Page 1: User Manual
MVF16 Interface AUDAC PROFESSIONAL AUDIO EQUIPMENT MVF16 Interface User Manual & Installation Guide... - Page 2 A U D A C P R O F E S S I O N A L A U D I O E Q U I P M E N T User Manual & Installation Guide AUDAC http://www.audac.be info@audac.be...
-
Page 3: Table Of Contents
Index INTRODUCTION ............................................3 ENVIRONMENT............................................. 4 SAFETY REQUIREMENTS ......................................... 4 CAUTION - SERVICING..........................................4 CONNECTIONS OF THE MVF16 INTERFACE..................................5 PIN-OUT ................................................6 EXAMPLE ................................................ 7 PERSONAL NOTES ............................................8 2 2 2 2... -
Page 4: Introduction
This section briefly describes the possibilities of the MVF16 interface. he MVF16 was developed to be used together with the INTER-M MVF2132 The MVF16 module provides 14 contacts which can be used to command the INTER-M MVF2132 via the serial interface. -
Page 5: Environment
Chapter Environment Do not place the unit in environments which contain high levels of dust, heat, moisture or vibration. Do not use the unit near water or other liquids. Make sure no water or other liquids can be spilled, dripped or splashed on the unit. This unit was developed for indoor use only. -
Page 6: Connections Of The Mvf16 Interface
Chapter Connections of the MVF16 interface The input contacts of the MVF16 interface should be operated by normal open switches. If a connection to ground is made, the corresponding track will play. If the connection is broken (the button was released), the track will be played completely. The fire alarm contact will stop the track immediately when the connection to ground is broken up. -
Page 7: Pin-Out
Pin-out 1: contact fire alarm (contact broken = track stops immediately) (track 1) 2: contact push – play (contact broken = track will be played completely) (track 2) 3: contact push – play (contact broken = track will be played completely) (track 3) 4: contact push –... -
Page 8: Example
Example To play track 3, close the switch. 7 7 7 7... -
Page 9: Personal Notes
Personal Notes 8 8 8 8...
