Summary of Contents for Masterclock CS5-LAN
- Page 1 Masterclock CS5 Lan Network Injector User Manual – v2014.01.16...
-
Page 2: Table Of Contents
See important limited warranty information starting on page 18. Masterclock CS5 Lan Network Injector User Manual – v2014.01.16... -
Page 3: Introduction
Flashing indicates no CS5 RS422 input is present Flashing indicates a network interruption, preventing the OFF indicate the network cable is disconnected unit from multicasting OFF indicate the network cable is disconnected Masterclock CS5 Lan Network Injector User Manual – v2014.01.16... -
Page 4: Installation
WinDiscovery. If you have not already downloaded WinDiscovery for another Masterclock product, you should do so now for your Masterclock CS5 LAN Injector. On the following page is the preferred wiring diagram for the Masterclock CS5 LAN Injector. -
Page 5: Reset To Factory Default
3. The unit will go through an initialization process. WinDiscovery Installation and Operation Included on the CD with your Masterclock CS5 LAN Injector is the WinDiscovery software application for detection, configuration and management of all your NTP devices from Masterclock. - Page 6 [Network Configuration] button. DEVICE SETTINGS (DS) The “Device Settings” window (lower left) configures the Masterclock CS5 LAN INJECTOR to receive and display in the format that you prefer. The top right section of the “Device Settings” window shows a list of the firmware and options associated with your Masterclock CS5 LAN INJECTOR.
- Page 7 [Clear All Device Assignments] button This feature allows the end user to clear all associations between all the MASTERCLOCK CS5 LAN INJECTOR s and all the clock displays. By clicking [Ok], all MASTERCLOCK CS5 LAN Injectors and clock displays on the network will have their assignments cleared.
- Page 8 DS > STATUS At the bottom left of the “Masterclock CS5 LAN Injector” window is the [Status] button. The “Masterclock CS5 LAN Injector” window includes a “Display Snapshot” of a graphic digital clock representing the face of the actual Masterclock CS5 LAN Injector in real time.
- Page 9 SET PASSWORD Each Masterclock device in your network may have its own password (see the “Properties” window to [Set Password]), or you may create a Global Password on the “Discover” window (see below). The default password is “public”. Your custom password should be one to eleven characters and is case-sensitive.
-
Page 10: Telnet
Open the Windows Control Panel, click on [Programs], click on [Turn Windows features on or off], check [√] Telnet Client and click [OK]. TO ENABLE TELNET IN LINUX See your system administrator. Masterclock CS5 Lan Network Injector User Manual – v2014.01.16... -
Page 11: Problems - Troubleshooting
2. The discovery process was not complete. After selecting the [Discover] button, wait until the discovery status indicates 100% completion 3. Verify that the MASTERCLOCK CS5 LAN INJECTOR is on the same physical network as the computer from which you are running WinDiscovery 4. - Page 12 In some cases, it may not be discovered in the WinDiscovery device tree. PROBLEM: Devices which have been assigned a MASTERCLOCK CS5 LAN INJECTOR appears in RED text under fallback IP address of 169.254.xxx.xxx will WinDiscovery device tree be displayed in the main WinDiscovery window with RED text, indicating a problem with the configuration.
- Page 13 2. If the device cannot resolve its DHCP mode, the unit will periodically perform a soft restart to reinitialize its communication port and DHCP configuration. 3. If the MASTERCLOCK CS5 LAN INJECTOR has no valid DNS server (or it is down) hesitations similar to those described in #1 will occur.
- Page 14 Configuration section. After the clock has been reset to factory defaults, the unit must be reconfigured. 2. The factory default password is “public”. Masterclock CS5 Lan Network Injector User Manual – v2014.01.16...
-
Page 15: Specifications
The CS5 automatically cycles through all possible baud rates using CS-524z protocol. CS-524z = 6 for 4800 baud rate = 7 for 9600 baud rate = 8 for 19,200 baud rate = 9 for 38,400 baud rate Masterclock CS5 Lan Network Injector User Manual – v2014.01.16... -
Page 16: Limited Warranty And Service
Masterclock warrants this Masterclock CS5 LAN Injector against defects in materials and workmanship for a period of one year from the date of sale. If Masterclock receives notice of such defects during the warranty period, Masterclock will, at its option, either repair or replace products that prove to be defective. -
Page 17: Certificates Of Conformity
Masterclock CS5 Lan Network Injector User Manual – v2014.01.16... - Page 18 Masterclock CS5 Lan Network Injector User Manual – v2014.01.16...
-
Page 19: Contact Information
Contact Us Masterclock, Inc. 2484 West Clay Street St. Charles, MO 63301 USA website www.masterclock.com USA and Canada 1-800-940-2248 1-636-724-3666 1-636-724-3776 (fax) International 1-636-724-3666 1-636-724-3776 (fax) Sales sales@masterclock.com Technical Support support@masterclock.com Masterclock CS5 Lan Network Injector User Manual – v2014.01.16...
