DR. BENDER

GmbH

Innovative Elektrowerkzeuge

Manual for

hand saw

SQUATINA 400

400 V 3~

Valid from 04.2006

Art.-Nr.

101359

Subject to alterations

DR. BENDER

GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91

info@dr-bender.de

Our website address is: http://www.dr-bender.de

• eMail:

Table of Contents

Need help?

Do you have a question about the SQUATINA 400 and is the answer not in the manual?

Questions and answers

Summary of Contents for DR. BENDER SQUATINA 400

Page 1 DR. BENDER GmbH Innovative Elektrowerkzeuge Manual for hand saw SQUATINA 400 400 V 3~ Valid from 04.2006 Art.-Nr. 101359 Subject to alterations All rights reserved DR. BENDER GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91 info@dr-bender.de Our website address is: http://www.dr-bender.de...
Page 2: Conformity Declaration
Innovative Elektrowerkzeuge EC Conformity Declaration for DR.BENDER stone processing machines PB WX8/10 SQUATINA 400 DR.BENDER GmbH, as manufacturer, hereby declares that the electrical stone processing machines mentioned above comply with the requirements of the following guidelines: Machine guidelines (98/37/EC) Electromagnetic compatibility (EMV) (89/336/EEC)
Page 3: Table Of Contents
10.2 Beluga WX8 B, 400V 10.3 Motor complete WX8 B, 400V 10.4 Gear complete WX8 B 10.5 Angular drive 10.6 WS rotor 10.7 WS rotor coplanar protection 10.8 Protection Squatina 400 10.9 Coplanar protection Squatina 400 10.10 Handle Squatina 400...
Page 4: General Notes
Warning It is compulsory to observe the safety instructions included in this manual! Special designs and versions may differ from the standard models in terms of their technical details. If any points are unclear, we urgently recommend that you contact DR.BENDER GmbH, indicating the machine type and machine number.
Page 5: Safety
Safety Warning Before using the machine for the first time, check the conformity of the data on the model plate with the mains voltage and frequency. Voltage deviations of ± 5 % and/or voltage deviations of ± 2 % are permissible. Only adequately qualified persons, based on their training and experience, may carry out repairs.
Page 6: Main Dimensions Und Technical Data
Main dimensions und technical data Dimensions 3.1.1 PB WX8/10 Powerbox 3.1.2 Squatina 400...
Page 7: Technical Data
Power requirement 8.000 / 16.000 Frequency 50 – 60 Protection class IP 67 Cooling medium Water Weight 12.5 3.2.2 Squatina 400 Rated voltage Current consumption Power requirement 8.000 Frequency 50 – 60 Idling speed 0 – 2660 stepless Full speed 0 –...
Page 8: Commissioning
(with ball plug valve) provided on the Powerbox. The water outlet of the Powerbox will be connected to the water inlet of Squatina 400. Caution: if possible, do not exceed the max. water pressure of 3 bar.
Page 9: Pb Wx8/10 Powerbox Operation
When pulled through, accelerating switch of Squatina 400 gently increases the speed. The setting wheel enables the additional decrease of the speed to the final one. When turned to the right up to...
Page 10: Bayonet Catch
Yet, the driving unit of Squatina 400 is designed for freehand cutting in terms of its sense of rotation. This means that in case of a drilling application, there appears an incorrect sense of rotation for drilling. For this purpose, a small phase changer is available, which is simply screwed in between the plug connection of Squatina 400 and the Powerbox.
Page 11: Saw Blade Replacement
To change the saw blade Remove the hexagon screw of the saw flange by turning it to the right. Caution, the screw is provided with left-hand thread. Remove the upper flange half together with the disk belonging to it. Insert the saw blade in the protection cover and insert it on the connecting joint of the output shaft.
Page 12: Safety Instructions
Safety instructions Important Only use the hand saw under supervision. Disconnect the mains plug and check that the switch has been turned off, when the hand saw remains unsupervised, during setup and disassembly works, in case of voltage drops (below 340 V), in case of uneven mains voltage (phase dissymmetry) or interruption of a phase (phase failure), for adjusting or fitting an accessory, Switch off the hand saw if it stops for any reason.
Page 13: Quarterly Care
Speed adjustment dependent on the cutting speed Squatina 400 may be operated with a maximum saw blade Ø of 400 mm. The cutting speed of a Ø 400 mm saw blade is of 55.7 m/s. Saw blade Ø...
Page 14: General Safety Instructions
General safety instructions Read and follow these instructions before you use the tool. Keep these safety instructions in a safe place. Keep your workplace tidy. Untidiness in the workplace can cause accidents. Protect yourself from electric shocks. Observe the applicable regulations. Avoid physical contact with earthed parts, such as pipes, heaters, furnaces and refrigerators.
Page 15 ”Stone and Earth” Professional Association must be satisfied. Electrical safety and fire safety: just as DR. BENDER did in the last 20 years, the new version of VDE 0100 also recommends the additional safety protection and fire protection of each tool...
Page 16: Spare Part Lists
10.0 Spare parts list 10.1 PB WX8/10 Powerbox...
Page 17 Pos. Article number Description Pcs. 100260 Control - Box 100679 Casing - rear part 801774 Gasket 2 ** 200755 Cooling element 801772 Gasket 1 ** 801450 O-Ring 2 ** 800076 Lock washer 901092 Allen screw 901093 Allen screw 801909 Grounding cable complete 900412 Slotted pan head screw 101149...
Page 18: Beluga Wx8 B, 400V
10.2 Beluga WX8 B, 400V...
Page 19 Pos. Art.-No. Description Pcs. 101305 Driving machine, complete 101306 Motor complete 101350 Gear complete 802082 Blank cover Wearing parts **...
Page 20: Motor Complete Wx8 B, 400V
10.3 Motor compl. WX8 B, 400V...
Page 21 Pos. Art.-No. Description Pcs. 101306 Motor, complete 101090 Motor casing 802022 Stator 101087 Rotor complete 901015 Deep-groove ball bearing 2 ** 801574 Ball bearing shim 900801 Circlip 801885 Spring ring 901030 Adjusting spring 401429 Flat gasket 1 ** 101307 Bearing cap 900571 Screwed cable joint 900231...
Page 22: Gear Complete Wx8 B
10.4 Gear compl. WX8 B...
Page 23 Pos. Art.-No. Description Pcs. 101350 Gear, compl. 200898 Gear casing 900639 Ball bearing shim 1 ** 900737 Deep-groove ball bearing 2 ** 901031 Shaft sealing ring 1 ** 800001 Circlip 900000 Deep-groove ball bearing 1 ** 301163 Drive spindle 800000 Circlip 900120 Adjusting spring...
Page 24: Angular Drive
10.5 Angular gear...
Page 25 Item Article number Description 101048 Angular gear complete 101049 Gear casing 900042 Needle sleeve 1 ** 902083 Needle sleeve 1 ** 101050 Crown wheel shaft complete 101051 Crown wheel shaft 900616 Cylindrical pin 900000 Grooved ball bearing 1 ** 101053 Crown wheel 800000 Circlip...
Page 26: Ws Rotor
10.6 WS Rotor 10.7 WS Rotor coplanar protection...
Page 27 Pos. Art.-No. Description Pcs. 101203 WS rotor, complete 101019 Rotor casing 900000 Grooved ball bearing 1 ** 801368 Circlip 301429 Output shaft 900202 Circlip 900116 Adjusting spring 301244 Flange 902076 Disk 901041 Hexagon screw 101081 Flange 900688 Allen screw Wearing parts ** Pos.
Page 28: Protection Squatina 400
10.8 Squatina 400 protection 10.9 Squatina 400 coplanar protection...
Page 29 Item Article number Description 101353 Protection complete 100276 Protection 401452 900302 Hexagon socket head cap screw with center hole 900661 Hexagon socket countersunk head screw 301434 Water supply complete 301433 Body 301435 Pipe 802036 Claw coupling complete 800841 Sealing ring K 1 ** 802038 Sealing ring S...
Page 30: Handle Squatina 400
10.10 Handle Squatina 400...
Page 31 Pos. Art.-No. Descripton Pcs. 301465 Handle complete 301462 Strap 301463 Tube handle 301464 Soft handle 900661 Hexagon socket countersunk head screw 902112 Hexagon socket head cap screw with center hole Wearing parts **...
