Summary of Contents for Soutwest Microwave MicroWave 330
- Page 1 Southwest Microwave, Inc. Security Systems Division INTREPID™ MicroWave 330 A DIGITAL MICOWAVE OUTDOOR PERIMETER INTRUSION DETECTION SYSTEM MicroWave 330 Installation and Operation Manual Version 0...
- Page 2 Copyright 1995 and 2012 Southwest Microwave, Inc. All rights Reserved. FCC Notice MicroWave 330 is classified as a field disturbance sensor. This device complies with FCC Rules Part 15.245. Operation is subject to the following two conditions: This device may not cause harmful interference and this device must accept interference received, including interference that may cause undesired operation.
- Page 3 INTREPID™ MicroWave 330 Software Southwest Microwave, Inc. thanks you for your purchase of the INTREPID MicroWave 330 Digital Microwave Intrusion Link. Please refer to the Universal Installation Service Tool II (UIST II) for the software setup of this sensor. . It is called:...
-
Page 4: Table Of Contents
3.3.1 High Security Overlaps ........................9 Transmitter Block Diagram ........................9 Receiver Block Diagram ........................10 Specifications ............................11 Installation Instructions .......................... 13 Location of MicroWave 330 ....................... 13 4.1.1 Required Area ..........................13 4.1.2 Terrain ............................14 4.1.2.1 Terrain in High Security Applications ..................14 4.1.3... -
Page 5: Introduction
22 or 24 gauge stranded shielded twisted pair wire (max 5,000 feet [1,500m] between devices) or with fiber optic devices. The address of each MicroWave 330 is set by a dip switch on the receiver circuit board. -
Page 6: Optional Power Supplies
MicroWave 330 will alarm on average sized humans walking, running or crawling on hands and knees through the detection pattern. Field adjustments can provide alarm on larger or smaller targets, depending on the specific site requirements. -
Page 7: Range Of Operation
3.2 Range of Operation A single MicroWave 330 may cover a distance of 800 feet (244m). The receiver is equipped with automatic gain control (AGC), which automatically adjusts receiver for the distance to be covered and sets the Path Fault parameter. -
Page 8: Overlaps
Vertical protection pattern will also depend upon Transmitter-Receiver distance, mounting height and “Sensitivity” setting. Actual patterns will vary somewhat with site topography and surface condition. Typical pattern height is 50 to 75% of pattern width. Approximate vertical protection pattern is shown in Figure 5. For example, at 50 feet (15m) with minimum sensitivity the pattern height is 5 feet (1.5m). -
Page 9: High Security Overlaps
High security applications also use stacked link configurations to meet site requirements. A stacked link may consist of two or more MicroWave 330 links or used in combination with the Model 300B link which operates at X-band frequency of 10.525 GHz. A stacked link greatly reduces the dead zone and increases PD. -
Page 10: Receiver Block Diagram
PS (ADC) ∫ Secure CPLD Level VCXO Shift 18.432 MHz Reset Watchdog Power Supply Wrong Channel 10.5-60VDC RS232 Configuration Channel Sync Port Com 1 Com 2 Modulation RS422 RS422 Alarm Alarm Network Network Figure 9 – MicroWave 330 Receiver Version 0... -
Page 11: Specifications
MicroWave 330R Receiver RF Assembly consists of a parabolic antenna (identical to antenna of Transmitter) and a Schottky diode detector. The detector converts modulated K-band energy from Transmitter into a low frequency signal for processing by Receiver Circuit Board. The received audio signal is amplified by an automatic gain control (AGC) preamplifier enabling the preamplifier output to be held to a constant level regardless of Transmitter Receiver distance (distance must be within maximum distance of link). - Page 12 Automatic Gain Control: Link automatically adjusts to slow changes in path loss due to environment. AGC range: -60dB. Cross Modulation: When installed in accordance with following installation instructions cross modulation (interference) from adjacent links will be 25dB below primary signal. 3.0 Transmittal Signal Radiated Power: 33Bm peak EIRP (maximum), square wave modulated.
-
Page 13: Installation Instructions
4.1.1 Required Area MicroWave 330 must be located in an area which is free of obstructions and moving objects such as chain link fences parallel to the detection field, trees, bushes and large areas of water as shown in Figure 11. Large moving objects within the protection pattern will be indistinguishable from an intruder and will cause nuisance alarms. -
Page 14: Terrain
If there is grass or vegetation in the protected area it must be kept cut to a maximum of three (3) inches (8cm) in Snow accumulation should not exceed three (3) inches (8cm) in height. height. MicroWave 330 should not be operated over open water. 4.1.2.1 Terrain in High Security Applications For maximum-security applications where detection of prone “commando style”... -
Page 15: Physical Protection
Choose the location that will provide best security, yet be free from false nuisance alarms. Always locate MicroWave 330 inside a controlled access area to prevent unwanted nuisance alarms due to random foot traffic, vehicles, or large animals. Typically, units should be mounted 2 ½ to 3 feet (0.76-0.91m) above ground level, and far enough inside fence to provide a clear area of protection as shown in Figures 14 &... -
Page 16: Mounting Of Microwave 330
This should be done in a corner as shown in Figure 15. Alternatively the synchronization capability in MicroWave 330 could be utilized. 4.2 Mounting Microwave 330 Prepare a rigid mounting surface for the MicroWave 330 Transmitter and Receiver as shown in Figure 16. 4" (10.2cm) O.D. Gnd. Lug & Wire Galvanized Pipe 48"... - Page 17 Stacking MicroWave 330 For high security applications where “prone crawl” detection is required, the MicroWave 330 can be stacked to provide a high probability of detection with a very low nuisance/false alarm rate and a reduction in dead zone as shown in Figure 17.
-
Page 18: Modes Of Operation
Com 3. Alarm reporting is configured at the controller and is communicated on the RS422 alarm polling network, Com 1 and Com 2. If a CM II or GCM II controller is used, MicroWave 330 can be configured using the UIST II through the controller. -
Page 19: Tethered Mode
RS422 alarm polling network, Com 1 and Com 2. If a CM II or GCM II controller is used, MicroWave 330 can be configured using the UIST II through the controller. -
Page 20: Wiring
Model 380 or Model 385 microwave transceivers can be used in close proximity without mutual interference. Two (2) MicroWave 330 links and seven (7) transceivers can be connected on the sync line. -
Page 21: Communications Wiring
Control Module II (RCM II) as the system controller connected to a Relay Output Module II-16 (ROM II-16) and a MicroWave 330 receiver. The MicroWave 330 is located on the perimeter. The RCM II and the ROM II- 16 are located in the control room for relay output interface to other control room devices. -
Page 22: Synchronized Wiring
Tethered configuration. In the synchronized configuration MicroWave 330 supports two (2) time slots, Phase 1 and Phase 2. This will allow for synchronizing two (2) MicroWave 330 links and up to seven (7) transceivers as shown in Figure 25. Two more links can be added if they are rotated 90° as explained in Section 4.2. -
Page 23: Remote Test
The synchronization wiring is shown in Figure 26 for two (2) MicroWave 330 links and two (2) Model 380 transceivers. The Phase 0 or Phase 1 setting is configured in the UIST II software program. The synchronization line must use a 22 or 24 gauge twisted, stranded, shielded pair wire. The last unit in the synchronization chain must be terminated with a 120 ohm resistor. -
Page 24: Terminals, Switches And Indicators
The “Channel Select Switch” SW1 as shown in Figure 28 is used in the Free Running mode to set the modulated frequency of the MicroWave 330 transmitter. The same channel must be used on transmitter and receiver. If transmitter and receiver are on different channels the “Channel Error” LED will illuminate. -
Page 25: Microwave 330R Receiver
MODULATION EXTERNAL INTERNAL Figure 29 – Internal – External Modulation Select Switch Transmitter 7.2 MicroWave 330R Receiver The electrical connections, switches and indicators for the MicroWave 330R receiver are shown in Figure 30. Pulse MODEL 330 463930-SST REV 0 Address E1 E2 ALIGNMENT REV-... -
Page 26: Address Switch
7.2.1 Address Switch The “Address Switch” is used to set the node address of the MicroWave 330 receiver which is used for the alarm polling by one of the INTREPID™ controllers (RCM II, CM II, GCM II, PSM or SDK). The address can be set from 0 to 239. -
Page 27: Microwave 330R Receiver Connections
MicroWave 330 Transmitter or Receiver. 9.0 Alignment and Testing The following outline will assist the installer in alignment and testing of the MicroWave 330 Digital Microwave Intrusion Link using a VOM (volt-ohm-meter) with an input impedance of 100,000 ohms/volt or greater... -
Page 28: Preventive Maintenance
The minimum alignment voltage for the MicroWave 330 is 0.5VDC. Although this is the minimum voltage, proper alignment and mounting height will typically be greater. The peak alignment voltage should range between 0.5 and 5 VDC depending upon link distance. -
Page 29: Limited Warranty
Step 3, checking for physical damage (cracks, leaks, corrosion, etc.) checking for isolation zone changes (washouts, materials placement, vegetation growth, loose fence fabric, etc.) 6. For troubleshooting information, please contact the factory about MicroWave 330 Service Manual. 11.0 Limited Warranty SOUTHWEST MICROWAVE, INC. -
Page 30: Returning Equipment Fro Non-Warranty Repair
13.0 Returning Equipment for Non-Warranty Repair Return of equipment out of warranty must first be authorized by SOUTHWEST MICROWAVE, INC. at which time a return authorization number will be issued. The returned equipment must be accompanied by an evaluation repair purchase order. Returned equipment will be examined and customer advised of cost of repair or replacement. - Page 31 Version 0...
