Summary of Contents for Aritech ATA-4/9 CSqX
-
Page 1: Installation And Operation
Installation and Operation Manual ATA-4/9 CSqX ATA-4/9 MSqX 4/9 CHANNEL SIMPLEX VIDEO MULTIPLEXERS INSTALLATION AND OPERATION MANUAL VEXT VEXT 0150-0147 Revision B... - Page 2 Installation and Operation Manual WARNING! The exclamation point, within an equilateral The lightning flash with the arrowhead symbol, triangle, is intended to alert the user to the within an equilateral triangle, is intended to alert presence of important operating and maintenance the user to the presence of uninsulated (servicing) instructions in the literature "dangerous voltage"...
- Page 3 All information and specifications furnished by Aritech are believed to be accurate and reliable. No responsibility is assumed by Aritech for neither its use nor any infringements of rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Aritech.
-
Page 4: Table Of Contents
Installation and Operation Manual CONTENTS 1 INSTALLATION AND GENERAL INFORMATION......1-1 1.1 P & F ..........1-1 RODUCT ESCRIPTION EATURES 1.2 U ..................1-2 NPACKING 1.3 I ............1-3 NSTALLATION NVIRONMENT 1.4 T ................1-3 RONT ANEL 1.5 T ................1-4 ANEL 1.6 P ................ -
Page 5: Product Description & Features
The family is made up of four models, either color or monochrome, with either 4 or 9 video inputs. Available in PAL/CCIR format. A key feature of the ATA-4/9 CSqX/MSqX is its simplicity. This results in quick and easy installation, and ease of use. The unit automatically senses which camera inputs are connected and then sets up the record list and sequence lists automatically. -
Page 6: Unpacking
The Aritech ATA-4/9 CSqX/MSqX can also decode tapes made on Dedicated Micros multiplexers. The ATA-4/9 CSqX/MSqX family is part of a large range of Aritech multiplexers. Tapes recorded on an ATA-4/9 CSqX/MSqX unit can also be played back in full-screen or multi-screen on the other advanced Aritech multiplexers, and vice-a-versa. -
Page 7: Installation Environment
Installation and Operation Manual Installation Environment • Install the multiplexer unit so that the cooling vents are not obstructed. • Protect the unit from extreme hot or cold temperatures. • Use an uninterruptable AC power supply (UPS). • Do not place any weight that exceeds 35 lb. (16 kg) on top of the multiplexer. The unit's technical specifications appear in Section 4, starting on page 4-1. -
Page 8: The Rear Panel
Installation and Operation Manual The Rear Panel The rear panel connections are the same on 4-channel and 9-channel multiplexers except the amount of Camera BNC inputs. VCR composite input, BNC VCR composite Monitor output VEXT connector output, BNC composite, BNC 12 Vdc power, VEXT 12V DC... - Page 9 Installation and Operation Manual Camera Output Connections When connecting cameras to the multiplexer, use only 75-ohm video coaxial cables and BNC connectors. For each camera, there are two BNC jacks. Either jack can receive a camera’s signal. This signal is looped (directly connected) to the other jack, making the camera’s signal accessible to other equipment.
-
Page 10: Monitor Connections
Installation and Operation Manual NOTE: In this manual, real-time mode is defined as 3-hour mode. VEXT simplifies multiplexer operation by automatically synchronising the multiplexer to the VCR. The VEXT signal is especially useful with VCRs having dual recording speeds (alarm and normal), because it makes the multiplexer follow alarms. - Page 11 Installation and Operation Manual Table 1-2. Default Switch Settings (Rear Panel). CAM 1-4 CAM 5-9 PROGRAM DS-1 DS-3 DS-2 HI-Z TERMINATION, CAMERAS 1-4 75 Ω Ω Ω Ω Set these switches to the HI-Z position if the inputs are to be looped. CAM 1-4 DS-1 HI-Z...
-
Page 12: Power Supply
Not Used NOTE: A VEXT pulse edge switch is available. It is needed only for problem solving. DO NOT change its setting unless you are advised to do so by Aritech Technical Support. Power Supply NOTE: Be sure to read Power-Up and Testing below before applying power. -
Page 13: Power-Up And Testing
Installation and Operation Manual Table 1-5. Multiplexer Power Supply. Input Voltage 110 to 240 V Tolerance ± 10% Frequency 50 to 60 Hz Output Voltage 12 V Power 25 W NOTES: Do not use any other power supply. The manufacturer accepts no responsibility for any damage caused by the use of any other power supply. - Page 14 Cameras Not Connected On power up, the ATA-4/9 CSqX/MSqX automatically senses which cameras are not active (not connected), and it does not include such cameras in the record list, and the default sequence list. (Refer to Section 2.2, page 2-7 for the procedure to add a camera to the system at a later stage.)
-
Page 15: Principal Operating Modes
Installation and Operation Manual PERATING ODES AND APABILITIES Principal Operating Modes Aritech units have three principal modes of operation: Table 2-1. The Three Principal Operating Modes. Mode Buttons Description Instructs the unit to display Live images in full-screen or Live multiscreen formats. -
Page 16: Record Mode
VCR. While the ATA-4/9 CSqX/MSqX is recording, all the displays on the monitor are live, full-screen displays, unless VCR VIEW mode is selected. The user can sequence the live full-screen camera images, or select a fixed live camera for display while recording. -
Page 17: Play Mode
If the VCR is not playing, and the ATA-4/9 CSqX/MSqX is in Record mode when VCR View is selected, then the images that are going to the VCR from the unit will be displayed. This can be used to verify that the unit is multiplexing correctly, and that the desired time-lapse mode has been selected. - Page 18 The Freeze function does not work while in VCR View, and the unit's LEDs do not indicate the camera displayed. The Aritech unit can properly interpret tapes encoded on Dedicated Micros (DM) multiplexers with a program switch setting on the rear panel. This is useful in installations that already have other DM multiplexers.
-
Page 19: Changing Cameras In The Quad Display
Installation and Operation Manual Changing Cameras in the Quad Display Changing Cameras in the Quad Display (9-channel units only) Any camera can be displayed in any position in the unit’s quad display. The default quad view display shows the cameras 1 to 4 in ascending order. In the Live mode, the user can display one camera in more than one position, while in Play mode, each camera can be displayed only once in the quad. -
Page 20: Autolist And Sequencing
Installation and Operation Manual Start Sequencing To select any full-screen display, press the camera number button, and then the SEQUENCE button. Cancel Sequencing To cancel sequencing, press either the SEQUENCE button (again), any camera number button, or the MULTISCREEN button. AutoList and Sequencing The AutoList function lets the user change the default camera sequence and dwell settings, and can accommodate up to 32 cameras. -
Page 21: 2.9 Video Loss
2.10 Adding and Removing Cameras Adding cameras to the unit If cameras are added after the ATA-4/9 CSqX/MSqX is powered up, those cameras will not be in the ATA-4/9 CSqX/MSqX’s sequence and record lists until the unit is powered off, and then on again. - Page 22 Installation and Operation Manual This page intentionally left blank 0150-0147 Revision B...
-
Page 23: Service
FACTORY SERVICE If the ATA-4/9 CSqX/MSqX requires factory service, contact the dealer who supplied the unit to you for the correct procedures to return the unit to the factory, or the nearest factory service center. - Page 24 Installation and Operation Manual This page intentionally left blank 0150-0147 Revision B...
-
Page 25: Technical Specifications
Installation and Operation Manual ECHNICAL PECIFICATIONS NOTE: All specifications are subject to change without notice. Aritech believes all specifications are correct, but no liability is assumed for omissions or errors whatsoever. Multiplexer Connectors (EIA/CCIR-Compatible) (One each, unless otherwise noted) Interface... - Page 26 Installation and Operation Manual Buttons and Indicators Buttons Each selects a corresponding camera, full-screen. LED 1 through 4 or 9 turns on when pressed. Button, Freezes any display in Live or Play mode. LED turns on FREEZE when pressed. Button, LIVE Selects Live mode.
- Page 27 Installation and Operation Manual Item Model Numbers Rack Mount Kit P/N 0110-R2A1 Replacement Manual P/N 0150-0147 Replacement Power Supply P/N 4010-0016 Power Supply Cables P/N 4310-0036 (230V, 50 Hz) Revision B 0150-0147...
- Page 28 Installation and Operation Manual This page intentionally left blank 0150-0147 Revision B...
-
Page 29: Standard Warranty Conditions
Aritech specifically disclaims, without limitation, any implied warranty of merchantability of fitness for a particular purpose. - Page 30 Installation and Operation Manual Upgrades Aritech reserves the right to make changes in design, or to make additions to, or improvements upon, this product without incurring any obligation to install the same on products previously manufactured. 0150-0147 Revision B...
- Page 31 Installation and Operation Manual ARITECH (EUROPE AND AFRICA) EXCELSIORLANN, 28 B-1930 zAVENTEM BELGIUM tel: 32-2-725 11 20 fax: 32-2-721 40 47 Revision B 0150-0147...
