Altimium MAT.HDMI44-4K User Manual

4k 4x4 hdmi
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MAT.HDMI44-4K
4K 4x4 HDMI Matrix Switcher
All Rights Reserved
Version: MAT.HDMI44-4K_2016V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAT.HDMI44-4K and is the answer not in the manual?

Questions and answers

Related Manuals for Altimium MAT.HDMI44-4K

Summary of Contents for Altimium MAT.HDMI44-4K

  • Page 1 User Manual MAT.HDMI44-4K 4K 4x4 HDMI Matrix Switcher All Rights Reserved Version: MAT.HDMI44-4K_2016V1.0...
  • Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...

  • Page 3: Safety Precautions

     Unplug the power cord when left unused for a long period of time.  Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...

  • Page 4: Table Of Contents

    4.2.4.2 Via 4-pin EDID DIP switcher ............12 4.3 TCP/IP Control....................13 4.3.1 Control Modes ..................13 4.3.2 Control MAT.HDMI44-4K via TCP/IP communication software ....15 4.3.3 Control MAT.HDMI44-4K via web-based GUI ........17 4.3.3.1 Scene Menu ................17 4.3.3.2 Control Menu ................18 4.3.3.3 Configuration Properties ..............
  • Page 5 4K 4x4 HDMI Matrix Switcher 4.4 Firmware Upgrade through USB port .............. 24 5. Specification ......................26 5.1 Supported Resolution ..................26 6. Panel Drawing ......................27 7. Troubleshooting & Maintenance ................28 8. After-sales Service ....................30 Altimium www.altimium.com...

  • Page 6: Introduction

    1. Introduction 1.1 Introduction to the MAT.HDMI44-4K MAT.HDMI44-4K is a professional 4x4 HDMI Matrix Switcher that features receiving up to 4 HDMI2.0& HDCP2.2 compliant signal and 4 HDMI1.4& HDCP1.4 compliant signal. It provides 4 auxiliary audio ports for de-embeded HDMI audio output. It also boasts powerful EDID management to ensure reliable AV distribution and routing.

  • Page 7: Product Appearance Of Mat.hdmi44-4K

    4K 4x4 HDMI Matrix Switcher 2. Product Appearance of MAT.HDMI44-4K 2.1 Front Panel SYSTEM MONITOR POWER OUTPUTS MAT.HDMI44-4K ① ② ③ ④ Figure 2- 1 Front Panel Name Description Illuminate red when power on; Power ① Turn green in standby mode;...

  • Page 8: Rear Panel

    IR IN: input port for IR control signal, connect with IR receiver e) TCP/IP: (optional) TCP/IP port for unit control ④ DC 12V Connect with DC 12V 2A power adaptor ⑤ Ground Connect to ground  Pictures shown in this manual are for reference only. Altimium www.altimium.com...

  • Page 9: System Connection

    Step2. Connect HDMI displays (e.g. HDTV) to HDMI OUTPUTs with HDMI cables; Step3. Connect speakers/ amplifiers to the AUDIO OUTPUTs with audio cables; Step4. Connect the RS232 ports of control device (e.g. a PC) and MAT.HDMI44-4K to enable serial control.

  • Page 10: System Applications

    3.4 System Applications As its good performance in control and transmission, the MAT.HDMI44-4K can be widely used in computer realm, monitoring, large screen displaying, conference system, television education and bank securities institutions etc.

  • Page 11: Rs232 Control

     Uninstallation Delete all the control software files in corresponding file path. 4.2.2 Basic Settings Firstly, connect MAT.HDMI44-4K with necessary input devices and output devices. Then, connect it with a PC installed RS232 control software. Double-click the software icon to run this software.

  • Page 12: Rs232 Communication Commands

    /:MessageOn; com port. Enable command feedback on LCD /:FeedbackON; /:FeedbackON; monitor on the front panel (default). Disable command feedback on LCD /:FeedbackOFF; /:FeedbackOFF; monitor on the front panel (default). Operation Commands Undo. Cancel the previous operation. Undo Ok! Altimium www.altimium.com...
  • Page 13 EDID data. Capture the EDID data of output x and EDIDC[x]B[y]. EDIDC3B1 save it as No.y EDID, y=1~10,12~14 Invoke No.y EDID data saved through EDIDExtract[x][y]. Pick up success COM port to input x, y=1~10,12~14 Altimium www.altimium.com...
  • Page 14 PCM. If the EDID data is not available, it will set to initial EDID. PWON. Work normally. PWON Enter standby mode. (Return to normal mode via front panel STANDBY. STANDBY buttons/ other command/ remote) Altimium www.altimium.com...
  • Page 15 Check the input channel for all outputs AV: 4-> 4 System %9961. Return the keylock status. Unlock!/System Locked! %9962. Check the power status PWON IN1: PCM Check the audio format of EDID … %9963. database for input x IN4: PCM Altimium www.altimium.com...
  • Page 16 %9975. Check the I/O switch status. Out 1 2 3 4 1 2 3 4 Check the status of digital audio of all %9977. outputs, N is for “off”, Y is for “on”. Audio N N Y Y Altimium www.altimium.com...

  • Page 17: Edid Management

     Invoking embedded EDID data: Send command “EDID[X]B[y].” to enable input to invoke embedded EDID data of MAT.HDMI44-4K . For example, send “EDID[4]B[3]” , the INPUT device (4) will gain embedded EDID data is that 720P 2D 2CH.  EDID Copy: Send command “EDIDM[X]B[y].”...

  • Page 18: Tcp/Ip Control

    4001. IP can be changed as you need, Serial Port cannot be changed.  Controlled by single PC Connect a computer to the TCP/IP port of the MAT.HDMI44-4K, and set its network segment to the same as the default IP of the MAT.HDMI44-4K (192.168.0.178).
  • Page 19 Figure 4- 3 Modify the IP of PC  Controlled by PC(s) in LAN The MAT.HDMI44-4K can be connected with a router to make up a LAN with the PC(s), this make it able to be controlled in a LAN. When control, just make sure the MAT.HDMI44-4K’s network segment is the same with the router.

  • Page 20: Control Mat.hdmi44-4K Via Tcp/Ip Communication Software

    Step3. Set the MAT.HDMI44-4K’s network segment to the same as the router. Step4. Set the PC’s network segment to the original one. Step5. Connect the MAT.HDMI44-4K and PC(s) to the router. In the same LAN, each PC is able to control the MAT.HDMI44-4K asynchronously.
  • Page 21 4K 4x4 HDMI Matrix Switcher Enter your command here. Commands are the same with RS232 commands listed in 4.2.3 RS232 Communication Commands Here you will receive the feedback after a command is sent. Figure 4- 6 Control interface of TCPUDP Altimium www.altimium.com...

  • Page 22: Control Mat.hdmi44-4K Via Web-Based Gui

    4.3.3 Control MAT.HDMI44-4K via web-based GUI In addition to control MAT.HDMI44-4K via communication software MAT.HDMI44-4K can be controlled via web-based GUI It allows users to interact with MAT.HDMI44-4K through graphical icons and visual indicators. Type 192.168.0.178 in your browser, it will enter the log-in interface shown as below: Figure 4- 7 Login GUI This system divides into administrator and user mode.

  • Page 23: Control Menu

    Click “cancel” to cancel the current operation. 4.3.3.2 Control Menu Click “Control” to enter the following interface, it provide intuitive I/O connection switching. Setting Button Figure 4- 9 Control Menu The button matrix displays every possible connection between every input and output; Altimium www.altimium.com...

  • Page 24: Configuration Properties

    Return Button Figure 4- 10 Embedded EDID All embedded EDID of MAT.HDMI44-4K are shown in the above interface. User can select EDID in accordance with actual needs. 2) Select “EDID Copy” to enter the following interface: Altimium www.altimium.com...
  • Page 25 EDID from output device. Step3: Click “Confirm” to save the setting or click “Cancel” to cancel operation. 3) Select “Audio Out” to enter the following interface to turn on/off the Audio Output passage. Return Button Figure 4- 12 Audio EDID Altimium www.altimium.com...
  • Page 26 Figure 4- 13 Status- LCD 2) Select “Button” to enter the following interface to modify the name of buttons. Return Button Figure 4- 14 Status- Button 3) Select “Scene” to enter the following interface to modify the name of scenes. Altimium www.altimium.com...
  • Page 27 MAC address, IP address, subnet mask, and Gateway. Return Button Figure 4- 16 Network 5. Password At the top of the interface, click “Password” to enter the following interface to inquire and modify the admin or user password. Altimium www.altimium.com...

  • Page 28: Tcp/Ip Configuration

    4.3.4 TCP/IP Configuration IP address, subnet mask, and Gateway of MAT.HDMI44-4K can be modified via GUI from the above description, but beyond that users can configure the IP port, including IP reset, password reset, and IP module firmware update on the WebServer.

  • Page 29: Firmware Upgrade Through Usb Port

    Steps to upgrade the device: Step1. Connect the control PC to the USB port of MAT.HDMI44-4K. Step2. Reboot MAT.HDMI44-4K to enter upgrade mode. Press and hold button 2& 3 when rebooting. The power indicator will keep blinking in upgrade mode.
  • Page 30 Figure 4- 21 Upgrade firmware via DfuSe Demonstration Step4. Click Choose… to load desired upgrade file (.dfu). Step5. Click Upgrade to start.  Make sure the button Leave DFU mode is available to ensure control PC and MAT.HDMI44-4K are connected successfully. Altimium www.altimium.com...

  • Page 31: Specification

    Recommend using quality HDMI cables in order to attain prefered transmission distance and effects. 5.1 Supported Resolution Display Ratio Resolutions 4096x2160 (30,50,60 Hz), 3840x2160 (24,25,30 50 60 Hz) 21:9 2560x1080 (60Hz) 1920x1080(1080P 3D), 1600x900, 1366x768, 1280x720, 1024x576 16:9 (60Hz) 16:10 1920x1200,1680x1050, 1440x900, 1360x768,1280x800 (60Hz) 1600x1200,1400x1050, 1280x1204,1024x768, 800x600,640x480 (60Hz) Altimium www.altimium.com...

  • Page 32: Panel Drawing

    4K 4x4 HDMI Matrix Switcher 6. Panel Drawing 436 mm SYSTEM MONITOR POWER OUTPUTS MAT.HDMI44-4K 23 mm Altimium www.altimium.com...

  • Page 33: Troubleshooting & Maintenance

    Adjust the distance and of the IR signal or not angle and point right at the pointing at the IR receiver IR receiver. Power Indicator remains off Fail loose power Check whether the cables when powered on connection are connected correctly Altimium www.altimium.com...
  • Page 34 Send it to authorized by RS232 / IR remote / been broken. dealer for repairing. front panel buttons If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com...

  • Page 35: After-Sales Service

     Product version and name.  Detailed failure situations.  The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor. Altimium www.altimium.com...
  • Page 36 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
