Summary of Contents for Huafeitech HF-V10-10P8G2SF
- Page 1 HF-V10-10P8G2SF Hardware Installation Manual Beijing Huafei Technology Co.,Ltd. Tel: 86-10-82894971 Fax: 86-10-82894971-8008 Email: market@huafeitech.com Website: www.huafeitech.com.cn Disclaimer: Information offered in this manual by Beijing Huafei Technology Co., Ltd is intended to be as accurate as possible. However, there might be unintentional errors, and we reserve the right to amend herein without notice.
-
Page 2: Table Of Contents
Table of Contents Table of Contents Chapter 1 Switch Overview............................1 1.1 Standard Configuration..........................1 1.2 Characteristic Parameters of HF- ........................2 Chapter 2 Installation Preparation..........................4 2.1 Cautions..............................4 2.2 Safety Advice............................4 2.2.1 Safety Principles..........................4 2.2.2 Safety Notices..........................4 2.2.3 Safety Principles for Live Working....................5 2.3 Requirements for Common Locations...................... -
Page 3: Chapter 1 Switch Overview
HF-V10 Hardware Installation Manual Chapter 1 HF-V10 Switch Overview The document describes the characteristics and parameters of HF-V10 and gives an overview of HF-V10. 1.1 Standard Configuration HF-V10 switch has 8 gigabit electric ports and 2 gigabit optical ports. See the following table: Table 1-1 Attributes of the necessary ports Port... -
Page 4: Characteristic Parameters Of Hf
HF-V10 Hardware Installation Manual Figure 1-2 Back template of the HF-V10 switch Table 1-2 Parts at the rear template of the HF-V10 switch Name Remarks Grounding The grounding must be fine. column ON means opening the power, Power switch while OFF means cutting off the power. - Page 5 HF-V10 Hardware Installation Manual 8 10/100/1000 Base-Tx ports Standard configuration 2 gigabit optical ports 240*150*42MM Specifications -10℃-45℃; 10%-85% no condensation Working temperature/humidity -40℃-85℃; 5%-95% no condensation Storage temperature/ humidity Input voltage: AC100-240V Power Source’s Characteristics Input frequency: 47-63Hz Input current: 1A/230V Up to 13W Power consumption...
-
Page 6: Chapter 2 Installation Preparation
HF-V10 Hardware Installation Manual Chapter 2 Installation Preparation 2.1 Cautions Similar to other electronic products, the semiconductor chip easily gets damaged if you power on and off abruptly and frequently.To restart up the switch of HF-V10, you have to open the power on-off three or five seconds after the power is cut off. You shall not collide harshly with HF-V10 or fall it from a high place, which may damage the internal hardware of the switch. -
Page 7: Safety Principles For Live Working
HF-V10 Hardware Installation Manual Only professionals are allowed to install or replace the switch. Please cut off the direct-current connection when you operate the hull or work near the power source. The final configuration of products must comply with relative national laws and ... -
Page 8: Requirements For Common Locations
HF-V10 Hardware Installation Manual 2.3 Requirements for Common Locations This part describes the requirements for the installation locations. 2.3.1 Environment HF-V10 switch adopts the wall-hanging installation mode.The switch has no fan, so an environment with good ventilation is needed for the heat cooling of the switch. For location planning and device locating, refer to section 2.3.2 “Location Configuration Prevention”. -
Page 9: Installation Tools And Device
HF-V10 Hardware Installation Manual If the power supply system does not have good grounding, or the input power disturbs too much and excessive pulses exist, the error code rate of communication devices increases and even the hardware system will be damaged. 2.4 Installation Tools and Device The following are the tools and devices needed for the typical installation of the HF- V10 switch:... -
Page 10: Chapter 3 Installing The Hf-V10 Switch
HF-V10 Hardware Installation Manual Chapter 3 Installing the HF-V10 Switch Caution: Only professionals are allowed to install or replace the devices of the router. 3.1 Installation Procedure of HF-V10 3.2 Installing the Chassis of HF-V10 The chassis of the switch can be put on the desk or fixed to the cabinet.Your network installation requirements can be met if you conduct the operations according to the following procedure.It can be described in the following two parts: Installing the Chassis on the Desk... -
Page 11: Installing The Chassis On The Desk
HF-V10 Hardware Installation Manual 3.2.1 Installing the Chassis on the Desk The HF-V10 switch can be directly put on the smooth and safe desk. Note: Do not put things weighing 4.5 kg or over 4.5 kg on the top of HF- V10. - Page 12 HF-V10 Hardware Installation Manual Figure 3-2 Connecting the console port of HF-V10 and computer Table 3-1 Definition of the pins of the console port Name Symbol Remarks Carrier Detecting No connect Data receiving Input Data-line device ready No connect Data transmitting Output No connect Transmission requesting...
-
Page 13: Connecting The Sfp Optical Port
HF-V10 Hardware Installation Manual Note: The console port of HF-V10 does not support flow control, so you shall set Data flow control to none when using a super terminal to set this switch; otherwise, single pass appears on the super terminal. The cable is used to connect the console port of the HF-V10 switch and the outside console terminal device.One end of the cable is a 8-pin RJ45 plug and the other end is a 9-hole plug (DB9).The RJ45 plug is put into the socket of the... -
Page 14: Connecting Ethernet Electric Port
HF-V10 Hardware Installation Manual 3.3.3 Connecting Ethernet Electric Port The HF-V10 switch has 8 10/100/1000Base-Tx ports.You can connect other Ethernet terminal devices to the UTP port through the cut-through or cross network cable.The numbering order of the pins in the UTP port is the same as the console port. Figure 3-4 RJ-45 connector of the console port Figure 3-5 Connecting the 10/100Base-Tx port and other Ethernet terminals Table 3-3 Definition of the pins of the 1000M RJ45 port... -
Page 15: Checkup After Installation
HF-V10 Hardware Installation Manual Sending the paraphase of TXD1- Output the data Receiving normal RXD1+ Input phase of the data Sending the normal phase TXD2+ Output of the data Sending the paraphase of TXD2- Output the data Receiving the paraphase RXD1- Input of the data... -
Page 16: Chapter 4 Hf-V10 Maintenance
HF-V10 Hardware Installation Manual Chapter 4 HF-V10 Maintenance Caution: Before opening the machine box, make sure that you have released the static you carried and then turn off the power on-off of the switch. Before operating any step in Appendix B, read the section “Safety Advice”. Before performing operations beside the power source or on the chassis, turn off the power on-off and plug out the power cable. -
Page 17: Closing Chassis
HF-V10 Hardware Installation Manual When the cover is opened, put it aside. The mainboard of the system appears. Note: After taking off the cover, put it horizontally and avoid it to be crushed or collided.Otherwise, the chassis is hard to install. 4.2 Closing Chassis The section mainly describes how to put the cover and close the chassis.Do as follows:... -
Page 18: Chapter 5 Hardware Fault Analysis
HF-V10 Hardware Installation Manual Chapter 5 Hardware Fault Analysis The part describes how to remove the faults from the switch. 5.1 Fault Separation The key for resolving the systematic faults is to separate the fault from the system. You can compare what the system is doing with what the system should do to detect the fault.You need to check the following subsystems: Connection of the power source ... - Page 19 HF-V10 Hardware Installation Manual It is on when power source provides Power LED power normally. If the indicator flickers, the system works System indicator normally. When it is on, the corresponding port is connected. LED Link/ACT LED indicator When it flickers, the corresponding port is transmitting data.
