OWNER'S MANUAL
HEDGE
CLIPPER
EH-25SK
EH-25LK
Hedge Clipper
OWNER'S MANUAL
OWNER'S MANUAL
Taille-haie
MANUEL DU PROPRIÉTAIRE
MANUEL DU PROPRIÉTAIRE
Heckenschneider
BEDIENUNGSANLEITUNG
BEDIENUNGSANLEITUNG
ISTRUZIONI PER L'USO
ISTRUZIONI PER L'USO
Podadera de setos
MANUAL DEL PROPIETARIO
MANUAL DEL PROPIETARIO
heggenschaar
GEBRUIKSHANDLEIDING
GEBRUIKSHANDLEIDING
Podador de Sebes
MANUAL DE INSTRUÇÕ ÇÕES ES
MANUAL DE INSTRU
Tosasiepi

Advertisement

Table of Contents
loading

Summary of Contents for OCHIAI EH-25SK

  • Page 1 MANUEL DU PROPRIÉTAIRE HEDGE Heckenschneider BEDIENUNGSANLEITUNG BEDIENUNGSANLEITUNG CLIPPER Tosasiepi ISTRUZIONI PER L'USO ISTRUZIONI PER L'USO Podadera de setos EH-25SK MANUAL DEL PROPIETARIO MANUAL DEL PROPIETARIO EH-25LK heggenschaar GEBRUIKSHANDLEIDING GEBRUIKSHANDLEIDING Podador de Sebes MANUAL DE INSTRU MANUAL DE INSTRUÇÕ ÇÕES ES...

  • Page 3: Read This First

    READ THIS FIRST ● Stop the engine and make sure that the cutting blade is For your safety, read this Owner's Manual and understand it thoroughly before operating this HEDGE CLIPPER. stopped when cleaning, checking, maintaining or working on the hedge clipper. ●...

  • Page 4: Table Of Contents

    SAFETY AWARENESS ENVIRONMENTAL PROTECTION Whenever you see the symbols shown below, heed their To help preserve the environment, properly discard used instructions! batteries, oils and fluids, or other engine components that you Always follow safe operating and maintenance practices. might dispose of in the future. Consult your authorized equipment dealer or local environmental waste agency for their proper disposal DANGER...

  • Page 5: Specifications

    SPECIFICATIONS Model EH-25SK EH-25LK Overall Dimensions Length x Width x Height 1,680×250×220 2,030×250×220 Weight Engine Type Forced air-cooled, 2-stroke, gasoline engine Displacement 26.3 Carburetor Diaphragm type Ignition Flywheel magneto with CDI Spark Plug NGK BPMR7A Starter Recoil starter Clutch/Diameter Automatic centrifugal type/54...

  • Page 6: Preparing For Operation

    PREPARING FOR OPERATION Location of Parts and Labels K -a A. Pipe Assembly B. Gear Case C. Cutting Blade D. Loop Handle E. Throttle Lever F. Throttle Lock G. Engine Switch H. Blade Angle Fixing Knob I. Engine Assembly J. Blade Cover K.
  • Page 7 A. Fuel Tank G. Recoil Starter M. Throttle Cable B. Tank Cap H. Recoil Starter Grip N. Clutch Housing C. Air Cleaner Assembly I. Spark Plug  /   S park Plug Cap O. Engine Serial Number Label D. Lift Up Lever J.

  • Page 8: Dealer/Owner Assembly Parts

    Dealer/Owner Assembly Parts Assembly Cutting Blade DANGER Blade angle change will be performed under the following conditions. ● Stop the engine. ● Fit the cover to the cutting blade. Setting the Angle of Cutting Blade ● Loosen the blade angle fastening knob (A).

  • Page 9: Fuel And Oil

    NOTE Fuel and Oil ○ Do not use gasoline that has been stored longer than two month. WARNING ○ To ensure proper starting at low ambient temperatures, fresh winter grade fuel must be used. Gasoline is extremely flammable and can be explosive ○...

  • Page 10: Operating Instructions

    ● OPERATING INSTRUCTIONS Turn the lift up lever clockwise to switch to the “STARTING” position. Starting the Engine Fuel ● Level the engine before fueling. A. Lift Up Lever ● Open the fuel tank cap and fill the fuel tank with 50:1 gas/oil pre-mixed fuel.

  • Page 11: Warming Up

    Warming Up Stopping the Engine ● After starting the engine, run NOTICE the engine at the idling speed (throttle lever position is fully Suddenly stopping engine from high-speed operation CLOSED) for a few minutes. can cause engine damage. Reduce engine speed to idle speed for one minute before shutting engine off after high-speed, full-load operation.

  • Page 12: Operation

    Operation Precautions After Operation ● Adjust the handle to a comfortable position and maintain WARNING good balance as recommended in this manual. ● Make sure the unit is assembled properly. To avoid serious injury, do not store the unit with fuel tank, because a fuel leak could start a fire.

  • Page 13: Maintenance And Adjustment

    MAINTENANCE AND ADJUSTMENT Periodic Maintenance Chart WARNING Prevent accidental starting during engine service by removing the spark plug caps. Interval Maintenance First Every Every Every Daily 20 hours 20 hours 50 hours 100 hours ● Check and replenish fuel ● Check for fuel leakage ●...

  • Page 14: Air Cleaner Service

    Air Cleaner Service Fuel Filter Service Clean the element every 20 hours. Clean the fuel filter element every 20 hours of operation. WARNING WARNING Gasoline and low-flash point solvents can be flammable Many solvents are highly flammable and may cause and/or explosive and cause severe burns.

  • Page 15: Spark Arrester Cleaning Service

    STORAGE Spark Arrester Cleaning Service Clean the spark arrester every 50 hours of operation. Drain Fuel System WARNING Engines can become extremely hot during normal WARNING operation. Hot engine components can cause severe burns. Stop the engine and allow it to cool before Gasoline is a toxic substance.

  • Page 16: Troubleshooting Guide

    TROUBLESHOOTING GUIDE If the engine malfunctions, carefully examine the symptoms and the operating conditions, and use the table below as a guide to troubleshooting. Symptom Probable cause Remedy Engine won’t start Insufficient compression Faulty Piston, Cylinder and Piston ring  or output is low Loose spark plug Tighten properly.
