INSTRUCTION MANUAL
Catalog Number 2901
Functional Guidelines
(D)
(A) = ALUMINUM HAMMER CASE
(B) = IMPACT RESISTANT HOUSING
(C) = FIELD REPLACEABLE CARBON BRUSHES
(D) = 7/16 QUICK CHANGE THREE BALL CHUCK
(E) = LED LIGHT for dark area working
(F) = EASY TOUCH FORWARD/REVERSE BUTTON
(G) = VARIABLE SPEED CONTROL TRIGGER with electronic brake
(H) = NON-SLIP, SOFT GRIP HANDLE reduces vibration and fatigue
(I) = ERGONOMICALLY DESIGNED WELL-BALANCED
HANDLE
(J) = EASY CONNECT SLIDING BATTERY SYSTEM
Cordless RoboImpact™
800-874-4702
(A)
(E)
(G)
(I)
(J)
aircraftdynamics.com
(B)
(F)
(H)
1
(C)
Advertisement
Table of Contents
Summary of Contents for Cordless RoboImpact 800-874-4702
-
Page 1: Instruction Manual
INSTRUCTION MANUAL Cordless RoboImpact™ aircraftdynamics.com 800-874-4702 Catalog Number 2901 Functional Guidelines (A) = ALUMINUM HAMMER CASE (B) = IMPACT RESISTANT HOUSING (C) = FIELD REPLACEABLE CARBON BRUSHES (D) = 7/16 QUICK CHANGE THREE BALL CHUCK (E) = LED LIGHT for dark area working... -
Page 2: Personal Safety
WARNING! “READ ALL INSTRUCTIONS” Always observe the safety regulations applicable to your company to reduce the risk of fire, electric shock and personal injury. Understand the following safety instructions before attempting to operate this product. Always wear eye protection when work- ing with power tools. -
Page 3: Battery Charger
Use only accessories that are recommended by Aircraft Dynamics. Accessories that may ♦ be suitable for one tool, may become hazardous when used on another tool. Service Tool service must be performed only by qualified repair personnel. Service or maintenance ♦... -
Page 4: Functional Description
Do not store the tool and battery pack in locations where the temperature may reach or exceed ♦ 122°F. Do not incinerate the battery pack even if it is severely worn out. The battery pack can explode ♦ in a fire. Be careful not to drop, shake, or strike the battery. - Page 5 ASSEMBLY Check for damage to the tool, parts or accessories which may have occurred during transport. Take the time to thoroughly read and understand this manual prior to operation. Attaching or Removing Battery Pack 1. To connect battery, line up the tracks and attach the battery pack.
- Page 6 Forward/Reverse Rotation Switch Operation To prevent damage, do not press Forward/Reverse button until the anvil comes to a complete stop. Forward Rotation Operation Push the button for forward rotation. After use, set the lever to its center position. Reverse Rotation Operation Push the button for reverse rotation.
-
Page 7: Lamp Indications
Charging the Li-ion battery (NOTE) When charging a cool battery pack (below (32°F) leave battery in warm place for over 1 hour • to warm the battery to the ambient temperature. Otherwise battery pack may not be fully charged. Cool down the charger when charging more than two battery packs consecutively. •... -
Page 8: Maintenance
4. If the power lamp (red) does not light immediately or goes out soon after the charger is plugged in, contact Aircraft Dynamics. 5. During charging, the charging lamp (green) will start flashing. When charging is completed, an inter- nal electronic switch will automatically be triggered to prevent overcharging. - Charging will not start if the battery pack is warm. - Page 9 ROBOIMPACT 18 VOLT CORDLESS 2901 (18V) � /_ pr y � CHARGER ��--- PN4419 18V BATTERY 4.0 Amp Li-ion PN 3419-4 �DPN ADPN Description Description � � Anvil Assembly Housing Upper Cover (1 )Anvil Hous,ng Lowe, Cover 19.1 (2)0-Ring (PT) Motor Assembly 19.2 19.3...
