Before performing the connection, make sure that

the ratings correspond to the power supply voltage

Office Coffee Service

Vending Machine

Model : DG-707FM(DSK-622-MA)

DG-808F3M(3Mixing bowl)

DG-808F5M(2Mixing bowl)

Table of Contents

Need help?

Do you have a question about the DG-707FM and is the answer not in the manual?

Questions and answers

Summary of Contents for Donggu DG-707FM

Page 1 Office Coffee Service Vending Machine Model : DG-707FM(DSK-622-MA) DG-808F3M(3Mixing bowl) DG-808F5M(2Mixing bowl) Main Office : 500-5, Sangdaewon-Dong,Jungwon-Ku, Sungnam-City, Kyungki-Do, Korea TEL. 82-31-731-3600 FAX. 82-31-733-1155 Before performing the connection, make sure that Email. info@venusta.net the ratings correspond to the power supply voltage...
Page 2: Table Of Contents
6. How to clean the connection tubes/How to use mountable water bottle ………………… 7. How to install and operate ……………………………………………………………………………… 8. How to adjust the taste control & water volume(DG-707FM) …………………… 9. How to adjust the taste control & water volume(DG-808F3M) …………………...
Page 3: Description Of Each Section
The cup barrel Push button/ Indication panel Coin sensor Coin slot Coin custody box 1Kind coin:option Cup outlet Cup outlet <DG-808F3M> <DG-707FM> DISPLAY OF Internal View DISPALY VENDING PRICE The rear side Water tank Canister(1,2,3) MENU BUTTON MODE COIN SLOT...
Page 4: How To Supply Water/How To Supply Materials
• You can see the paper cup ● Supply the water to reach 3cm comes out through the outlet <DG-707FM> <DG-808F3M> distance from the top of the with beep sound water tank. ● If the water overflows or gets into the assembly, it may cause the defect of the machine.
Page 5: How To Clean The Connection Tubes/How To Use Mountable Water Bottle
How to clean the connection tubes How to install and operate When using the machine for the first time or exception the connection tubes to be clogged due to the This product is adjusted for the best taste at factory when it comes out. Try to make the drink be tasteful. hardened materials during operation, press the cleaning button, it will clean them automatically.
Page 6: How To Adjust The Taste Control & Water Volume(Dg-707Fm)
How to adjust the taste control & water volume(DG-707FM) How to adjust the taste control & water volume(DG-808F3M) This function can be set-up following individual taste. This function can be set-up following individual taste. Set the Enable /Disable switch in the control Press the "MODE"...
Page 7: How To Adjust The Temporary Taste Control Of The Front Door(For User)
How to adjust the temporary taste control of the front door(FOR USER) How to adjust the temporary taste control function Enable & Disable of the front door(FOR USER) (DG-707FM / DG-808F3M) (DG-707FM / DG-808F3M) Set the Enable /Disable switch in the control box inside the...
Page 8: How To Set Price(Dg-707Fm)
How to set price(DG-707FM) How to set price(DG-808F3M) Set the Enable /Disable switch in the control box inside the Set the Enable /Disable switch in the control box inside the door to Enable. door to Enable. Amount indicator --- Amount indicator --- Press the "MODE"...
Page 9: How To Check Your Selling Cups(Dg-707Fm)
How to check your selling cups(DG-707FM) How to check your selling cups(DG-808F3M) Set the Enable /Disable switch in the control box inside the Set the Enable /Disable switch in the control box inside the door to Enable. door to Enable.
Page 10: The Function For My Cup(Individual Cup) Use(Dg-707Fm)
The function for My cup(Individual cup) use(DG-707FM) The function for My cup(Individual cup) use(DG-808F3M) Set the Enable /Disable switch in the control box inside the Set the Enable /Disable switch in the control box inside the door to Enable. door to Enable.
Page 11: How To The Adjustment Of Water Temperature
How to the adjustment of water temperature How to the operation test(DG-707FM / DG-808F3M) (DG-707FM / DG-808F3M) Set the Enable /Disable switch in the control box inside the Set the Enable /Disable switch in the control box inside the door to Enable.
Page 12: How To The Cleaning
How to the cleaning Inside water tank Mixing bowl Remove fur stacked inside water tank Wash it with soft sponge gourd after with soft sponge. soaping it in the water to make hardened material become soft. •Clean it over two times per one month •After removing water completely, place it back in the specified position.
Page 13: How To Disassemble Parts
How to disassemble parts How to disassemble the mixing bowl Hold the canister with both fingers and remove After remove "A" part, it by lowering and pulling it upward part "A" Turn off upward part "B". Remove the mixing part in the Remove Drink outlet hose &...
Page 14: How To Replace Fuse
Remove the broken fuse and Close the fuse holder. insert the new one. Specification Model DG-707FM DG-808F3M Power supply 220(110)V50/60Hz(Export standard spec. is negotiable) Consumption power 818W Overheati n g preventi o n functi o n Bimetal system(Turn off to 115℃)
