- Page 1 H347B 5 zones burglar central unit USER'S MANUAL...
-
Page 2: Table Of Contents
H347B - User’s Manual Contents Introduction Chapter 1 1.1 Central Unit Description ...................4 1.2 Operating Features ....................4 1.3 Technical Features....................5 Installation Chapter 2 2.1 General Instructions....................6 2.2 “Radiophonic Listening” function................6 2.3 Power Supply......................7 2.4 System Configuration and Wiring ................8 2.4.1 Zone 1 (wired) ....................8... - Page 3 Contents 4.2.1 Enabling System ..................20 4.2.2 Desabling System ..................20 4.2.3 Optional Command Systems..............20 4.3 Zones Exclusion.....................21 4.4 Zones Operating ....................21 4.4.1 Zone 1 wired (delayed/immediate) ............21 4.4.2 Zones 2 / 3 / 4 (immediates)..............21 4.5 Alarm Memory......................23 4.6 Acoustic Signallings ....................23 Maintenance Chapter 5 5.1 Replacing of the parts ....................24...
-
Page 4: Chapter 1 Introduction
HILTRON products. Central Unit Description The H347B is a burglar central unit with microprocessor technology for Burglar Protection System , s for sm all and medium private and commercial premises. It allows to manage a wired zone by traditional NC line, and also to manage three radio zones where you can connect... -
Page 5: Technical Features
DECLARATION OF CONFORMITY PROGETTAZIONE E PRODUZIONE APPARECCHIATURE ELETTRONICHE CONSTRUCTOR: HiLTRON S.r.l. ADDRESS: Via Caserta al Bravo, 218 - 80144 - NAPOLI PRODUCT CODES: 347B, 356B, 268B, 348B, 346B, 350B, 353B, 345B. THE PRODUCTS RESULT CONFORM TO THE FOLLOWING STANDARDS REQUIREMENTDS:... -
Page 6: Chapter 2 Installation
Do not expose this product to bound temperatures or to bad weather. The H347B is protected from tampering, but we suggest you to place this product in a protected place or in a volumetric detector zone, for further protection of the Central Unit. -
Page 7: Power Supply
Installation Power Supply After the unit is fixed at the wall, connect again the H158B power supplier/battery charger to 12V / 7Ah battery. It’s important to know that the Central Unit is powered exclusively by the 12V / 7Ah lead battery which is costantly in charge. Look out of connection polarity to avoid damaging the product. -
Page 8: System Configuration And Wiring
H347B - User’s Manual System Configuration and Wiring Refer to descriptions below for connecting the clamps of H347B: 1 2 3 4 5 6 7 8 9 10 1 - 2 13Vdc output voltage. Maximum current supplied: 400mA max. 1 - 3... -
Page 9: Telephone Dialer
Installation 2.4.2 Telephone Dialers Use the following pictures to connect a monochannel telephone dialer. TELEPHONE DIALER Telephone Line 2.4.3 Additional Sirens Use the following pictures to connect additional indoor sirens type H125H or traditional self-powered sirens type H295G. Tamper 13,8Vcc Art. -
Page 10: Programming Procedures
H347B - User’s Manual Programming Procedures Initial Setup Before you programming the central unit, be sure that the device is installed in position of optimum reception.(par. 2.2) Power on the H347B. To enter in the programming mode, hold down for 5 seconds “PROG”... -
Page 11: Rf Channel Test
During this function, the “MAIN POWER” LED is lit and “Alarm” LED blinks. This function allows to check the proper operation of peripheral radio devices.The H347B utters some beeps whenever it receives signals from the connected devic with the System Code programmed (if the System Code is not programmed, the "Roadiophonic Listening"... -
Page 12: Times Regulation
H347B - User’s Manual 3.1.2 Times Regulations LED lit LED blinking In this mode, “ON” LED is lit, “ALARM” LED blinks, and “ VISUALIZATION OF THE ZONES ” LEDs 1, 2 and 3 blink. If the System Code is not programmed, skip this procedure pressing “ZONE STATUS / ALARM MEMORY"... -
Page 13: Settings
Programmazione 3.1.3 Settings LED lit LED blinking In this mode, “24H” LED is lit and “ALARM” LED blinks. 3.1.3.1 Entering/Exiting Acoustic Signalling Pressing “EXCLUSION" (EXCLUSION) Zone 1 button, the entering/exiting acoustic signalling is activated by the inside BUZZER. During this function, Zone 1 LED is lit. To desable this function press again “EXCLUSION"... -
Page 14: Acoustic Signalling In Case Of Main Power Supply Absence And Anomaly Of Power Suppliers, On Desabled System
H347B - User’s Manual 3.1.3.4 Acoustic Signalling in case of main power supply absence and anomaly of power suppliers on desabled sytstem Press “EXCLUSION” Zona 4 to check on desabled system the main power supply and detectors and sirens power supply. During this fuction,... -
Page 15: System Code
Programming 3.1.4 System Code LED lit LED blinking During this function, “SENSORS” LED is lit, “ALARM” LED blinks, and the Zones 1, 2 and 3 LEDs blink.This function allows to program and to display the System Code of Central Unit; each devices connected to the Central Unit must have the same code. -
Page 16: System Code Display
H347B - User’s Manual In case of mistakes during the entering of System Code, press “ EXCLUSION ” Zone 3 button. The Programming mode returns to the par.3.1.4. 3.1.4.2 System Code Display Pressing “ EXCLUSION ” Zone 4 button, Zones 1, 2... -
Page 17: End Of Programming Procedures
Programming 3.1.5 End of Programming Procedures LED lit LED blinking In this mode, “SIRENS” LED is lit, “ALARM” LED blinks and “ZONES STATUS CONTROL” Zones 3 and 4 LEDs blinks. 3.1.5.1 Default Settings Reset Pressing “EXCLUSION” Zones 3 and 4 LEDs turn off, and Zone 1 and 2 LEDs are lit;... -
Page 18: 345B Remote-Control Programming
H347B - User’s Manual Remote control H345B settings Hold down the button s for some seconds, rel ease them when the green LED is lit. Set the System Code using 345B buttons: “1” “0” - Left Button (red): to enter “1”. -
Page 19: Operating Procedures
348B detectors tamper ; Blinking (with button pressed) - "24h" LED to show the sabotage of H347B Central alarm memory in case of main Unit; power supply absence - "MAIN POWER” LED to show the main power supply... -
Page 20: Enabling / Desabling System
Central Unit. If an alarm occurs, the impulse of desabling sent by the 345B will be received both from the H347B Central Unit and from the 350B Siren. This allows a very fast desabling of all sounding alarms. 4.2.3... -
Page 21: Zones Exclusion
Operating Zones Exclusion This option allows to exclude the zones you don’t want protect. In example, during the night you can exclude the zones with a volumetric protection (detectors) and leave included the zones with a perimetral protection (sensors) For this reason, you must know the zone where the sensors and the detectors are installed. - Page 22 H347B - User’s Manual H346B sensors has only a transmission activity in the system; every transmission includes all the following informations: Contact Status NC Line Status 24h Protection Tamper Status Battery Status The change of one listed parametre causes the integral transmission of the informations.
-
Page 23: Alarm Memory
- “SENSORS” LED is lit to show ad indicare la manomissione del tamper dei sensori H346B e rivelatori H348B; - "24h" LED is lit to show ad indicare la manomissione del tamper della centrale H347B; - "MAIN POWER” LED is lit to show the main power supply absence. -
Page 24: Chapter 5 Maintenance
H347B - User’s Manual Maintenance Replacing of parts The H347B does not include wearing parts, but we suggest you to check the batteries periodically and to replace every 3 years. Cleaning Use a damp soft cloth for cleaning. Do not use diluents and/or harsh sponge.
