Summary of Contents for Godrej ET-200IRHMB-M
-
Page 2: Table Of Contents
CONTENTS 1. Product Features 2. Precautions 3. OSD Operations 4. Troubleshooting 5. E-waste 6. Warranty Card... -
Page 3: Product Features
Product Features 1. High definition; adopt latest Megapixel CMOS Sensor; horizontal resolution separately of 1.3 MP. 2. Day/Night mode: the sensor changes the day/night mode automatically to show qualified colour pictures during daytime and clear pictures at night. 3. OSD menu: set technical parameters by concise words. 4. -
Page 4: Osd Operations
OSD SETTINGS OSD menu SUB MENU Manual Lens Shutter Sens-up Exposure Brightness D-WDR Defog Backlight HSBLC Manual Outdoor Indoor White Balance Auto Day/ night Black and white Colour 2DNR 3DNR Camera title D-effect Motion Special Privacy language Defect RS485 Sharpness Monitor Adjust Video Out... - Page 5 OSD SETTINGS LENS- Manual Indoor (Iris speed) Outdoor (Min shutter,Max shutter), (Iris speed) Iris Speed MANUAL : The default setting is manual. If the installed lens is manual one, please select this option. : If the installed lens is manual one, please select this option. The user can select the option by “RIGHT”...
- Page 6 Backlight compensation includes the following 3 options: : It means close the backlight compensation function. The default setting is OFF. : It means open the backlight compensation function.； HSBLC : It means shelter from the over brightness light, such as car license plate recognition light.
- Page 7 D-N DELAY: It is the time interval needed for the camera to switch from day to night condition and vice-versa for N-D DELAY. NOISE RATIO- 2DNR High,middle,low,off 3DNR High,middle,low,off It reduces noise. SPECIAL- Camera title Freeze D-effect Mirror Negative Image Motion On (Area,Display,Sensitivity,Color,Trans,Alarm,Default) Privacy...
- Page 8 ADJUST- Sharpness Auto (Level,Start AGC,End AGC),Off LCD (Gamma,Blue gain,Red gain) Monitor CRT (Black level,Blue gain,Red gain) On,OFF Video Out PAL/NTSC This option is used to sharpen the image. It also contains LCD and CRT option. Need to adjust gamma, blue gain, red gain as per monitor characteristics for proper image reproduction.
-
Page 9: Troubleshooting
TROUBLESHOOTING Item Problems Remedies Check the connection of video line or power No picture or unstable line Checking is there something dirt on the lens, then use customized lens paper or cotton The image is so blurred buds with alcohol drenched to clean. check the focus length and OSD settings The image is so dim Adjust the CNT of monitor and iris. -
Page 10: E-Waste
Schedule 1 (please refer to our website www.godrej.com in the „Good & Green‟ section of CSR module for more details). Under these rules, specific roles and responsibilities are defined for producers , consumers and recyclers handling and managing ewaste. - Page 11 „Good & Green‟ section of CSR module for more details). All our products intended to be recycled under the category of ewaste (as defined above) carry a label or stamp of the WEEE symbol (A wheelie bin with a cross) , which states that it falls under the hazardous waste category and is not to be disposed along with normal garbage.
-
Page 12: Warranty Card
WARRANTY CARD...
