Snazzi SN1510-A5 Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Snazzi*
A S E R I E S
Model No. SN1510-A5
Operating Instructions
D UAL ST RE A M NE TWO R K T V B O X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN1510-A5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Snazzi SN1510-A5

  • Page 1 Snazzi* A S E R I E S Model No. SN1510-A5 Operating Instructions D UAL ST RE A M NE TWO R K T V B O X...

  • Page 2: Table Of Contents

    Contents Product Overview ..............................4 Introduction ...................................... 4 Key Features ....................................5 System Requirements ..................................6 Package Contents ................................... 8 Specifications ....................................9 Guide to Parts and Control................................11 Viewing the Remote Control ............................... 14 Hardware Installation ............................18 Local Operations ..............................25 Using Rule ......................................
  • Page 3 net-TV 2012 ................................60 What is net-TV 2012 ..................................60 Easy Setup ..................................... 78 Channel Scan ....................................86 Favorite Channel Settings ................................88 Instant Recording ..................................90 USB Schedule Recording ................................91 Download Recorded Files ................................93 Play Recorded Files ..................................95 IR Learning ....................................

  • Page 4: Product Overview

    Product Overview Introduction The net-TV Box is a device that connects to your cable or set-top box and streams your TV shows and DVR content over the network for you to watch and control anywhere you go. net-TV Box provides simultaneous dual streams Full D1 video quality. With the net-TV Box placed in a living room for instance, you can enjoy any videos from anywhere in your home by using the computer, smart phone, tablet PC and receiver box on these client devices.

  • Page 5: Key Features

    Key Features High quality encoding Dual streams Advanced video (H.264) and audio coding Supports two services at the same time, and (AAC) provides high quality encoding at low their video resolution can both achieve D1. bitrates saving bandwidth without compromising Users can watch different video source quality in live streaming applications.

  • Page 6: System Requirements

    System Requirements net-TV Box  Cable or DSL modem, Home network router (UPnP compatibility highly recommended)  Cable TV source  External connected video device such as DVD, DVR or STB  256 Kbps upstream network speed (higher upstream network speeds yield higher quality video) ...
  • Page 7 net-TV mobile2 for Android:  An Android mobile phone or Tablet with 3G or 4G wireless service or Wi-Fi Internet connectivity  Android 1.6 or later  5 MB free memory is required on the Android device to install the net-TV mobile2 ...

  • Page 8: Package Contents

    Package Contents The product package includes the following items and accessories:  One ID number is supplied on the sticker of Box for remote application login. << >>...

  • Page 9: Specifications

    Specifications System Embedded Linux Dual core (ARM 9 + DSP) Memory FLASH:16MB; RAM:256MB DDR2 Signal System NTSC and PAL Network protocols HTTP, UDP, TCP/IP, SMTP, FTP, NTP, PPPoE, DHCP, UPnP, RTSP Interface ANTENNA 1 x Antenna IN, 75Ω (F type) 1 x Antenna OUT, 75Ω...
  • Page 10 LEDs 3 x Indicate power, network and USB status Reset button 1 x semi-recessed pushbutton to load factory default. Recording Video compression H.264 Main profile @ Level 3.0 Support resolutions D1, Half D1 , CIF all @30/25 fps Audio Compression Recording File format Recordable Media USB External HDD or USB Flash drive...

  • Page 11: Guide To Parts And Control

    Guide to Parts and Control Front Panel USB Port: DISK: Connect a USB storage device for record or playback. WiFi: Connect a wireless USB adapter to access network (Only supports Ralink’s 2571 chip.) IR Blaster Port: Connected with a supplied IR blaster cable, via the learning function of remote control, the box can emit IR signals to control STB remotely.
  • Page 12 Rear Panel DC-IN: Connect the supplied power adapter. ETHERNET: Connect a network with an always-on broadband connection. AV-OUT: Connect to the A/V input of TV by the supplied 3-in-1 AV cable. RESET: Press it with pen-point for three seconds, the box will reset to the default setting. AV-IN: Connect to external A/V devices (such as STB) by the supplied 3-in-1 AV cable.
  • Page 13 Table 1 The Status Indicators: The net-TV Box has three status lights on the front to indicate what’s happening. Indication Meaning ● Light off The power of the box is off. ● Dark green static The box is starting up or in standby. ●...

  • Page 14: Viewing The Remote Control

    Viewing the Remote Control Video source switch On/off the video output to TV. 0-9 numerical buttons, +100 and channel return Menu key, press it to enter to function setting page. Mute button, temporary sound switch-off. CH ^/CHv /VOL+/VOL-/ENTER Generally CH ^/v keys are used for channel selection and VOL+/ - keys for volume control.
  • Page 15 Play control keys Please refer the following page for the detailed instructions. << >>...
  • Page 16 These six keys have different functions when playing recorded files and watching TV/AV programs: Keys Functions when playback Functions when watching programs Last file Set schedule recording Play or pause Open the play list Next file Function reservation for other products. Swap between main picture and sub Fast rewind picture under PIP.
  • Page 17 Lift the cover at the back of the remote control upward as shown in the figure. Install two AAA size batteries. Make sure to match the “+” and “-“ ends of the batteries with the diagram inside the compartment. Replace the cover. Remove the batteries and store them in a cool, dry place if you won’t be using the remote control for a long time.

  • Page 18: Hardware Installation

    Hardware Installation Front Panel << >>...
  • Page 19 Connecting the IR Blaster Attach the supplied IR Blaster to the device connected to the IR Blaster port of the net-TV Box, and place the other head on the top of the video source such as Set Top Box to point at its Infrared receiver. ✍...
  • Page 20 Connect USB storage If you want to set schedule recording or play the recorded files, you should plug the USB storage device in the DISK port at the front panel of the net-TV Box. ✍  The external USB device must be FAT32 format. ...
  • Page 21 How to format the USB device with partition more than 32GB If the USB device partition is more than 32GB, and it can’t be format to FAT32 by Window system, you con format it to FAT32 by following these steps: Download a copy of fat32format.zip from http://www.ridgecrop.demon.co.uk/download/fat32format.zip, Extract the single EXE file to somewhere suitable, like C:\.
  • Page 22 Rear Panel << >>...
  • Page 23 Connect Audio/Video Source Use the supplied 3-in-1 AV cable to connect the AV-IN jack on the unit and connect the other end of it to the 3RCA to 3RCA cable and S-video cable, then to the corresponding out jack on your video device. Connect cable or antenna Disconnect the Coaxial/RF cable from your TV's Antenna IN and reconnect it to the Antenna IN of net-TV Box.
  • Page 24 Connect output Use the supplied 3-in-1 AV cable to connect the AV-OUT jack on the net-TV Box. Then connect the other end to the 3RCA to 3RCA cable, then to the output of your TV. Connect to your network Connect the net-TV Box’s ETHERNET port to the corresponding port on your Modem or Router using a LAN cable.

  • Page 25: Local Operations

    Local Operations Using Rule This product supports dual D1 streams. And every two of the local, LAN and WAN users can watch different programs independently. It can support two of the following services at the same time, and their video resolution can both achieve D1.
  • Page 26 Connection rule (except schedule recording): 1. When both the two video sources (TV & AV) are idle, the first login user can switch source. 2. And if user sends connection request when only one source is in use (such as TV), it will automatically distribute the other source (AV) them for requester.

  • Page 27: On Screen Menu

    On Screen Menu You can also set the net-TV Box via OSD operation on TV without opening computer. Use the supplied remote control and aim it at front led cap of the net-TV Box, then press the “ ” key, it will pop up the main menu page on TV as shown on the right.
  • Page 28 Picture Select the 「Picture」 item, and press the “ENTER” or “” to enter in the「Picture」page. You can adjust brightness, contrast, hue and saturation in this page. You can also set the default value by press the “Default” button. Use the “/” keys to select the item, enter the value directly with the number keys or adjust the value with “...
  • Page 29 Channel Select the「Channel」item, and press the “ENTER” or “” to enter in the「Channel」page. Country/Region: Select the Country or Region where you have installed the Box. Scan Type: Select the scan type as Frequency scan or Channel scan. Signal Source: Select the TV signal source: Cable or Air.
  • Page 30 Setup Select the「Setup」item, and press the “ENTER” or “” to enter in the「Setup」page. You can set display language and clock, view system information and update firmware here. Display Language: You can set the OSD display language in this page. Use the “/” keys to select the desired language, <<...
  • Page 31 press “ENTER” key to save the setting. Clock Settings: You can set time zone, date and time in this page. Use the “/” keys to select the desired value, and use the “/” keys to adjust the value, press “ENTER” key to save the settings.
  • Page 32 System Information : You can view the information such as IP Address, ID Number, MAC Address, Firmware Version and Connection Type in the page. << >>...
  • Page 33 Firmware Update: You can update firmware in the page. You have to insert the USB storage with firmware update file in net-TV Box first. It will automatically display the firmware update file in the USB storage. Move the cursor to select the update file and then press “ENTER”...
  • Page 34 Remote Assistance: To enable the remote assistance service please first confirm that the network equipment which net-TV Box connected is a router, and the computers that connected to the router can access to the web, just the net-TV Box can't go online via internet (the NET light doesn’t turn green).
  • Page 35 Network You can set network connection type in the「Network」 page. DHCP: Choose this option to obtain an IP Address automatically from your ISP. (Applicable to most Cable MODEM or router users) PPPoE: Select this option when you want to connect the Receiver Box to DSL/ADSL modem directly.
  • Page 36 Static IP: Select this option and enter the static IP information provided by your ISP, such as IP Address, Subnet Mask, Default Gateway and DNS. WiFi: Select a WiFi wireless network, if it has password protection you should enter the correct password later. <<...
  • Page 37 UPnP You can set the UPnP type in the 「UPnP」page. Auto: The default UPnP setting is Auto. If there is more than one net-TV Box connected to a router, it will adjust communication port automatically. Custom: If the effect of automatic port isn’t satisfying, you can set AV port for yourself.
  • Page 38 Disable: Select disable to close UPnP and change to DMZ or Virtual Server. If the router supports UPnP, please don’t select the item. If you select the item (only available under LAN) you have to enter the corresponding ports in the fields when set to DMZ or Virtual Server.

  • Page 39: Watch Live Tv

    Watch Live TV net-TV Box is very simple to use. To watch live TV, just control the box in the way you control TV set. “VOL+” & “VOL-” ：Adjust Volume. ：Adjust Channel. “CH ^” & “CH v” ：Input number to change channel directly. “...
  • Page 40 switch (3 seconds delay). << >>...

  • Page 41: Picture In Picture (Pip)

    Picture In Picture (PIP) PIP(Picture In Picture) function means that both the two video sources are displayed on TV as main picture and sub picture at the same time. Enable PIP: When watching one video source, pressing “ PIP” key can display the other video source as sub picture on TV (as right).

  • Page 42: Instant Recording

    Instant Recording When watching the TV/AV programs you can record them and enjoying them later. First plug the USB storage device to USB connector of the Box, and ensure that the USB status light of Box is Press “ ” on the remote control, the Box will begin to record programs, and it will display the recording sign on the screen.

  • Page 43: Schedule Recording

    Schedule Recording You can set the schedule recording task at the local Box and record the video without power on PC. Press the “ (Schedule)” key on the remote control to enter in the「Schedule Recording」page when watching TV/AV programs. It lists all the schedule recording tasks that have been set on the left, and show the current time and the detail information of the selected task on the right.
  • Page 44 The description of the items in the recording task list is as following: “ ” for example, it’s the first recording task in the list, start recording time is 04/18 Mon 16:00, repeat mode is Once, that is record only for one time. Item Description Serial number...
  • Page 45 The description of the items in the detailed recording task is as following: Item Description The repeat mode of schedule recording task. There are three modes: Once, Daily and Weekly. Once: Only record once Repeat: Daily: Record every day. Weekly: Record on the same day every week. The date of schedule recording task.
  • Page 46 When the repeat mode is “Daily”, you can select the recording days from Sunday to Saturday (as right). And it will record at the selected days every week. When the repeat mode is “Weekly”, you can select the recording day from Sunday to Saturday (as right). And Box will record at the same day every week.

  • Page 47: Play Recorded Files

    Play Recorded Files You can play the recorded files in your USB storage device by following these steps: First plug the USB storage device to USB connector of the Box, and make sure that the USB indication light is (Playlist)” on the remote control to enter the 「Play List」 page. It will list all the recorded files on.
  • Page 48 ✍ If you don’t know how to switch the playback mode, press “ ” to enter into to the 「Playback Options」page. This page shows the loop mode switch method. << >>...

  • Page 49: Net-Tv Mobile2

    net-TV mobile2 Instructions before installation net-TV mobile2 is an network TV player which designed based Android, iPhone and iPad for net-TV Box. Android phones and Tablet use the same application named net-TV mobile2. The application used for iPhone and iPad is also named net-TV mobile2 but it’s a different application. net-TV mobile2 for Android net-TV mobile2 for iPhone and iPad Android Phones...
  • Page 50 Install the application 1. Start the “Market” in the application list of Android or “App Store” in the application list of iPhone or iPad. Market App Store 2. Enter the keywords “net-TV mobile2”.click the search button. 3. Then click the application which you want to install. 4.
  • Page 51 Login Before login, please make sure that your phone can access internet. 1. Click the application icon to start it. 2. Enter in the ID and password of net-TV Box you want to connect in the login page, then click the “Login” button. 3.
  • Page 52 Interface instructions << >>...
  • Page 53 ✍  Clicking on the video area can hide or display the remote control panel.  As following, when the remote control panel is hidden, you can adjust the screen brightness and volume by dragging up-down on the video display area, and long touch can switch the video aspect ratio. Above functions are for Android device only.
  • Page 54 Video source and quality switch Click the 「 」 button, it will pop up the source and quality switch page as right. There are two video sources: TV and AV. Select the desired source then click 「OK」button to confirm (the default is TV). The video quality has three items: CIF, H-D1 and D1, user can select according to the displayed bit rate (the default is H-D1).
  • Page 55 TV remote control panel 」 button then select TV in the source page.) Switch to the TV source (Click the「 0~9 channel number keys. Click one or two channel numbers to switch to the desired channel. +100 channel select key. When the desired channel number is a three digit number, click the key and then click the last two digits can switch channel quickly.
  • Page 56 AV remote control 」 button and select AV in the source page.) There are two remote control Switch to the AV source (Click the「 panels of AV, you can click the 「 」 to switch among them. ✍ The application doesn’t support the IR learning function, it will auto download the IR learning table from net-TV Box when switch to AV source.
  • Page 57 Schedule Recording With net-TV mobile2, you can set the USB schedule recording tasks remotely, and then the Box will record the programs at the preset time. (You should connect the USB storage to the net-TV Box before). Enter the Box’s ID and password in the login panel then click “ ”...
  • Page 58 Add or edit schedule task In the Schedule List panel, you can click the “ ” button to add a new recording task or click the existed task to edit. Then it will go to the Schedule Setting page as following. Recording repeat mode: Once: record only once;...
  • Page 59 Delete schedule task You can delete the schedule recording task in the Schedule List. Click the “ ” button on the top of Schedule List panel to enter into the schedule delete page as right. Then click the “ ” button to delete the corresponding recording task.

  • Page 60: Net-Tv 2012

    net-TV 2012 What is net-TV 2012 Users can connect net-TV Box remotely by using net-TV 2012 installed on computer. The functions it supports are: watching TV/AV programs, Time-Shifting, instant recording and setting schedule recording. Software Installation Before installing the net-TV Box, please make sure that your PC meets the minimum system requirement and is equipped with a HDD with at least 100MB free space.
  • Page 61 Choose the destination folder where net-TV 2012 will reside and then click “Next” to install. The defaults location is C:\Program Files\ net-TV\net-TV 2012\. Click Finish to exit the installation wizard. ✍ After finishing the installation, it will come up a net-TV 2012 icon “...
  • Page 62 Remove Software Click 「Start ► Programs ► net-TV 2012 ► Uninstall net-TV 2012」 to remove the software. It will pop up a dialog asked “Are you sure you want to uninstall this product?”, Click 「Yes」to uninstall the program. When the program is completed, you have finished removing net-TV 2012 application software. <<...
  • Page 63 Login Double click net-TV 2012 icon “ ” on your desktop to start your net-TV 2012. The login window is attached to the center of the player window. It comes out along with the player window. The application can login the net-TV Box from any place via network. User can enter the ID and Password and click the 「login」button to build up connection.
  • Page 64 Operation Interface The operation interface of net-TV 2012 includes 4 parts: 1. Main panel including video display area 2. On-screen remote control panel 3. Right click menu 4. Function setting pages << >>...
  • Page 65 Main Panel Instructions Items Instructions Login/Logout Video display area Minimize Full-screen Close the application Playback / Pause Open the Playlist (Recorded files list) Instant recording / Pause Function setting key Video source switch Current status display Playback and Time-Shifting control slide bar and On/Off Time-Shifting switch.
  • Page 66 On-Screen Remote Control Panel Instructions When you switch the video source to TV source, the on-screen remote control panel will be TV on-screen remote control panel, and when you switch to AV source, it will be AV on-screen remote control panel. TV On-Screen Remote Control Panel Remote control / Channel list / Favorite switch item.
  • Page 67 Favorite channel list panel Channel list panel << >>...
  • Page 68 AV On-Screen Remote Control Panel Power Button Number Buttons Menu Button Mute Button Direction & OK Buttons Volume Up & Down Buttons Channel Up & Down Buttons Playing Control Buttons IR learning shortcut button ✍ The definition of the buttons on this panel is just the general meaning of them, you can also customize them yourself.
  • Page 69 Mouse and Keyboard Operations You can perform the following net-TV 2012 operations with your computer’s mouse and keyboard. Keyboard operations Shortcut Key Operations Shortcut Key Operations Select the aspect ratio Schedule recording Pop-up the right-click menu Full screen Enable or disable channel OSD Exit 「Home」...
  • Page 70 Mouse operations Items Operations Rotating the mouse wheel On a screen, rotating the mouse wheel away from you volume up, and rotating it towards you volume down. Scroll wheel click Mute Right clicking anywhere inside the window displays a context menu as Right click described below.
  • Page 71 Right click menu When you run net-TV 2012, you could move your mouse cursor and right click to open the pop-up menus. The commands on this menu are the same with those on the control panel but you could find some more options. Items Operations Set the schedule recording task.
  • Page 72 Setting Page Instructions GENERAL  Path: Snapshot: Select the directory path to save the captured picture files. Record: Select the directory path to save the recorded files.  Direct Connection: Disable(System default): Connect to Server to obtain the connection information of the Box first, then connect Box according to the information.
  • Page 73 CHANNEL This page is used to scan channel.  Channel Setting: Country or Region: Select the Country or Region where you have installed the Box. Signal: Select the TV signal reception mode including Cable TV, Air TV and Frequency Scan. Load: Load the channel table you have saved beforehand.
  • Page 74 VIDEO  Resolution: There are three resolutions for you to choose, and the vertical resolutions have a little difference under different TV system (NTSC/PAL). Auto Adjust bit rate and frame rate: When you select the item it will auto adjust the Bit Rate and Frame Rate.
  • Page 75 NETWORK  UPnP Settings: The Box uses the UPnP communication protocol to transmit the audio and video data stream to petitioner for default.  Auto The default UPnP setting is Auto. If there is more than one Box connected to a router, it will adjust communication port automatically.
  • Page 76 SCHEDULE This page implements the settings of the schedule recording.  Add: The button only takes effect when there is a USB flash drive connected to the Box. Press the 「Add」 button to add a new recording schedule.  Edit: Edit the selected schedule.
  • Page 77 MY ACCOUNT  My Account: ID: ID number of the net-TV Box. Alias: You can login by using the alias that you have set. Enter the alias that you want, and then click「OK」 to complete alias setting. (The default alias is the same as the Box’s ID.) ...

  • Page 78: Easy Setup

    Easy Setup Confirm Whether the UPnP is Useable With the net-TV Box connected to network and power on, the net-TV Box will proceed to the start and network detecting program, the PWR led will turn constant on. Then you should notice that whether the NET led is green, if the NET led is green, it means that net-TV Box has been connected to internet, and you can login the net-TV Box and skip the instruction of EasySetup.
  • Page 79 Select 「UPnP Function Testing」, and then click 「Test」 to start the testing. If the test result is that UPnP is not enabled, please refer to the manual of the Router or contact manufacture of the Router for help to enter in the setting page of the Router to Enable the PnP function.
  • Page 80 Change the Network Configuration When you decide to connect net-TV Box to xDSL Modem (If Cable Modem supports plug-n-play function, you needn’t make any change) directly, you must change the factory connection status of the net-TV Box, so you should use the Ethernet Cable to connect your net-TV Box and computer.
  • Page 81 Search Device Then the EasySetup will search the net-TV Box that have been connected, it will list the information of the searched net-TV Box, such as ID / IP Address / MAC Address. Then double click the device to login or click 「Next」 directly to forward to the setting page.
  • Page 82 Network Configuration (Choose one from four options)  Dynamic IP: Choose this option to obtain an IP address automatically from your ISP.  Static IP: If the applied network type is Static IP, please select the [Static IP] option, and enter the related information provided by ISP(If there is any problem, please contact your ISP.) in the below blank column.
  • Page 83 If you select PPPoE network configuration, after finish the information input and click 「Finish」 button, it will notice you connect net-TV Box to ADSL Modem and replug in the power source. Please plug out the Ethernet Cable from the computer which is connected to net-TV Box and reconnect it to the xDSL Modem that has been set.
  • Page 84 The Remote Assistance Settings Service To enable the service please first confirm that the network equipment which the IPTV Box connected is a router, and the computers that connected to the router can access to the web, just the IPTV Box can't go online via internet (the NET light doesn’t turn green).
  • Page 85 Then the EasySetup will search the net-TV Box that have been connected, it will list the information of the searched net-TV Box, such as ID / IP Address / MAC Address. Then double click the device to login or click 「Next」 directly to forward to the setting page.

  • Page 86: Channel Scan

    Channel Scan When you login net-TV 2012 for the first time or the channel table is empty, it will pop up a window for channel searching. Please press “Yes” to scan channel. If you have not scanned channel at first or want to scan channel later, you can set as following steps: Choose Country or region where the Box has been installed.
  • Page 87 You can switch the channel following one of these steps:  Use the 0-9 number buttons to switch channel. If the channel number is only one digit number (as 9), you can click “0” and “9” to switch directly or click “9” to switch (3 seconds delay). If it’s a two digit number (as 59), you can click the two digits (“5”...

  • Page 88: Favorite Channel Settings

    Favorite Channel Settings When you are watching TV program on net-TV 2012, you can set the current channel as favorite channel and delete the current channel from the favorite channel list. Switch the source to the TV source and click the “ ”...
  • Page 89 Click add button “ ” to set the current channel as favorite channel, then select the “ ” item at the top to go to the favorite channel panel, you will find the channel has been added to the favorite channel list. You can also click delete button “...

  • Page 90: Instant Recording

    Instant Recording When watching the TV/AV programs you can record them and enjoying them later. Press the recording button “ ” to begin to record programs. While recording, it will display the recording sign on the video display area. The time means the recorded duration.

  • Page 91: Usb Schedule Recording

    USB Schedule Recording Before setting the schedule recording, make sure that there is a USB Flash Drive connected to the Box. Click the setting button to go to the setting page and select the 「Schedule」 page. Select the time zone of your net-TV Box on the pull-down menu of 「Time Zone」.
  • Page 92 Select the recording information in the pop-up schedule set page, such as recording mode, date, start time and duration. For detail information, please refer to Schedule Recording Items instructions Click 「Add」 to complete your settings. The newly added task will show up on the following scheduled task list.

  • Page 93: Download Recorded Files

    Download Recorded Files You can download the recorded files from the net-TV Box to your PC by following these steps: Login the net-TV Box. Right click the image window and select 「Download files from net-TV Box」 on the popup menu. On the setting page, 「Box file list」...
  • Page 94 USB device. << >>...

  • Page 95: Play Recorded Files

    Play Recorded Files You can use net-TV 2012 to play the recorded files saved in the USB storage which connected to Box by following these steps: After login, right click and select 「Play recorded files」 on the pop-up menu. Then it will list all the recorded files in the USB storage in the PlayList panel (as right figure).

  • Page 96: Ir Learning

    IR Learning Before you can control a new video device via the on-screen remote control panel of the net-TV player, you have to create a new IR learning table to save the corresponding buttons of your physic remote control. Click the source switch button “ ”...
  • Page 97 Select “Create” option in the pop-up IR table page, then click 「Next」 to create a new IR learning table. Then click the 「Start Learning」 button to begin to learn. << >>...
  • Page 98 Then all the unlearned keys on the on-screen remote control will become gray, click the key you want to learn (1 for instance) until it become the standby status as following. Then aim your physical remote control at the remote sensor of net-TV Box and press “1” button. After the box receive and remember the IR learning signal, “1”...
  • Page 99 According to the steps above, you can complete learning all the keys of the physical remote control. While you are learning one key but net-TV Box doesn’t receive the IR signals, it will show the fail message. Then you merely need to click the key and learn again. After learning all the keys, click the 「Stop Learning」...
  • Page 100 Upload to box If your Box reset to factory default because some causes, the IR learning table in it will be clear up. In order to avoid repeating IR learning process, you can upload the IR table saved in PC to the Box. If you have more than one Box connected to same video device, you can also upload the IR table to other Box.
  • Page 101 Download from box When you connect the box, PC will download the IR table from box to the application install directory automatically. If you want to make a backup of the IR table at other path, you can download the IR table with the “Download from box”...

  • Page 102: Time-Shifting

    Time-Shifting The Time-Shifting function makes the Box can record the playing program at any time, and you can continue to watch later, it’s also easy to skip advertisements. So if you need leave the player when watching program, you can enable the Time-Shifting function, and the Box will begin to record the programs automatically, then you can watch the program when get back.

  • Page 103: Firmware Update

    Firmware Update To upgrade the net-TV Box firmware, follow these instructions: When you upgrade the net-TV Box firmware, you will lose current configuration settings, so make sure you backup the net-TV Box settings before you upgrade its firmware. Download the latest firmware upgrade file from the manufacturer website. Login net-TV 2012, right-click the image window to get the pop-up menu shown as the following figure.
  • Page 104 Click the 「Update」 button on the pop-up window. View the folders and select the downloaded file. << >>...
  • Page 105 The Firmware update procedure is totally 2 phases: transmit the update file to the Box and the Box itself update. ✍ During the firmware update, don’t switch off the product itself or stop the activity, otherwise the product may be out of order. After the completion of the firmware update, the window as right will pop up.
  • Page 106 Snazzi* B O X w ww. s n a zz i .c om...
