Installing Propane Containers

KZ recreational vehicles are equipped with 20 or 30 pound propane
containers, depending on floor plan models.
Mounting and attaching instructions are listed below:
1. Thread the long rod into the base plate.
2. Set both bottles into place.
3. Drop the double hook bracket over the rod and hook onto the
bottles.
4. Attach the wing-nut to hold the bracket and tighten to hold the
bottles to the plate.
5. Attach the regulator with the vent down to the bracket.
6. Attach the main hose from the regulator to the manifold fitting in
the frame.
7. Attach two short pigtail hoses to the regulator and bottles at the
ACME fitting.
8. Test all propane connections for leakage.
To remove the propane containers for refilling:
1. Remove the bottle covers (if used).
2. Close the main valve on the container.
3. Remove the two hoses at the ACME connection.
4. Install the rubber cap over the valve ACME connection, if so
equipped.
5. Remove/loosen the wing nut holding the clamp hook.
6. Remove the clamp hook.
7. Fill the bottle and reverse the procedure to install.
connections for leakage.

Regulator

Propane regulators must always be installed with the regulator vent
facing downward. Regulators that are not in compartments have
been equipped with a protective cover. Make sure that the regulator
vent faces downward and that the cover is kept in place to minimize
vent blockage. Should the vent be covered or blocked, regulator
CANNOT function.
The regulator has the only moving components in the propane
system. It's sole function is to reduce the high and varied pressure
from the propane containers to safe and consistent low operating
pressure. The small inlet is the first stage, which reduces the
container pressure to 10-13 pounds.
www.pdffactory.com
63
Test all
