- Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com GSD600 Gas Leak Detector Users Manual...
- Page 2 GSD600 Gas Leak Detector Users Manual GSD600_Rev001 © 2008 Amprobe Test Tools. All rights reserved.
- Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 4 Sensor cap ➌ indicator LeD ➍ on/off button ➎ Adaptor jack (power adaptor not supplied with GSD600) ➏ earphone jack (earphone not supplied with GSD600) ➐ Mute slide switch. Make sure to take in consideration any left over methane number when taking a new Combustible Gas >640...
- Page 5 GSD600 Gas Leak Detector CoNtENtS features ...............................5 Standard Accessories ...........................5 operation ............................5 power on/off pushbutton ......................5 warm-up Status ..........................5 Mute function ..........................5 Leakage Checking ..........................6 battery Replacement ...........................6 Troubleshooting ..........................6 Maintenance ............................6 Situations to be avoided .......................6 Situations to be avoided whenever possible ................6...
- Page 6 The frequency of the beep will increase when the detected gas concentration becomes higher. while using the meter with the earphone, the meter will automatically be muted, allowing the user to hear the beeper through the earphone. The earphone is not supplied with the GSD600. A standard earphone will work with this unit.
- Page 7 if the earphone is not in use, the user can mute the beeper by switching the mute button to the on position. The user then has the LeD’s as the indicator and no sound. Leakage Checking To check for pipe leakage, proceed as follows: Approach the pipe slowly with the sensor pointing to the pipe.
- Page 8 Minimum BAt. voltage: 4.8V probe length: 447 mm (17.6 inches) Size: 175 x 70 x 38 mm (hxwxT) Indicator: intermittent beep (Acoustic) / LeD (Visual) Range GSD600 Gas Leak Detector Methane 40 to 640 ppm propane 35 to 580 ppm Sensitivity...
