- Page 1 Crosstrainer iConsole CTR 2.1 Owners manual For questions or missing parts, please contact Fitness Benelux: Twekkelerweg 263 +31 (0)74-7600219 Fitness 7553 LZ Hengelo service@fitnessbenelux.nl Benelux Benelux The N etherlands www.fitnessbenelux.nl Uw partner in fitness...
-
Page 2: Table Of Contents
CONTENT Safety Instruction Check List Assembly Instruction 7-16 Exploded Drawing Parts List 18-20 Computer Instruction 21-27 iConsole+ App Training Instruction Crosstrainer iConsole CTR 2.1... -
Page 3: Safety Instruction
Ensure that those present are aware of possible hazards, e.g. movable parts during training. Warning: incorrect/excessive training can cause health injuries. Consult your physician before staring with any exercise program. He or she can advise on the kind of training and which impact is suitable. Crosstrainer iConsole CTR 2.1... -
Page 4: Check List
Main frame Computer Rear stabilizer Front Stabilizer Footplate (Left) Water bottle holder Footplate (Right) Plastic cover for foot support bar(Left) Front bottom plastic cover (Left) Plastic cover for foot support bar(Right) Front bottom plastic cover (Right) Crosstrainer iConsole CTR 2.1... - Page 5 CHECKLIST (contents of packaging) Handlebar (Left) Handlebar (Right) Handlebar post Upper handlebar (Left) Upper handlebar (Right) Foot support bar (Left) Foot support bar (Right) Lower handlebar Rotation rod Adapter Crosstrainer iConsole CTR 2.1...
- Page 6 NO 91*4 NO 101*1 NO 29*5 NO 32*4 NO 86*4 NO 10*4 NO 11*4 NO 9*4 NO 11*2 NO 87*4 NO 14*2 NO 35*2 NO 88*4 NO 22*1 NO 27*2 NO 23*2 NO 24*2 NO 100*2 Crosstrainer iConsole CTR 2.1...
-
Page 7: Assembly Instruction
Cap nut (91) Tighten fully. Opmerking: U kunt de dop aan de achterkant verstellen om de crosstrainer stabiel te houden Note: You can adjust the Rear End Cap to keep the elliptical trainer stable. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1... - Page 8 Self tapping Screw M4x15mm (29) and Screw M5x15mm (30). II. Align the Front Bottom Plastic Cover (21L&21R) together by using Self-tapping Screw M3x15mm (22), Self tapping Screw M4x15mm (29) and Screw M5x15mm (30). Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
-
Page 9: Assembly Instruction
Lower Handlebars (17) onto the Rotation Rod and secure in place with Φ19.5*Φ38*0.5mm Flat Washer (11) and M8*20 Allen Bolt (14) for each side. Washer (18), Φ8.5*Φ36*3mm Flat Washer, M8 Spring Washer (11) and M8*20 Allen Bolt (14) for each side. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1... - Page 10 M8*20 Allen Bolt (14), M8 Spring Washer (11) and M8 Flat Washer (35) for each side. Tighten fully. place with M8*20 Allen Bolt (14), M8 Spring Washer (11) and M8 Flat Washer (35) for each side. Tighten fully. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
- Page 11 Attach the Plastic Covers (28L+28R) onto the Footplate Support Bars (33L+33R) using M4 Self tapping Screws (29) and M5 Screws (30). Align the Handlebar Post (95), So it is straight and then fully tighten the bolts. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
- Page 12 Attach Handlebars (3L+3R) by using M8 Allen Bolt (14) and M8 Flat Washer (92) for each side. Attach Handlebars (3L+3R) by using M8 Allen Bolt (14) and M8 Flat Washer (92) for each side. Make sure Make sure bolts are fully tightened. bolts are fully tightened. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
- Page 13 Attach the Upper Handlebar (8L+8R) onto the Lower Handlebar (17) by using M8 Allen Bolt (10), M8 Spring M8 Spring Washer (11) and M8 Curved Washer (9). Washer (11) and M8 Curved Washer (9). Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
- Page 14 Then Secure the Computer (1) with Handlebar Post by using M5 Screws (97). Then Secure the Computer (1) with Handlebar Post by using M5 Screws (97). Make sure all the bolts are fully Make sure all the bolts are fully tightened. tightened. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
- Page 15 Attach the Footplate (31L+31R) onto the Foot Support Bar (33L+33R) using M6 Carriage Bolts (32), M6 Flat M6 Flat Washers (88), M6 Spring Washers (87) and M6 Knob (86), tighten fully. Washers (88), M6 Spring Washers (87) and M6 Knob (86), tighten fully. Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1...
-
Page 16: Assembly Instruction
Place the Water Bottle Holder (19) into the hole in the front, by using Screw M5x20 mm (20). adapter, the adapter input (102) is at the back of the device. Now your machine is ready for use! Now ready for use! Crosstrainer iConsole CTR 2.1 Crosstrainer iConsole CTR 2.1... -
Page 17: Exploded Drawing
EXPLODED DRAWING Crosstrainer iConsole CTR 2.1... -
Page 18: Parts List
Plastic cover for foot support bar(Left) Plastic cover for foot support bar(Right) Self-tapping screw M4*15 Screw M5*15 Footplate (Left) Footplate (Right) Carriage bolt M6*50 Foot support bar (Left) Foot support bar (Right) Bushing Flat washer 8*28*2T Round cover Crosstrainer iConsole CTR 2.1... - Page 19 DC line Sensor Washer 20*25*2 Belt wheel Pedal Axle Anti-loose Allen bolt M8*12 Belt Hex head screw M6*12 Flat washer 6*13*1T Idler Axle for Idler Flat washer 10*19*1.5 Belt adjustment set 2 sets Waved washer Φ10*15*0.3T Crosstrainer iConsole CTR 2.1...
-
Page 20: Parts List
Front Stabilizer Cap nut M8 Flat washer 8*19*1.5T Main frame Lower tension cable Handlebar post Rotation rod Screw for computer M5*12 Upper tension cable Hex bolt M8*20 Allen key wrench with phillips head Combination wrench Adapter Crosstrainer iConsole CTR 2.1... -
Page 21: Computer Instruction
4. Start/ Stop Start of Stop uw workout 4. Start/ Stop Start or Stop workout. Vermeerder/Verminder waarde 5. Encoder 5. Encoder - Increase / Decrease Value. Bevestig/ waardeselectie - Confi rm / Setting selection. Crosstrainer iConsole CTR 2.1... - Page 22 Manual mode workout. PROGRAM 12 PROGRAM selections. USER User creates resistance level profi le. H.R.C. Target HR training mode. RECOVERY Heart rate recovery status BODY FAT Body fat measurement. WATTS Workout power consumption. Range 10 ~ 350. Crosstrainer iConsole CTR 2.1...
- Page 23 Door de knop te draaien kan u kiezen uit M(Handmatig)、P(Programma) 、♥ (H.R.C.)、 display. Door de knop te draaien kan u kiezen uit M(Handmatig)、P(Programma) 、♥ (H.R.C.)、 the matrix display with 1HZ. Turning the encoder can choose M(Manual), P(Program), ♥ (H.R.C.), W(Wattage)、U(Gebruiker). W(Wattage)、U(Gebruiker). W(Wattage)、U(Gebruiker). W(Watt), U(User) cyclically. Crosstrainer iConsole CTR 2.1...
- Page 24 STOP KEY could stop and all values would remain (HR signal would not effect). Pressing RESET KEY could De STOP knop stopt alles en de waarden blijven staan (HR signaal wordt niet aangetast). return to PROGRAM SELECT. (see fig. 4-3) De RESET knop laat u terug gaan naar PROGRAM SELECT. Crosstrainer iConsole CTR 2.1...
- Page 25 (2) Nadat u de tijd heeft ingesteld bij TIME kunt u op de START knop drukken om het programma te Tijdens het selecteren zal de standaardwaarde, gabaseerd op leeftijd, knipperen. starten. (2) Nadat u de tijd heeft ingesteld bij TIME kunt u op de START knop drukken om het programma te Crosstrainer iConsole CTR 2.1 starten.
- Page 26 Indien de gebruiker wenst te stoppen met instellen, het the same as last setting. ingestelde waarde. inhouden van de knop voor 2 seconden zorgt ervoor dat de waarde terug gaat naar de laatst ingestelde waarde. Crosstrainer iConsole CTR 2.1...
-
Page 27: Computer Instruction
Tijdens of na het meten drukt u op de RECOVERY knop in de laatste And after testing continue display real HR value. And after testing continue display real HR value. display te tonen. Na het testen zal de realtime hartslag worden weergegeven. Crosstrainer iConsole CTR 2.1... -
Page 28: Iconsole+ App
Android is available in English, German, Traditional Chinese, Simplifi ed Chinese. otherwise all others would display in English. iOS is available in English, Simplifi ed Chinese. The users can select their prefer language under those options, otherwise all others would display in English. Crosstrainer iConsole CTR 2.1... -
Page 29: Training Instruction
Veel plezier toegewenst met het gebruiken van de crosstrainer! For questions or missing parts, please contact Fitness Benelux: Twekkelerweg 263 +31 (0)74-7600219 Fitness 7553 LZ Hengelo service@fitnessbenelux.nl Benelux Benelux The N etherlands www.fitnessbenelux.nl Uw partner in fitness Crosstrainer iConsole CTR 2.1...
