Modoo MHF-R220BT Installation Manual

Installation guide

① On the back of the MHF-R220BT unit you will see two pairs of clips.
Place the bottom pair of clips on the underside of your existing
Rearview mirror. Lift the unit so that the bottom clips extend
allowing the top clips to be fixed in position on top of your Rearview
mirror and securely hold the handsfree unit in place. Adjust the
fitted unit to your preference for clear rear vision.
② Select a suitable position for the microphone depending on your
vehicle type, this should be placed close to the users head - the
driver's sun visor is normally adequate.
"It is highly recommended to have the front of the microphone
(side with more holes) directly facing the operator for the best voice
pickup." The microphone can be placed either back or front of the
visor by detaching, rotating and re-attaching microphone holder to
correct side of the microphone.
③ Clip a microphone on the driver's sun visor recommended to keep a
distance of the microphone from the MHF-R220BT unit as long as
possible.
④ Insert the power jack of the power adapter cable (4M).
⑤ Connect the Power Adapter Cable into its respective socket on the
MHF-R220BT unit.
⑥ The power lead should be secured and hidden into the vehicles
interior using the seals or joins around the windscreen and door
"A-Frame" and under your dashboard. Ensure that you leave
yourself enough cable to be able to connect to your cigarette lighter
socket.
Note :
Please ensure that the microphone and power cable do not interfere with
the safe operation of your vehicle.
6
Pairing your Bluetooth cellular phone
with the MHF-R220BT
The MHF-R220BT supports both HandsFree and Headset Profiles. The
default profile is HandsFree. Follow the pairing instructions for the first
use, after that the unit will pair automatically.
Power On :
It appears
Pairing in "HandsFree" mode
1. When the power is on, press the "VOL ▲ ▲ " button for
3 seconds.
2. You will hear a beep tone.
The HandsFree unit is
now ready to be paired
for the first time.
Pairing HF
It appears on the mirror.
3. For the next procedure, Go to the next page to follow
the instruction of ;
Go to Cellular phone pairing mode
Pairing in "Headset" mode
1. After the above 1~2, then press the "VOL ▲ ▲ " button for
3 seconds again.
2. You will hear a second
beep tone, which shows
the unit is ready to be
paired for the first time.
Pairing HS
It appears on the mirror.
3. For the next procedure, Go to the next page to follow
the instruction of ;
Go to Cellular phone pairing mode
Headset mode
The " "
Caller ID Voice Dialling
' ', '
start
on the mirror.
Voice : "Power On"
(Next page)
(Next page)
does not support
Reject Call
' and ' '
7
