MiG-15

ARF Electric Ducted Fan Jet

This Assembly Guide is intended to provide the experienced modeller with a basic outline on how to assemble

this advanced ARF. Due to the large number of ways in which it is possible to ﬁ t out this aircraft you may ﬁ nd

many steps ommitted or different to how you would do it. Please use your extensive personal experience to

complete the model as you see ﬁ t. The manufacturers, distributors and retailers will not accept liability for the

way in which you choose to complete this ARF. Do it well - It is your responsibilty.

(or .91 Nitro Ducted Fan)

ASSEMBLY GUIDE

SPECIFICATIONS:

Wingspan:

Length:

Weight inc. ﬂ ight batteries:

72in (1828mm)

8500g
