Summary of Contents for Seawave ST60 Wireless
- Page 1 ST60- Wireless Owner's Handbook ST60- Wireless cut the cable page 1 - 20 Doc: ST60_Wireless_Manual_E_V10 LastEdit: 03.02.2005 Printed: 03.02.2005...
-
Page 2: Table Of Contents
ST60- Wireless Owner's Handbook Contents 1 Introduction ..............1.1 Operating modes . -
Page 3: Introduction
ST60- Wireless Owner's Handbook Introduction Thank you for your order of this ST60-Wireless set. We are convinced, that with the use of this device the installation will be much easier. The units are ruggediest and will serve you well for many years. The ST60-Wireless replaces in a ST60 System the long cable from the windsensor to the ST60 Display through a radio transmission. -
Page 4: Operating Modes
ST60- Wireless Owner's Handbook 1.1 Operating modes Different modes of operation For economizing energy, the transmitter is used in different modes of operation. The main criterion is the power on time of the receiver. 1.1.1 Standby mode When the receiver is switched off, the transmitter terminates the havy energy consuming measuring. -
Page 5: Warning
Their design and manufacture conforms to the appropriate Electromagnetic Compati- bility (EMC) standards, but correct installation is required to ensure that performance is not compromised. please visite our homepage: www.seawave.ch for up to date information..for your messages..for your suggestions.. -
Page 6: Technical Data
ST60- Wireless Owner's Handbook Technical data Radiofrequency 868.35MHz, band (see label on the device) Range set-20 30m length of the mast, external antenne, ALU cover Battery Lithium battery: 3.6V/7.2Ah with case. NOT reloadable Weight of transmitter 290g without battery Weight of receiver 105g Weight of battery Temp.range operation... -
Page 7: Operating Instruction
ST60- Wireless Owner's Handbook Operating instruction ST60-Wireless is designed to work normally without any operation. At delivery the ST60 Wireless ist "ready to use" Exeption: when a unit is exchanged, transmitter and receiver have to be synchronised in the "Learn mode" (see instruction below) The receiver contains 7 LED's to sho received data transmition of data... -
Page 8: Led's After Poweron
ST60- Wireless Owner's Handbook Battery green State of the transmitters battery voltage The state of the battery is shown by this LED. - permanent light => battery is full - flashing light => battery reduced full change critical empty 100% The important characteristic of the Lithium battery is, that the voltage is kept practically constant up to the end of life. -
Page 9: Button Sw1 And Corresponding Displayed Status
ST60- Wireless Owner's Handbook 4.3 Button SW1 and corresponding displayed status With the button SW1, parameters of the receiver can be called. status LED after release of the SW1 SW1 pressed not active aktive, but no link between transmitter and receiver aktive, transmitter and receiver connected activates racing mode system in "learn mode"... -
Page 10: Learn-Mode
ST60- Wireless Owner's Handbook 4.4 Learn-Mode Each ST60-Wireless equipment has world-wide a clear 32-Bit address. This address is used, so that only the matching devices can with one another exchange data. With the exchange of equipment transmitters and receivers must be co-ordinated again up in vein. This is made with a new ' learning '. -
Page 11: Maintenance
ST60- Wireless Owner's Handbook Maintenance 5.1 Maintenance The transmitters and receivers mechanical and electronic components are maintenance free. 5.1.1 Battery change From time to time the battery has to be exchanged. It is not possible, to give a fixed maintenance interval, because the operation periode depends much about how the system is used. -
Page 12: Installation
ST60- Wireless Owner's Handbook Installation Transmitter and receiver may be connected without further preparation. Befor you climbe the mast, we recommend to test the devices on the ground, to be shure, that everything functions. 6.1 Radio connection Transmitter and receiver exchange data over radiosignals. Such a radio connection is without problem (also in closed cabine) if you watch the following guidlines: dont install the transmitter or receiver in a metall case dont install the transmitter or receiver too near to motors.. -
Page 13: Calibration
ST60- Wireless Owner's Handbook Calibration 7.1 ST60-Wireless ST60-Wireless doesn't need any calibration between transmitter and receiver. 7.2 Raytheon calibration Calibaration of the total system has to take place as with the system connected through cable. Please see original installation manual from Raytheon. 7.3 ST60- transmitter and/or receiver exchange In the case of exchange ST60-Wirless components, transmitter / receiver or both, a new calbibration can be omitted (the devices dont store any calibration values) but we recom-... -
Page 14: Function Diagram
ST60- Wireless Owner's Handbook Function diagram Transmitter Receiver PowerON PowerON (battery screwed into the transmitter) (Bordnetz eingeschaltet) SM_Startup Initialisations default parameters SSPEED_Sailing SS_StartUp:=T PowerON Delay done SM_Learn CS_Learn LearnREQ wait on Learn... Learn OK Reset Learn abort/timeout timeout SW1-Test SW1-T => Display SM_Measure CS_Idle CS_Test... -
Page 15: Troubleshooting
- sensor is not screwed on the receiver - sensor may be damaged - measurment electronic of the transmitter my be damaged for more 'tips and tricks', visit our homepage: www.seawave.ch We will publish further information..Serial number Serial Nbr: 1.1.1001... -
Page 16: Dimensions
ST60- Wireless Owner's Handbook 10 Dimensions 10.1 Transmitter page 16 - 20 Doc: ST60_Wireless_Manual_E_V10 LastEdit: 03.02.2005 Printed: 03.02.2005... -
Page 17: Receiver
ST60- Wireless Owner's Handbook 10.2 Receiver page 17 - 20 Doc: ST60_Wireless_Manual_E_V10 LastEdit: 03.02.2005 Printed: 03.02.2005... -
Page 18: Declaration Of Conformity
ST60- Wireless Owner's Handbook 11 Declaration of conformity page 18 - 20 Doc: ST60_Wireless_Manual_E_V10 LastEdit: 03.02.2005 Printed: 03.02.2005... - Page 19 ST60- Wireless Owner's Handbook page 19 - 20 Doc: ST60_Wireless_Manual_E_V10 LastEdit: 03.02.2005 Printed: 03.02.2005...
- Page 20 ST60- Wireless Owner's Handbook page 20 - 20 Doc: ST60_Wireless_Manual_E_V10 LastEdit: 03.02.2005 Printed: 03.02.2005...
