Summary of Contents for Lanner UP-2010
- Page 1 Network Communications Hardware Platforms for Network Computing UP-2010 V1.1 User's Manual Release Date: 2016/03/04...
-
Page 2: Overview
Resource Website installed and used in accordance with the instruction manual, may cause harmful interference to radio Lanner http://www.lannerinc.com communications. Operation of this equipment in a residential area is likely to cause harmful interference Product http://www.lannerinc.com/download-... - Page 3 Consignes de sécurité LITHIUM BATTERY CAUTION: Risk of Explosion if Battery is replaced by an incorrect type. Suivez ces consignes pour assurer la sécurité générale : Dispose of used batteries according to the instructions • Laissez la zone du châssis propre et sans poussière pendant et après l’installation.
-
Page 4: Table Of Contents
Block Diagram Front Components Rear Components Chapter 3: Motherboard Information Inside UP-2010 Jumpers & Connectors on the Intel Rangeley Main Board Jumpers & Connectors on the PCIe I/O Board Connectors and Jumpers List Jumper Settings & Connector Pinouts on the Intel Rangeley Main Board Jumper Settings &... -
Page 5: Chapter 1: Introduction
1U Rackmount Intel® Atom™ Processor Processor Options C2758 (4M Cache, 2.40 GHz) Platform Thank you for choosing Lanner UP-2010. Lanner Chipset UP-2010 is an enterprise-class 1U rackmount network 64Mb Flash Memory with BIOS security appliance with high-density Ethernet ports and AMI®... -
Page 6: Package Contents
Package Contents Ordering Information 24 ports RJ45 (Marvell 98DX3035) w/o Your package contains the following items: bypass, Intel® Atom™ Processor UP-2010 • 1 – WG-UP2010 POE Switch System C2718 (4MB Cache, 2.00 GHz) FC-BGA13E, Tray, MB-UP2010W + FCUPWG2010 • 2 – Power cable •... -
Page 7: Chapter 2: System Components
Chapter 2: System Components Mechanical Drawing... -
Page 8: Block Diagram
Block Diagram Intel DDR3 1600 Rangeley ECC SO-DIMM Platform CF Card C2758 PCIe x8 *2... -
Page 9: Front Components
Front Components Component Description Remarks F1 LED Indicators Power/Status/HDD F2 Console 1 x RJ-45 port to be connected with a terminal PC for diagnose and management purposes F3 USB 2.0 Ports 2 x USB 2.0 type A connectors. F4 Management 1 x RJ-45 management port F5 LAN ports 24 x Ethernet LAN ports... -
Page 10: Rear Components
Rear Components Component Description Remarks R1 Fan 2 x cooling fans R2 PSU 500W power supply unit... -
Page 11: Chapter 3: Motherboard Information
Chapter 3: Motherboard Information Inside UP-2010 The internal of UP-2010 is a composition of the Intel The main Intel Rangeley main board and a PCIe module board for high- Rangeley board density network ports powered by Marvell engines and Intel controllers. -
Page 12: Jumpers & Connectors On The Intel Rangeley Main Board
Jumpers & Connectors on the Intel Rangeley Main Board FAN2 FAN1 FAN3 DIMM2 JBAT1 DIMM1 SPIROM1 PS4S2 PCIE2 PS4S1 USB2 SATA 6G1 PKMB1 LPC1 PCIE1... -
Page 13: Jumpers & Connectors On The Pcie I/O Board
Jumpers & Connectors on the PCIe I/O Board PCIEC1 PWR2 PCIEC2 PWR1 SPIROM1 COM1 USB1... -
Page 14: Connectors And Jumpers List
Connectors and Jumpers List Connectors/Jumpers on the Intel Rangeley board Labels Function DIMM 1,2 2x DDR SO-DIMM sockets FAN1, 2, 3 3 x FAN connectors 1 x CompactFlash socket SATA6G1 1 x SATA port at 6Gbps interface PS4P1 1 x SATA 4-pin power connector PS4P2 1 x SATA DOM power connector PKMB1... -
Page 15: Jumper Settings & Connector Pinouts On The Intel Rangeley Main Board
Jumper Settings & Connector Pinouts on the Intel Rangeley Main Board CF1: CompactFlash socket J4: Reset mode setting Pin No. Description HW Reset Switch input (default 1-2) Pin No. Description Pin No. Description SW Reset DET1 CF_DD3 CF_DD11 CF_DD4 CF_DD12 CF_DD5 CF_DD13 CF_DD6... - Page 16 SATA6G1: SATA port PKMB1: keyboard/mouse pin header Pin No. Description Pin No. Description Pin No. Description +P5V_KM MS_L_CLK MS_L_DAT KB_L_DAT KB_L_CLK LPC1: Low Pin Count pin header PS4S1: SATA 4-pin power port Pin No. Description Pin No. Description CLK_33M_P80 LPC_AD1 PLTRST_PORT80_N LPC_AD0 Pin No.
- Page 17 PCIE1: PCIe x 8 lane socket PCIE2: PCIe x 8 lane socket Pin No. Side B Side A Pin No. Side B Side A +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V SMB_CLK CLK_EN +12V +12V SMB_DAT P3V3...
-
Page 18: Jumper Settings & Connector Pinouts On The Pcie I/O Board
Jumper Settings & Connector Pinouts on the COM1: RJ45 Console port PCIe I/O Board J6: MDC/MDIO I/F Option Pin No. Description Pin No. Description NRTS_N LNSINA LNSOUTA NCTS_N Pin No. Description SW_MDC0 SW_MDIO0 RJ1: RJ45 Connector w/transformer J5: Ethernet Switch debug port Pin No. - Page 19 RJ2/3: RJ45 8 Port Connector w/transformer (2X4) SPIROM1: SPI ROM Pin header Pin No. Description Pin No. Description SW_SPI_HOLD_N SPI_CS_N P3VSB SW_SPI_MISO SW_SPI_SCK SW_SPI_MOSI Pin No. Description Pin No. Description CN1 :Dual SFP+ connectors A/C/E/G 1 TDP0 B/D/F/H 1 TDP0 A/C/E/G 2 TDN0 B/D/F/H 2...
- Page 20 PCIEC1: PCIe x 8 lane connector (gold fingers) PCIEC2: PCIe x 8 lane connector (gold fingers) Pin No. Side B Side A Pin No. Side B Side A +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V...
-
Page 21: Chapter 4: Hardware Setup
Chapter 4: Hardware Setup Installing System Memories Preparing the Hardware Installation The system comes with 2 x 204-pin DDR3 SO-DIMM sockets up to 16GB each on the Intel Rangeley main WARNING: To reduce the risk of personal injury, board. Please follow the steps below for installations. electric shock, or damage to the equipment, please make sure the device is totally powered 1. -
Page 22: Installing A Compactflash Card
Installing a CompactFlash Card Replacing the PSU (Power Supply Unit) The system comes with a CF card slot on the Intel Please follow the instructions below to replace the power Rangeley main board. Please follow the steps below for supply unit in case it is worn out. installation. -
Page 23: Replacing The Cooling Fans
Replacing the Cooling Fans Please follow the instructions below to replace the cool- ing fans in case they are worn out. 1. Loosen and remove the 4 screws on the fan. 2. Remove the FAN connector(s) and take out the used fan. -
Page 24: Appendix A: Programming Watchdog Timer
Appendix A: Appendix B: Programming Watchdog Setting up Console Timer Redirections A watchdog timer is a piece of hardware that can be Console redirection lets you monitor and configure a used to automatically detect system anomalies and reset system from a remote terminal computer by re-directing the processor in case there are any problems. -
Page 25: Appendix C: On Linux
Appendix C: On Linux Assign an IP address to the interface by entering the Follow these instructions when installing the Intel® following, where <x> is the interface number: LAN controller base driver for the in Red Hat® and Linux ifconfig eth<x> <IP_address> operating system. -
Page 26: Appendix D: Terms And Conditions
Appendix D: RMA Service Requesting a RMA# Terms and Conditions To obtain a RMA number, simply fill out and fax the “RMA Request Form” to your supplier. Warranty Policy The customer is required to fill out the problem code as listed. If your problem is not among the codes All products are under warranty against defects in listed, please write the symptom description in the materials and workmanship for a period of one year...
