Summary of Contents for Hyco Sapphire SAP02HC
- Page 1 Product Instruction Manual apphire SAP02HC Hot and cold floor standing cooler V16.5/1 Version 3.2 Jan 2015...
-
Page 2: Important Safety Points
Thank you for purchasing the SAP02HC from our Sapphire range of chilled water products. The SAP02HC provides instant high quality chilled water together with filtered hot water for tea and coffee making. Please read and follow these instructions carefully to ensure that installation and operation is simple and safe. - Page 3 • Children should not use the hot tap when unsupervised • This appliance is intended to be used in household and similar applications such as: • staff kitchens areas in shops, offices and other working environments • farm houses and by clients in hotels •...
- Page 4 NO. NAME NAME Heating indicator light Access panel Cooling indicator light Heating switch Safety lock Cooling switch Cold water tap Power cord Hot water tap Water drainage Drip tray Water inlet...
-
Page 5: Installation
2. Installation • The unit should be installed with easy access to the electrical plug • This appliance should be installed indoors, on a flat surface no less than 15cm from the back wall • Install the appliance in a dry, well ventilated area; keep the ventilation openings at the back of the unit uncovered and unobstructed •... - Page 6 the door and press it down To replace the front it down 1. Ensure locating pins are 2. Push the door lined up at base of unit downwards and close 3. The door should “snap” back into place 3. Connect the ¼” plastic tubing provided to the water inlet at the rear of the cooler and connect to the installation kit as per instructions provided.
- Page 7 4. Turn on water supply to the unit and check all connections (including the installation kit) for leaks. 5. BEFORE switching power onto the unit hold down the hot water lock button whilst operating the hot water tap until water flows. Ensure that water has flowed from the hot water faucet before plugging and switching the appliance on to heat.
-
Page 8: Operation
3. Operation Hot water Turn on the heating switch (red) on the back of the unit. The heating circuit will be switched on and heating power light will illuminate as per Fig 1. When the hot water Fig 1. Fig 2. set point is reached the hot water ready Hot water ready Heating... - Page 9 Leak proof valve If there are any internal leaks that cause water to pool in the base of the unit, the leak proof valve fitted on the water inlet will operate, closing the water inlet valve and stopping the leak. •...
-
Page 10: Specifications
5. Specifications Voltage / Frequency V~Hz Heating Power 500W Cooling Power Heating capacity 5L/h >90°C Cooling capacity 2L/h<10°C Ambient temperature 18-38°C Pure Water flowrate >0.5L/min Working pressure 0.2Mpa-0.35Mpa Product Code Description SAP02_PAPER Replacement absorbent paper SAP02_TAP Replacement Hot & Cold taps PERT_TUBE ¼”... - Page 11 1110mm 395mm 300mm...
- Page 12 Incorrect installation, consequences of lime scale deposits and failure to follow correct operating instructions are excluded. Consequential costs such as labour charges or damage to surroundings are expressly excluded. Hyco Manufacturing Ltd Normandy Court Express Way Castleford, WF10 5NR...
