900 MHz Belt-Clip Radio
900 MHz Belt-Clip Radio
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCR900 and is the answer not in the manual?

Questions and answers

Summary of Contents for ITRON BCR900

  • Page 1 900 MHz Belt-Clip Radio 900 MHz Belt-Clip Radio User’s Guide...
  • Page 2 Suggestions If you have comments or suggestions on how we may improve this documentation, send them to TechnicalCommunicationsManager@itron.com If you have questions or comments about the software or hardware product, contact Itron Technical Support Services: Contact • Internet: www.itron.com • E-mail: support@itron.com •...
  • Page 3 Compliance Statement Canada Déclaration de Conformité Under Industry Canada regulations, this radio Conformément à la réglementation d'Industrie transmitter may only operate using an antenna of Canada, le présent émetteur radio peut fonctionner a type and maximum (or lesser) gain approved avec une antenne d'un type et d'un gain maximal for the transmitter by Industry Canada.
  • Page 4 Specific Absorption Rate Data The FCC ID:E09BCR900/IC:864A-BCR900 model of 900MHz Belt-Clip Radio meets the government’s requirements for exposure to radio waves. Your 900 MHz BCR has a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S.

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction ....................1 Related Documents ....................1 Documentation Conventions ..................1 Chapter 2 900 MHz Belt Clip Radio Basics ............... 3 Unpacking Your 900 MHz Belt Clip Radio ..............3 Turning the 900 MHz Belt Clip Radio On and Off ............. 7 Chapter 3 900 MHz Belt Clip Radio Features ............

  • Page 7: Chapter 1 Introduction

    Clip Radio (BCR) and provides information relating to its use and maintenance. Related Documents The 900 MHz Belt Clip Radio is designed for use with handheld and laptop computers running Itron mobile data collection software applications. For detailed information about these applications, see the following documents: •...
  • Page 8 Introduction Warning This type of note is used to warn of potential physical harm to the user or hardware. It is critical that you pay strict attention to Warning notes, read the information carefully, and heed the advice and/or instructions. Tip This type of note provides the user with extra hints/tips to make a task easier to perform or a concept easier to understand.

  • Page 9: Chapter 2 900 Mhz Belt Clip Radio Basics

    900 MHz Belt Clip Radio Basics The 900 MHz Belt Clip Radio is a lightweight, compact device designed for use with Itron mobile data collection software running on FC200 and FC300 series handhelds and laptop computers. It is used for reading, programming, and maintenance of Itron endpoints.
  • Page 10 Belt clip Communication cable When you unpack your BCR, make sure you have all of the components listed here. If any are missing, contact Itron Support Services immediately. Charge the BCR’s battery to 100 percent capacity (this takes about three and a half hours) before using it. This helps insure the accuracy of the BCR’s power gauge calculations.
  • Page 11 5.0 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. Use only Itron-approved accessories with this device. To install the battery Unscrew the four screws that secure the battery compartment cover to the back of the 900 MHz Belt Clip Radio.
  • Page 12 900 MHz Belt Clip Radio Basics Plug the connector into the socket in the top of the battery compartment. Insert the battery into the compartment, carefully tucking the wires into the space above the battery. Replace the compartment cover and fasten it in place with the four screws you removed in step 1.

  • Page 13: Turning The 900 Mhz Belt Clip Radio On And Off

    900 MHz Belt Clip Radio Basics Turning the 900 MHz Belt Clip Radio On and Off Turn on your 900 MHz BCR as soon as you have unpacked and charged it. To conserve battery power, turn the radio off whenever you are not using it.

  • Page 15: Chapter 3 900 Mhz Belt Clip Radio Features

    H A P T E R 900 MHz Belt Clip Radio Features The 900 MHz BCR unit comes equipped with: An ON/OFF button (1) (see Turning the 900 MHz Belt Clip • Radio On and Off on page 7) • Three LED status indicators (2) on top of the unit •...

  • Page 16: Led Status Indicators

    900 MHz Belt Clip Radio Features LED Status Indicators Three LED status indicators are located on the top of the radio, labeled POWER, COMM, and LINK. POWER LED The POWER LED indicates the power status of the BCR’s battery pack. Power status LED indicator On/charging...

  • Page 17: Comm

    900 MHz Belt Clip Radio Features COMM The COMM LED indicates the radio’s Bluetooth connectivity status. Bluetooth status LED indicator On and waiting to Double-flashes blue every two seconds connect On and connected Single-flashes blue every two seconds USB Connection Flashes red every two seconds LINK The LINK LED indicates radio activity.

  • Page 18: Usb Communication Port

    900 MHz Belt Clip Radio Features USB Communication Port The 900 MHz Belt Clip Radio has one dual-function communication port on the bottom of the device. The port provides the radio with a USB cable connection that enables it to receive both USB communications and power from a host PC. In addition, the radio is equipped with an internal port for wireless Bluetooth communications.

  • Page 19: Antenna Types

    900 MHz Belt Clip Radio Features Antenna Types The 900MHz Belt-Clip Radio is approved for use with the following antenna types: Antenna Part number Gain Type Impedance length Description 8¼-inch FC3277ANTENNA (ships with BCR 2.1 dBi Vertical 50 ohms antenna Accessory Kit) Omni Use this antenna when reading...
  • Page 20 900 MHz Belt Clip Radio Features Industry Canada Conformity This radio transmitter (IC: 864A-BCR900) has been approved by Industry Canada to operate with the antenna types listed previously with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna...

  • Page 21: Chapter 4 Mounting The 900 Mhz Belt Clip Radio

    H A P T E R Mounting the 900 MHz Belt Clip Radio The 900 MHz BCR’s ergonomically designed belt clip provides a convenient, hands-free way to carry the BCR while installing, reading, and maintaining meters and endpoints. It lets you wear the radio comfortably while walking or driving.

  • Page 23: Chapter 5 Maintaining Your 900 Mhz Belt Clip Radio

    H A P T E R Maintaining Your 900 MHz Belt Clip Radio Your 900 MHz Belt Clip Radio is rugged and water-resistant. However, you should take the following precautions to ensure that it gives you many years of reliable service. •...

  • Page 24: Battery Basics

    Ion) battery pack as its main power source whenever it is not receiving power through its cradle or USB cable. Warning Do not use any power source other than the Itron-recommended battery. Using another power source could damage the BCR. Warning—Risk of Explosion! There is a risk of explosion if the battery is replaced by an incorrect battery type.
  • Page 25 Maintaining Your 900 MHz Belt Clip Radio Itron recommends the following practices to ensure long battery life: • Charge the radio at room temperature (approximately 68° F/20° C) for best results. Charge the radio at the end of each work day.
  • Page 26 Maintaining Your 900 MHz Belt Clip Radio To charge the battery through the USB cable Connect the Hirose connector (1) on one end of the USB cable to the BCR’s communication port (see USB Communication Port). Connect the USB connector (2) on the opposite end to your PC's USB port.
  • Page 27 Plug one end of the AC adapter into the corresponding socket in the back of the the cradle. Caution Use only an Itron-approved AC adapter with a 12-volt, 3.5 amp input power rating with this device. Plug the other end into an AC electrical outlet.

  • Page 28: Replacing The Charging Cradle's Contact Pins

    Spare or replacement contact pins are available directly from Itron customer service representatives (part number 320-0167-002). Use only replacement pins provided by Itron with the 900 MHz Belt Clip Radio charging cradle. Storing Your 900 MHz Belt Clip Radio Your 900 MHz Belt Clip Radio can be safely stored for two weeks or less with simple preparation.

  • Page 29: Daily Operation

    Note Remove the BCR’s battery before storing the device for periods longer than two weeks. Daily Operation Itron recommends the following daily measures to help maximize the service life of your 900 MHz Belt Clip Radio and resolve any problems you might experience.
  • Page 30 Maintaining Your 900 MHz Belt Clip Radio Do not subject the radio to extreme temperatures, such as leaving it in a vehicle in bright sunlight. Extended exposure to warm temperature extremes can result in permanent reduction in available energy from the battery pack. Charging is disabled below 32°...

  • Page 31: Chapter 6 Safety

    H A P T E R Safety Your 900 MHz BCR is ergonomically designed for safe, comfortable use. However, as with all equipment, you should follow good working practices while using it. Some people experience discomfort while using electronic equipment. If ignored, this discomfort can lead to repetitive stress injury (RSI), also known as cumulative trauma disorder or repetitive motion injury.

  • Page 32: Usage In Hazardous Locations

    Safety • Inspect the AC adapter before use. Do not use it if there are any signs of damage or deterioration. • Make sure all connectors are firmly connected. • Avoid mechanical strain to cables and connectors. • Make sure the adapter’s green LED is lit while the adapter is in use.
  • Page 33 Safety Warning—Explosion Hazard Substitution of components may impair suitability for Class 1, Division 2 locations. Avertissement—Risque d’Explosion La substitution de composants peut rendre ce materiel inacceptable pour les emplacements de classe 1, division 2. 900 MHz Belt-Clip Radio User’s Guide Proprietary and Confidential...

  • Page 35: Chapter 7 Troubleshooting

    If you have a problem with your 900 MHz Belt Clip Radio, review the appropriate troubleshooting steps listed below. After that, if the problem remains unresolved, contact an Itron customer service representative (e-mail: support@itron.com; phone: 1 800 635 8725). Problem...

  • Page 36: Optimizing Bluetooth Performance

    • If the battery’s power does not last following a full charge, return the BCR to an approved Itron service center to have its battery replaced. USB connection • Visit the FTDI website and download...
  • Page 37 Troubleshooting • Because of the way the Bluetooth communication protocol works, communicating devices must be closer to each other when they first establish communication than they must be to maintain the connection afterwards. If the connection fails between the BCR and the computer, you may have to move closer to reconnect.

  • Page 39: Appendix A 900 Mhz Belt Clip Radio Capabilities And Limitations

    900 MHz Belt Clip Radio Capabilities and Limitations Equipment Description Model: 900 MHz Belt Clip Radio FCCID: EO9BCR900 IC ID: 864A-BCR900 900 MHz Belt Clip Radio Transmitter Information Transmit frequency MAS: 952 MHz–957 MHz Transmit frequency ISM: 908 MHz–923.8 MHz MAS transmitter conducted power: +22 dBm ISM transmitter conducted power: +10.5 dBm...
