HAKKEN SPZ-252U2i Instruction Manual

Diamond core drill
Hide thumbs
Table of Contents

Advertisement

Quick Links

DIAMOND CORE DRILL
SPZ-252U
i
2
INSTRUCTION MANUAL
◎ Thank you for purchasing our products.
◎ Before using, please read Instruction manual carefully, and use the machine
safely by following the instructions.
◎ After reading, please keep it where anyone can utilize.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPZ-252U2i and is the answer not in the manual?

Questions and answers

Related Manuals for HAKKEN SPZ-252U2i

Summary of Contents for HAKKEN SPZ-252U2i

  • Page 1 DIAMOND CORE DRILL SPZ-252U INSTRUCTION MANUAL ◎ Thank you for purchasing our products. ◎ Before using, please read Instruction manual carefully, and use the machine safely by following the instructions. ◎ After reading, please keep it where anyone can utilize.
  • Page 2 Read the operating instructions before use. Only for EU countries Disposal of electric tools together with household waste is not permissible! In observance of European Directive on waste electrical and electronic equipment and its implementation in accordance with national law, electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility.

  • Page 3: Table Of Contents

    CONTENTS 1.WARNING AND CAUTION 【1】 Safety Notice for Electric Tools ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 【2】 Notes for Usage of Core Drill ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 【3】 For Mounting Drill Carriage Assy. and Pole Base ・・・・・・・・・・・・・・・・・・・・ 2.DESCRIPTION ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3.SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4.STANDARD ACCESSORIES ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5.APPLICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6.GENERAL DRAWING AND SPECIFICATIONS IN OPERATION ・・・・・・・・・・・・・...

  • Page 4: Warning And Caution

    1. WARNING AND CAUTION ◎ To avoid the risk of fire, electric shock and personally injury, follow all the instruction mentioned in "Safety Notice for Electric Tools" and "Notes for Usage of Core Drill". ◎ Before using, please read "WARNING & CAUTION", and follow the instructions for your safety. ◎...
  • Page 5  WARNING 11. Use CONSEC recommended accessories and options. ◎ In case that you use the accessories and the options which are not listed in the manual or CONSEC's catalogue, it might cause the accidents or personal injury. Please do not use the accessories and the options which CONSEC does not recommend.

  • Page 6: Notes For Usage Of Core Drill

    【2】Notes for Usage of Core Drill (In case of combination with CONSEC's original Drill Carriage Assy. and Pole Base.)  WARNING 1. Check for the embedded conduit etc. ◎ In case that you contact to the electric wire or conduit in that there are electric current, you may receive the electric shocks.
  • Page 7  WARNING 15. Do not use the Core Bit which exceeds the maximum diameter of Core Bit. 16. Connection for water supply must be ensured. ◎ Water might be splashed to the electric tool or person in working area. 17. In case that Pole Base is fixed, ensure to fix it at stable place. 18.

  • Page 8: For Mounting Drill Carriage Assy. And Pole Base

    Core Drill. Use Drill Motor in one of the following ways. ◎ To combine with a genuine “HAKKEN” brand Drill Carriage Assy. and Pole Base. ◎ To combine with the CE marked Drill Carriage Assy. and Pole Base.

  • Page 9: Description

    2. DESCRIPTION Motor PRCD (Cord 2.4m) Water Cock Hose Band 00 (Standard Accessories) Plug Hose 12×250 (Standard Accessories) Carbon Cap Switch (Built-in Circuit Breaker) Name Plate Clamp Adjust Bolt （Hex. Socket Set Screw） Lock Dial G 1/2 (The inside of Main Shaft) Feeding Handle Unified screw (1-1/4”-7 UNC) Grip...

  • Page 10: Specifications

    3. SPECIFICATIONS Model SPZ-252U Motor Single phase series commutator Motor Power Supply Single-phase A.C. 230V 50Hz Rated Current 8.7A Max. Output 2400W No Load Speed 490 / 1150min Max. Bit Dia. 254mm 10” Core Bit Installing Screw Outside Unified screw (1-1/4”-7UNC) inside G 1/2 Drill Motor Weight (Excluding cord)

  • Page 11: General Drawing And Specifications In Operation

    6. GENERAL DRAWING AND SPECIFICATIONS IN OPERATION ◎ Drill Head installed on to □49 Pole Base. Drill Head Drill Motor □49 Drill Carriage Assy. Feeding Handle □49 Pole Base Bolt Square Washer Hex. Nut Leveling Bolt Core Bit Water Collector Fitting Water Collector －9－...

  • Page 12: Operational Instructions

    7. OPERATIONAL INSTRUCTIONS (Explanation referring to general drawing during operation.) 【1】 Anchoring Core Drill ◎ Core Drill can be anchored by means of Anchor Bolt, Vacuum Pad or Support Jack. Follow the below procedures for bolt anchor method. 【2】 Anchoring Core Drill by Anchor Bolt 1.Installation of anchor bolt 1) Drill anchor bolt hole, using a hammer drill.
  • Page 13 6.Arrangement for water supply ◎ Connect a hose between a water source and water cock using Hose Adapter.  WARNING Do not stop water supply during operation. 7.Core Drilling  WARNING When drilling a through-hole, take proper measures to provide for protection on the other side where Core Bit penetrates.

  • Page 14: Maintenance

    8. MAINTENANCE AND INSPECTION 【1】 Maintenance 1) Clean the surface of the machine after using. Regarding the outer frame of the Drill Head, the part of the gear case is made of aluminum, and the part of the motor is made of the sturdy synthetic resin. If gasoline, thinner, petroleum or kerosene are adhered to the outer frame of the Drill Head, the surface of the Drill Head will be damaged.
  • Page 15 2.Checking and adjustment of Drill Carriage Assy. (In case of combination with □49 Drill Carriage Assy.) ◎ Set Drill Head onto Pole Base. While moving feeding handle, tighten 4 pieces of hex. socket set screws on Drill Carriage Assy. in good balance with hex.
  • Page 16 5) After completion of 1) - 4), pull out Clutch Adjusting Pin. Hang Single-ended Wrench 36mm on the Main Shaft and then stick the main shaft by a handle of the wrench touching the pole. Make sure that the main shaft is locked.

  • Page 17: For Repairing

    0.8 meter from the floor during no-load operation. 11. WARRANTY We will guarantee the HAKKEN Core Drill SPZ-252U i for 6 months from the date of delivery. During this period we will rectify material and production defects free of charge. We are not responsible for any other damage direct nor indirect other than this.

  • Page 18: Ce Declaration Of Conformity

    12. CE DECLARATION OF CONFORMITY CONSEC CORPORATION 4-6-8 Shoko Center, Nishi-ku, Hiroshima 733-0833 Japan under We declare our sole responsibility that our below-mentioned products are in conformity with all the relevant provisions. Product Name : Diamond Core Drill Model : SPZ-252U Council Directive : 2006/95/EC , 2004/108/EC , 2006/42/EC Relative Standard...
  • Page 19 MEMO －17－...
  • Page 20 Main office : 4-6-8 Shoko Center Nishi-ku Hiroshima 733-0833 Japan International Department : 1-7-5-1, Sakaimachi, Naka-ku, Hiroshima, 730-0853 Japan Phone : 81-82-297-3231 Fax : 81-82-297-3230 E1930-1 －18－...
