Wheatstone Corporation Bridge 2001 Technical Manual

Digital audio network router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Bridge 2001

Digital Audio

Network Router
T echnical
Manual
Wheatstone Corporation
July 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bridge 2001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wheatstone Corporation Bridge 2001

  • Page 1: Digital Audio

    Bridge 2001 Digital Audio Network Router T echnical Manual Wheatstone Corporation July 2001...
  • Page 2 Bridge 2001 Digital Audio Network Router Bridge 2001 Digital Audio Network Router Bridge 2001 Digital Audio Network Router Bridge 2001 Digital Audio Network Router Bridge 2001 Digital Audio Network Router ©2001 Wheatstone Corporation 600 Industrial Drive New Bern, North Carolina 28562...
  • Page 3 Any modifications not expressly approved in writing by Any modifications not expressly approved in writing by Wheatstone Corporation could void the user's authority to operate Wheatstone Corporation could void the user's authority to operate Wheatstone Corporation could void the user's authority to operate...

  • Page 4: Table Of Contents

    C O N T E N T S Bridge 2001 Technical Manual Table of Contents Chapter 1 – General Information Introduction ................1-2 Power Supply ................1-3 Power Supply Cable Pinout ..................1-3 Failsafe Dual Redundant Supply ................1-4 Energizing ....................... 1-4 I/O Connections ................
  • Page 5 C O N T E N T S Analog Input Card (ADI-2001) Overview ................... 2-13 Analog Input Interface ............. 2-13 Internal Programming Options ..........2-13 Status LED’s ................2-14 Hook-Ups Upper DB-25 - Analog Audio Connections ............2-15 Lower DB-25 - Analog Audio Connections ............2-15 8 RJ-45 - Analog Audio Connections ..............
  • Page 6 C O N T E N T S Ethernet IP Addressing ............2-34 Ethernet Interface Wiring ............2-34 Internal Programming Options ..........2-34 Switch Settings ................ 2-35 DIPSW1-SW4 - 485 Termination ................2-35 SW5 - CPU Reset ....................2-35 DIPSW6 - Utility Switches ..................2-35 DIPSW7 - Rack ID ....................
  • Page 7 C O N T E N T S Optical Fiber Interface ............. 2-48 Connector Type ....................2-48 Optical Fiber ......................2-48 ONI Panel Pinout Drawing ............2-49 Stacking Card (CEX-2001) Overview ................... 2-50 Configuring the Virtual Chassis ..........2-50 TDM Assignment ....................2-50 CEX-2001 Rack ID ....................
  • Page 8 C O N T E N T S SW3 - Reset ......................2-65 DIPSW6 - Rack ID ....................2-66 Jumper Settings ................2-66 J1 - Factory Use Only - Reset ................. 2-66 J2 - Factory Use Only - Watchdog Disable ............. 2-66 J3 - Sample Rate Select - 48kHz/44.1kHz ..............
  • Page 9 Console Address ...................... 3-8 RS-485 Select / Termination ..................3-8 Chapter 4 - XPoint Software Setup Guide Bridge 2001 Ethernet/IP Address Quick Start ......4-2a Ethernet Cabling ...................... 4-2a Default IP Address ....................4-2a Changing your PC’s IP Address ................4-2a Changing the Bridge 2001’s IP Address ..............
  • Page 10 C O N T E N T S Input Card Definition ..................4-10 Viewing Defined Source & Destination Signals ..........4-10 Configuration Rules and Recommendations ............4-11 Completing the Configuration ................4-11 Saving Your Configuration ................. 4-11 Config.txt File ..................... 4-11 Signal Definition ...............
  • Page 11 G E N E R A L I N F O R M A T I O N General Information Chapter Contents Introduction ................1-2 Power Supply ................1-3 Power Supply Cable Pinout ..................1-3 Failsafe Dual Redundant Supply ................1-4 Energizing .......................

  • Page 12: Introduction

    General Information Introduction The Bridge 2001 Digital Audio Network Router rackmount unit occu- pies four 19” wide rack (total height 7”) with 16” depth. The 2001 is a unit that can take up to 512 discrete analog and digital audio inputs in Audio Engineering Society (AES) format, and switch them to any of 512 separate outputs.

  • Page 13: Power Supply

    Under no circumstances should the metal cover be removed! If you have a problem with the power supply, the unit must be returned to Wheatstone Corporation for repair. Once the supply is rackmounted, it should be connected to the 2001 using the factory supplied cable(s).

  • Page 14: Failsafe Dual Redundant Supply

    G E N E R A L I N F O R M A T I O N either one of the PWI-40 module’s power connectors. If you are using two power supplies (failsafe option) the second power supply will be plugged into the remaining power connectors on the rear PWIH(PWI)- 2001 and PWI-40 modules.

  • Page 15: I/O Connections

    G E N E R A L I N F O R M A T I O N I/O Connections A family of I/O connector modules plug right into the cage rear to give you a choice of DB-25 or RJ-45 connections for analog or digital audio interface, or BNC connectors for use with 75 ohm digital audio equipment.

  • Page 16: Digital Audio Connections

    G E N E R A L I N F O R M A T I O N with a scribe or other sharp instrument; this will unlock the pin from the shell, and it can be removed and inserted into the correct position. Spread the vee apart to lock the pin in the new position.

  • Page 17: Unbalanced Digital Connections (Spdif)

    (HOT) to the HI input pin and SPDIF shell (ground) to the LO input. Connect SH at the 2001 router end only. SPDIF OUTPUTS - The Bridge 2001 digital outputs are fixed, profes- sional, AES-3 formatted outputs. SPDIF consumer format is not sup- ported.
  • Page 18 H A R D W A R E Hardware Chapter Contents Chassis/Backplane Overview ............2-4 Chassis Configuration Guidelines ..........2-5 Audio Slots ........................ 2-5 Reserved Slots ......................2-5 Backplane Termination ..............2-5 Digital Input Card (AES-2024) Overview ..................2-6 AES Input Interface ............... 2-6 Internal Programming Options ............
  • Page 19 H A R D W A R E Hook-Ups DB-25 - Digital Audio Connections ................2-22 8 BNC - Digital Audio Connections ................. 2-22 8 RJ-45 - Digital Audio Connections ............... 2-23 DB Panel Pinout Drawing ............2-24 8 BNC Panel Pinout Drawing ............2-25 8 RJ Panel Pinout Drawing ............
  • Page 20 H A R D W A R E Typical Ethernet Cable ............2-39 Typical Crossover Cable ............2-39 PWIH Panel Pinout Drawing ............ 2-40 Audio Network Card (OAN-2001) Overview ................... 2-41 Internal Programming Options ..........2-42 Switch Settings ................ 2-42 DIPSW1-SW4 - 485 Termination ................
  • Page 21 H A R D W A R E Logic I/O Card (LIO-2001) Overview ..................2-55 Input Ports ................. 2-55 Output Ports ................2-56 Typical Input/Output Circuit ............. 2-56 Software Programming ............. 2-57 Internal Programming Options ..........2-57 Jumper/Dipswitch Settings ............2-57 Status LED’s ................
  • Page 22 H A R D W A R E Digital Signal Processor Card (DSP-2001) Overview ..................2-72 Internal Programming Options ........... 2-72 Switch Settings ................2-73 SW1 - DSP Reset Switch ..................2-73 Jumper Settings ................2-73 J1 - Factory Use Only - Watchdog Reset ..............2-73 J2 - Factory Use Only - Watchdog Reset ..............

  • Page 23: Chassis/Backplane Overview

    H A R D W A R E Hardware Chassis / Backplane Overview The 2001 chassis may be configured to suit a variety of I/O card complements including—analog or digital audio input and output cards, chassis expansion and audio network cards. A system may include a single cage, multiple co-located cages, or a central chassis connected to one or more satellite frames in a star configuration.

  • Page 24: Chassis Configuration Guidelines

    H A R D W A R E Chassis Configuration Guidelines While new 2001 systems are pre-configured to customer specifications at Wheatstone’s factory, future expansion of a system may require some re- configuration of existing hardware to accommodate new resources. Audio Slots Audio I/O cards may be mounted in almost any slot, though there are some basic guidelines and considerations to take into account when filling...

  • Page 25: Digital Input Card (Aes-2024)

    H A R D W A R E Digital Input Card (AES-2024) Overview There are two versions of digital audio input cards for the 2001: • AES-2024/8 card will accept up to 8, AES-3 formatted stereo sources (i.e. 16 mono channels); •...

  • Page 26: Status Led's

    H A R D W A R E Digital Input Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. JTAG HEADER - FPGA programming - factory use only.

  • Page 27: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to the AES-2024 card takes place at the rear I/O connectors modules: DB, 2DB, 8BNC or 8RJ-45. The DB module has one female DB-25 connector and 2DB has two DB connectors for audio input connections. The BNC module contains eight BNC connectors for use with 75 ohm digital audio equipment, likewise the 8RJ-45 module contains eight RJ-45 connectors for use in balanced, unshielded twisted pair (UTP) wiring systems.
  • Page 28 H A R D W A R E Pin 21 – HI Pin 9 – LO AES 3 In Pin 22 – SH Pin 7 – HI Pin 20 – LO AES 4 In Pin 8 – SH Pin 18 – HI Pin 6 –...

  • Page 29: 8 Bnc-Digital Audio Connections

    H A R D W A R E 8 BNC—Digital Audio Connections This panel is used only for AES-2024/8 card. Pinout drawing on page 2-12b shows all wiring connections at a glance. BNC 1 Pin 1 – HI AES 1 In BNC 1 Pin 2 –...
  • Page 30 H A R D W A R E RJ-45#6 Pin 3 – HI AES 11 In RJ-45#6 Pin 6 – LO RJ-45#6 Pin 1 – HI AES 12 In RJ-45#6 Pin 2 – LO RJ-45#7 Pin 3 – HI AES 13 In RJ-45#7 Pin 6 –...
  • Page 31 H A R D W A R E DB Panel Digital Input Connections for AES-2024/8 AUDIO GROUND AES 1 IN SH AES 1 IN LO AES 1 IN HI AES 2 IN SH AES 2 IN LO AES 2 IN HI AES 3 IN SH AES 3 IN LO AES 3 IN HI...
  • Page 32 H A R D W A R E 2DB Panel Digital Input Connections for AES-2024/16 AUDIO GROUND AES 1 IN SH AES 1 IN LO AES 1 IN HI AES 2 IN SH AES 2 IN LO AES 2 IN HI AES 3 IN SH AES 3 IN LO AES 3 IN HI...
  • Page 33 H A R D W A R E 8 BNC Panel Digital Input Connections for AES-2024/8 AES1 IN AES2 IN AES3 IN AES4 IN 75Ω Ω Ω Ω AES5 IN AES6 IN AES7 IN AES8 IN page 2 – 12b page 2 –...
  • Page 34 H A R D W A R E 8RJ Panel Digital Input Connections RJ-45 #1 RJ-45 #5 AES 2 IN HI AES 10 IN HI AES 2 IN LO AES 10 IN LO AES 1 IN HI AES 9 IN HI AES 1 IN LO AES 9 IN LO RJ-45 #2...

  • Page 35: Analog Input Card (Adi-2001)

    H A R D W A R E Analog Input Card (ADI-2001) Overview The Analog input cards accept up to 8 stereo analog audio sources (i.e.16 mono channels). A Signal Definitions form in the supplied XPoint software allows the user to set attributes for the input channel hardware including signal name, type, circuit #, etc.

  • Page 36: Status Led's

    H A R D W A R E Analog Input Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA , Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. JTAG HEADER - FPGA programming - factory use only.

  • Page 37: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to the ADI-2001 card takes place at the rear I/O connectors modules: 2DB or 8RJ-45. The 2DB module has two female DB-25 connectors for audio input connections. The 8RJ-45 module contains eight RJ-45 connectors for use in balanced, unshielded twisted pair (UTP) wiring systems.

  • Page 38: Rj-45-Analog Audio Connections

    H A R D W A R E Pin 7 – HI Pin 20 – LO Channel 12 (Stereo 6 Rt) In Pin 8 – SH Pin 18 – HI Pin 6 – LO Channel 13 (Stereo 7 Lt) In Pin 19 –...
  • Page 39 H A R D W A R E 2DB Panel Analog Input Connections AUDIO GROUND CHANNEL 1 (STEREO 1 LT) IN SH CHANNEL 1 (STEREO 1 LT) IN LO CHANNEL 1 (STEREO 1 LT) IN HI CHANNEL 2 (STEREO 1 RT) IN SH CHANNEL 2 (STEREO 1 RT) IN LO CHANNEL 2 (STEREO 1 RT) IN HI CHANNEL 3 (STEREO 2 LT) IN SH...
  • Page 40 H A R D W A R E 8RJ Panel Analog Input Connections RJ-45 #1 RJ-45 #5 CHANNEL 2 (STEREO 1 RT) IN HI CHANNEL 10 (STEREO 5 RT) OUT HI CHANNEL 2 (STEREO 1 RT) IN LO CHANNEL 10 (STEREO 5 RT) OUT LO CHANNEL 1 (STEREO 1 LT) IN HI CHANNEL 9 (STEREO 5 LT) OUT HI CHANNEL 1(STEREO 1 LT) IN LO...

  • Page 41: Digital Output Card (Do-2001)

    H A R D W A R E Digital Output Card (DO-2001) Overview Each Digital Output card provides 8 physical AES-3 formatted outputs. The eight physical AES outputs are divided into 16 channels or circuits in software to allow the greatest routing flexibility. A Signal Definitions form in the supplied XPoint software allows the user to set attributes for the output channels including signal name, type, circuit #, etc.

  • Page 42: Aes Channel Status Implementation

    NOTE: When changing the audio sample rate of AUX BITS USE: 24 BIT - main audio the Bridge 2001 Digital Audio Network Router, changes must be made in the following places: AUDIO WORD LENGTH: 24 BIT DO-2001 Digital Output Card, CPU-2001 Host...

  • Page 43: Status Led's

    H A R D W A R E Digital Output Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA , Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. JTAG HEADER - FPGA programming - factory use only.

  • Page 44: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring from the DO-2001 card takes place at the rear I/O connectors modules: DB and 8 BNC. The DB module has one female DB- 25 connector for digital audio output connections. The 8 BNC module contains eight BNC connectors for use with 75 ohm digital audio equip- ment.

  • Page 45: Rj-45-Digital Audio Connections

    H A R D W A R E BNC 4 Pin 1 – HI AES 4 Out BNC 4 Pin 2 – SH BNC 5 Pin 1 – HI AES 5 Out BNC 5 Pin 2 – SH BNC 6 Pin 1 – HI AES 6 Out BNC 6 Pin 2 –...
  • Page 46 H A R D W A R E DB Panel Digital Output Connections AUDIO GROUND AES 1 OUT SH AES 1 OUT LO AES 1 OUT HI AES 2 OUT SH AES 2 OUT LO AES 2 OUT HI AES 3 OUT SH AES 3 OUT LO AES 3 OUT HI AES 4 OUT SH...
  • Page 47 H A R D W A R E 8 BNC Panel Digital Output Connections use for 75 ohm AES-3 Id based systems AES1 OUT AES2 OUT AES3 OUT AES4 OUT 75Ω AES5 OUT AES6 OUT AES7 OUT AES8 OUT page 2 – 25 2001 / Jul 01...
  • Page 48 H A R D W A R E 8RJ Panel Digital Output Connections RJ-45 #1 AES 2 OUT HI AES 2 OUT LO AES 1 OUT HI AES 1 OUT LO RJ-45 #2 AES 4 OUT H AES 4 OUT LO AES 3 OUT HI AES 3 OUT LO RJ-45 #3...

  • Page 49: Analog Output Card (Ao-2001)

    H A R D W A R E Analog Output Card (AO-2001) Overview Each Analog Output card provides 16 physical monaural output channels . These output channels are configured in software to be any combination of mono, stereo or 5.1 output signals. A Signal Definitions form in the supplied XPoint software allows the user to set attributes for the output channels including signal name, type, circuit #, etc.

  • Page 50: Status Led's

    H A R D W A R E Analog Output Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA , Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. JTAG HEADER - FPGA programming - factory use only.

  • Page 51: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring from the AO-2001 card takes place at the rear I/O connectors modules (2DB and 8RJ). The 2DB module has two DB-25 connectors and 8RJ has eight RJ-45 connectors for audio output connections. Upper DB-25—Analog Audio Connections These include four (1-4) outputs.

  • Page 52: Rj-45-Analog Audio Connections

    H A R D W A R E Pin 7 – HI Pin 20 – LO Channel 12 (Stereo 6 Rt) Out Pin 8 – SH Pin 18 – HI Pin 6 – LO Channel 13 (Stereo 7 Lt) Out Pin 19 –...
  • Page 53 H A R D W A R E 2DB Panel Analog Output Connections AUDIO GROUND CHANNEL 1 (STEREO 1 LT) OUT SH CHANNEL 1 (STEREO 1 LT) OUT LO CHANNEL 1 (STEREO 1 LT) OUT HI CHANNEL 2 (STEREO 1 RT) OUT SH CHANNEL 2 (STEREO 1 RT) OUT LO CHANNEL 2 (STEREO 1 RT) OUT HI CHANNEL 3 (STEREO 2 LT) OUT SH...
  • Page 54 H A R D W A R E 8RJ Panel Analog Output Connections RJ-45 #1 RJ-45 #5 CHANNEL 2 (STEREO 1 RT) OUT HI CHANNEL 10 (STEREO 5 RT) OUT HI CHANNEL 2 (STEREO 1 RT) OUT LO CHANNEL 10 (STEREO 5 RT) OUT LO CHANNEL 1 (STEREO 1 LT) OUT HI CHANNEL 9 (STEREO 5 LT) OUT HI CHANNEL 1 (STEREO 1 LT) OUT LO...

  • Page 55: Host Cpu (Cpu-2001)

    H A R D W A R E Host CPU (CPU-2001) Overview The host CPU card used in the Bridge 2001 incorporates a PC/104 computer mounted on a backplane interface card (the HC-2001 PCB). The host computer utilizes RAM, a flash disk (which emulates a standard IDE hard drive) and an Ethernet port.

  • Page 56: Ethernet Ip Addressing

    H A R D W A R E Ethernet IP Addressing Wheatstone 2001 digital audio network routers ship with the host CPU IP address set for 192.168.1.160 and the personal computer’s NIC set for 192.168.1.212. Stand-alone systems (not interfaced to a station’s existing network) require no IP address changes.

  • Page 57: Switch Settings

    CPU; SW2 and SW4 are for receiver terminations. An RS-485 bus may only be BIAS TERMINATED at one end. All applicable Bridge 2001 OAN and CPU cards are set for BIAS TERMINA- TION by default. All peripheral devices are set for NO TERMINATION by default.

  • Page 58: Sw9 - Master Select

    H A R D W A R E etc.) the system will revert to onboard crystal reference until AES input returns. Autodetect disabled forces system to ignore AES reference and always use the onboard crystal and bypass PLL. Pos.2 - not used Pos.3 - not used Pos.4 - not used SW9 - Master Select...

  • Page 59: Status Led's

    H A R D W A R E CPU Card Status LED’s ETHERNET ACTIVITY (DS1) - ON indicates TCP/IP activity. ETHERNET LINK (DS2) - ON indicates Ethernet is link OK. DONE LED (DS1) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing.

  • Page 60: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to and from CPU card takes place at the rear I/O connector module (PWIH-2001) that plugs into the extreme left-hand slot (if you are looking at the rear of the cage). There are three DB-9 female serial interface connectors, one RJ-45 Ethernet connector and two power supply connectors.
  • Page 61 H A R D W A R E YPICAL THERNET ABLE TXD + White/Orange White/Orange TXD - Orange Orange RXD + White/Green White/Green RJ-45 RJ-45 Plug Blue Blue Plug White/Blue White/Blue RXD - Green Green White/Brown White/Brown Brown Brown SED FOR CONNECTING THE MODULE TO YOUR NETWORK HUB YPICAL ROSSOVER...
  • Page 62 H A R D W A R E PWIH Panel I/O Connections I/O PORTS (Left"A" DB-9) AES SYNC OUT SH - AES SYNC OUT LO USED USED AES SYNC OUT HI RX1 LO (RS-485) RX1 HI (RS-485) SERIAL RX (RS-232) TX (RS-232) TX1 LO (RS-485) TX1 HI (RS-485)

  • Page 63: Audio Network Card (Oan-2001)

    H A R D W A R E Audio Network Card (OAN-2001) Overview The Audio Network card is used to connect a master chassis to a remote chassis via a fiber optic link or CAT-5 cable. Audio Network cards must be installed in pairs (i.e.

  • Page 64: Internal Programming Options

    SW2 and SW4 are for receiver terminations. An RS-485 bus may only be BIAS TERMINATED at one end. All applicable Bridge 2001 OAN and CPU cards are set for BIAS TERMINA- TION by default. All peripheral devices are set for NO TERMINATION by default.
  • Page 65 H A R D W A R E applicable Bridge 2001 OAN and CPU cards are set for BIAS TERMINA- TION by default. All peripheral devices are set for NO TERMINATION by default. Set the TERMINATION to ON for the last controller or console only, in a RS-485 chain.

  • Page 66: Dipsw7 - Rack Id

    H A R D W A R E DIPSW7 - Rack ID If the OAN card is a Remote-Primary Audio Network Card, this OAN card must supply the Rack ID to its backplane from the 4 bit onboard switch. Remote Rack ID’s must be 5 or higher. SW7 RACK ID RACK ID RACK ID8 RACK ID4 RACK ID2 RACK ID1...

  • Page 67: J3, J5 - Clock Selection

    H A R D W A R E J3, J5 - Clock Selection OAN cards are designed to have two clock options - surface mounted crystals, or a socketed crystal. Surface mount crystals can be used without crystal in socket - just short the pins closest to the desired crystal (J3) to enable it.

  • Page 68: Status Led's

    H A R D W A R E OAN Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing. I/O INTERFACE (DS2) - lights when the rear panel card is powered. POWER SUPPLY STATUS (DS3-DS5) - ON indicates power supply is OK.

  • Page 69: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to and from OAN-2001 Card takes place at the rear I/O connector module (ONI-2001). CAT5 or multi-mode optical fiber Audio Network connections to companion OAN cards are made via RJ-45 or SC type optical connectors.

  • Page 70: Optical Fiber Interface

    H A R D W A R E Optical Fiber Interface Connector Type The OAN audio network card provides a SC Duplex style connector for interfacing optical fiber. The SC (subscription channel) connector is a low insertion loss, locking mechanism with excellent strain relief char- acteristics.
  • Page 71 H A R D W A R E ONI Panel I/O Connections SERIAL RX1 LO (RS-485) I/O PORTS RX1 HI (RS-485) (Upper "A" RX1 (RS-232) TX1 (RS-232) DB-9) TX1 LO (RS-485) TX1 HI (RS-485) RX2 LO (RS-485) I/O PORTS RX2 HI (RS-485) (Lower "B"...

  • Page 72: Stacking Card (Cex-2001)

    H A R D W A R E Stacking Card (CEX-2001) Overview The Stacking card is used to connect up to 4 co-located racks into a larger virtual chassis. The stacking approach is most useful when configuring medium to large centrally located systems which employ a large number of analog or digital audio I/O cards.

  • Page 73: Cex-2001 Rack Id

    H A R D W A R E CEX-2001 Rack ID The CEX -2001 Rack ID numbering scheme differs significantly from the methods used on OAN-2001 and CPU-2001 circuit boards. Stacked racks have Rack ID’s of 1 through 4 inclusive. The Rack ID numbers for stacked frames are a by-product of the TDM assignment dipswitch setting described in the previous section.

  • Page 74: Jumper Settings

    H A R D W A R E Jumper Settings J1 - Crystal Select NOTE: When changing the au- Stacking cards are designed to have two clock options - surface dio sample rate of the Bridge mounted crystals, or a socketed crystal. Surface mount crystals can be 2001 Digital Audio Network Router, changes must be made used without crystal in socket - just short the pins closest to the desired...

  • Page 75: Status Led's

    H A R D W A R E Stacking Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA , Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. RESET SWITCH (SW2) - momentary pushbutton.

  • Page 76: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to and from Stacking Card takes place at the rear I/O connectors module (CEI-2001). There are two specially wired high density SCSI type connectors for looping the Stacking cards together. page 2 –...

  • Page 77: Overview

    H A R D W A R E Logic Input/Output Card (LIO-2001) Overview The LIO-2001 is a programmable hardware GPI with a feature set designed for broadcast studio control applications. Twelve independent, opto-isolated solid state relay inputs and outputs may be programmed through the XPoint GUI software to function as routable logic or trigger ports.

  • Page 78: Output Ports

    H A R D W A R E Output Ports Each of the twelve LH1522AB solid state relay outputs SIMPLE OUTPUT EXAMPLE may be configured in software to function as normally EXT DEVICE open or normally closed circuits when cross connected to ROUTER LIO OUT PLAY IN...

  • Page 79: Software Programming

    H A R D W A R E Software Programming For details on programming the LIO-2001, please refer to the “Logic I/O Control” chapter in the XPoint Software Setup Guide later in this manual. Internal Programming Options There are no user programming options on the LIO-2001 card. Jumper / Dipswitch Settings J1 - Not installed.

  • Page 80: Status Led's

    H A R D W A R E Logic Input/Output Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. JTAG HEADER - FPGA programming - factory use only.

  • Page 81: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to the LIO-2001 card takes place at the 2DB rear I/O connector module. The 2DB module has two female DB-25 connectors for logic input and output connections. Upper DB-25—Logic Input Connections These include 12 input sources.
  • Page 82 H A R D W A R E Pin 8 – Logic 5 Out + Pin 21 – Logic 5 Out - Pin 7 – Logic 6 Out + Pin 20 – Logic 6 Out - Pin 6 – Logic 7 Out + Pin 19 –...
  • Page 83 H A R D W A R E 2DB Panel Logic I/O Connections AUDIO GROUND LOGIC 1 IN - LOGIC 1 IN + LOGIC 2 IN - LOGIC 2 IN + LOGIC 3 IN - LOGIC 3 IN + LOGIC 4 IN - LOGIC 4 IN + LOGIC 5 IN - LOGIC 5 IN +...

  • Page 84: Quad Audio Network Card (Qat-2001)

    H A R D W A R E Quad Audio Network Card (QAT-2001) Overview The Quad Audio Network card provides a robust and deterministic link between multiple audio racks or control surfaces via fiber optic or CAT-5 cable. The 4 ports, A,B,C & D, may be independently configured in hardware for either audio or control surface connections.
  • Page 85 H A R D W A R E In systems incorporating control surfaces and DSP, each control surface link is made to a QAT port co-located with its corresponding DSP cards. These “MT” ports carry all fader, switch, logic, LCD meter, source and destination information to and from the control surface and the companion DSP cards located in the Remote Tier racks.

  • Page 86: Internal Programming Options

    SW1 and SW4 are for receiver terminations. An RS-485 bus may only be BIAS TERMINATED at one end. All applicable Bridge 2001 QAT and CPU cards are set for BIAS TERMINA- TION by default. All peripheral devices are set for NO TERMINATION by default.

  • Page 87: Dipsw7 - Fiber/Cat5 Ports A-B-C-D

    H A R D W A R E DIPSW7 - Fiber/CAT5 Ports A-B-C-D Selects whether the audio network or control surface connection will be made through optical fiber or copper CAT-5 cable. DIPSW8 - Primary/Secondary Ports A-B-C-D Some system configurations may have multiple QAT cards in each rack. The Primary setting is used to distinguish which QAT port will act as the Clock/Sync master in the Remote chassis.

  • Page 88: Dipsw6 - Rack Id

    H A R D W A R E DIPSW6 - Rack ID If the QAT card is a Remote-Primary Audio Network Card, this QAT card must supply the Rack ID to its backplane from the 4 bit onboard switch. Remote Rack ID’s must be 5 or higher.

  • Page 89: Status Led's

    H A R D W A R E QAT Card Status LED’s SAMPLE RATE STATUS - DS1 - ON indicates that the rate is 48 kHz DS4 - ON indicates that the rate is 44.1 kHz DONE LED (DS2) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing.
  • Page 90 H A R D W A R E LINK STATUS LED’s RX STATUS (DS8,12,16,20) - ON indicates that the data A, B, C or D receive link is OK. LINK STATUS (DS9,13,17,21) - ON indicates that a hard- ware A, B, C or D link is established. ACTIVITY LED (DS10) - Flashes on port messages.

  • Page 91: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to and from QAT-2001 Card takes place at the two rear I/O connector modules: The QCT-2001 is used for CAT5 connections made via four RJ-45 connectors. The QOT-2001 is used for multi-mode optical fiber connec- tions made via four SC type optical connectors (optical fiber interface described on the page 2-48).
  • Page 92 H A R D W A R E QCT Panel I/O Connections SERIAL RX1 LO (RS-485) I/O PORTS RX1 HI (RS-485) (Upper "A" RX1 (RS-232) TX1 (RS-232) DB-9) TX1 LO (RS-485) TX1 HI (RS-485) RX2 LO (RS-485) I/O PORTS RX2 HI (RS-485) (Lower "B"...
  • Page 93 H A R D W A R E QOT Panel I/O Connections I/O PORTS SERIAL (Upper "A" DB-9) RX1 LO (RS-485) RX1 HI (RS-485) RX1 (RS-232) TX1 (RS-232) TX1 LO (RS-485) TX1 HI (RS-485) Audio Network (SC Connector "A", "B", "C" & "D") OPTO page 2 –...

  • Page 94: Digital Signal Processor Card (Dsp-2001)

    H A R D W A R E Digital Signal Processor Card (DSP-2001) Overview The DSP-2001 card is the digital signal processing card used by the Bridge System to mix and condition input signals. DSP cards in a given system are physically identical. Their fuctionality is determined by input and mix software which is loaded into each DSP card’s memory on surface powerup.

  • Page 95: Switch Settings

    H A R D W A R E Switch Settings SW1 - DSP Reset Switch Momentary press and hold resets the DSP and reloads software from surface. DIPSW2 - Not used Jumper Settings J1 - Factory Use Only - Watchdog Reset Momentary shorting does a complete reset.

  • Page 96: Status Led's

    H A R D W A R E DSP Card Status LED’s FAIL (DS1) - Normally OFF; Lights to indicate card failure. DONE LED (DS2) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing. ERROR (DS3) - Normally OFF; Lights to indicate clock error.

  • Page 97: Microphone Card (Mic-2001)

    H A R D W A R E Microphone Card (MIC-2001) Overview The Microphone input/output cards accept 8 mono microphone input audio sources and provides 8 mono direct output channels. A Signal Defini- tions form in the supplied XPoint software allows the user to set attributes for the input and output channels hardware including signal name, type, circuit #, etc.

  • Page 98: Status Led's

    H A R D W A R E Microphone Card Status LED’s DONE LED (DS1) - Normally OFF; ON when programming the FPGA, Flashes when system clock is missing. POWER SUPPLY STATUS (DS2-DS4) - ON indicates power supply is OK. JTAG HEADER - FPGA programming - factory use only.

  • Page 99: Hook-Ups

    H A R D W A R E Hook-Ups All user wiring to the MIC-2001 card takes place at the rear I/O connectors modules: 2DB or 8RJ-45. The 2DB module has two female DB-25 connectors for audio input/output connections. The 8RJ-45 module contains eight RJ-45 connectors for use in balanced, unshielded twisted pair (UTP) wiring sys- tems.

  • Page 100: Rj-45-Analog Audio Connections

    H A R D W A R E Pin 7 – HI Pin 20 – LO Direct 4 Out Pin 8 – SH Pin 18 – HI Pin 6 – LO Direct 5 Out Pin 19 – SH Pin 4 – HI Pin 17 –...
  • Page 101 H A R D W A R E 2DB Panel Mic Analog Input/Output Connections AUDIO GROUND MIC 1 IN SH MIC 1 IN LO MIC 1 IN HI MIC 2 IN SH MIC 2 IN LO MIC 2 IN HI MIC 3 IN SH MIC 3 IN LO MIC 3 IN HI...
  • Page 102 H A R D W A R E 8RJ Panel Mic Analog Input/Output Connections RJ-45 #1 RJ-45 #5 MIC 2 IN HI DIRECT 2 OUT HI MIC 2 IN LO DIRECT 2 OUT LO MIC 1 IN HI DIRECT 1 OUT HI MIC 1 IN LO DIRECT 1 OUT LO RJ-45 #2...
  • Page 103 C O N T R O L L E R D E V I C E S Controller Devices Chapter Contents XP Configuration GUI ..............3-2 XY Controller GUI ............... 3-3 XY Rack Controller ..............3-3 Wheatstone Console XY Controller .......... 3-4 XY Controller Settings ...............

  • Page 104: Xp Configuration Gui

    C O N T R O L L E R D E V I C E S Controller Devices The 2001 audio network router has provisions for two levels of software control and also two dedicated hardware controllers. Software configuration and control of the system is handled by the XPoint Configuration GUI described below.

  • Page 105: Xy Controller Gui

    250 is a more practical limit). Its main purpose is to provide an alternative, software based method of controlling the Bridge 2001 utilizing a station’s existing network infrastruc- ture. Multiple, simultaneous users may connect signal sources to destinations and monitor the status of audio resources throughout a facility. A signal visibility feature allows users to only “see”...

  • Page 106: Wheatstone Console Xy Controller

    C O N T R O L L E R D E V I C E S Wheatstone Console XY Controller Identical in function to the XY Rack Controller, the console XY controller is packaged to mount in a Wheatstone console meterbridge or, as an XY-4/8 module, in the console mainframe.

  • Page 107: Xy Controller Rs-485 Connections

    C O N T R O L L E R D E V I C E S XYD-600 METERBRIDGE-MOUNTED CONTROLLER DIPSWITCH # POSITION WEIGHT XY-4/8 MODULE DIPSWITCH # POSITION WEIGHT XY Controller Signal Visibility Once addressed, the XY controllers have the ability to “see” any or all of the sources, destinations and Salvos’...

  • Page 108: Serial Port Options

    C O N T R O L L E R D E V I C E S Serial Port Options All RS-485 communications ports in the Bridge 2001 are software configured to be XY Controller, Wheatstone Console or Virtual Serial ports.

  • Page 109: Wheatstone Console Interface

    C O N T R O L L E R D E V I C E S Wheatstone Console Interface The Bridge 2001 has a powerful level of integration designed into the system which allows the user to map specific Wheatstone console input channel alpha-numeric displays, to router destinations.

  • Page 110: Console Cpu Module Settings

    C O N T R O L L E R D E V I C E S Console CPU Module Settings Certain dipswitch settings must be made on the connected Wheatstone consoles in order for them to be recognized by the 2001 system software. These settings are console address, serial port mode and RS-485 termina- tion.
  • Page 111 X P O I N T S O F T W A R E S E T U P G U I D E XPoint Software Setup Guide Chapter Contents Bridge 2001 Ethernet/IP Address Quick Start ......4-2a Ethernet Cabling ...................... 4-2a Default IP Address ....................4-2a Changing your PC’s IP Address ................4-2a Changing the Bridge 2001’s IP Address ..............

  • Page 112: Bridge 2001 Ethernet/Ip Address Quick Start

    Ethernet Cabling • Use a CAT 5 crossover ethernet cable to connect a PC directly to the Bridge 2001. • Use a standard CAT5 ethernet cable to connect the Bridge 2001 to your network hub. Default IP Address The Bridge 2001 router IP Address is set to 192.168.1.160 at the factory. In order to connect using the XPoint software, the PC must have a matching network prefix (i.e...

  • Page 113: Changing The Bridge 2001'S Ip Address

    • If you changed your PC's IP Address, enter the parameters exactly as displayed above. • If you changed the Bridge 2001's IP Address, enter the parameters you entered using the Network Configuration Utility program. If you are connected to the router, you should see a "Connecting to..." message in the status bar at the bottom of the screen.

  • Page 114: Getting Started

    X P O I N T S O F T W A R E S E T U P G U I D E XPoint Software Setup Guide Getting Started All Wheatstone Bridge 2001 Audio Network Router hardware is pre- configured at the factory according to customer specifications. This approach greatly speeds the installation process getting you “online”...

  • Page 115: Connection Between The Configuration Gui And Master Rack

    X P O I N T S O F T W A R E S E T U P G U I D E Connection Between the Configuration GUI and Master Rack Depending on the state of the system when the current default configuration files were saved, the Configuration GUI may start in the OFF-LINE or ON- LINE mode.
  • Page 116 X P O I N T S O F T W A R E S E T U P G U I D E Once the configuration has been uploaded the GUI enters the ONLINE state as shown to the left: Connected To 192.
  • Page 117 X P O I N T S O F T W A R E S E T U P G U I D E To connect to the Host CPU while in OFFLINE mode, select the View / Mode / Online menu option. The status indicator on the screen will then change to CONNECTING as discussed above.

  • Page 118: System Configuration Menus

    X P O I N T S O F T W A R E S E T U P G U I D E System Configuration Menus From the user point of view, configuration of the 2001 system is relatively simple, since the Configuration GUI does much of the actual underlying configuration assignment work automatically.

  • Page 119: Rack Configuration

    X P O I N T S O F T W A R E S E T U P G U I D E Rack Configuration Note that your system was pre-configured and this step is not necessary unless you are changing or adding hardware located in one or more racks. The first step in configuring the system should be to lay out the required hardware via the setup menus on the Configuration GUI.

  • Page 120: Card/Signal Definition

    X P O I N T S O F T W A R E S E T U P G U I D E Card/Signal Definitions Note that your system was pre-configured and this step is not necessary unless you are changing or adding hardware located in one or more racks. If you only need to change the signal Name, see “Signal Definition”...

  • Page 121: Cpu Card Definition

    X P O I N T S O F T W A R E S E T U P G U I D E CPU Card Definition If the selected card is a CPU card, the same form is presented but the section labelled “Audio Network Link to Remote”...

  • Page 122: Input Card Definition

    X P O I N T S O F T W A R E S E T U P G U I D E Input Card Definition There are no user definable hardware parameters on analog or digital input cards. However, the form to the right appears after left clicking on an input card in the RackDefs form.

  • Page 123: Configuration Rules And Recommendations

    X P O I N T S O F T W A R E S E T U P G U I D E Configuration Rules and Recommendations The following rules and recommendations should be considered when configuring the hardware (most are required to ensure proper clock connec- tion between racks): 1.
  • Page 124 X P O I N T S O F T W A R E S E T U P G U I D E Using any text editor or word processor open this file to view the configura- tion listing. This document provides a listing of all configured hardware, including location, cabling, and jumpering details.
  • Page 125 X P O I N T S O F T W A R E S E T U P G U I D E COM PORT 2:: Console Bus Slave 9600 (baud rate) SW5-1 = OFF (Local) SW5-2 = ON (Primary) SW7[1,2,3,4] = 0000 (Rack ID) (0 = OFF, 1 = ON) Set SW5-3 as follows:: OFF=48Khz , ON=44.1 khz Set SW5-4 as follows:: OFF=fiber, ON=CAT5...

  • Page 126: Signal Definition

    X P O I N T S O F T W A R E S E T U P G U I D E Signal Definition Up to 512 separate source and destination signals may be defined via the Configuration GUI (up to 2048 in multi-tier installations). To add or edit a signal from the GUI’s main grid, right click on one of the Source or Destination signals and select “Modify Signal Definition”.

  • Page 127: Configuring Logic I/O

    X P O I N T S O F T W A R E S E T U P G U I D E Configuring Logic I/O Overview The LIO-2001 adds 12 programmable logic input and 12 output functions per card. The addition of logic I/O adds a powerful level of complexity to your Wheatstone router and care must be exercised during configuration to ensure the proper results.

  • Page 128: Routable Logic Signal Definitions

    X P O I N T S O F T W A R E S E T U P G U I D E Routable Logic Signal Definitions There are two types of routable logic signals - Logic I/O Only or Mapped Logic I/O. All routable logic signals must first be defined using the Signal Definitions form.

  • Page 129: Defining Routable Logic Functions

    X P O I N T S O F T W A R E S E T U P G U I D E Defining Routable Logic Functions Mapped logic and Logic I/O Only signals rely on common function names as a way of “knowing”...

  • Page 130: Configuring Triggered Port Logic

    X P O I N T S O F T W A R E S E T U P G U I D E Configuring Triggered Port Logic Triggered logic ports enable the firing of salvos or temporary audio connections from a GPI or simple switch closure.

  • Page 131: Signal Locking

    X P O I N T S O F T W A R E S E T U P G U I D E Signal Locking To lock a signal, right click on one of available output channels on the crosspoint grid and select “Lock Connection”: That crosspoint output signal becomes locked as indicated by red line through the signal on the GUI display and shown on form below:...

  • Page 132: Salvo Definition

    X P O I N T S O F T W A R E S E T U P G U I D E Salvo Definition Macro control of the 2001 router is accomplished by creating and firing Salvos. A Salvo is simply a group of cross connects, disconnects and “do nothings”...

  • Page 133: Xy Rack Or Console Xy Controller Configuration

    X P O I N T S O F T W A R E S E T U P G U I D E XY Rack Console XY Controller Configuration To configure a hardware based XY Controller, the operator must first log-in to the GUI as an Administra- tor.

  • Page 134: Console Configuration

    X P O I N T S O F T W A R E S E T U P G U I D E Console Configuration To map crosspoint output signals to console input channels the operator must first log in to the GUI as an Administrator. Then select the Configure / Console Interface menu option, which will display the following form: Each module in a console is identified via the...

  • Page 135: Xy Gui Controller Configuration

    X P O I N T S O F T W A R E S E T U P G U I D E XY GUI Controller Configuration In order to configure an XY GUI the operator must first log-in to the GUI as an administrator.

  • Page 136: Main Menu Summary

    X P O I N T S O F T W A R E S E T U P G U I D E Main Menu Summary The following is a summary of all the available menu choices when logged into XPoint as the Administrator.
  • Page 137 X P O I N T S O F T W A R E S E T U P G U I D E Diagnostics Menu View App Log : Opens network communications activity log. Can save log to a file for technical support purposes. View Switch Status : Lists all active installed hardware, card firmware revisions.

  • Page 138: Glossary

    G L O S S A R Y Glossary The terminology used in this manual is defined as follows: • Channel - A single, monaural audio stream. The 2001 can switch up to 512 discrete inputs to 512 discrete outputs (256 x 256 stereo) per tier.
  • Page 139 G L O S S A R Y The following terms apply to switch configuration: • Switch ID - A unique identifier assigned to each 2001 switch. Used in multi-tier configurations (described below). • Rack ID - The physical chassis ID number. The master chassis is always identified as Rack ID 1.

  • Page 140: Appendices

    A P P E N D I C E S Appendices Appendix 1 Configuring the 2001 Switch Network Parameters ....A-3 Appendix 2 Failover CPU Configuration /Operation ........A-6 Appendix 3 Replacement Parts List ............... A-9 page A – 1 2001 / Jul 01...

  • Page 141: Appendix 1

    A P P E N D I C E S Appendix 1 Contents Configuring the 2001 Switch Network Parameters ....A-3 page A – 2 2001 / Jul 01...

  • Page 142: Configuring The 2001 Switch Network Parameters

    A P P E N D I C E S Configuring the 2001 Switch Network Parameters Caution! Your system has been preconfigured at the factory for a default IP address of192.168.1.160. Incorrect use of this utility program can cause system malfunction. Check the IP address label inside the master rack before making changes.
  • Page 143 A P P E N D I C E S 6. Enter Network Mask [0xFFFFFF00]...: FFFFFF00 0xFFFFFF00 = hexadecimal FFFFFF00 = 255.255.255.0 dotted decimal Note: Do NOT enter the 0x base identifier. Enter the network mask for your subnet. See your system administrator if you’re unsure of the proper value.

  • Page 144: Appendix 2

    A P P E N D I C E S Appendix 2 Contents Failover CPU Configuration /Operation ........A-6 page A – 5 2001 / Jul 01...

  • Page 145: Failover Cpu Configuration /Operation

    CPU failure. AES Sync If you are synchronizing the Bridge 2001 to an external AES reference clock, be sure to make connections to both CPU’s AES SYNC inputs. Note that to ensure impedance matching , do not parallel the AES inputs or outputs, provide dedicated AES drivers/receivers.
  • Page 146 A P P E N D I C E S Automatic Operation In the unlikely event of a primary CPU failure the backup CPU is notified via backplane logic and immediately requests the latest configuration from the GUI. The GUI in turn will download the latest configuration including the real-time status of all crosspoint connections.

  • Page 147: Appendix 3

    2001 Switch. A complete list of available components is shown on the next page. Contact Wheatstone technical support for further informa- tion. Wheatstone Corporation (600 Industrial Drive, New Bern, North Carolina, USA 28562) may be reached by phone at 252-638-7000, fax 252-637-1285, electronic mail “email@wheatstone.com”.
  • Page 148 A P P E N D I C E S REPLACEMENT PARTS — 2001 SWITCH COMPONENT DESCRIPTION WS P/N "008312" AES-2024/8 DIGITAL 8 INPUT CARD AES-2024/16 DIGITAL 16 INPUT CARD "008313" "008304" DO-2001 DIGITAL OUTPUT CARD ADI-2001 ANALOG INPUT CARD "008306"...

Table of Contents
