Bedienungsanleitung
k
PAVILLON „ROWA"
Instruction Manual
t
GAZEBO "ROWA"
Version 2017/
Art. Nr. 5540

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROWA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for tepro ROWA

  • Page 1 Bedienungsanleitung PAVILLON „ROWA“ Instruction Manual GAZEBO “ROWA” Version 2017/ Art. Nr. 5540...
  • Page 2 Dimensionen Pavillon 298 cm Gestell 12x2mm 12x2 20x20x 20x20x0.6 0,6mm 20x20x0,6mm 20x20x0.6 12x1.6 12x1,6mm 15x15x0,5mm 15x15x0.5 12x1,6mm 12x1.6 15x15x0,4mm 15x15x0.4 30x30x0.5 30x30x0,5mm 20x20x0.6 20x20x0,6mm...
  • Page 3: Table Of Contents

    Inhalt Bevor Sie das Produkt benutzen ................. 4 Lieferumfang ......................4 - 5 Bestimmungsgemäßer Gebrauch ................5 Zu Ihrer Sicherheit ....................5 - 6 Signalsymbole ......................5 Sicherheitshinweise ....................5 - 6 Montage ........................7 - 9 Vorbereitung ....................... 7 Aufbau ........................
  • Page 4: Bevor Sie Das Produkt Benutzen

    Bevor Sie das Produkt benutzen Paneel A2 Prüfen Sie nach dem Auspacken sowie vorne rechts vor jedem Gebrauch, ob der Artikel Schäden aufweist. Sollte dies der Fall sein, benutzen Sie den Artikel nicht, sondern benachrichtigen Sie Seitenpaneel bitte Ihren Händler. B x 3 Die Bedienungsanleitung basiert auf den in der Europäischen Union gültigen...
  • Page 5: Bestimmungsgemäßer Gebrauch

    Reklamationen nach erfolgter oder Vorsicht Geringes Risiko! angefangener Montage hinsichtlich Sachverhalte, beim Beschädigung oder fehlender Teile Umgang Gerät werden nicht anerkannt. beachtet werden sollten. Bestimmungsgemäßer Sicherheitshinweise Gebrauch Gefahr Unfallgefahr! Dieses Produkt nicht Ein Pavillon ist eine nicht ortsfeste, frei dafür bestimmt, durch stehende, für den nicht dauerhaften Einsatz,...
  • Page 6 – Vorsicht Feuer! Brandgefahr! Im Achtung Beschädigungsgefahr! oder in der Nähe des Pavillons darf Verwenden sie keine starken kein offenes Feuer z. B. Fackeln sowie oder schleifenden Lösemittel keine Grills oder Heizpilze platziert oder Scheuerpads, da diese werden. die Oberflächen angreifen und Scheuerspuren hinterlassen.
  • Page 7: Montage

    Montage Aufbau Vorbereitung Schritt 1 Gefahr Verletzungsgefahr! Nichtbeachtung Anweisungen kann Problemen und Gefahren bei der Verwendung des Pavillons führen. – Achten Sie beim Aufbau darauf, sich nicht die Finger zu klemmen oder an scharfen Kanten zu verletzten. 1. Beachten Sie die Abbildungen der Montageschritte und lesen Sie sich diese Bedienungsanleitung zunächst vollständig durch.
  • Page 8 Schritt 3 Schritt 5 Heben Sie die Dachkonstruktion an und stecken Sie die Dachstreben in die Paneelverbindungen (C) und die Paneele (A, A1, A2). Hängen Sie die Paneelverbindungen (C) oben zwischen den Paneelen (A, A1, A2) ein. Schritt 6 Schritt 4 Befestigen sie die Dachspitze (M) auf dem Dachkreuz (D).
  • Page 9 Schritt 7 Schritt 9 Knoten Sie die Spannseile (N) oben an die Paneele. Knoten Sie jeweils einen Hering (L) an die Enden der Spannseile. Ziehen Sie die Spannseile in einem Winkel von ca. 45° stramm zum Boden. Schlagen Hering entsprechender Stelle ein. Achten Sie dabei auf eine gute Spannung.
  • Page 10: Wartung Und Pflege

    • An den Nähten des Textilmaterials Produkt: Art. Nr. 5540, können anfangs Wassertropfen Pavillon „Rowa“ creme durchdringen. Mit der Zeit setzen sich Staubpartikel in die feinen Nahtlöcher Gewicht: ca. 41,5 kg und dichten diese ab. • Verwenden Sie zum Abdichten ggf. im Gesamtmaße,...
  • Page 11: Service

    Inverkehrbringer tepro Garten GmbH Carl-Zeiss-Straße 8/4 D-63322 Rödermark Email: info@tepro-gmbh.de oder backoffice@tepro-gmbh.de Web: www.tepro-gmbh.de Service Bei technischen Fragen wenden Sie sich bitte an den Service. Dieses Produkt wurde sorgfältig hergestellt und verpackt. Sollte es dennoch einmal Grund zur Beanstandung geben,...
  • Page 12 Dimensions Gazebo 298 cm Frame 12x2mm 12x2 20x20x 20x20x0.6 0.6mm 20x20x0.6mm 20x20x0.6 12x1.6 12x1.6mm 15x15x0.5mm 15x15x0.5 12x1.6mm 12x1.6 15x15x0.4mm 15x15x0.4 30x30x0.5 30x30x0.5mm 20x20x0.6 20x20x0.6mm...
  • Page 13 Contents Before using the product ..................... 14 Scope of delivery ....................14 - 15 Intended use ......................... 15 For your safety....................... 15 - 16 Signal symbols ......................15 Safety instructions ..................... 15 - 16 Assembly........................ 17 - 19 Preparation ....................... 17 Setup .........................
  • Page 14: Before Using The Product

    Before using the product After unpacking and before every use, check whether the item shows any signs Panel A2 of damage. front right Should this be the case, do not use the item, but notify your retailer. The operating manual is based on the Side panel norms and regulations that are applicable in the European Union.
  • Page 15: Intended Use

    be missing or defective, please contact Caution Low risk! your dealer. Facts that should be respected Claims relating to damages or missing when handling the device. parts made after assembly has taken place or commenced will not be recognised. Safety instructions Danger Risk of accidents! Intended use This product is not intended for...
  • Page 16 The gazebo is not suitable for year- Attention Risk of damage! round installation outdoors, since it Do not use any strong or is not able to withstand strong winds, grinding solvents or abrasive storms, hail, snow, or the like. pads, since these can attack –...
  • Page 17: Assembly

    Assembly Setup Preparation Step 1 Danger Risk of injury! Failure to follow the instructions can lead to problems and dangers when using gazebo. – During setup take care not to jam your fingers or injure yourself on sharp edges. 1. Pay attention to the figures accompanying the assembly steps and read through this instruction manual thoroughly first.
  • Page 18 Step 3 Step 5 Raise the roof construction and stick the trusses into the panel connections (C) and the panels (A, A1, A2). Hang the panel connections (C) in place, above, between the panels (A, A1, A2). Step 6 Step 4 Fasten the roof tip (M) to the roof cross piece (D).
  • Page 19 Step 7 Step 9 Knot the tension ropes (N) above to the panels. Knot one tent peg (L) to the ends of each of the tension ropes. Pull the tension ropes at an angle of approx. 45° tightly to the ground. Drive the tent pegs into the ground at those locations.
  • Page 20: Care And Maintenance

    • At the stitches of the textile material, drops of water can initially get through. Product: Item No. 5540, Gazebo With time, dust particles enter these “Rowa” creme fine stitching holes and seal these up. Weight: approx. 41.5 kg • If needed, use a commercially available seam sealer.
  • Page 21: Service

    Distributor tepro Garten GmbH Carl-Zeiss-Straße 8/4 D-63322 Rödermark Email: info@tepro-gmbh.de or backoffice@tepro-gmbh.de Web: www.tepro-gmbh.de Service Please contact our service point for assistance with technical questions. This product was carefully manufactured and packaged. Should you nevertheless have a complaint, our employees are more than happy to assist.
