Summary of Contents for Adeunis RF AMR Gateway
- Page 1 W-MBus GPRS AMR Gateway User Guide version V2.5.1 Gateway software version V3.0.0 ADEUNIS RF 283 rue Louis Néel - Parc Technologique Pré Roux 38920 CROLLES - France Tel. : +33 (0)4 76 92 07 77 - Fax : +33 (0)4 76 04 80 87 www.adeunis-rf.com...
-
Page 2: Disclaimer
V3.0.0 Disclaimer This document and the use of any information contained therein, is subject to the acceptance of the Adeunis RF terms and conditions. They can be downloaded from www.adeunis-rf.com. Adeunis RF makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. -
Page 3: Table Of Contents
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 Table of contents Information Products version Disclaimer Technical Support Safety instructions 1.1. Environmental recommendations 1.2. Warnings 1.3. Usage Recommandations 1.4. Waste disposal by users in private households in the European Union Main Features 2.1. - Page 4 ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 File data 6.1. Extension 6.1.1 Compression 6.1.2 Encryption 6.1.3 Compression + encryption 6.2. Decryption file 6.2.1 File format 6.2.2 Hexadecimal format 6.2.3 First part 6.2.4 Second part 6.2.5 Third part 6.2.6 Last part 6.3.
- Page 5 ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 EU Declaration of Conformity ADEUNIS RF 283 rue LOUIS NEEL 38920 Crolles, France 04.76.92.01.62 www.adeunis-rf.com Declare that the DoC is issued under our sole responsibility and belongs to the following product:...
- Page 6 ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 Déclaration UE de Conformité Nous ADEUNIS RF 283 rue LOUIS NEEL 38920 Crolles, France 04.76.92.01.62 www.adeunis-rf.com Déclarons que la DoC est délivrée sous notre seule responsabilité et fait partie du produit suivant : Modèle produit :...
-
Page 7: Safety Instructions
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 1. Safety instructions 1.1. Environmental recommendations All unnecessary packing materials have been eliminated. We have made every possible effort to ensure that the packaging can easily be separated into three types of materials: cardboard (box), expandable polystyrene (buffer material) and polyethylene (bags and protective foam layer). -
Page 8: Main Features
(EN13757) and send them as files to a remote FTP server , via a GPRS network. Markets covered by the AMR Gateway are the metering (automatic meter reading) and energy efficiency in the building (BMS / BAS). 2.1. Operating principle 2.2. -
Page 9: Technical Specifications
Weights 485gr Standards EN300-220, EN301-489, EN60950, EN13757-4 2.3.1 Default configuration By default, irrespective of the version, the configuration of the AMR Gateway is the following : WMBUS listening period WMBUS mode GPRS connection WMBUS Frame length 4 minutes / day... -
Page 10: Autonomy Table
Number of transmitters received and stored in memory Note : during the 4 minutes of listening, the WMBUS received frames are identified by the AMR Gateway. A received frame will be stored only once during this period. This mechanism avoids the memory to be overloaded by products emitting very often. -
Page 11: General Description
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 2.4. General description Note: the term «external antenna» means 868MHz antenna for receiving frames WMBUS 2.4.1 External antenna / Self-powered version ARF8011BA AMR gateways external antenna version are supplied with the following accessories : •... -
Page 12: Mechanical Installation - Optimizing Performance
Adeunis RF. It is therefore necessary for the user to provide a SIM card to ADEUNIS RF that will perform the installation thereof and all functional tests before shipment to the customer. -
Page 13: Gateway Configuration
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 5. Gateway configuration Adeunis RF AMR Gateway can be configured remotely by sending a XML file Type. This file, once established, is sent to the gateway during a GPRS connection. Upon receipt of the file, the gateway identifies as a configuration file. -
Page 14: Parameters
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 5.1.1.3 Parameters Description Parameter Format Default Comment PIN Code <syst pincode=””/> Num : 4 0000 Example : 0000 Login <syst login=””/> Text Operator Login Password <syst password=””/> Text ADMIN Operator Password <syst apn=””/>... - Page 15 ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 Description Parameter Format Default Comment Password <cust ftp_pwd=””/> Text Password to use for FTP connec- tion Maintenance Address <cust ftp_maint_addr=””/> IP or text IP address for monitoring file Port Maintenance See note(1)
-
Page 16: Upgrade File
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 Example for one wmbus reception per hour and 1 file transfer per day at midnight every day: <cal dd=”7FFFFFFF” hh=”0” tx=”1”/> <cal dd=”7FFFFFFF” hh=”1” tx=”0”/> <cal dd=”7FFFFFFF” hh=”2” tx=”0”/> <cal dd=”7FFFFFFF” hh=”3” tx=”0”/>... -
Page 17: Parameters
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 5.1.2.3 Parameters Description Parameter Format Default Config File Version <config version=””/> Config File Name <config file=””/> Text config Firmware Version <firmware version=””/> Text 3.0.0 Firmware Name <firmware file=””/> Text amrgateway 5.1.3 Command file The command file is used to clear all meter filtering enter in the gateway. -
Page 18: Log File
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 5.1.5 Log file After receiving the file(s), the AMR Gateway creates or appends his assigned log file contains in the log folder. 5.1.5.1 File name Type Format SerialPart NamePart Example TXT File SerialPart_NamePart.xml... -
Page 19: Compression + Encryption
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 6.1.3 Compression + encryption Both option can be activated for file. The file will used both extension : .gz + .aes Example : 0999208001A_140402_011821.gp2.aes.gz 6.2. Decryption file 6.2.1 File format When the FTP server connection is established, the gateway sends a. GP2 file... -
Page 20: Last Part
ADEUNIS RF - WMBUS GPRS GATEWAY USER GUIDE V2.5.1 6.2.6 Last part WMBUS frame 30 4c 07 00 00 00 00 00 a1 61 3f 03 13 97 87 73 98 4f 04 03 41 9f e9 86 22 13 11 07 15 42 56 6c 19 Example : WMBUS frame starts with Manufacturer ID, product ID and then the DATA.
