Inc. 3-31...
  • Page 72 If you are installing the chassis in an open-frame rack, install eight standard #12-24 pan-head screws into each of the open mounting holes aligned with the rack, starting from the bottom. 3-32 © 2008 Foundry Networks, Inc. December 2008...
  • Page 73 Push the ejectors in until they are flush with the module front panel. This action will fully seat the module in the backplane. Modules have a snug fit for maximum EMI protection. December 2008 © 2008 Foundry Networks, Inc. 3-33...

  • Page 74: D Etails

    NOTE: Any empty slots must contain slot blanks to ensure proper air flow within the chassis. NOTE: During the initially installation of the modules into a NetIron MLX 3200, Foundry recommends inserting all the modules into the appropriate chassis slots before tightening the screws into the chassis. 3-34 © 2008 Foundry Networks, Inc. December 2008...
  • Page 75 Due to the high density of cables that the NetIron MLX-32 chassis can support, it may be difficult to insert and remove the RJ-45 and optical connectors. An insertion/extraction tool has been provided in the NetIron MLX-32 accessory kit to make this task easier. See Figure 3.28. December 2008 © 2008 Foundry Networks, Inc. 3-35...
  • Page 76 With the cable management lower cover swung open, the remaining modules in the lower half of the chassis follow a similar path downwards, above the power supplies. Figure 3.29 diagrams the cable routing, with the upper and lower covers removed for clarity. 3-36 © 2008 Foundry Networks, Inc. December 2008...
  • Page 77 Details of cable routing are as follows: CAUTION: Be sure not to exceed the minimum recommended bend radius for the cables: 2" for MRJ-21 cables, and 1.5" for Category 5 (RJ-45) and fiber-optic cables. December 2008 © 2008 Foundry Networks, Inc. 3-37...

  • Page 78: Uadrant

    Route slot cards #1 and #2 cables directly to the left through the side comb. See Figure 3.30. Figure 3.30 Routing Upper-left Quadrant Cables to the Left Uppe e Quad a Side combs (18) Cables from Slot #1 Cables from Slot #2 3-38 © 2008 Foundry Networks, Inc. December 2008...
  • Page 79 Route slot card #3 and #4 cables up through Comb A. See Figure 3.31. Route slot card #5 and #6 cables up through Comb B. Route slot card #7 and #8 cables up through Comb C. December 2008 © 2008 Foundry Networks, Inc. 3-39...

  • Page 80: Uadrant

    Route slot card #15 and #16 cables directly to the right through the side comb. See Figure 3.32. Figure 3.32 Routing Upper-right Quadrant Cables to the Right Upper Right Quadrant Side combs (18) Cables from Slot #15 Cables from Slot #16 3-40 © 2008 Foundry Networks, Inc. December 2008...
  • Page 81 Route slot card #13 and #14 cables up through Comb A. See Figure 3.33. Route slot card #11 and #12 cables up through Comb B. Route slot card #9 and #10 cables up through Comb C. December 2008 © 2008 Foundry Networks, Inc. 3-41...

  • Page 82: Q Uadrant

    Route slot card #18 and #17 cables directly to the left through the side comb. See Figure 3.34. Figure 3.34 Routing Lower-left Quadrant Cables to the Left Lower Left Quadrant Cables from Slot #17 Cables from Slot #18 Side combs (18) 3-42 © 2008 Foundry Networks, Inc. December 2008...
  • Page 83 Route slot card #20 and #19 cables down through Comb A. See Figure 3.35. Route slot card #22 and #21 cables down through Comb B. Route slot card #24 and #23 cables down through Comb C. December 2008 © 2008 Foundry Networks, Inc. 3-43...
  • Page 84 Route slot card #32 and #31 cables directly to the right through the side comb. See Figure 3.36. Figure 3.36 Routing the Lower-right Quadrant Cables to the Right Lower Right Quadrant Cables from Slot #31 Cables from Slot #32 Side combs (18) 3-44 © 2008 Foundry Networks, Inc. December 2008...

  • Page 85: Hassis

    NOTE: The 2400W AC and DC power supplies for the NetIron MLX-32 are new parts and will be released shortly. Please check with Foundry Networks for availability of these parts. To install a power supply in a NetIron MLX-32 chassis, do the following: Remove the blank power supply faceplate, and expose the empty power supply slot.

  • Page 86: Hassis

    Connecting AC Power to a NetIron MLX-32 Chassis AC power is supplied through an AC power cord that is installed in the front of each power supply in the NetIron MLX-32 chassis. 3-46 © 2008 Foundry Networks, Inc. December 2008...
  • Page 87 Use a Phillips head screwdriver to remove the center screw holding the safety cover over the power supply lugs. See Figure 3.39. Figure 3.40 Removing the center screw Center Screw Safety Cover Use a Phillips head screwdriver to unscrew each of the power lugs. See Figure 3.40. December 2008 © 2008 Foundry Networks, Inc. 3-47...
  • Page 88 #4 AWG Power Supply Wire Power lug Reconnect the power lugs to the power supply unit. Re-attach the safety cover over the power supply lugs that was removed in Step 1. See Figure 3.42. 3-48 © 2008 Foundry Networks, Inc. December 2008...

  • Page 89: Port Or Ethernet Port"

    “Attaching a PC or Terminal to the Console Port or Ethernet Port” on page 3-50. For information about connecting a management port to a network, see “Attaching the Management Module’s Ethernet Port to a Network” on page 3-50. December 2008 © 2008 Foundry Networks, Inc. 3-49...
  • Page 90 PC or terminal. You can order the serial cable separately from Foundry Networks or build your own cable. If you prefer to build your own, see the pinout information in “Console Port Pin Assignments” on page 8-5.

  • Page 91: Verifying Proper Operation

    If your power source is AC, attach one end of a Foundry-supplied AC power cord to the AC power supply as described in the appropriate section: • “Connecting AC Power to a NetIron MLX-4 Chassis” on page 3-9 • “Connecting AC Power to a NetIron MLX-8 Chassis” on page 3-17 •...
  • Page 92 You can do the following: • Make certain that the module is installed properly. For more information, see “Installing NetIron MLX-4 Modules” on page 3-7, “Installing NetIron MLX-8 Modules” on page 3- 15, “Installing NetIron MLX-16 Modules” on page 3-23, or “Installing NetIron MLX-32...
  • Page 93 You can do the following: • Make certain that the module is installed properly. For more information, see “Installing NetIron MLX-4 Modules” on page 3-7, “Installing NetIron MLX-8 Modules” on page 3- 15, “Installing NetIron MLX-16 Modules” on page 3-23, or “Installing NetIron MLX-32...
  • Page 94 You must replace the switch fabric module. For information about performing this task, see “Replacing a Switch Fabric Module” on page 6-8. 3-54 © 2008 Foundry Networks, Inc. December 2008...
  • Page 95 DC power to power to the chassis. If the DC IN the NetIron MLX LED is lit Green, then there is a Series chassis. problem with the power supply and it must be replaced. December 2008 © 2008 Foundry Networks, Inc. 3-55...
  • Page 96 Table 3.5: Desired and Abnormal LED States After System Power On (Continued) Desired State Meaning Abnormal Meaning/Action State The power supply is in Amber The power supply is normal operating malfunctioning. condition. 3-56 © 2008 Foundry Networks, Inc. December 2008...

  • Page 97: Displaying The Module Status

    PC or Terminal to the Console Port or Ethernet Port” on page 3-50, make sure the terminal emulation session is running on the same serial port you attached to the Console port. December 2008 © 2008 Foundry Networks, Inc. 3-57...
  • Page 98 For more information, see “Installing NetIron MLX-4 Modules” on page 3-7, “Installing NetIron MLX-8 Modules” on page 3-15, “Installing NetIron MLX-16 Modules” on page 3-23, or “Installing NetIron MLX-32 Modules” on page 3-33.

  • Page 99: Assigning Permanent Passwords

    NOTE: You cannot assign a password using the Web management interface. You can assign passwords using the IronView Network Manager if an Enable password for a Super User is already configured on the device. December 2008 © 2008 Foundry Networks, Inc.

  • Page 100: Configuring Ip Addresses

    Out of band/ In band Management interface Ethernet 10/100/1000 port on Out of band active or redundant management module Any interface over which Any interface module port In band user packets are routed © 2008 Foundry Networks, Inc. December 2008...

  • Page 101: Assigning An Ip Address To A Management Interface

    Privileged EXEC Level NetIron(config)# Global CONFIG Level Configure the IP address and mask for the management interface by entering the following commands: NetIron(config)# interface management 1 NetIron(config-if-mgmt-1)# ip address 10.0.1.1 255.255.255.0 Syntax: enable [<password>] December 2008 © 2008 Foundry Networks, Inc.
  • Page 102 Syntax: configure terminal Syntax: [no] ip address <ip-addr> <ip-mask> [secondary] Syntax: [no] ip address <ip-addr>/<mask-bits> [secondary] Use the secondary parameter if you have already configured an IP address within the same sub-net on the interface. © 2008 Foundry Networks, Inc. December 2008...

  • Page 103: Enabling And Disabling The Interfaces

    To connect a NetIron MLX Series router to another network device using a fiber port, do the following: • Install a fiber optic module (SFP transceiver or XFP as required by your interface module) December 2008 © 2008 Foundry Networks, Inc.

  • Page 104: Troubleshooting Network Connections

    Table 4.2 outlines the LEDs related to the network connections, the desired state of each LED, possible abnormal states of each LED, and what to do if an LED indicates an abnormal state. © 2008 Foundry Networks, Inc. December 2008...
  • Page 105 CLI. If you have configured an IP address on the device, you also can use the Web management interface or IronView Network Manager. If a problem persists after taking these actions, contact Foundry’s technical support. December 2008 © 2008 Foundry Networks, Inc.

  • Page 106: Testing Network Connectivity

    The CLI displays trace route information for each hop as soon as the information is received. Traceroute requests display all responses to a given TTL. In addition, if there are multiple equal-cost routes to the destination, the Foundry device displays up to three responses by default. © 2008 Foundry Networks, Inc. December 2008...
  • Page 107 Temperature readings of the management, switch fabric, interface, and fan control modules and the interval at which the system reads the temperature of these modules • MAC address of the NetIron MLX Series chassis December 2008 © 2008 Foundry Networks, Inc.
  • Page 108 LP4 Sensor3: UNUSED LP4 Sensor4: 38.5C LP4 Sensor5: 47.750C LP4 Sensor6: UNUSED Fans are in auto mode. Temperature Monitoring Poll Period is 60 seconds --- MISC INFO --- Backplane EEPROM MAC Address: 000c.dbf3.5500 © 2008 Foundry Networks, Inc. December 2008...
  • Page 109 The total power budget for the chassis minus the total power used by the system core and the interface modules currently installed. Slot Power-On Priority The configured power-on priority of each interface module installed in a chassis slot. December 2008 © 2008 Foundry Networks, Inc.
  • Page 110 The priority of each chassis slot as configured by the lp-slot-priority command. The priority can be 1 – 8, where 1 is the lowest priority and 8 is NetIron MLX-4: Slot1 – Slot4 the highest priority (the default priority is 1). If the supply of power to the NetIron MLX-8: Slot1 –...
  • Page 111 If multiple temperature warning messages are sent to the log, the latest one replaces the previous one. The static buffer is not configurable. December 2008 © 2008 Foundry Networks, Inc.

  • Page 112: Managing The Cooling System

    In general, each fan speed, except for low, has a low and high temperature threshold associated with it as shown in Figure 5.1. The low fan speed has a high temperature threshold only. © 2008 Foundry Networks, Inc. December 2008...
  • Page 113 SNMP trap. For information about viewing the warning messages, see “Displaying Temperature Warnings” on page 5-12. Table 5.3 outlines the default low and high temperature thresholds for each module and fan speed. December 2008 © 2008 Foundry Networks, Inc.
  • Page 114 Foundry establishes this guideline to ensure fan speed stability. For example, if you are changing the temperature thresholds for a management module’s high and medium-high fans speeds, the NetIron MLX Series system will accept the following values because the low temperature © 2008 Foundry Networks, Inc. December 2008...
  • Page 115 Displaying Temperature Thresholds for Modules and Fan Speeds To check the current settings of the low and high temperature thresholds for modules and fan speeds, you can enter the following command at any level of the CLI: December 2008 © 2008 Foundry Networks, Inc.
  • Page 116 Fan Speed Hi: 77 - 95 state = 0 (FAN_STATE_LOW) max_ts_shut_off_count = 1 shut_off_count = 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Syntax: show fan-threshold 5-10 © 2008 Foundry Networks, Inc. December 2008...

  • Page 117: Manually Setting The Fan Speed

    For the <fan-speed> parameter, you can specify the following: auto – The system is adjusted by the monitoring system. hi – The system sets the fan speed to high. low – The system sets the fan speed to low. December 2008 © 2008 Foundry Networks, Inc. 5-11...

  • Page 118: Monitoring The Cooling System

    This section describes how to view the system log. If you have configured the NetIron MLX Series system to use a Syslog server or SNMP trap receiver, see the documentation for the server or receiver. 5-12 © 2008 Foundry Networks, Inc. December 2008...

  • Page 119: Temperature Log Reduction

    Managing the Interface Modules This section contains the following information: • Configuring interface module boot parameters • Changing the priority of chassis slots for interface modules • Disabling and reenabling power to the interface modules December 2008 © 2008 Foundry Networks, Inc. 5-13...

  • Page 120: Configuring Interface Module Boot Parameters

    <slot-number> command at the Privileged EXEC prompt. • If you want to retain the Multi-Service IronWare images in the interface module’s flash memory, enter the lp 5-14 © 2008 Foundry Networks, Inc. December 2008...
  • Page 121 The <slot-number> parameter specifies the NetIron MLX Series chassis slot number that contains the interface module to which the immediate synchronization applies. You can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 – 32 for NetIron MLX-32.
  • Page 122 The <slot-number> parameter specifies the NetIron MLX chassis slot number that contains the interface module that will undergo an immediate boot. You can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 –...
  • Page 123 The <slot-number> parameter specifies the NetIron MLX Series chassis slot number that contains the interface module that will undergo an immediate boot. You can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 – 32 for NetIron MLX-32.
  • Page 124 MLX Series chassis or to an interface module in the specified chassis slot number only. You can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 – 32 for NetIron MLX-32.
  • Page 125 The <slot-number> parameter indicates that the chassis slot number for which you are changing the priority. You can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 – 32 for NetIron MLX-32.

  • Page 126: Displaying Cpu Usage

    2478 mpls mpls_glue bgp_io ospf ospf_r_calc isis isis_spf mcast msdp vrrp ripng ospf6 ospf6_rt mcast6 gvrp_mgr snmp rmon lacp dot1x dot1ag hw_access 1049 ospf_msg_task telnet_0 telnet_1 5-20 © 2008 Foundry Networks, Inc. December 2008...

  • Page 127: Displaying Management Module Cpu Usage

    A problem could exist If the CPU usage is distributed unevenly to one task, other than the idle task, for a prolonged period. If this situation occurs, contact Foundry’s technical support for assistance. Enabling and Disabling Packet Logging for Management and Interface December 2008 © 2008 Foundry Networks, Inc. 5-21...
  • Page 128 NetIron(config)# packet-logging 1 start 0 Syntax: packet-logging <slot-number> start <packet-direction> For the <slot-number> parameter, you can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 – 32 for NetIron MLX-32.
  • Page 129 Syntax: show packet-logging <slot-number> memory | flash pktlog.txt For the <slot-number> parameter, you can specify 1 – 4 for NetIron MLX-4, 1 – 8 for NetIron MLX-8, 1 – 16 for NetIron MLX-16, or 1 – 32 for NetIron MLX-32.

  • Page 130: Removing Mac Address Entries

    Use the module <slot> parameter to remove all MAC addresses for an interface module in a specified chassis slot. Use the vlan <number> parameter to remove all MAC addresses for a specified VLAN. 5-24 © 2008 Foundry Networks, Inc. December 2008...

  • Page 131: Hardware Maintenance Schedule

    Replacing the NetIron MLX Series air filters quarterly And replace the following hardware components as needed: • All modules (management, interface, and switch fabric) • Fiber-optic transceivers • AC or DC power supplies • Fan assemblies December 2008 © 2008 Foundry Networks, Inc.

  • Page 132: Replacing A Management Module

    To remove a management module from the NetIron MLX Series chassis, do the following: Put on the ESD wrist strap and ground yourself by inserting the plug into the ESD connector located on the front of the chassis. © 2008 Foundry Networks, Inc. December 2008...

  • Page 133: Replacing An Interface Module

    If hot removing or inserting a module, please allow a minimum of two seconds after a module (or power supply or fan tray) has been removed before inserting a module in the same slot. December 2008 © 2008 Foundry Networks, Inc.

  • Page 134: Removing An Interface Module

    CAUTION: If you do not install a module in a slot, you must keep the slot panel in place. If you run the chas- sis with an uncovered slot, the system may overheat. Installing a New Interface Module You can install a new interface module while the NetIron MLX Series chassis is powered on and running. © 2008 Foundry Networks, Inc. December 2008...
  • Page 135 Go to config mode and turn off the module for interactive mode: NetIron(config)# no lp boot system interactive <slot number> 10. Exit config mode and reboot the module: NetIron# power-off lp <slot number> NetIron# power-on lp <slot number> December 2008 © 2008 Foundry Networks, Inc.
  • Page 136 Foundry NetIron MLX Series Installation and Basic Configuration Guide Figure 6.2 Installing a Module in a NetIron MLX-4 Chassis Interface Module Figure 6.3 Installing a Module in a NetIron MLX-8 Chassis Interface Module © 2008 Foundry Networks, Inc. December 2008...
  • Page 137 Maintaining a NetIron MLX Series Router Figure 6.4 Installing a Module in a NetIron MLX-16 Chassis Interface Module Figure 6.5 Installing a Module in a NetIron MLX-32 Chassis December 2008 © 2008 Foundry Networks, Inc.

  • Page 138: Replacing A Switch Fabric Module

    Disable the module by entering the power-off snm <slot-number> command at the Privileged EXEC level of the CLI. For the <slot-number> parameter, specify 1 - 3 for NetIron MLX-4, 1 - 3 for NetIron MLX-8, 1 - 4 for NetIron MLX-16, or 1 - 8 for NetIron MLX-32.
  • Page 139 You can install a new fiber-optic transceiver in a 10 Gigabit Ethernet port while the NetIron MLX Series chassis is powered on and running. Before installing one of these transceivers into the port, have the following on hand: December 2008 © 2008 Foundry Networks, Inc.
  • Page 140 You can replace a power supply while the NetIron MLX Series chassis is powered on and running. The power supplies (AC or DC) are located in slots along the bottom of the NetIron MLX-32, NetIron MLX-16 and NetIron MLX-8 chassis and in the rear of the NetIron MLX-4 chassis. CAUTION: If hot removing or inserting a module, please allow a minimum of two seconds after a module (or power supply or fan tray) has been removed before inserting a module in the same slot.

  • Page 141: Clearing Power Supply Failure Timestamps

    The current configured power supply monitoring threshold value is also displayed at the end of the output. Syntax: show power-supply-monitoring Enabling a Power Supply Shutdown The power-off power-supply command allows you to shutdown a power supply manually. December 2008 © 2008 Foundry Networks, Inc. 6-11...

  • Page 142: Powering On The Power Supply Through The Cli

    Disconnect the power cables from the power supply. In the NetIron MLX-4, use the screwdriver to loosen the two screws on both sides of the power supply front panel. Then pull the ejectors forward until the power supply is pulled from its connection to the backplane.
  • Page 143 Gently pull the handle on the power supply front panel upward and toward the top of the power supply front panel. This action locks the power supply in place. 10. In the NetIron MLX-4, use the screwdriver to secure the two screws on either side of the power supply front panel.

  • Page 144: Replacing Fan Assemblies

    “Replacing Fan Assemblies in the NetIron MLX-16” on page 6-15 • “Replacing the Fan Tray Assembly in the NetIron MLX-4 and NetIron MLX-8” on page 6-17 You can replace a fan or a fan control module while the NetIron MLX Series chassis is powered on and running.
  • Page 145 The NetIron MLX-16 has three fan assemblies: one accessible from the front of the chassis and two accessible from the rear. The front assembly pushes air into the chassis and the rear fans pull air out. December 2008 © 2008 Foundry Networks, Inc. 6-15...
  • Page 146 Pushing the assembly in seats the fan connector with the chassis connector. Secure the fan assembly to the chassis by tightening the four captive screws. Access the CLI, and enter the show chassis command to verify that both fans are operating normally. 6-16 © 2008 Foundry Networks, Inc. December 2008...
  • Page 147 Replacing the Fan Tray Assembly in the NetIron MLX-4 and NetIron MLX-8 The NetIron MLX-4 and NetIron MLX-8 have a fan tray assembly accessible from the front of the chassis. The fan tray assembly pulls air out of the chassis.
  • Page 148 Foundry NetIron MLX Series Installation and Basic Configuration Guide You can remove and replace a fan tray assembly while the NetIron MLX-4 or NetIron MLX-8 chassis is powered on and running. To replace a fan tray assembly, you need the following: •...
  • Page 149 “Replacing the Air Filter in the NetIron MLX-16” • “Replacing the Air Filter in the NetIron MLX-4 or NetIron MLX-8” Replacing the Air Filters in the NetIron MLX-32 The two air filters in the NetIron MLX-32 chassis are located between the upper and lower card cages. To replace...
  • Page 150 Insert a new filter, being careful that it aligns within the narrow channel. Repeat steps 2-3 with the second filter. Replace the air inlet cover and screw in the four captive screws until they are securely attached to the chassis. 6-20 © 2008 Foundry Networks, Inc. December 2008...
  • Page 151 Pull the filter retainer away from the chassis as shown in Figure 6.14. There is a hook on the back of the retainer that is attached to the grab-strap. As you pull the retainer out, the filter is pulled along with it. December 2008 © 2008 Foundry Networks, Inc. 6-21...
  • Page 152 Push the filter retainer into the chassis and tighten the two screws. Replacing the Air Filter in the NetIron MLX-4 or NetIron MLX-8 To replace the air filter in the NetIron MLX-4 or NetIron MLX-8, do the following: Loosen the two screws in the front of the filter retainer.
  • Page 153 Maintaining a NetIron MLX Series Router Figure 6.15 Air Filter Removal and Replacement for NetIron MLX-4 Direction Airflow in Chassis Filter Filter Retainer Fan Tray Figure 6.16 Air Filter Removal and Replacement for NetIron MLX-8 Direction Airflow in Chassis Filter...
  • Page 154 Foundry NetIron MLX Series Installation and Basic Configuration Guide 6-24 © 2008 Foundry Networks, Inc. December 2008...
  • Page 155 The images required are described in Table 7.1. Table 7.1: Software Image Files Module Image Type Image Name Management Module Monitor xmb<xxxxx> NetIron MLX-4, -8, -16 Boot xmprm<xxxxx> IronWare xmr<xxxxx> FPGA mbridge Management Module Monitor xmb<xxxxx>...
  • Page 156 Switch Fabric Module FPGA SBRIDGE NetIron MLX-4, -8, -16, - 32 NOTE: In reference to Table 7.1, the image file names, such as <xxxxx> specify a variable that is release- specific information. Specific contents of this field are determined by release and are available in the relevant release notes.
  • Page 157 03.5.00 as described in Table 7.2. Because the functions that are most likely to change are now contained within the IronWare image, updates from version 03.5.00 to later versions will usually only require updating the IronWare image. December 2008 © 2008 Foundry Networks, Inc.
  • Page 158 Use the procedures described in “Upgrading the Interface Module’s Monitor and Boot Images” on page 7-17. Upgrade the interface module’s IronWare image. Use the procedures described in “Upgrading the Interface Module’s IronWare Image” on page 7-18. If required for this release, upgrade the managment module’s MBRIDGE FPGA image. © 2008 Foundry Networks, Inc. December 2008...
  • Page 159 Use the procedures described in “Displaying Flash Memory and Version Information” on page 7-6. Using this procedure you can determine the images currently installed. In particular, you should compare the list of FPGAs installed against the information in the relevant Multi-Service IronWare release notes. December 2008 © 2008 Foundry Networks, Inc.
  • Page 160 Compiled on Jul 12 2007 at 18:02:12 labeled as xmr03500b1 o LP Kernel Image (Monitor for LP Image Type 0) Version 3.5.0T175, Size 387125 bytes, Check Sum 27dd Compiled on Jul 10 2007 at 19:15:06 labeled as xmlb03500 © 2008 Foundry Networks, Inc. December 2008...
  • Page 161 Compiled on Jul 10 2007 at 19:14:32 labeled as xmlprm03500 FPGA Version (Stored In Flash): Valid PBIF Version = 2.11, Build Time = 4/3/2007 13:0:00 Valid XPP Version = 3.11, Build Time = 5/14/2007 14:22:00 December 2008 © 2008 Foundry Networks, Inc.
  • Page 162 Check sum – A unique ID for the image. If the contents of the image change, the check sum changes also. • Compilation date and time – The date and time that Foundry compiled the image. © 2008 Foundry Networks, Inc. December 2008...
  • Page 163 • Modification date and time – Date and time that the startup configuration was last saved. Boot Flash The model number and size of the management module’s boot flash. December 2008 © 2008 Foundry Networks, Inc.
  • Page 164 • Compilation date and time – The date and time that Foundry compiled the image. Boot Flash The model number and size of the interface module’s boot flash. 7-10 © 2008 Foundry Networks, Inc. December 2008...
  • Page 165 NI-X-SF Switch Fabric Module 1 (Serial #: Not Exist, Part #: Not Exist) FE 1: Type fe200, Version 2 NI-X-SF Switch Fabric Module 3 (Serial #: PR25050068, Part #: 31548-100A) FE 1: Type fe200, Version 2 December 2008 © 2008 Foundry Networks, Inc. 7-11...
  • Page 166 : Version 3.5.0T165 Copyright (c) 1996-2007 Foundry Networks, Inc. Compiled on Jul 10 2007 at 19:13:00 labeled as xmb03500 (424476 bytes) from code flash IronWare : Version 3.5.0T163 Copyright (c) 1996-2007 Foundry Networks, Inc. Compiled on Jul 19 2007 at 19:02:20 labeled as xmr03500 (5834918 bytes) from Primary...
  • Page 167 : Version 3.5.0dT165 Copyright (c) 1996-2007 Foundry Networks, Inc. Compiled on Dec 28 2007 at 11:04:34 labeled as xmb03500d (422393 bytes) from code flash IronWare : Version 3.8.0T163 Copyright (c) 1996-2007 Foundry Networks, Inc. Compiled on Mar 27 2008 at 07:23:18 labeled as xmr03800b208 (6223678 bytes) from Primary...
  • Page 168 : Version 3.5.0dT175 Copyright (c) 1996-2007 Foundry Networks, Inc. Compiled on Dec 28 2007 at 11:05:54 labeled as xmlb03500d (387229 bytes) from code flash IronWare : Version 3.8.0T177 Copyright (c) 1996-2007 Foundry Networks, Inc. Compiled on Mar 27 2008 at 07:57:28 labeled as xmlp03800b208 (3301300 bytes) from Primary FPGA versions: Valid PBIF Version = 3.04, Build Time = 1/23/2008 15:50:00...
  • Page 169 Directory of /flash/ 08/31/1908 13:26:14 3 $$snmp_boots 08/06/2008 03:42:12 705 $$sshdsspub.key 07/30/2008 10:21:56 1,712 $$sslcert.key 08/09/2008 09:03:14 980,769 IMF.cfg 08/10/2008 12:49:09 981,804 IMF1.cfg 08/16/1908 06:38:47 2,663,857 ___mbridge 08/15/1908 09:21:34 2,663,857 ___mbridge.old <<<<<<<<<<<<< December 2008 © 2008 Foundry Networks, Inc. 7-15...
  • Page 170 Once you have deleted the file and noted the available bytes free, execute the switchover command again to make the original Management module the active one. You can now follow the procedures to upgrade the Multi-Service IronWare. 7-16 © 2008 Foundry Networks, Inc. December 2008...
  • Page 171 Copies the latest boot image from the TFTP server boot all | <slot-number> to all interface modules or to the specified interface module (slot-number). For information about the image name to specify, see Table 7.1. December 2008 © 2008 Foundry Networks, Inc. 7-17...
  • Page 172 The combined image never upgrades an FPGA. If an FPGA upgrade is required for a release, you must use the copy tftp lp command to download the new FPGA image to the interface module as described for earlier releases. 7-18 © 2008 Foundry Networks, Inc. December 2008...
  • Page 173 Reboot the management module upon which you upgraded the MBRIDGE images. Determining the MBRIDGE Image Versions To display the versions of the MBRIDGE images currently installed on the Gigabit Ethernet modules, enter the show version command at any level of the CLI: December 2008 © 2008 Foundry Networks, Inc. 7-19...
  • Page 174 : Version 3.0.0T145 Copyright (c) 1996-2003 Foundry Networks, Inc. Compiled on Sep 2 2005 at 07:29:12 labeled as xmb03000 (336710 bytes) from code flash IronWare : Version 3.0.0T143 Copyright (c) 1996-2003 Foundry Networks, Inc. Compiled on Sep 2 2005 at 07:27:21 labeled as xmr03000 (6054708 bytes) from Primary...
  • Page 175 Version 3.5.0dT165, Size 422393 bytes, Check Sum 310f Compiled on Dec 28 2007 at 11:04:34 labeled as xmb03500d o Startup Configuration Size 2086 bytes, Check Sum 613f Modified on 12:05:03 GMT+00 Fri Mar 21 2008 December 2008 © 2008 Foundry Networks, Inc. 7-21...
  • Page 176 17, XPP version 112.18, and XGMAC version 83 installed. Beginning with version 3.8.00, the show flash command is enhanced to display the management modules or a specified line card, as shown in the following: 7-22 © 2008 Foundry Networks, Inc. December 2008...
  • Page 177 Boot Flash - Type AM29LV040B, Size 512 KB o Boot Image Version 3.5.0T165, Size 424484 bytes, Check Sum b751 Compiled on Jul 10 2007 at 19:13:56 labeled as xmprm03500 All show flash done December 2008 © 2008 Foundry Networks, Inc. 7-23...
  • Page 178 WARNING: You must use an FPGA images that is specified for the NetIron MLX Series or NetIron MLX Series routers. Use of FPGA images intended for other product will render your chassis inoperable. To upgrade one or more FPGA images on an Ethernet Interface module, perform the following steps: 7-24 © 2008 Foundry Networks, Inc. December 2008...
  • Page 179 | slot2 lp <image-name> fpga-stats all [<module-type>] • copy slot1 | slot2 lp <image-name> fpga-stats <chassis-slot-number> If you specify the module-type (for example, 4x10g), the router copies the STATS images for that particular December 2008 © 2008 Foundry Networks, Inc. 7-25...
  • Page 180 If you want to retain the IronWare images in the interface module’s code flash, enter the lp cont-boot no- sync <slot-number> command at the Privileged EXEC prompt. After the management module finishes booting, do the following: 7-26 © 2008 Foundry Networks, Inc. December 2008...
  • Page 181 Traffic Policing • UDLD • LACP • The following features are not supported by Hitless OS upgrade: • All MPLS Features • IPv4 and IPv6 Multicast • VLAN Translation • Policy-based Routing December 2008 © 2008 Foundry Networks, Inc. 7-27...
  • Page 182 This makes it necessary to have a connection to the console interface on both management modules. • Upon being reset, the management and interface module CPUs are unable to send and receive any packets. 7-28 © 2008 Foundry Networks, Inc. December 2008...
  • Page 183 Figure 7.1 provides a detailed diagram of the Hitless reload process. December 2008 © 2008 Foundry Networks, Inc. 7-29...
  • Page 184 MP Sync Done SW info request/acknowledge Switchover Reset MP Sync Done LP SW info reset Reset LP module up Reset LP module L2, L3, L4 done? LP module L2, L3, L4 done response 7-30 © 2008 Foundry Networks, Inc. December 2008...
  • Page 185 CLI prompt. Each device can have one startup configuration file and one running configuration. The startup configuration file is shared by both flash modules. The running configuration resides in DRAM. December 2008 © 2008 Foundry Networks, Inc. 7-31...
  • Page 186 NetIron# reload When the system detects differences between the running and startup configurations, it prompts you as follows: Are you sure? (enter ‘y’ or ‘n’): Enter y, and press the Enter key. 7-32 © 2008 Foundry Networks, Inc. December 2008...
  • Page 187 Do not load port configuration information for secondary ports in a trunk group. Since all ports in a trunk group use the port configuration settings of the primary port in the group, the software cannot implement the December 2008 © 2008 Foundry Networks, Inc. 7-33...
  • Page 188 “no” in front of the ip address command, then add the new address. Otherwise, the CLI displays an error message and does not implement the command. Here is an example: 7-34 © 2008 Foundry Networks, Inc. December 2008...
  • Page 189 From a management station, send the following SNMP PDU to the agent: SnmpSet (1.3.6.1.4.1.1191.1.1.2.1.5.0 = <tftp-ip-address> 1.3.6.1.4.1.1991.1.1.2.1.8.0 = <config-file-name> 1.3.6.1.4.1.1991.1.1.2.1.9.0 = <command-integer> where: <tftp-ip-addr> is the TFTP server’s IP address. <config-file-name> is the configuration file name. December 2008 © 2008 Foundry Networks, Inc. 7-35...
  • Page 190 When you save changes to the system-config file on the active module, the active module automatically synchronizes (without comparison) the standby module’s system-config file with its own. 7-36 © 2008 Foundry Networks, Inc. December 2008...
  • Page 191 IronWare images on one or all interface modules. • You want to disable synchronization; for example, you have upgraded the IronWare image of one interface module but want to continue running the older image on all other interface modules. December 2008 © 2008 Foundry Networks, Inc. 7-37...
  • Page 192 Reloading After a Specific Amount of Time To schedule a system reload to occur after a specific amount of time has passed on the system clock, use one of the following methods. 7-38 © 2008 Foundry Networks, Inc. December 2008...
  • Page 193 CLI command at the Privileged EXEC level to erase the image in the flash.) If you are copying a configuration file to flash, edit the file to remove unneeded information, then try again. December 2008 © 2008 Foundry Networks, Inc. 7-39...
  • Page 194 Correct the error, then retry the transfer. TFTP remote - disk full. TFTP remote - illegal operation. TFTP remote - unknown transfer ID. TFTP remote - file already exists. TFTP remote - no such user. 7-40 © 2008 Foundry Networks, Inc. December 2008...
  • Page 195 This section contains the following hardware specifications for the NetIron MLX Series chassis: • “Power Specifications” • “Physical Dimensions” • “Operating Environment” • “Storage Environment” • “Safety Agency Approvals” Power Specifications This section contains the power specifications for the NetIron MLX Series chassis. December 2008 © 2008 Foundry Networks, Inc.
  • Page 196 Table 8.4: Wattage Consumed by Individual Components Module Maximum Power Consumption, in Watts Management (NetIron MLX-4, NetIron MLX-8 and NetIron MLX-16) Management (NetIron MLX-32) Switch Fabric NI-X-SF1 4-slot switch fabric module (NetIron MLX-4, NetIron MLX-8 and NetIron MLX-16) © 2008 Foundry Networks, Inc. December 2008...

  • Page 197: Physical Dimensions

    Hardware Specifications Table 8.4: Wattage Consumed by Individual Components Module Maximum Power Consumption, in Watts NI-X-SF3 8/16-slot switch fabric module (NetIron MLX-4, NetIron MLX-8 and NetIron MLX-16) NI-X-32-SF 32-slot switch fabric module (NetIron MLX-32) 1-port POS OC192 125W 2-port POS OC192...

  • Page 198: Operating Environment

    EN 55022 (CE mark) (Class A) • EN55024 (CE mark) (Immunity) for Information Technology Equipment • ICES-003 (Canada) (Class A) • AS/NZ 55022 (Australia) (Class A) • VCCI (Japan) (Class A) • EN 61000-3-2 • EN 61000-3-3 © 2008 Foundry Networks, Inc. December 2008...

  • Page 199: Port Specifications

    Figure 8.2 Console Port Pin Assignments Showing Cable Connection Options to a Terminal or PC DB-9 to DB-9 DB-9 to DB-25 Female Switch Terminal or PC Female Switch Terminal or PC Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved December 2008 © 2008 Foundry Networks, Inc.

  • Page 200: Management Port Pin Assignments

    “10/100/1000 Ethernet Port” on page 2-8. Table 8.8: Management Port Pin Assignments Pin Number MDI-X Ports Not used (10BaseT) CMT (100BaseTX) Not used (10BaseT) CMT (100BaseTX) Not used (10BaseT) CMT (100BaseTX) Not used (10BaseT) CMT (100BaseTX) © 2008 Foundry Networks, Inc. December 2008...

  • Page 201: Regulatory Statements

    Machine noise information regulation - 3. GPSGV, the highest sound pressure level value is 88.4 dB(A) in accordance with EN ISO 7779. Maschinenlärminformations-Verordnung - 3. GPSGV, der höchste Schalldruckpegel beträgt 88.4 dB(A) gemäss EN ISO 7779. December 2008 © 2008 Foundry Networks, Inc.
  • Page 202 This apparatus has radio wave acceptability registration as a Class A device, so sellers or users should be aware of this. If it is sold or purchased incorrectly, it should be exchanged with a home apparatus (Class B). © 2008 Foundry Networks, Inc. December 2008...

  • Page 203: Cautions And Warnings

    CAUTION: All devices with DC power supplies (NetIron MLX-4, -8, -16, and -32) are intended for installation in restricted access areas only. A restricted access area is where access can be gained only by service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for the location.
  • Page 204 CAUTION: For a DC system (NetIron MLX-4, -8, and -16), use a grounding wire of at least 6 American Wire Gauge (AWG). The 6 AWG wire should be attached to an agency- approved crimp connector (provided on the NetIron MLX-16 chassis), crimped with the proper tool.
  • Page 205 CAUTION: Carefully follow the mechanical guides on each side of the power supply slot and make sure the power supply is properly inserted in the guides. Never insert the power supply upside down. December 2008 © 2008 Foundry Networks, Inc.
  • Page 206 (amp) ratings of all devices installed on the same circuit as the device. Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. © 2008 Foundry Networks, Inc. December 2008...
  • Page 207 Al formatear una tarjeta flash todos los archivos de ésta se borran. CAUTION: Never leave tools inside the chassis. VORSICHT: Lassen Sie keine Werkzeuge im Chassis zurück. MISE EN GARDE: Ne laissez jamais d'outils à l'intérieur du châssis. December 2008 © 2008 Foundry Networks, Inc.
  • Page 208 (escribir memoria) para guardar la configuración en ejecución en el archivo startup- config. CAUTION: Removal of NetIron MLX-32 rear fan modules allows access to bus bars and backplane. Avoid contact with these parts. There are hazardous energy levels at these locations. © 2008 Foundry Networks, Inc. December 2008...
  • Page 209 PRECAUCIÓN: Use un circuito derivado separado para cada cordón de alimentación de CA, con lo que se proporcionará redundancia en caso de que uno de los circuitos falle. December 2008 © 2008 Foundry Networks, Inc.
  • Page 210 MLX-32 uniquement) sont destinés à être installés uniquement dans des zones à accès réglementé. Une zone à accès réglementé est une zone dont l'accès n'est possible qu'au personnel de service utilisant un verrou, une clé ou un outil spécial, ou d'autres moyens de sécurité. © 2008 Foundry Networks, Inc. December 2008...
  • Page 211 If hot removing or inserting a module, please allow a minimum of two seconds after a module (or power supply or fan tray) has been removed before inserting a module in the same slot. December 2008 © 2008 Foundry Networks, Inc.
  • Page 212 (o la fuente de alimentación o la bandeja del ventilador) antes de introducir un módulo en la misma ranura. B-10 © 2008 Foundry Networks, Inc. December 2008...
  • Page 213 être isolées de tout câblage exposé à l'extérieur. L'ajout de dispositifs de protection primaire n'offre pas une protection suffisante pour permettre de raccorder par contact métallique ces interfaces à un câblage ou une installation en extérieur. December 2008 © 2008 Foundry Networks, Inc. B-11...
  • Page 214 Cette marque vous assure que vous pouvez utiliser le cordon d'alimentation avec le dispositif en toute sécurité. B-12 © 2008 Foundry Networks, Inc. December 2008...
  • Page 215 Ponga el instrumento más pesado en la parte inferior y los instrumentos progresivamente más livianos más arriba. WARNING: For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor. December 2008 © 2008 Foundry Networks, Inc. B-13...
  • Page 216 Foundry recommends that you disconnect a power supply from its power source before removing and replacing the supply. The NetIron MLX-4, -8, or -16 chassis can be running while a power supply is being removed and replaced, but the power supply itself should not be connected to a power source.
  • Page 217 POUR SOULEVER, MANIPULER OU MONTER CES ÉQUIPEMENTS, DEUX PERSONNES AU MINIMUM SONT NÉCESSAIRES. ADVERTENCIA: Un chasis NetIron MLX-4, -8, ó -16 muy concurrido es muy pesado. SE REQUIEREN DOS O MÁS PERSONAS CUANDO SE VAYA A ALZAR, MANEJAR O MONTAR ESTE DISPOSITIVO.
  • Page 218 Pour éviter d’endommager le châssis et les composants, ne jamais tenter de soulever le châssis par les poignées du ventilateur ou de l’alimentation. Ces poignées n’ont pas été conçues pour supporter le poids du châssis. B-16 © 2008 Foundry Networks, Inc. December 2008...
  • Page 219 Les ports marqués BITS1, BITS2 sont des circuits de sécurité à très basse tension (SELV). Ces circuits doivent uniquement être connectés à d’autres circuits SELV. Tous les équipements interconnectés via ces ports doivent se trouver dans le même bâtiment que l’unité. December 2008 © 2008 Foundry Networks, Inc. B-17...
  • Page 220 (SELV, por sus siglas en inglés). Los circuitos SELV sólo deben conectarse a otros circuitos SELV. Todos los equipos interconectados deben estar situados en el mismo edificio que la unidad. B-18 © 2008 Foundry Networks, Inc. December 2008...

This manual is also suitable for:

Netiron mlx-8Netiron mlx-16Netiron mlx-32

Table of Contents
