Summary of Contents for insize ISE-2DT
- Page 1 MN ISE -2DT-E www.insize.com ISE-2DT DIGITAL LEVEL OPERATION MANUAL...
- Page 2 Power Key And Touch Panel Introduction Thanks for buying our product. ISE-2DT is a high precision dual axis Power key has 4 functions below. level with a color LCD and touch panel. It is possible to do high speed Power on: Pushing the key once if power is off then the power horizontal plane setting for high precision machines or home is on with a sound.
- Page 3 Spec: To setup the spec. for the FLAT mode. Main Menu The main menu is composed as the following picture. Each functions can be chosen by touching the letters. Go Back: To exit the 'Spec' menu. Tolerance: To setup the tolerance of the tilted direction display line, the green line or bubble means within the tolerance.
- Page 4 P4 depend on situation. If user touches the area of the floated Line width: To change the width of the tiled direction indicating point on the screen, ISE-2DT calculates and displays the heights line at the POLE mode. of the other 3 points. The floated point should be filled up at the last after user finishes to adjust the 3 points level.
