AirWire900 convertr-60 User Manual

CONVRTR-60 Configuration Variables (CV)
Use the AirWire T5000 throttle to setup the CONVRTR-60 CVs as well as the attached decoder.
Only a few CVs are used by the CONVRTR-60 and these are usually programmed at the same time
as when programming attached decoder.
When programming the address, the throttle will automatically send the proper sequence of CVs to
the attached decoder regardless of the number of digits in the address.
The CONVRTR-60 accepts both SERVICE PROGRAM commands and OPS PROGRAM
commands.
Do not use OPS PROGRAM to change the address.
Factory Value
CV #
Value Range
1 3 0-99
8 135 135
17 0 0-605
18 0 0-605
29 2 0-605
200 0 0-16
CONVRTR-60 Warranty Information
This warranty covers substantial defects in materials and workmanship in the
module.
What This Warranty Does Not Cover
This warranty does not cover any problems which result from improper installation,
modifications, battery polarity reversal, improper operation, leaking batteries, excessive battery
voltages, excessive decoder current draw, incorrect connections to decoders, abuse, accidents, or
acts of God such as excessive heat, floods, damage caused by exposure to moisture and rain,
lightning, earthquakes, volcanic events, tidal waves or hurricanes.
Warranty Duration
The coverage of this warranty lasts for 90 days. After this period, standard repair rates apply.
Depending on the problem, CVP reserves the right to repair or replace.
Help, Repairs and Returns
If you purchased your CONVRTR-60 from one of our AirWire900 dealers, please call them first.
They are your best and quickest source for answers to questions about CONVRTR-60. They are
also experts in installation and offer such services should it be required. If you purchased your
CONVRTR-60 direct from CVP Products, call us first.
If you are asked to return an item to CVP for service, you must follow the instructions on the
website listed under the "Repair Services" link. There you will find the street address plus other
helpful tips about how and where to send items to CVP Products.
Do not send items to us for repair without first obtaining authorization and an RMA.
CONVRTR-60 Electrical Ratings
Maximum Input Battery Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Volts DC
Minimum Input Battery Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.3 Volts DC*
Minimum Surge Current without Tripping . . . . . . . . . . . . . . . . . . . . . . . . . 55A
Maximum Continuous Current (thermally limited) . . . . . . . . . . . . . . . . . . 6A
Over-Current Trip (Min/Max) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55A to 98A
Reverse Polarity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Not Protected
FCC ID Number X7J-A10040601 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
*Decoder dependent - it might need a higher input voltage to operate reliably
CVP Products P.O. Box 835772 Richardson, TX 75083-5772 www.cvpusa.com 972-238-9966
16
Description
1-99 Primary Address
CVP Manufacturer ID
Loco Address Hi-Byte
Loco Address Lo Byte

Decoder configuration

Frequency Select
CONVRTR-60
at 100°C
Part 15 Compliant
DEC 2016 r0
The AirWire900
CONVRTR-60
CONVRTR-60 Familiarization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Example Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Wiring Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Recommended Soldering Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Verifying Battery Connector Polarity . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Basic Hookup Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Quick-Start Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Changing The Frequency, Forgotten Frequency Method . . . . . . . . . . 9
Reset CONVRTR-60 To Original Factory Settings . . . . . . . . . . . . . . . 10
Using OPS Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Overload and Fault Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting Tips, LED Indicator Use . . . . . . . . . . . . . . . . . . . . . . 12
Operational Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Battery Considerations and Suppliers . . . . . . . . . . . . . . . . . . . . . . . . . 14
Track Power Operation - Not Recommended, But...
List Of CONVRTR-60 CVs And Electrical Ratings
Need Help? Contact Your Dealer/Installer First!
Should you have any questions regarding your CONVRTR-60, your dealer is the best source
of information, tips and techniques. Also, almost all dealers do CONVRTR-60 installations
or can recommend good installers. It might take a little more time and cost more, but you'll
be assured of an installation that works and works well the first time.
micro DECODER , CONVRTR-15, CONVRTR-25, CONVRTR-60, AirWire900, the stylized AirWire name and the logo
are registered trademarks of CVP Products © 2016
®
™ User Guide
. . . . . . . . . . . . 15
. . . . . . . . . . . . Back
Contents
CONVRTR-60 module
Test Diode
This User Guide
