- Page 1 MECHANICAL CONTACT RUBBER SAFETY SENSITIVE EDGE INSTALLATION MANUAL...
-
Page 2: Legend Symbols
The DF sensitive edge should not be employed for any other purpose than its intended use, as specified above. Instal- ling the device in a manner other than as indicated in the manual may hamper the device’s safety function. - Page 3 4.4 Size measurements Measurements in mm DF15 DF17 DF20 DF25 4.5 Parts description Head plug Rubber profile Steel cable Cable hooking mechanism Aluminium profile Mounting bracket Micro switch holder mechanism Micro switch Terminal for electric connection 10 - DFI box 11 - Control board 12 -...
-
Page 4: Installation
5 Installation Warning: improper installation may cause serious damage. Follow all installation instructions. 5.1 Preliminary checks It is necessary to verify that the sensitive edge’s fixing point is on a suitable surface prior to installation. 5.2 Tools and materials Make sure all tools and materials necessary are within reach to install the edge in maximum safety, according to regulations in force. - Page 5 5.4 Preparation of sensitive edge for varying lengths 1) Identify the area to be protected, nominal length (LN). NB.: in vertical installations, reduce nominal length (LN) by 30 mm to prevent contact with ground. 30mm 2) Cut the aluminium profile (LP) and the rubber profile (LG) in the following manner: LP = LN - 40 mm;...
- Page 6 5) Insert the micro switch holder mechanism. Once inserted, release the lever with slight downward pressure and tighten the two UNI6955 ø 2.9x13 screws 6) Insert the steel cable in the connecting terminal hole; insert everything in the lever, tension the cable and screw. Once the cable is adjusted, cut any excess cable.
- Page 7 8) Only for vertical installations: bore a hole with a ø 4 mm bit in the bottom pre-marked area of the plug to prevent condensate from gathering within. Insert the plug and secure it with 3 UNI 6954 ø 3.9 x 13 screws and washers.
- Page 8 5.5 Electrical connections See paragraph 5.3, Cable List, for choice of cables. Electrical connection of sensitive edge to control SENSITIVE EDGE panel at terminals for NC safety contacts. CONTROL PANEL Electrical connection with control board (DFI) connected between the sensitive edge mounted on moving wings and control panel.
-
Page 9: Information For End User
UNI EN ISO 14001 standard to ensure environmental protection. Please continue our efforts to protect the environment—which CAME considers one of the cardinal elements in the development of its operational and market strategies—simply by observing brief recommendations as regards disposal: DISPOSAL OF PACKAGING –... - Page 10 THIS PAGE LEFT INTENTIONALLY BLANK...
- Page 12 CAME UNITED KINGDOM LTD UNIT 3, ORCHARD BUSINESS PARK TOWN STREET, SANDIACRE NOTTINGHAM - NG10 5BP - U.K. Tel 0044 115 9210430 Fax 0044 115 9210431...
