Maxx Wave MW-1404 Quick Install Manual

Hide thumbs

Advertisement

Table of Contents

MW-1404 Quick Install Guide
Unifi Controller Edition
Port(s)
1
2-4
Console
Disclaimer: Maxxwave is not responsible if you update your device's kernel, as this will cause the box to be inoperable.
Page | 1
IP
Static: 192.168.1.2
User set Static or DHCP
N/A
Maxxwave 1404 Quick Install Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MW-1404 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxx Wave MW-1404

  • Page 1 MW-1404 Quick Install Guide Unifi Controller Edition Port(s) Static: 192.168.1.2 User set Static or DHCP Console Disclaimer: Maxxwave is not responsible if you update your device’s kernel, as this will cause the box to be inoperable. Page | 1 Maxxwave 1404 Quick Install Guide...
  • Page 2 Initial Connection Set-Up 1) Plug in a cable from your computer to Port 1 of the Maxxwave 1404 Appliance. 2) Set your computer’s IP address to: 192.168.1.3, Subnet: 255.255.255.0 and the gateway can be left blank. 3) Open up a web browser and go to http://192.168.1.2. 4) Default username: ubuntu, Default password: ubuntu Page | 2 Maxxwave 1404 Quick Install Guide...
  • Page 3 5) After initial log in, configure the settings for Ports 2 – 4. These ports will act as a switch. Optional Selections (shown in Figure 1): • DHCP Client: Select if the controller needs to get an IP from your DHCP server •...
  • Page 4 Figure 2 – The DHCP Server tab can be used to configure the appliance as a DHCP server. Note: This screen [Figure 2] allows you to enable a DHCP server for your network. If a preexisting DHCP server is already set up on your network, then you do not need to use this feature.
  • Page 5 Figure 3 – The Static IP Address tab can be used to set a static IP on the device. Note: Each box in this screen [Figure 3] may have static settings for the controller. However, ensure you input the correct information for use on your network so the controller will function properly. Do not assign the controller an IP on your network that is already in use.
  • Page 6 6) - Now unplug your laptop from Port 1. Plug the networking equipment you wish to set up to either port 2, 3, or 4. Remember to also plug your laptop into the networking device. - Be sure to remove the static IP you set up earlier. That way the computer connects to your network properly. - Open up a web browser and go to https://IPofCONTROLLER:8443 EX.
  • Page 7 7) Follow the on screen prompts of Figure 4. If you wish to gain access to your device, proceed by plugging a console cable into the Console port of the router. Connect the other end of the cable into your computer and use an application like Putty to gain access by setting your baud as 115200, data bits as 8, and the stop bit as 1, with no flow control.
