GT-tronics CC264BPA-S Manual

CC264BPA-S_Bluetooth LE Module
Features
 Fully compliant to Bluetooth Smart (4.2 Low Energy single mode) specifications
 High efficiency on-module printed PCB RF antenna (CC264BPA-S)
 Very few external BOM-count to create a fully functional application circuit
 Texas Instrument CC26xx SimpleLink
 48MHz ARM Cortex-M3 MCU core for applications with 128K flash memory for ISP
 8-KB SRAM for Cache and 20-KB Ultra-Low Leakage SRAM
 Dedicated ARM Cortex-M0 core, 4KB SRAM, and ROM for RF operations
 Dedicated processor and 2KB SRAM for ultra-low power sensor control
 Coin battery-friendly 1.8-3.8V operation
 Ultra Low power consumption, 6.5mA during Active-TX at 0dBM
 Increased modulation index providing possible range of 100m+ in open area
 Continuous Time Comparator and Ultra-Low Power Analog Comparator
 TRNG and AES-128 encryption for data encryption and authentication
 4 General-Purpose Timer Modules (8 × 16-Bit or 4 × 32-Bit Timer, PWM Each)
 Programmable UART, SPI, I2S, I2C, and GPIO interface
 12-Bit ADC, 200-ksamples/s, 8-Channel Analog MUX and battery monitor
 Support for 8 Capacitive Sensing Buttons
 Support user-developed applications and custom profile over GATT
 Integrated RF Shied can models available (CC264BPA-S / CC265BPA-S)
 Bluetooth Certification BQB: Available upon request
 FCC Certification: Available for CC264BPA-S
 REACH / RoHS compliant
Applications
 Internet of Things (IoT) Device
 iBeacon
 Wireless Keyboard and Mouse
 GamePad and Game Controller
 HID applications
 Mobile phone and tablet accessory
 Medical and healthcare monitor
 Sports and Fitness equipment
 Proximity and Lost-prevention Key Fob
 Smart Wearable
SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
TM
Wireless MCU
 RC and Interactive Toy
 Home/Building Automation
 Machine-to-Machine data transfer
 Remote Sensor Network
 Wireless Alarm and Security
 Automatic Meter Reading (AMR)
 Electronic Shelf Labeling
 Lighting and HAVC control
 Remote Control and Assisted Living
© 2015 - GT-TRONICS REV 05 2016-02-02
