USER MANUAL
AUTOMATIC SLIDING DOOR PRODUCT LINE 300
1/25/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Doorson 300

  • Page 1 USER MANUAL AUTOMATIC SLIDING DOOR PRODUCT LINE 300 1/25/2016...
  • Page 3: Table Of Contents

    NORMAL OPERATION OF 300 A . . . . . . . . . . . . . . . . . .
  • Page 4: Introduction

    The purpose of the detailed instructions is to better acquaint you with the automatic door system of the product line 300 so that you may make better use of it . We recommend that this manual is kept somewhere close to the door .
  • Page 5: Manufacturer Contact

    .doorson .com PRODUCT DESCRIPTION Automatic sliding doors product line 300 consist of an intelligently regulated modern drive mechanism . The door controller allows you to use a wide range of accessories (mode selectors, motion and presence sensors, safety sensors, battery units, electric locks, anti-burglar switches, keyboards, remote controls, magnetic card readers, connection to the fire safety system…), which ensure high operation safety and...
  • Page 6: Product Purpose

    . In the product line 300 the 300F and 300EF doors are fireproof doors . The 300 THALES r, 300 r, 300 T r, 300 P r, 300 SC r, 300 C r, 300 A and 300 EF are suitable for the installation on escape routes and emergency exits .
  • Page 7: Technical Data

    4+4 or 5+5 ESG 8 or 10mm In-built glass for profiles PR 5 insulated 3+3-9d-3+3, 6k-9d-6k, 5k-9d-5k or 5k-12d-5k DOORSON aluminium profiles PR4 family – for a single safety glazing PR5 family – for an isolation safety glazing MAXIMUM DOOR DIMENSIONS AND WEIGHTS The clear opening width extends from 800 to 3000 mm and the height is up to 3000 mm .
  • Page 8: Product Line 300

    PRODUCT LINE 300 Door types TYPE DRIVE DESCRIPTION 300 THALES standard standard door standard standard door 300 r standard redundant standard door - redundant 300 T standard telescopic door 300 T r standard redundant telescopic door - redundant 300 P...
  • Page 9: Safety Recommendations

    SAFETY RECOMMENDATIONS Automatic sliding doors product line 300 are made according to the latest technologies and in compliance with current technical regulations . Doors have to be installed according to the installation manual . Note the next points that the doors will function properly and with the prescribed safety: •...
  • Page 10: Door Operation

    DOOR OPERATION MODE SELECTION The operating mode of automatic sliding doors product line 300 are chosen with the mode selectors COM20, COM21 or with additional devices via additional entries on the EC4 door controller . Modes of operation REDUNDANCY SYMBOL...
  • Page 11: Com20

    DOOR OPERATION COM20 COM20 is the most advanced mode selector for automatic sliding doors product line 300 . The touch screen serves to change the operating mode, adjust system settings and show warnings and errors “in words“, not in LED codes .
  • Page 12: Additional Entries

    IN CASE OF POWER FAILURE Automatic sliding doors product line 300 can be equipped with a battery support in case of power supply shortage due to a power cut in the electric power network . In such a case the LED diode LED1 in the EC4 door controller switches off, the doors open and remain still in open position after the power failure .
  • Page 13: Exit And Entrance Into The Building

    DOOR OPERATION EXIT AND ENTRANCE INTO THE BUILDING The following exit or entrance procedures can be used if automatic sliding doors product line 300 are installed at the entrance of a building, which is also the only entrance: EXIT from the building: “EXIT SUMMER”...
  • Page 14: Redundancy Testing

    DOOR OPERATION REDUNDANCY TESTING The redundancy system prevents the doors to stay in closed position if the door control system ceases to operate (hardware/software fault) . In this case the door opens and remains open . Such functionality prevents people from staying trapped in the room/building . Such safety functionality is needed if the doors are installed on escape routes! The redundancy system is tested every twelve hours in mode EXIT or AUTO .
  • Page 15: Fire Signal

    Automatic sliding doors product line 300 can be connected to a fire central, however, the systems 300 THALES r, 300 r, 300 C r, 300 T r, 300 P r, 300 SC r, 300 A, 300 F and 300 EF MUST be connected to the fire central if it exists .
  • Page 16: Electric Lock El5

    ELECTRIC LOCK EL5 The electric lock EL5 locks the door leaf/leaves . Door is locked mechanically when the red handle on the electric lock EL5 is in the LOCK position . For unlocking the red handle on the electric lock EL5 has to be moved to the UNLOCK position .
  • Page 17: First Startup

    FIRST STARTUP The cable installation for the power supply and connection to the door system may be carried out only by a specially trained person and according to current regulations . The door construction must be additionally grounded in the case that the automatic doors are installed on a steel construction .
  • Page 18: Type 300 A

    TYPE 300 A NORMAL OPERATION OF 300 A During the building’s opening hours when the doors are in operation the sliding door must be unbolted, so that in the case of panic conditions the doors can be wide open by force . A GREEN button must be visible on the bolt of the sliding doors .
  • Page 19: Activation Of The Break-Out Function

    TYPE 300 A ACTIVATION OF THE BREAK-OUT FUNCTION The sliding and fixed wings open out in the direction of the emergency exit by physical force regardless of the position of the sliding wings . If the sliding wings are in movement at the moment they immediately stop .
  • Page 20: Type 300 F And 300 Ef

    DOORS FOR ESCAPE ROUTES AND EMERGENCY EXITS WITH BREAK-OUT FUNCTION AND FIRE RESISTANCE The 300 EF projected automatic sliding fire doors for escape routes and emergency exits are designed to be installed at the borders of fire sectors and at the passages of escape routes . Under normal conditions, the door acts like a sliding door, whereas in case of emergency, the sliding leaves will close unconditionally using the stored potential energy and the integrated swinging leaves will unbolt, enabling easy escape .
  • Page 21: Fire Door Operation

    TYPE 300 F AND 300 EF FIRE DOOR OPERATION NORMAL – SLIDING MECHANISM In this mode, the door leaves are locked and cannot be opened; the door works like a regular sliding door . The mechanical redundant unit is under tension . THE TRANSITION FROM SLIDING TO FIRE OPERATION In case of emergency, i .e .
  • Page 22: System Settings

    SYSTEM SETTINGS Settings on the automatic sliding doors product line 300 can be configured only with the mode selector COM20 or via PC software . The system settings can only be configured by a person who has been appropriately qualified for maintenance by the manufacturer .
  • Page 23: Light And Sound Diagnostics

    LIGHT AND SOUND DIAGNOSTICS The EC4 door controller has two light indicators . They indicate the following: • LED1 – main power supply • LED2 – battery power supply Door controller EC4 and mode selector COM20 have a built-in buzzer announcing errors and warnings . The sound and light diagnostics are alike . The mode selector COM20 shows errors and warnings graphically on the screen, while the mode selector COM21 shows errors and warnings via the light indicator .
  • Page 24: During Errors

    LIGHT AND SOUND DIAGNOSTICS SHORT PULSE • – follows after a long pulse and indicates number 1 . Short pulse 0,1 s 0,5 s Example in figure: SHORT PULSE PAUSE SHORT PULSE PAUSE SHORT PULSE PAUSE SHORT PULSE PAUSE SHORT PULSE = 5 On occurrence of the warning, the light signals appear in the following order: WARNING CODE INTERVAL FLASHING...
  • Page 25: Handling During Errors

    LIGHT AND SOUND DIAGNOSTICS HANDLING DURING ERRORS Use the following guidelines! In case of an error, consider the following guidelines: • Read the error code . For showing the code press the WAKE BUTTON and release it immediately . Then read the code and write it down or remember it, maybe you will need to call the service later on;...
  • Page 26: Warnings

    LIGHT AND SOUND DIAGNOSTICS WARNINGS Warnings WARNING num. WARNING SOLUTION FIRE INPUT Check X7-3 and X7-6 STOP INPUT Stop input Check X8-6 and X8-7 EMERGENCY INPUT Check X21-2 and X21-3 BLOCK ABORTED Check X7-4 and X7-5 or S401 MONITORING ENTRY SAFETY SENSOR Check sensor and wiring MONITORING EXIT SAFETY SENSOR Check sensor and wiring...
  • Page 27 LIGHT AND SOUND DIAGNOSTICS Warnings - continue WARNING num. WARNING SOLUTION NO BATTERY CONNECTED Connect or deactivate battery (Sett . Nr . 21) MONITORING SIDE SAFETY SENSOR 2 Check sensor and wiring SIDE SAFETY SENSOR 2 ACTIVE OVER 1 m . Check sensor and wiring SIDE SAFETY SENSOR 1 ACTIVE Check sensor...
  • Page 28: Errors

    LIGHT AND SOUND DIAGNOSTICS ERRORS Errors ERROR NUM. ERROR SOLUTION STARTUP TIMEOUT Wait 1 minute / Reset door controler / Call service STARTUP OVERLOAD Wait 1 minute / Reset door controler / Call service ENCODER OR MOTOR Wait 1 minute / Reset door controler / Call service FIRE MODULE Reset door controler / Call service DIRECTION...
  • Page 29: Transport And Storage

    LIGHT AND SOUND DIAGNOSTICS Napake - nadaljevanje ERROR NUM. ERROR SOLUTION WINDING MOTOR Reset door controller / Call service ACTUATORS Reset door controller / Call service BRAKE Reset door controller / Call service END SWITCH Reset door controller / Call service EC4 NOT READY Reset door controller / Call service FIRE INPUT...
  • Page 30: Maintenance

    • Do not clean the doors with a water jet. Major refitting is not necessary during the lifespan of the automatic sliding doors product line 300 . The replacement of a damaged glass, drive components and additional components can only be carried out by the manufacturer, his service agent or similarly qualified persons in order to avoid an electrical hazard .
  • Page 31: Service Information

    SERVICE INFORMATION SERVICE ADVICE: It is recommended that the doors are checked and tested once a year . The check-up and testing can be carried out only by the manufacturer’s authorized service . Status records of the device have to be made during the annual check-up and testing . Doors on escape routes have to be tested once a year! MARKING The CE label is attached on the inner left or right end of the drive cover .
