QuickSpecs
Overview
HP Entry-Level Power Supplies
Looking for high-efficiency power solutions at an entry-level price for your ProLiant Gen9 Essential Server? HP Entry-Level Power
Supplies offer an optimized set of features with options for both redundant and non-redundant power configurations.
The HP 550W FIO Power Supply offers Silver-certified 80 Plus power efficiency (up to 89%) with an optimized set of features for
non-redundant power configurations.
The HP 800W Gold (Redundant)/900W (Non-Redundant) AC Power Input Module with Power Backplane can be configured to
support power redundancy in ProLiant servers that offer only a single power supply bay, providing additional protection against
power loss. With an 80 Plus Gold power efficiency rating (up to 92%), this power option helps to reduce operating expenses while
protecting against trapped power capacity in the data center. Hot-plug AC power input modules allow for better serviceability
with fast and easy deployment and replacement.
1. Power Supply Identification Label
HP 800W Gold (Redundant)/900W (Non-Redundant) AC Power Input Module with Backplane
1. AC Power Input Module #1
2. Hot-Plug Quick Release Lever
3. AC Power Input Module #2
HP 550W FIO Power Supply
c04390737 – DA – 15030 Worldwide — Version 2 — December 1, 2014
2. C-14 Input Connector
4. C-14 Power Input Connector
5. Power Supply Backplane
HP Entry-Level Power Supplies
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP Entry-Level

Summary of Contents for HP Entry-Level

  • Page 1 Supplies offer an optimized set of features with options for both redundant and non-redundant power configurations. The HP 550W FIO Power Supply offers Silver-certified 80 Plus power efficiency (up to 89%) with an optimized set of features for non-redundant power configurations.
  • Page 2 HP ProLiant Gen9 Essential Server Power Supplies – Non-Redundant Power Supplies NOTE: Supports Silver-level efficiency (89%) with a standard C14 inlet connector. No support for HP Power Discovery Services. Only compatible with select HP ProLiant Gen9 Essential servers. HP 550W FIO Power Supply Kit 730941-B21 NOTE: This is a Factory Installed Option (FIO) only.

  • Page 3: Standard Features

    The HP 550W FIO Power Supply meets 80PLUS Silver certification requirements. The HP 800W/900W Gold Power Supply meets 80PLUS Gold certification requirements. To review 80Plus certification reports for all HP Power Supply options, please refer to the 80Plus website at: www.80plus.com. Compatibility To check for power supply compatibility, please review the appropriate HP Server Quickspec at www.hp.com/go/qs.

  • Page 4: Service And Support

    The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have...
  • Page 5 HP C13 - C14 WW 250V 10Amp 0.7m Jumper Cord 142257-B28 HP C13 - C14 WW 250V 10Amp 1.4m Jumper Cord 142257-006 HP C13 - C14 WW 250V 10Amp 1.4m 15 pc Jumper Cord 142257-007 HP C13 - C14 WW 250V 10Amp 2.0m Jumper Cord A0K02A HP C13 - C14 WW 250V 10Amp 2.5m Jumper Cord...

  • Page 6: Power Specifications

    2201 2176 2169 2130 2127 2124 2121 2119 HP 800W Gold (Redundant) AC Power Input Module HP's Generic Part Number (Backplane) 743908-001 (744689-B21) with Power Backplane HP's Generic Part Number (Power Input Mod) 743907-001 (745813-B21)* HP's Spares Part Number (Backplane)
  • Page 7 QuickSpecs HP Entry-Level Power Supplies Power Specifications HP 900W Gold (Non-Redundant) AC Power Input HP's Generic Part Number (Backplane) 743908-001 Module (744689-B21) with Power Backplane HP's Generic Part Number (Power Input Mod) 743907-001 (745813-B21)* HP's Spares Part Number (Backplane) 754376-001...

  • Page 8: Technical Specifications

    HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. c04390737 – DA – 15030 Worldwide — Version 2 — December 1, 2014 Page 8...
  • Page 9 Hewlett Packard web site at: http://www.hp.com/go/green. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment. c04390737 – DA – 15030 Worldwide — Version 2 — December 1, 2014...

  • Page 10: Summary Of Changes

    The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
