Summary of Contents for Satir UTR

  • Page 1 SATIR UTR User’s manual Trademark Acknowledgments • SATIR is a trademark of SATIR Ltd. • Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies. Copyright © 2017 SATIR Ltd. All rights reserved.

  • Page 2: Table Of Contents

    SATIR UTR Content 1. Overview ........................1 1.1 Device Brief Introduction ................1 1.2 Packing list ....................1 2. Main technical parameters ..................2 3. Operation and use ..................... 3 3.1 Brief introduction of device component ............3 3.2 Basic operation ....................4 3.3 Function and operation ..................

  • Page 3: Overview

    SATIR UTR 1. Overview Device Brief Introduction SATIR UTR handheld thermal camera is equipped with advanced UFPA (uncooled focal plane array) infrared detector and used for observation of mid and short-range target, like people, vehicle, ship, etc. SATIR UTR handheld thermal camera is designed in all-metal case,...

  • Page 4: Main Technical Parameters

    SATIR UTR 2. Main technical parameters A. Constitute: Thermal camera and binocular module, thermal camera is including thermal detector, lens, circuit board and keys. B. Control mode: Control keys. C. Video output: High resolution OLED display, binocular observation. D. Power supply: 7.2V Li-ion battery，power dissipation is less than 5W.

  • Page 5: Operation And Use

    SATIR UTR 3. Operation and use 3.1 Brief introduction of device component (4) Control keys (1) Main body (2) Infrared lens (3) Battery compartment 1) Main body: Used to convert the infrared radiation to image and implement other functionality. 2) Infrared lens: Infrared lens converge the infrared radiation of target and background on the detector.

  • Page 6: Basic Operation

    SATIR UTR (6) Mounting bolt (8) Video output port (7) Power switch (5) Binocular 5) Binocular: Design in binocular, clear and bright, detachable and separated from main body to realize observation. 6) Mounting bolt: Used to fix the binocular, unscrew to demount the binocular.

  • Page 7: Function And Operation

    SATIR UTR 3.2.2 Turn on the device  Press the power switch and keep holding for 3 seconds to start the device and the OLED displayer will light.  The device will start up completely in 20 seconds.  Open the lens cover, aim the device at the area or the object you want to observe, go on observation and operation.
  • Page 8 SATIR UTR “－” “+” “A” “M” Distribution of key on main body Function of each key is as follows. Function Focus on the target far in the distance or switch to next items of the menu. Focus on the target near in the distance or switch to last －...
  • Page 9 SATIR UTR （2） Internal/external reference Internal or external reference can improve image quality and reduce the pattern noise and image quality degrading which due to the environment change. The device will execute the internal reference several times when booting. You can execute the reference manually if you found the degradation of image quality.
  • Page 10 SATIR UTR （3） Image polar setting Thermal image has “BlackHot” and “WhiteHot” display modes. In “WhiteHot” mode, the higher the temperature of the target, the more white the target displays on the screen and the lower the temperature of the target, the more black the target displays on the screen.
  • Page 11 SATIR UTR Press the “M” key to enter the menu and press the “M” key continuously to switch to “LEVEL” or “GAIN”, and then press the “+” key to increase the level or gain of the image, press the “-” key to decrease the level or gain of the image.
  • Page 12 SATIR UTR switch to “MODE”, and then press the “+” key to switch to “Manu” mode or press the “-” key to switch to “AUTO” mode. MP4 function （12） Press the “A” key and “-” key at the same time to switch to “MP4 MODE”...
  • Page 13 SATIR UTR the menu and press the “M” key continuously to select “MP4 MODE” . Then press the “+” key or “-” key to select “SETTING” mode and press the “A” key to enter “SETUP” menu. Setting items Operation Press the “+” or “-” key to select “CYCLIC RECORD” and then press the “A”...

  • Page 14: Video Output

    SATIR UTR press the “A” key to confirm. Press the “+” or “-” key to select language as required and then press the “A” key to save the setting and return to “SETUP” menu. Press the “+” or “-” key to select “DEFAULT SETTING”...
  • Page 15 SATIR UTR Unscrew the fixed screw of binocular, and then pull out the binocular from main body. Fix the screw after separation to avoid missing. Combination of binocular and main body Unscrew the screw and put the binocular into the original place of the main body, then slightly push the binocular into the main body completely.

  • Page 16: Screen Information

    SATIR UTR “+” “M” “A” Separated binocular The keys on the binocular are defined as above shown picture and the functions of the keys are the same as the key on main body. 3.6 Screen information There will display some information when the operating the device and the information distribution is shown like the following picture.

  • Page 17: Accessory

    SATIR UTR 4. Accessory Battery system Every HE606 handheld thermal camera is equip with two rechargeable Li- ion batteries and an intelligent charger (including the power cable). 4.1.1 Battery The batteries are high-performance rechargeable Li-ion batteries, built in overcurrent and overheating protection, up to 500 cycles of charge and discharge.

  • Page 18: Other Accessories

    SATIR UTR Other accessories 4.2.1 Video output cable and connector 4.2.2 Binocular extension cord 4.2.3 Lens cleaning tools...

  • Page 19: Trouble Shooting

    SATIR UTR 5. Trouble shooting When something is wrong with the device, user should contact the technologists immediately and provide relative information including device module, serial number, production date, software version, the description of troubles, etc. And it will help the technologists provide the user the high efficiency and high quality service.

  • Page 20: Attention And Maintenance

    SATIR UTR 6. Attention and maintenance 6.1 Attention The infrared detector is working by accepting infrared radiation so that the superheated objects such as sun, laser welding torch, nozzle of jet engine will damage the detector by forming high temperature area on the surface of the detector and even the image is hard to observe when suffer certain damage.

  • Page 21: Storage And Transportation

    SATIR UTR Storage and transportation 6.3.1 Storage The camera and its accessories should be placed in the carrying case and stored in drying and well ventilated storage environment. Also stay out of the sun and the hot reservoir. When stored over 3 months, take out the camera for booting and checking.

  • Page 22: Contact Information

    SATIR UTR 7. Contact information...
