Summary of Contents for Sharper Image SI670
- Page 1 TV Everywhere!™ SI670 Instructions Read and save these instructions.
- Page 3 We offer generous return privileges and excellent warranties on all our products. For more than 25 years, The Sharper Image has shared the fun of discovering innovative products that make life easier and more enjoyable.
-
Page 5: Table Of Contents
Table of Contents Introduction................6 Quick Start ................8 Receiver/Monitor ..............8 Transmitter/Tuner ..............9 Source Selection ..............10 Channel Programming ............11 Viewing Stand and Wire Brackets ........12 General Instructions..............15 Parts Diagram ..............15 Operation Overview ............19 Setup ................... -
Page 6: Introduction
Introduction The TV Everywhere! ™ is a full-featured TV, “split” into two parts: 1. The tuner/transmitter connects to an audio/video source (cable, VCR, DVD player, etc.), interprets the signal and for- wards the picture and sound to the receiver. 2. The receiver is connected to and plays back through your TV. The following items are included with the product: •Tuner/Transmitter •... - Page 7 Introduction The cables are color-coded to match equipment standards and will allow you to connect to a video source in any of the following ways: • Directly to an existing unused coaxial cable. • Split connection from an existing coaxial cable. •To the audio/video out jacks of a VCR or DVD player.
-
Page 8: Quick Start
Quick Start Remote Control 1. Slide to open and remove the battery cover from the rear of the remote control. 2. Install the two included AA batteries and replace the cover. Transmitter/Tuner 1. Option 1: Connect the CABLE INPUT post on the transmitter/ tuner to a coaxial cable signal source. -
Page 9: Transmitter/Tuner
Receiver 1. Connect the color-coded RCA posts on the receiver to the matching input posts on your remote television set. 2. Connect the AC adapter to the DC POWER jack and to a 110V household outlet. TRANSMITTER/TUNER Cable In RECEIVER Television Out Television Out (Wireless) -
Page 10: Source Selection
Source Selection 1. Press the POWER ON/OFF button on the the Tuner/ Transmitter first, then the Receiver POWER ON/OFF button. 2. To activate the mode options, press the MODE SELECT button on the remote (or the receiver front panel). Input Source TV, Video, VCR3 or VCR4 appear on the screen. -
Page 11: Channel Programming
Channel Programming Note: The following steps are for coaxial connections in the TV mode. Turn on the receiver/monitor and the VCR (if connected) off. 1. To activate mode selection options, press the MODE SELECT button. 2. Select TV mode (if not already selected). 3. -
Page 12: General Instructions
General Instructions Parts Diagram Receiver Television Out (Wireless) - Page 13 Parts Diagram Transmitter/Tuner Cable In Television Out (Standard/Wired Connection)
- Page 14 Setup Receiver 1. Connect the color-coded RCA posts on the receiver to the matching input posts on your remote television set. 2. Connect the AC adapter to the DC POWER jack and to a 110V household outlet. NOTE: The Transmitter/Tuner must be connected and powered on before the Receiver.
- Page 15 Setup 2. Connect the yellow RCA post on the transmitter/tuner to a yellow output post on a VCR, DVD player or other video source. 3. Connect the red and white audio posts on the transmitter/ tuner to the matching output posts on the VCR, DVD player or other audio source.
-
Page 16: Operation Overview
Operation Overview Overview Upon power up, the unit defaults to normal viewing mode. The receiver/monitor must be turned on to make any changes. 1. To access programming and other options, press the MODE SELECT button on the receiver/monitor. 2. To scroll through the mode selection options, press the LEFT/ RIGHT button: •... - Page 17 • Fine Tuning: Make minor adjustments to the tuned frequency. (This feature should be used sparingly, if at all.) Input Source 1. To activate mode selection options, press the MODE SELECT button on the re,ote. The Input Source mode is displayed. (Input Source TV, Video, VCR3 or 4 appear on the screen.) 2.
-
Page 18: Mode Selections
Mode Selections Note: In all modes except TV, the channel and viewing opera- tions are controlled by the viewing source’s (VCR, DVD player, etc.) remote. The receiver/monitor CHANNEL buttons can be programmed to learn and mimic two functions of the source remote while operating in the Video, VCR3 or VCR4 modes. - Page 19 Mode Selections Automatic Channel Programming If you only have a coaxial connection and wish to control chan- nels through the receiver/monitor (as you would with a standard TV), follow these steps: 1. Turn on the receiver/monitor and the VCR (if connected) off. 2.
- Page 20 Mode Selections Manual Channel Programming & Editing Individual channels can be added or deleted from memory by using the follow steps for the Program Memory function: 1. To activate mode selection options, press the MODE SELECT button. 2. Select TV mode. 3.
- Page 21 Mode Selections Fine Tuning Individual channel reception can be adjusted using the Fine Tuning mode. The channels are preprogrammed for best recep- tion under most conditions. This feature should not be required except in rare circumstances. 1. To activate Mode selection options, press the MODE SELECT button.
- Page 22 Mode Selections Chart...
-
Page 23: Programming Remote Functions
Programming Remote Functions The CHANNEL buttons can be programmed to mimic two functions of another remote control when the unit is in the VCR3, VCR4 or Video Modes. (Example: The unit is connected to the RCA jacks of your VCR and you want the CHANNEL buttons to mimic the STOP and PLAY buttons on your VCR when you are watching a video in Video mode.) 1. - Page 24 Programming Remote Functions Figure 5 Figure 6 3. Press and hold the LEARN button on the transmitter/tuner until the SIGNAL LED blinks. 4. Point the remote control you wish to mimic toward the transmitter/tuner and press the button on the remote that you would like to mimic for the CHANNEL button on the receiver/monitor.
- Page 25 Programming Remote Functions 5. Press and release the LEARN button. 6. Point the remote control and press the second button you wish to mimic. This is now stored for the CHANNEL button on the receiver/monitor. Note: The receiver/monitor displays instructions and guides you through the learning mode process.
-
Page 26: Troubleshooting
Troubleshooting If the display does not function properly: 1. Turn the power off on both units and wait 10 seconds before turning both back on. In most cases, this action resets the unit and normal function resumes. 2. If no image appears on the monitor, press and hold the MODE SELECT button on the side panel for 5 seconds, then release. -
Page 28: Statement Of Fcc/Dhhs Compliance
Statement of FCC Compliance WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 29: Fcc Label Compliance Statement
Statement of FCC Compliance • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for assistance. FCC Label Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause... -
Page 30: Warranty
The Sharper Image will repair any defects in materials or workmanship. In the event repair is not possible, The Sharper Image will either replace this product with one of similar features and price, or refund the full purchase price of the product, whichever you prefer.
