- Page 1 AUTOMATIC TELEPHONE ALARM DIALER DIAL 1602M OPERATION AND INSTALLATION INSTRUCTION MANUAL...
- Page 2 ROGER s.c. DIAL 1602 v1.0 25/11/1999 TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS TABLE OF CONTENTS POWER SUPPLY POWER SUPPLY POWER SUPPLY POWER SUPPLY The dialer requires DC power supply from 11 do 15V. A loss of TABLE OF CONTENTS..............1 power supply results in resetting the dialer time and date, however, INTRODUCTION................
- Page 3 [#]. You can exit the Record/Play procedure with the [#] the start procedure. When the power supply voltage is higher than key. 9.5V, the dialer will display the [Roger DIAL1602] message and - 2 -...
- Page 4 ROGER s.c. DIAL 1602 v1.0 25/11/1999 [3] Installer/User Code alarm line blocking from the moment the notification action was To reprogram the code, you should first determine which code will stopped, which was initiated in this line. It is shared by both alarm be changed ([0] or [1] key) and then, by pressing any numeric key, inputs.
-
Page 5: Technical Specification
ROGER s.c. DIAL 1602 v1.0 25/11/1999 (if it is allowed) or direct to the ready mode. See the schematic of Double message dialer changing the dialer modes. When the notification procedure is completed, the dialer switches to the pause during which it blocks the alarm input from which the... - Page 6 ROGER s.c. DIAL 1602 v1.0 25/11/1999 - 5 -...
- Page 7 ROGER s.c. DIAL 1602 v1.0 25/11/1999 Schematic of changing the DIAL1602 dialer operating modes. NOTE ! Pause after the duress alarm equals 0 minutes. (INSTAL. CODE-Installer code; USR. CODE-User Code) - 6 -...
