Summary of Contents for MicroDigial MDC-4 SERIES
-
Page 1: User Manual
www.microdigital.co.kr USER MANUAL Supreme Resolution Day & Night Color Camera... - Page 2 USER INFORMATION CAUTION CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN NO USER-SERVICEABLE PARTS INSIDE. REFER FOR SERVICING TO QUALIFIED SERVICE PERSONNEL. THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSISTING OF A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT. THIS EXCLAMATION POINT SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE...
- Page 3 USER INFORMATION ◆ Information • This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 USER INFORMATION PRECAUTIONS Only use the camera under conditions where • Do not install the camera temperatures are between -10°C and +50°C. in extreme temperature Be especially careful to provide ventilation conditions. when operating under high temperatures. • Do not install or use the cam- era in an environment where It can cause the image quality to be poor.
- Page 5 USER INFORMATION Ignoring this information may result in material loss and/or serious Indicates “Never Allowed.” personal injuries including death. Ignoring this information may Indicates “No Disas- result in material loss and/or a sembling.” slight injuries. • Exposure to a spotlight or an object emitting strong light may cause smear or blooming. •...
-
Page 6: Table Of Contents
CONTENTS • DESCRIPTION 8 - 10 • SPECIFICATION 11 - 12 • FEATURES 13 - 14 • COMPONENTS 15 - 29 15 - 17 ▪ BOX CAMERA ▪ BULLET CAMERA 18 - 24 ▪ DOME CAMERA 25 - 27 28 - 29 ▪... - Page 7 CONTENTS • OSD STRUCTURE -MAIN MENU • LENS • 46 - 48 EXPOSURE ▪ SHUTTER ▪ AGC ▪ SENS-UP ▪ BLC ▪ D-WDR ▪ RETURN • 49 - 50 WHITE BALANCE • 51 - 52 DAY & NIGHT • 3D DNR •...
-
Page 8: Description
DESCRIPTION Before operating the camera, confirm the camera model and proper input power voltage. In order to help you understand this manual thoroughly, we’ll introduce our model description. ◆ MODEL DESCRIPTION • EX) MDC - H8220 TDN - 30 HU Built in Heater / UTC Number of IR-LED H 8 2 2 0... - Page 9 DESCRIPTION CASE TYPE MODEL COLOR PIXEL POWER IR/HEATER TYPE LENS / CASE 1: MINI BULLET i : IP 1: B/W 1: 270K 0: DC 12V IR : No. of 2: MODULE H : HD 2: COLOR 2: 520K 1: DUAL IR-LED 3: MINI SQUARE 6: 1.3M...
-
Page 10: Description
DESCRIPTION PRECAUTIONS DAY / NIGHT FILTER & MECHANISM DAY / NIGHT DIGITAL DAY / NIGHT Fixed Fixed LENS DAY / NIGHT DIGITAL DAY / NIGHT VARIFOCAL VARIFOCAL DC Auto LENS Iris Lens DAY / NIGHT DIGITAL DAY / NIGHT VARIFOCAL VARIFOCAL DC Auto LENS... -
Page 11: Specification
SPECIFICATION Signal System NTSC Scanning Frequency 15,734KHz(H), 59.94Hz(V) 15,625KHz(H), 50.00Hz(V) Image Sensor 1/3” Interline Transfer Type High Sensitivity Color CCD Sync. System INT / LL Total Pixels Number 1020(H) X 508(V), 520K pixels 1020(H) X 596(V), 610K pixels Effective Pixels Number 976(H) x 494(V), 480K pixels 976(H) x 582(V), 570K pixels Horizontal Resolution... -
Page 12: Specification
SPECIFICATION LENS MODEL TYPE LENS C / CS MOUNT MDC-4xxx C / CS MOUNT (ICR-IR Cut Filter Removable Mechanism) 35H, 45, 40H, 32 Filter Changeable Vari-Focal 6.0~50.0mm DC Auto Iris Lens 20, 20H, 36H, 48 Filter Changeable Vari-Focal 3.5~16.0mm DC Auto Iris Lens MDC-6xxx 24H, 42 32U, 40HU... -
Page 13: Features
FEATURES 1/3” Interline Transfer Type High Sensitivity Color CCD 1/3” IT 700TV Lines The combination of a 1/3” Interline Transfer Type High Sensitivity Color CCD and DNR DSP provides an excellent resolution of 700 TV lines. 700 TV LINE Min. Illumination With an incredibly Minimum Illuminatio of Amazing 0.0001Lux can Capture Good Images Even in Extremely Low Light Conditions and Related Noises are Significantly Reduced by the Ultra Advanced DNR(Digital Noise Reduc-... -
Page 14: Features
FEATURES DIGITAL ZOOM Digital zoom available, OFF(x1) / ON(x2~x32) can be selected IR SMART It enables users to distinguish the indistinguishable images saturated by SMART IR LED. Additional Functions 1. OSD - ON Screen Display menu with multi-Language support. 2. FreeArea Selectable function of BLC and MOTION DETECTION 3. -
Page 15: Components
COMPONENTS 1. Camera 2. Manual MICRODIGITAL Width Height depth MICRODIGITAL... -
Page 16: Over View
COMPONENTS MDC-4220CDN / TDN Over view Back focus clamp Camera mounting screw hole. screw & Hole 1 Lens protection cap 2 CS-MOUNT Lens adaptor 1 Lens protection cap Cover the lens when not in use. 2 CS-mount lens adaptor Attach the CS-mount lens here, and if you want to use C-mount lens, also please attach C-ring to the CS-mount and then also 3 Back focus clamp screw Loosen the clamp screw with a L-Wrench before adjusting the Back Focal length. -
Page 17: Rear View
COMPONENTS Rear view 1 Auto iris lens connector Connection terminal for an auto iris lens. 2 Video output terminal Sends video signals and connects to the video input terminal of the monitor. 3 Power lamp Lights up when the correct power is supplied to the camera. 4 OSD button 5 Power input terminal : Low voltage power connection. -
Page 18: Bullet Camera
COMPONENTS 1. Varifocal IR Bullet Camera 2. Cable for Extra Video 3. L-WRENCH 4. Screw for Installation 5. Manual MICRODIGITAL... - Page 19 COMPONENTS MDC-6220TDN-20 & 20H (65Ø)/24H(U)42(U)(75Ø) 1 Lens 2 IR-LED / Heater (Option) 3 Zoom / Focus Lever 4 OSD Joystick (Option) 5 Cable Management Bracket 6 VBS-Extra for connecting to LCD (Option) VBS-EXTRA MICRODIGITAL...
- Page 20 COMPONENTS Dimension MDC-6220 24H(U) 42(U) Dimension Diameter 65ø 75ø Width Length 20pcs 20pcs IR LED 20pcs 42pcs IR-LED, IR-LED, & Heater IR LED IR LED 4pcs Heater 4pcs Heater Power Consumption Normal 140mA IR LED ON 320mA 350mA 500mA Heater ON 460mA 480mA ▶Specifications and Designs are subject to change without prior notice due to improvement...
- Page 21 COMPONENTS MDC-6220TDN-32 & 40H (90Ø) 1 Lens 2 IR-LED / Heater (Option) 3 Zoom / Focus Lever 4 OSD Joystick (Option) 5 Cable Management Bracket 6 VBS-Extra for connecting to LCD (Option) VBS-EXTRA MICRODIGITAL...
- Page 22 COMPONENTS Dimension MDC-6220 32(U) 40H(U) Dimension Diameter 90ø Width Length IR LED & 32pcs Giant 16pcs Giant / 24pcs IR-LED, Heater IR-LED 4pcs Heaters Power Consumption Normal 140mA IR LED ON 570mA 440mA Heater ON 570mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...
- Page 23 COMPONENTS MDC-6220TDN-35H & 45(76Ø) / 36H & 48 (95Ø) 1 Lens 2 IR-LED / Heater (Option) 3 Zoom / Focus Ring 4 OSD Joystick 5 Cable Management Bracket FOCUS ZOOM MICRODIGITAL...
- Page 24 COMPONENTS Dimension MDC-6220VTD Dimension Diameter 95ø 76ø Width 92.3 Length 12pcs Giant 12pcs Giant 36pcs / 23pcs 48pcs IR LED & Heater & 33pcs IR-LED & IR-LED & IR-LED IR-LED 3pcs Heater 4pcs Heater Power Consumption Normal 140mA IR LED ON 520mA 620mA 480mA...
-
Page 25: Dome Camera
COMPONENTS Vandal Resistant Dome Camera Vandal Resistant Dome Camera (Surface Type) (Surface Type) Service Monitor Cable Manual L-Wrench Mounting Screw Vandal Resistant Dome Camera (Flush Type) L-Wrench Tapping Screw Manual Service Monitor Cable Surface Mount Bracket Surface Mount Screw MICRODIGITAL... - Page 26 COMPONENTS MDC-7220FDN (68Ø) / 7220VDN, TDN, TDN-30 (100Ø) 1 Lens 2 3 Axis bracket · Adjust the pan and tilt to give the correct angle of view. 3 OSD Joystick / Board 4 VBS-Extra for connecting to LCD · Please use the supplied wire when connecting to an external monitor. 5 IR LED MDC-7220VDN / TDN MDC-7220FDN...
- Page 27 COMPONENTS Dimension MDC-7220V TD-30 (100Φ) MDC-7220V / VTD (100Φ) MDC-7220F (68Φ) MDC-7220 VTD-30 Dimension Diameter 68ø 100ø Width Height 30pcs IR LED IR-LED Power Consumption Normal 150mA 170mA IR LED ON 450mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL...
- Page 28 COMPONENTS MDC-8220VDN / TDN-30, 30H (100Ø) 1 Lens 2 IR-LED 3 OSD Board / Heater (Option : 6pcs) 4 Zoom / Focus Lever 5 VBS-Extra for connecting to LCD · Please use the supplied wire when connecting to an external monitor. 6 3 Axis bracket ·...
-
Page 29: Components
COMPONENTS Dimension MDC-8220 TDN-30 TDN-30H Dimension Diameter 100ø Height 115mm Width 145mm 30pcs 30pcs IR LED IR-LED, 6pcs IR-LED Heater Power Consumption Normal 200mA IR LED ON 400mA 400mA Heater ON 460mA ▶Specifications and Designs are subject to change without prior notice due to improvement MICRODIGITAL... -
Page 30: Installation
INSTALLATION MDC-4xxx Lens • The camera is supplied without a lens. Lenses, such as auto iris, CS-Mount and C-Mount, can be used. ▹When using an auto iris lens Strip back about 8mm of the outer sheath of the auto iris lens cable. ·... - Page 31 INSTALLATION VIDEO TYPE LENS DC TYPE LENS PIN NO. NAME WIRE COLOR NAME WIRE COLOR OPEN NOT USE DAMP COIL - GREEN VIDEO WHITE DAMP COIL + RED POWER DRIVE COIL + BLACK GROUND BLACK DRIVE COIL - BROWN Replace the auto iris lens connection plug cover. Remove the lens ·...
- Page 32 INSTALLATION MDC-6xxx • There are three ~ four mounting holes on the bracket so that users can install the unit in any place such as on the ceiling, On the wall, on the fence and etc. • Fix the camera on the bracket. •...
- Page 33 INSTALLATION MDC-7xxx • Open the dome with the ring unscrewed. • There are two mounting holes on the dome base so that users can install the unit in any place such as on the ceiling, on the wall, on the fence and etc. •...
- Page 34 INSTALLATION MDC-8xxx • Open the dome cover on the base by L-Wrench. • Remove the tapping screw on the dome camera base by screw driver. Surface type ▶ · Fixed the surface mount bracket to a ceiling using three mounting screw. ·...
-
Page 35: Installation
INSTALLATION MDC-8xxx Flush type ▶ · Remove the surface mount bracket then insert dome camera base into the drilled holes. · Draw out power/video wires to the connecting places. · Fixed the dome camera base to a ceiling using three mounting screw. •... -
Page 36: Osd Operation
OSD OPERATION MDC-4xxx 1) Connection to Monitor Camera Monitor - As the connecting method varies with the instruments, refer to the manual sup- plied with the instrument. - If necessary, you can connect the monitor to the REMOTE jack on the back of your camera. - Page 37 OSD OPERATION MDC-4xxx Settings can be made using the 4 or 5 buttons located on the nearby of the camera. Camera MENU LEFT RIGHT DOWN MDC-6xxx 1) Connection to Monitor Power Input - As the connecting method varies with the instruments, refer to the manual sup- plied with the instrument.
- Page 38 OSD OPERATION MDC-6xxx Power Input 2) Connection to Power - Connect the adaptor to the power input connector as shown in the following figure. The Standard voltage for camera option : DC 12V± 10%, AC 24V ±10%. ▪ Nomal we donnot use the RS-485 addisional cable. only have power and video Connecting to Monitor and Power Video Output For 12V DC Power Type...
- Page 39 OSD OPERATION MDC-6xxx Push(set) MDC-6220TDN -35H, 36H, 45, 48 ♦ Unscrew the OSD button cap MDC-6220TDN-20 / 20H MDC-6220TDN ♦ Unscrew the front cover -24H, 42, 30, 40H ♦ Unscrew the front cover MICRODIGITAL...
- Page 40 OSD OPERATION MDC-7xxx Push(set) MDC-7220FDN ♦ Unscrew the dome cover Push(set) MDC-7220VDN / TDN / TDN-30 ♦ Unscrew the dome cover MICRODIGITAL...
- Page 41 OSD OPERATION MDC-8xxx Without Heater type OSD Board VBS-Extra OSD Joystick Connector With Heater type OSD Board Power Module connector connector MICRODIGITAL...
-
Page 42: Osd Operation
OSD OPERATION UTC CONTROLLER ▶CONNECTION ▪Camera(BNC) ➜Remote Controller ➜ BNC ➜ Monitor / DVR Remote Controller Monitor / DVR Remote Controller CONNECTOR ▶UTC Specification Content Spec Remark Support VIDEO format NTSC / PAL Video Input Level 1.0 Vp-p / 75 Ohm BNC Video Output Level 1.0 Vp-p / 75 Ohm BNC Control... -
Page 43: Instructions
INSTRUCTIONS OSD(On Screen Display) Button ▹ SET button • Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. ▹ UP & DOWN buttons • Used for selecting items by moving the cursor up or down on the menu screen. ▹... -
Page 44: Osd Structure
OSD STRUCTURE Function Menu Structure ■ DC / VIDEO / MANUAL LENS ■ SHUTTER ■ BLC • 1/50~1/100K / x2~x256 /AUTO / FLK • OFF / BLC / HSBLC ■ AGC ■ D-WDR EXPOSURE • LOW / MIDDLE / HIGH •... -
Page 45: Lens
OSD STRUCTURE- MAIN MENU LENS ▹ This function is Control brightness of the screen • DC : select auto iris lens · The brightness of the screen can be adjusted in DC mode. · The brightness can be adjusted within the range of 0 ~100. ·... -
Page 46: Exposure
OSD STRUCTURE- MAIN MENU EXPOSURE MAIN MENU EXPOSEURE MODE OFF(INDOOR,OUTDOOR) 1. LENS DC (MAUAL ) SHUTTER AUTO( FLK , OFF ) 2. EXPOSURE HIGH(LOW , MIDDLE) 3. BACKLIGHT DWDR SENSUP AUTO (OFF) 4. WHITE BAL. RETURN RET (SAVE & END ) 5. -
Page 47: Blc
OSD STRUCTURE- MAIN MENU BACKLIGHT MAIN MENU 1. LENS DC (MAUAL ) 2. EXPOSURE 3. BACKLIGHT D-WDR DWDR (BLC ,HSBLC ,OFF) 4. WHITE BAL. 5. DAY & NIGHT 1. LOW LEVEL ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 8 AUTO 6. SMART 3DNR 2. HIGH LEVEL ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙... -
Page 48: White Bal
OSD STRUCTURE- MAIN MENU MAIN MENU 1. LENS 2. EXPOSURE F – DNR AUTO 3. BACKLIGHT BLC ,(HSBLC ,OFF) 4. WHITE BAL. 1. DETECT LEVEL ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 3 5. DAY & NIGHT AUTO 2. RETURN RET (SAVE & END ) 6. SMART 3DNR 7. -
Page 49: Return
OSD STRUCTURE- MAIN MENU DAY & NIGHT MAIN MENU 1. LENS 2. EXPOSURE D & N AUTO 3. BACKLIGHT DWDR 4. WHITE BAL. 1. DELAY ∙∙∙∙∙I∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 5. DAY & NIGHT AUTO (EXT ,B/W ,COLOR) 2. D N(AGC) ∙∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙ 118 6. -
Page 50: Dnr
OSD STRUCTURE- MAIN MENU SMART 3DNR MAIN MENU SMART 3DNR 1. VALUE ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 50 1. LENS 2. SMART NR OFF(ON) 2. EXPOSURE 3. SMART LEVEL - - - 3. BACKLIGHT DWDR 4. SENSITIVITY - - - 4. WHITE BAL. 5. RETURN RET (SAVE &... - Page 51 OSD STRUCTURE- MAIN MENU FUCNTION MOTION 1. MOTION ON (OFF) 1. AREA 1(2, 3, 4 ) 2. PRIVACY OFF(ON ) 2. AREA DISPLAY ON (OFF) 3. D-EFFECT 3. VALUE ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 80 4. IMAGE ADJ 4. MOTION VIEW ON (OFF) 5. COMM ADJ 5.
- Page 52 OSD STRUCTURE- MAIN MENU FUCNTION D-EFFECT 1. D-ZOOM OFF(ON) 1. MOTION ON (OFF) 2. SMART DZOOM OFF(ON ) 2. PRIVACY OFF(ON ) 3. DIS OFF(ON) 3. D-EFFECT 4. FREEZE OFF(ON) 4. IMAGE ADJ 5. MIRROR OFF(ROTATE, 5. COMM ADJ V-FLIP, MIRROR) 6.
-
Page 53: Image Adj
OSD STRUCTURE- MAIN MENU FUCNTION IMAGE ADJ 1. SHARPNESS ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 20 1. MOTION ON (OFF) 2. MONITOR LED (CRT ) 2. PRIVACY OFF(ON ) 3. LENS SHADING OFF(ON ) 3. D-EFFECT 4. DEFECT 4. IMAGE ADJ 5. RETURN RET (SAVE & END ) 5. -
Page 54: Defect
OSD STRUCTURE- MAIN MENU IMAGE ADJ LENS SHADING 1. SHARPNESS ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 20 1. LEVEL ∙∙∙∙∙I∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 2. MONITOR LED (CRT ) 2. H-CENTER ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 103 3. LENS SHADING ON(OFF ) 3. V-CENTER ∙∙∙∙∙∙∙∙∙I∙∙∙∙∙∙∙∙∙ 103 4. DEFECT 4. RETURN RET (SAVE & END ) 5. -
Page 55: Reset
OSD STRUCTURE- MAIN MENU FUCNTION COM ADJ 1. MOTION ON (OFF) 1. CAM TITLE OFF(ON ) 2. PRIVACY OFF(ON ) 2. PROTOCOL PELCO-D (NICP, DONG 3. D-EFFECT YANG, SPD-S, PELCO-P) 4. IMAGE ADJ 3. RS485 5. COMM ADJ 4. RETURN RET (SAVE &... - Page 56 TOTAL SECURITY SOLUTION Design and specifications are subject to change without notice. www.microdigital.co.kr sales@microdigital.co.kr #1212, Hoseodae Venture Tower, 319, Gasan-Dong, Geumcheon-Gu, Seoul, Korea Tel :+82-2-2627-5279 / Fax :+82-2-2627-5295 P/N : 3690-0002B...
