NIXXO Tanium User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

TABLE OF CONTENTS

4
5
6
6
7
8
9
10
12
12
13
13
14
14
15
18
18
20
21
22
23
24
26
27
28
28
28
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tanium and is the answer not in the manual?

Questions and answers

Related Manuals for NIXXO Tanium

Summary of Contents for NIXXO Tanium

  • Page 1: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION Locking a message FEATURES OPTIONAL FUNCTIONS Activating menu board GETTING STARTED Setting alarm Description of control button Setting auto timer Description of icons Setting reminder alert Turning your pager on and off Entering greeting Setting date & time Ready messages Choosing different alert modes Setting low battery alert...

  • Page 2: Introduction

    INTRODUCTION Welcome to Nixxo Pager World! Your new pager provides you with many enhanced features, such as 20 kinds of ready messages, 3 alarms, and English & French menu script. Nine segment display makes easy to read messages. This user guide gives instructions on how to use Titanium pager.

  • Page 3: Features

    FEATURES FLEX Protocol Individual Delete & Delete All 520 Characters Private Message Memory 1 Daily & 2 Event Alarms (20 Slots x 26 Characters) User Selectable 15 Melodies & 5 Tones 20 Ready Messages Vibration Alert (User Option On/Off) User Programmable Auto On/Off Timer AGC (Auto Gain Control) Function Available Reflective Backlighting Display Side View 1 Line Display (9 Segment)

  • Page 4: Getting Started

    1. DESCRIPTION OF CONTROL BUTTON Screen Titanium Function Button Read Button Function Button Read Button Enter menu set Read messages Change alert mode Select menu Stop alert or alarm...

  • Page 5: Description Of Icons

    2. DESCRIPTION OF ICONS Tone Alert Auto On/Off Timer Vibration Alert Low Battery Melody Alert Duplicate Message Pager Alarm Service Area Indicator Locked Message Continued Message Full Memory Capacity...

  • Page 6: Turning Your Pager On And Off

    3.TURNING YOUR PAGER ON AND OFF TURN OFF To turn your pager off, press two times. When Tone off is displayed, press to scan menu until Power off is displayed. Press to turn off. TURN ON Press for 2 seconds to turn your pager on. Greeting message is displayed.

  • Page 7: Setting Date And Time

    4. SETTING DATE AND TIME Press . Backlight comes on. Then press again. Tone Off? is displayed. Press repeatedly until SET TIME is displayed. Press to select menu. The month indicator begins to blink. Press to move to the desired number. Press to enter correct month.

  • Page 8: Choosing Different Alert Modes

    5. CHOOSING DIFFERENT ALERT MODES You can choose one of 3 types of alert modes : beep, vibration or musical alert. 1. VIBRATION ALERT Press to change the sound alert to vibration alert. Backlight comes on. Press again. Tone Off is displayed. Press to confirm.
  • Page 9 Press to display Melody Set. Press to confirm. To scan sound, press The screen shows the number for each sound. From 1 to 15 are melody alerts and from 16 to 20 are beep alerts. When the screen displays an alert you want, press to confirm.

  • Page 10: Messages

    1. READING MESSAGES When a message is received, Titanium either audibly alerts (beep or musical alert) or vibrates and display the message. To stop vibration or audible alert, press any button. If Titanium has any unread message, the screen displays PAGE . To see the current time, press The current time is will be displayed 3 seconds later.

  • Page 11: Duplicate Messages

    2. DUPLICATE MESSAGES If pager receives a duplicate message, duplicate icon displays on top of the screen. 3. DISPLAY If the pager has 20 messages, PAGE FULL is displayed. If Titanium receives more than 20 messages, the oldest message gets deleted as new message is received.

  • Page 12: Erasing A Message

    4. ERASING A MESSAGE After reading a message, press Backlight comes on. Press again. You are prompted with ERASE? display. Press to confirm. If you want to exit this mode, press 5. ERASING ALL MESSAGES ERASE ALL command erases all messages except the locked messages. Press .

  • Page 13: Locking A Message

    6. LOCKING A MESSAGE You can protect messages from being erased by ERASE ALL function. SET MESSAGE LOCK FUNCTION Press . Backlight comes on. Press and hold for 2 seconds. The screen changes to ERASE ALL . Press to display SET LOCK FNC .Then press Press to turn the message lock ON .
  • Page 14 LOCK A MESSAGE Press repeatedly to display the message to be locked. Press . Backlight comes on. Press again. The screen shows ERASE? Press . The screen displays LOCK? Press . The message is now locked. When you read a locked message, you can see icon on top of the screen.
  • Page 15 Press . Backlight comes on. Press again. Unlock ? is displayed. Press to confirm.

  • Page 16: Optional Functions

    1. ACTIVATING MENU BOARDS Titanium has 2 menu boards. FIRST MENU BOARD To activate a menu board, press . Backlight comes on. Press again. Tone off or Tone on is displayed. is pressed, the following menu shown on the down is displayed one after another.
  • Page 17 SECOND MENU BOARD To activate the second menu board, press . Backlight comes on. Press and hold for 2 seconds. At first the screen displays Tone off or Tone on , but it changes to ERASE ALL , which is the first option of the second menu board. is pressed, the following menu is displayed one after another.

  • Page 18: Setting Alarm

    2. SETTING ALARM Titanium has 2 types of alarms : daily alarm (everyday : alarm1) special alarm (one time : alarm 2, 3 ) From standby mode, press two times to activate menu. Press and release until SET ALARM displays. Press to activate alarm menu.

  • Page 19: Setting Auto Timer

    Press to confirm. Press to enter the hour to the desired hour. Then press to confirm. Repeat the above procedures to set each field. The standby screen displays icon . 3. SETTING AUTO TIMER You can set your pager to power on or off automatically at a selected time of day. You can save battery power by using this function.

  • Page 20: Setting Reminder Alert

    Press Press to select On . Then press to confirm. Follow the same procedures of time setting to set the on and off times. (Refer to page 9.) The standby screen displays icon 4. SETTING REMINDER ALERT You can set your pager to alert every 5 minutes in case you have unread messages. Activate the second menu board.

  • Page 21: Entering Greeting

    Press and release until Unread FNC is displayed. Then press Press to select On . Then press to confirm. 5. ENTERING GREETING You can enter greeting messages upto 12 characters including space. The greeting is shown on the initial screen when power is on. Activate the second menu board.

  • Page 22: Ready Messages

    Repeat the above steps until you have entered the entire message. NOTE ) When entering characters, A ~ Z are followed by space (_) which is followed by 0 ~9 , space (_) and dash(-). 6. READY MESSAGES Twenty ready messages are permanently stored in the memory of Titanium pager. When the pager receives a code number instead of phone number, it activates ready messages.
  • Page 23 Press to set Press to select ready on Press to confirm. CODES FOR READY MESSAGES CODES MESSAGES CODES MESSAGES CODES MESSAGES 020 Call home 027 Pick you up 034 Appt. time 021 Call office 028 Home urgt 035 I am sorry 022 Come home 029 I am home 036 Go to store...

  • Page 24: Setting Low Battery Alert

    7. SETTING LOW BATTERY ALERT You can set your pager to low battery alert using this function, when the battery is low. From standby mode, press Press and hold for 2 seconds to activate the second menu board. ( Refer to page 19. ) Press and release until LOW BAT_Fnc is displayed.

  • Page 25: Setting Script Language

    8. SETTING SCRIPT LANGUAGE Your pager provides you with two menu script languages to choose from; English and French. From standby mode, press Press and hold for 2 seconds to access the second menu board. ( Refer to page 19.) Press and release until SET LANGUAGE is displayed.

  • Page 26: Battery Information

    1.LOW BATTERY INDICAITON Titanium displays icon when battery is low. If the pager is set on low battery alert, it sounds a beep alert. 2. REPLACING BATTERY Titanium is designed to operate with a single AAA-size alkaline battery. Slide the battery cover in the direction of the arrow Lift the battery cover away from rear cover.
