HBCR001

Universal Remote User Manual

FCC ID:NMCHBCR001

Make sure your HBC unit is updated with the latest firmware

which can support your Universal Remote.

Table of Contents

Need help?

Do you have a question about the HBCR001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Uclear HBCR001

Page 1 HBCR001 Universal Remote User Manual FCC ID:NMCHBCR001 Make sure your HBC unit is updated with the latest firmware which can support your Universal Remote.
Page 2: Table Of Contents
Contents Contents -------------------------------------------------------------- Quick User Guide -------------------------------------------------- Warnings and Safety Instructions ------------------------------ Features -------------------------------------------------------------- Kit Includes --------------------------------------------------------- Installation ------------------------------------------------------------ General Operaions -------------------------------------------------- Intercom Connection ----------------------------------------------- General Button Configurations ----------------------------------- General Status Indicator Configurations ---------------------- Technical Data ------------------------------------------------------ Notices ----------------------------------------------------------------...
Page 3: Quick User Guide
Quick User Guide General Functions and Layouts LED Indicator Vol ‘Up’ Button ‘Power’/ DFU/ ‘Answer’ Button Charging Socket Vol ‘Down’ Button Velcro Hook Back view Front view Button functionality is identical to HBC Unit. For more complete instructions, please refer to your HBC Series User Manual. Pairing with HBC unit seconds until LED blink blue and red alternatively.
Page 4 Quick User Guide While holding the ‘Up’ or ‘Down’ button, power ‘On’ the Universal Remote, only release the ‘Up’ or ‘Down’ button until the LED blinks blue and red alternatively. Just Connect Mode It is only necessary to do the pairing for the first time. After pairing with your unit, your Universal Remote will connect automatically to your paired unit once you power on your device.
Page 5 Quick User Guide Power On Press the ‘Power’ button once, the Universal Remote will be turned on. Power Off The Universal Remote will be turned off automatically once the paired HBC unit is off. Reset Connected Micro USB cable to the computer USB port or power sources. Plug in and plug out the micro USB cable from Universal Remote.
Page 6 Quick User Guide Firmware Update Download and install the new version software from UCLEAR website. support your Universal Remote. Connected securely the USB cable to the computer USB port. Powered off the Universal Remote by holding ‘Up’ and ‘Down’ buttons at the same time.
Page 7: Warnings And Safety Instructions
Warning and Safety Instructions This manual uses the icons to highlight certain instructions. Below is an explanation of the icons. Attention This icon highlights special instructions and precautions intended to avoid damage to the system. Non-compliance may void the product warranty. Warning This icon provides precautions important to prevent injuries to the user.
Page 8: Features
Remote in any way as it may cause the system to malfunction causing hurt to you. Features The UCLEAR Universal Remote is a convenient and safe alternative or replacement for the 3 buttons on Helmet Communicator. Compatible with product series (HBC200, HBC100+, and future...
Page 9: Kit Includes
Kit Includes Universal Remote Package Contains: 1 Universal Remote 1 Micro USB Charger (1m long) 1 Velcro Strap 1 Quick Start Guide (150mm long)
Page 10: Installation
Installation 1. Place the Velcro strap near to the handle bar. (As per illustration above) 2. Loop the Velcro strap around the handle bar.
Page 11 Installation 3. Place the Universal Remote onto the Velcro strap. 4. Ensures the Universal Remote is fastened. Installation completed. Enjoy!
Page 12: General Operaions
General Operations Your UCLEAR Universal Remote is now all set and ready to go! Universal Remote to HBC, HBC to Mobile Phone Establish connection between Universal Remote and HBC: Power ‘On’ the HBC unit, hold ‘Up’ and ‘Down’ buttons for seconds until LED blinks blue and red alternately.
Page 13 Hold the ‘Up’ and ‘Down’ buttons on the HBC unit for 2 seconds. The LED indicator would blink blue and red alternately. Turn on the mobile phone bluetooth and select the respective UCLEAR HBC name to pair with the unit.
Page 14 General Operations Pick up incoming call: Press the Universal Remote ‘Answer’ button once. Reject calls: Hold the Universal Remote ‘Answer’ button for 2 seconds. Voice calls: Hold the Universal Remote ‘Down’ and ‘Answer’ buttons for 2 seconds. Last number redial: Hold the Universal Remote ‘Up’...
Page 15: Intercom Connection
Intercom Connection Step 1 Pair the Universal Remote to respective HBC unit, if they have not been paired before. To connect the Universal Remote to the helmet communicator, Power ‘On’ the HBC unit and hold ‘Up’ and ‘Down’ buttons for 2 seconds until LED blinks blue and red alternately.
Page 16 Intercom Connection Step 2 Pairing between HBC units. other HBC units. Pairing process needs to be carried out only once. Pick one units as the 1st device, hold ‘Answer’ and ‘Up’ buttons for 3 seconds.The status indicator wouldblink purple. For the 2nd device, hold ‘Answer’ and ‘Up’ buttons for 3 seconds. The status indicator wouldblink purple.
Page 17 Or more… Step 4 Connect the Phone to HBC device if phone is used If the phone is paired with the respective HBC unit, turn on the mobile phone bluetooth functions, select the UCLEAR HBC device name to connect. Or more…...
Page 18 Or more… Next turn on the mobile phone bluetooth functions and search for bluetooth devices. Select the UCLEAR HBC device name to pair with the desired device. Most mobile phones when paired would be automatically connected with both phone and music bluetooth capabilities.
Page 19: General Button Configurations
General Button Configurations Action Button Not Connected Power on Press ‘Answer’ button once While holding ‘Up’ or ‘Down’ button, on the Pairing ‘Power’ Connected to HBC (HBC connected to phone) Activate HBC pairing Hold ‘Up’ and ‘Down’ buttons for 2 seconds Press ‘Answer’, ‘Up’...
Page 20: General Status Indicator Configurations
General Status Indicator Configurations The table below shows the status indicator configurations State Status Indicator Power on (No connection) Blink purple once every second Pairing to HBC unit Blink blue and red alternatively slowly Connecting to HBC unit Blink blue and red alternatively quickly Connected to HBC unit Blink blue slowly once every 2 seconds Battery low...
Page 21: Technical Data
Technical Data Unit Dimension (L x W x H) 60mm x 20mm x 12mm Weight Bluetooth Version 4.1 , Class 2 RFComm Carrier frequency 2.402 – 2.480 GHz RF output power 7.76dBm Power Power consumption 50mW (max) Power input (Charging) 5V / 300 mA 3.7V, 30mAh x 2, Lithium-ion Polymer Built-in-battery...
Page 22: Notices
Notices compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 23 Notices BATTERY WARNING: The UCLEAR Universal Remote contains a rechargeable lithium ion polymer CHARGING NOTICE: equipments, please follow all the instructions below: Do not immerse the product, AC adaptor or speakers in water. Do not install, place or use the product near any source of heat for example: stove, radiator, oven, toaster, coffee maker or otherap- paratus that gives off heat.
Page 24 Notices LIMITATIONS OF WARRANTY: All product warranties for the product by are limited to those mentioned in the product manual. WAIVER AND DISCLAIMER: BITwave, and all their representatives, partners, agents, distributors, suppliers and resellers shall not be liable and will be held harmless from any and all litigation, claims, debts, demands, actions and liability which may arise, directly or indirectly, from operating or using the product for any damages, losses, distress, pain, suffering, discomfort, loss and injuries including...
Page 25 All information here is accurate as of the date of printing. product on www.uclear-digital.com from time to time PERSONAL SAFETY: Do not open the seal of the hardware, tamper, repair or modify any parts.
Page 26 TECHNICAL SUPPORT: For additional information please visit our website at www.uclear-digital.com For customer and technical support in the US and Canada, please contact: BITwave USA LLC 1093 E lron Eagle Dr. #115...
Page 27 BITwave Pte Ltd. LICENCES: The UCLEAR trademark and logo is exclusively owned by BITwave Pte Ltd. Any use of the mark by any other parties without prior written permission of BITwave Pte Ltd constitutes an infringement of legal rights. The Bluetooth trademark is owned by Bluetooth SIG and is used under licence by BITwave Pte Ltd.
Page 28 Notices Cet appareil s’accorde avec Industrie Canada licence-exempte RSS standard. (1) cet appareil ne peut pas causer l’intervention, et (2) cet appareil doit accepter de l’intervention, y compris l’intervention qui peut causer l’opération non désirée de. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada...
