Summary of Contents for nxt C3700
-
Page 2: Table Of Contents
1.Live 2.Guide 3. My Content 4. Settings 5. Features 6. Diagnostics... - Page 3 This user's guide covers the installation Skyworth C3700 set-top box which includes step by step configuration of all features available Information captured in this document is subject to change. Skyworth reserves the right, to carry out changes in the product design and specifications in line with engineering and technology advancements.
- Page 4 1. Read, follow and keep these instructions safely. 2. Heed all warnings. 1. Do not use this apparatus near water. 2. Clean only with dry cloth. 3. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 4.
- Page 5 Packing items RCA cable External Power supply...
- Page 6 Stand by mode or program watching state HELP Display help and diagnostic information Number pad to enter menu item or to select a channel Switch between TV and Radio mode Switches back to previous channel or menu BACK Displays EPG menu Select language for audio channels LANG Display program synopsis information of the...
- Page 7 Front Panel Rear Panel CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER COMPOSITE VIDEO BROADCAST SIGNAL CONNECT TO USB DEVICE CABLE IN: CONNECT TO CABLE SIGNAL LOOP OUT: CONNECT TO ANOTHER RECEIVER The picture is for reference only. Your equipment may be configured differently.
- Page 8 PREPARATION OF REMOTE CONTROL 1. Open the battery cover. 2. Insert the batteries in the correct direction. Please ensure that the anode and cathode ends of the battery are corresponding to the polarity indicated in the remote control. 3. Replace the battery cover. OPERATION SCOPE OF THE REMOTE CONTROL Point the remote control towards the Set Top Box in order...
-
Page 10: Live
Once you have installed and powered on the Set Top Box the main menu list will be displayed as follows: - Live - Guide - My Content - Settings - Features - Diagnostics Use these keys to navigate up/down and select required options Use these keys to navigate main menu and left /right to select the required options. -
Page 11: Settings
3.1 Scheduled Recordings Show scheduled recordings. 3.2 My Recordings All shows you record will be listed in this menu. You can see the recorded shows on the right side of the screen. 3.3 Disk Space Usage This displays how much disk space you have already used. To re-format the harddisk press the red key on your remote control unit. - Page 12 4.1.3 Language This menu allows you to select from different languages (if available) for display menus and different audio tracks. 4.1.4 Screen Saver This menu allows you to select when screensavers should come on the set top box. 4.1.5 Opacity Level This menu allows you to select how transparent the menus should be on screen.
-
Page 13: Features
4.4 Timers a. Reminders: These are notifications for shows that you want to be reminded about. This menu allows you to customise how reminders are set and when notifications should appear. b. Notification: Select when notifications should appear on the set top box c. -
Page 14: Diagnostics
5.2 Mail Select this menu in order to see messages that have been sent to you by NXT Digital. 5.3 Search 5.3.1 Search Guide Select this menu in order to search for specific programmes or information on your Set Top Box. - Page 15 6.2 CA Information Select this menu to show all conditional access information relating to this set top box. 5.3 Secure Device Select this menu to show device security information.
- Page 16 Problem Possible causes What to do Check that the main cable is plugged into The display on the front Mains cable is not properly connected panel does not light up. the power socket. or faulty. No sound or picture, but the Press the standby button on the remote receiver is in standby mode.
