MOCS Owner’s Manual TABLE OF CONTENTS PLC System Specifications CPU System Specifications Overview Installation Operation Spare Parts Troubleshooting Precautions Options...
PLC SYSTEM SPECIFICATIONS Power Supply 100 to 240 VAC, 50/60 Hz Voltage / frequency 24 VDC Operating 85 to 264 VAC Voltage range 20.4 to 26.4 VDC Power 60 VA max. Consumption 20 W max. Inrush current 60 A max. External power supply Voltage 24 VDC...
CPU SPECIFICATIONS CPU Feature Summary Form Factor Mini-ITX, compatible with microATX (6.75 inches by 6.75 inches 171.45 millimeters by 171.45 millimeters]) Processor Support for the following: • Soldered-down Dual-Core Intel® Atom® processor Memory • One 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) socket •...
Page 5
CPU SPECIFICATIONS continued CPU Environmental Specifications Parameter Specification Temperature Non-Operating -20 °C to +70 °C Operating 0 °C to +55 °C Shock Unpackaged 50 g trapezoidal waveform Velocity change of 170 inches/second² Packaged Half sine 2 millisecond Product weight (pounds) Free fall (inches) Velocity change (inches/sec²) <20 21-40 41-80...
OVERVIEW The Essex Inc. MOCS, or Machine to Operator Communication System, is designed to work in conjunc- tion with the Essex process control products to automatically audibly alert the operator via wireless com- munication to any off-standard condition that requires a machine shut down or alarm. MOCS allows one operator to monitor multiple machines without the necessity of constant visual contact.
Connections to the Control Panel 120 VAC power required Connect MOCS Interface panel as per included wiring diagram (if applicable) Run relay contact to Process Control panel or MOCS Interface panel must be a maintained contact for MOCS to function properly...
Alert volume can be adjusted with the volume knob. See below. For MOCS Plus, to call a team member, press the Push-To-Talk (PTT) button located on the lapel microphone/speaker and hold. Speak into the microphone, using a normal speaking voice. See below.
Page 9
Charging time is approximately 2 hours. The receiver’s indicator light will blink red while charging. Changing the Battery in the Basic MOCS Receiver To change the battery unlock the front door panel on the Receiver. See below Replace with AA rechargeable batteries. See below...
26.15.000.NS Noise Suppressor for MOCS 26.15.000.PC PC for MOCS 26.15.000.PCPS PC Power Supply for MOCS 26.15.000.E OSHA approved Ear Buds for MOCS 26.15.000.BR Belt-pack Receiver for Basic MOCS 26.15.000.T.2 Transmitter for MOCS Plus Rechargeable AA batteries for Basic MOCS Receiver...
TROUBLESHOOTING MOCS Problem Solution Cannot turn the MOCS Plus radio or Basic MOCS Re- The battery pack may be dead. Recharge or replace the ceiver power ON battery pack. The battery pack may not be installed correctly. Remove the battery pack and install again.
OPTIONS Basic MOCS Description System will alert the operator with stop information directly and automatically. Components Control panel with one-way radio transmitter and built in charging points for receivers Belt pack receivers OSHA approved ear buds MOCS Plus Description System will alert the operator with stop information directly and automatically, and also allows 2- way communication between operators.
